Summary of Contents for Jet JAT-405
- Page 1 Pneumatic Angled Die Grinder #505405, JAT-405 #505406, JAT-406 JAT-406 JAT-405 Operation & Parts Manual M-505405 Edition 2 06/2015 427 New Sanford Road LaVergne, TN 37086 Ph.: 800-274-6848 www.jettools.com Copyright © 2015 JET...
-
Page 2: Warranty And Service
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand. -
Page 3: Safety Warnings
10. The air tool must be properly lubricated before operating. Do not use this tool for other than its intended use. If used for other purposes, JET disclaims 11. Never start a percussion type air tool (chipper, any real or implied warranty and holds itself breaker, buster, etc.) without securing the... - Page 4 33. Do not lubricate the tool with combustible or storing tool. liquids, such as kerosene, diesel or jet fuel. 23. Make sure tool is switched off, and your finger 34. Do not dispose of this tool with normal off the trigger, before connecting to air supply.
-
Page 5: About This Manual
As with any tool operation, safety of operator and bystanders should be first priority. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com. -
Page 6: Tool Specifications
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations. -
Page 7: Setup And Assembly
Do not use detergent oil. Re-connect air. Run die grinder at low throttle without load for a few seconds to Figure 1 (JAT-405 shown) distribute the oil throughout tool. Loosen collet nut using the two wrenches on... - Page 8 Use a light oil containing rust inhibitors, such as common causes. (See also “Troubleshooting” SAE #10. Many JET air tools have integral oil section.) reservoirs, which should be kept filled when in-line •...
- Page 9 Figure 2 Recommended arrangement of air piping and air line system ...
- Page 10 Troubleshooting JAT-405/406 Angled Die Grinders Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846. Problem Possible cause Remedy Tool will not start. Air valve closed or obstructed.
-
Page 11: Replacement Parts
Replacement parts Service parts are listed on the following pages. To order parts or reach our service department, call 1-800- 274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately. ... - Page 12 #505405, JAT-405, Right Angled Die Grinder – exploded view JAT-405,406 Angled Die Grinders ...
- Page 13 #505405, JAT-405, Right Angled Die Grinder – parts list Index Part No. Description Index Part No. Description JAT405-01 Motor housing 23 JSM5252-23 Front coupling 40337 Lever pin 3x18L 24 51224 Collet 1/4in. JSM5252-03 Air inlet 25 52225 Collet nut JSM5252-04...
- Page 14 #505406, JAT-406, 115° Angled Die Grinder – exploded view JAT-405,406 Angled Die Grinders ...
- Page 15 #505406, JAT-406, 115° Angled Die Grinder – parts list Index Part No. Description Index Part No. Description JAT405-01 Motor housing 24 51224 Collet 1/4in. 40337 Lever pin 3x18L 25 52225 Collet nut JSM5252-03 Air inlet 26 JSM5252-26 Front cap JSM5252-04 Throttle lever 27 52227 Double-end wrench...
- Page 16 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.jettools.com JAT-405,406 Angled Die Grinders ...
