Alpine SPV-65-JLT Installation Manual

6.5” 2-way component system soundbar
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
SPV-65-JLT
6.5" 2-Way Component System
Soundbar
Installation Manual
˜ Model: Wrangler JL 2018-Up
˜ Model: Gladiator JT 2020-Up
**Not compatible with OEM amplified systems
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
˜ Congratulations on purchasing the SPV-65-JLT. This installation manual is designed to take you through the
step-by-step installation of SPV-65-JLT into a 2018-Up Jeep Wrangler JL or Jeep Gladiator JT 2020-Up. Please
familiarize yourself with the owners manual as this is a challenging installation. If you still have additional
questions please call 1-800-TECH-101.
Note
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by an Alpine authorized dealer.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
SPV-65-JLT
v20200731
Jeep
˜ 1/6
