Installation
(SPX-177A)
Woofer: Surface mount
Notes:
Attach gasket tape as shown.
If spacer ring is used with grille, snap-fit tabs on spacer ring
must be removed for proper fit.
Woofer: Factory/stealth
Notes:
Attach gasket tape as shown.
Installation
(SPX-177A)
Woofer : Montage en surface
st4.2x25mm
Remarques :
Fixez le cordon isolant comme indiqué sur l'illustration.
Si vous utilisez l'entretoise avec une grille, il est indispensable que vous enleviez les
pattes à pression sur cette première en vue d'en assurer le montage adéquat.
Woofer : Usine / montage caché
st4.2x25mm
Remarques :
Fixez le cordon isolant comme indiqué sur l'illustration.
st4.2x25mm
st4.2x25mm
5
