- Page 1 Pneumatic 7in. Angle Grinder #505452, JAT-452 Operation & Parts Manual M-505452 Edition 2 06/2015 427 New Sanford Road LaVergne, TN 37086 Ph.: 800-274-6848 www.jettools.com Copyright © 2015 JET...
-
Page 2: Warranty And Service
Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand. -
Page 3: Safety Warnings
10. The air tool must be properly lubricated before operating. Do not use this tool for other than its intended use. If used for other purposes, JET disclaims 11. Never start a percussion type air tool (chipper, any real or implied warranty and holds itself breaker, buster, etc.) without securing the... - Page 4 When not in use, disconnect tool from air 33. Do not lubricate the tool with combustible source. liquids, such as kerosene, diesel or jet fuel. 22. Shut off air supply and discharge any residual 34. Do not dispose of this tool with normal pressure from tool before removing hose, household waste.
-
Page 5: About This Manual
As with any tool operation, safety of operator and bystanders should be first priority. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com. -
Page 6: Tool Specifications
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations. -
Page 7: Setup And Assembly
Any missing parts or damage should be reported connection to fail. Instead, add a leader hose ® immediately to your JET distributor. Do not use a and install any quick-change couplings damaged tool. Read this instruction manual farther down the line. - Page 8 Lubrication Information Use a light oil containing rust inhibitors, such as SAE #10. Many JET air tools have integral oil If the air tool is not performing according to reservoirs, which should be kept filled when in-line specifications, the following are among the most oilers are not used.
- Page 9 Figure 2 Recommended arrangement of air piping and air line system ...
- Page 10 Troubleshooting JAT-452 Angle Grinder Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846. Problem Possible cause Remedy Tool will not start. Air valve closed or obstructed.
-
Page 11: Replacement Parts
Replacement parts Service parts are listed on the following pages. To order parts or reach our service department, call 1-800- 274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately. ... - Page 12 #505452, JAT-452, 7in. Angle Grinder – exploded view JAT-452 Angle Grinder ...
- Page 13 #505452, JAT-452, 7in. Angle Grinder – parts list Index Part No. Description Index Part No. Description JAT452-01 Motor housing 28 JAT452-28 Spring JAT452-02 Spring 29 JAT452-29 Screw M4x0.7P JAT452-03 Air inlet 30 TS-2361051 Spring washer M5 JAT452-04 Throttle lever 31 70109NPN O-Ring 9.8x1.9...
- Page 14 This page intentionally left blank. JAT-452 Angle Grinder ...
- Page 15 This page intentionally left blank. ...
- Page 16 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.jettools.com JAT-452 Angle Grinder ...
