PAS17BA
(Base Unit Only)
PAS17BA-BC
(with Batteries and Charger)
OPERATOR'S MANUAL & PARTS LIST
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE OPERATING THIS EQUIPMENT.
©
PAS17-Man 8/2008
Tacony, Inc., All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAS17BA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powr-Flite PAS17BA

Summary of Contents for Powr-Flite PAS17BA

  • Page 1 PAS17BA (Base Unit Only) PAS17BA-BC (with Batteries and Charger) OPERATOR’S MANUAL & PARTS LIST WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. © PAS17-Man 8/2008 Tacony, Inc., All rights reserved...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Warranty......................3 Safety Instructions ..................3 Machine Set-Up ....................4 Machine Specification..................4 Daily Operation and Maintenance ..............5 How to Install Batteries................5 How to Charge the Batteries ..............5 How to Install the Squeegee............... 5 How to Install Pad Holder and Brush............

  • Page 3: Warranty

    2 years motors, 1 year parts and workmanship (excludes normal wear items). In case you as our customer, meet any trouble with your machine, contact your Powr-Flite rep- resentative who will be happy to be of service to you and will take care of the warranty settlement.

  • Page 4: Machine Set-Up

    19. Recovery Tank Squeegee Mount Knob 20. Squeegee Hose Squeegee 21. Vacuum Hose Squeegee Tilt Knob 22. Key Switch Solution Drain Hose Machine Specification PAS17BA+ Automatic Scrubber Brush Width 17" Squeegee Width 30" Solution Tank 11 gal. Recovery Tank 12 gal.

  • Page 5: Daily Operation And Maintenance

    Daily Operation and Maintenance How to Install Batteries Caution: Batteries are heavy. Install (2) 12-volt 115 a.h. deep cycle batteries. New Batteries should be given a full charge before first use. Limit use of new batteries during first 5 cycles. 1.

  • Page 6: How To Operate The Machine

    How To Operate The Machine 1. To turn the power on, turn the key switch (22). The power/battery indicator (b) will light up. 2. Check the battery capacity to see if it is full – all indicators are lit up when batteries are fully charged.

  • Page 7: What To Do When You're Operating The Machine

    What to Do When You’re Operating The Machine Vacuuming Up Solution 1. Make sure the squeegee is in the down position. 2. As the machine moves forward and solution is dispensed, the squeegee will vacuum it up into the recovery tank. 3.

  • Page 8: Replacement Parts

    Replacement Parts Part Description Brush SF616 Poly Scrub Brush (Optional) PFLG16 Lite Grit Scrub Brush (Optional) PFMG16 Medium Grit Scrub Brush (Optional) PFHG16 Heavy Grit Scrub Brush (Optional) Clutch Plate UP2P Clutch Plate (must be used with all scrub brushes) Pad Holder PAS17PD 17”...

  • Page 9: Chassis Assembly

    Chassis Assembly Ref. Part No. Description 33668 Chassis 33669 Bracket 33670 Screw 33671 33672 Castor 33673 Screw 33674 Washer 33675 Bearing 33676 Wheel 33677 Spacer 33678 33679 Bolt 33680 Screw 33681 Spring Washer Valve Assembly Ref. Part No. Description Qty. Ref.

  • Page 10: Brush Assembly

    Brush Assembly Ref. Part No. Description 33682 Brush Motor 33683 33684 Bolt 33685 Cover 33686 Skirt 33687 Strap 33688 Bracket 33689 Water Drain Out 33690 Washer 33691 Bolt SF616 Brush (See “Replacement Parts”) 33692 Brush Driver 33693 Screw 33694 Bolt 33695 33696 Spacer...

  • Page 11: Vacuum Motor Assembly

    Vacuum Motor Assembly Ref. Part No. Description Ref. Part No. Description 33703 Elbow 33711 Muffler 33704 Bracket 33712 Sponge 33705 Connector 33713 Core 33706 Gasket 33714 Screw 33707 Vacuum Motor 33715 Bolt 33708 33716 Spacer Ring 33709 Hose 33717 Bolt 33710 Sleeve 33718...

  • Page 12: Lift Assembly

    Lift Assembly Ref. Part No. Description 33732 Lift 33733 Washer 33734 33735 Eccentricity Bushing 33736 Washer 33737 Screw 33738 33739 Pedal Cover 33740 Pedal 33741 Spring Pin 33742 Bolt 33743 Pin Shaft 33744 Washer 33745 Cotter Pin 33746 33747 33748 Pin Shaft Squeegee Assembly Ref.

  • Page 13: Squeegee Lift Assembly

    Squeegee Lift Assembly Ref. Part Description 33749 Bolt 33750 Plate Right 33751 Pipe 33752 Handle 33753 Plate Left 33754 Screw 33755 Washer 33756 Screw 33757 33758 Liner 33759 Rope Assembly 33760 Hang Ring 33761 33762 Balance Frame 33763 Shaft 33764 Cotter Pin 33765 Washer...

  • Page 14: Vacuum Hose Assembly

    Vacuum Hose Assembly Recovery Drain Hose Assembly Ref. Part No. Description Qty. Vacuum Hose Assembly 33829 Sleeve 33830 Hose Solution Drain Hose Assembly 33831 Sleeve 33832 O-Ring Recovery Drain Hose Assembly 33833 Drain Out Plug 33834 Screw 33835 Hose Clamp 33836 Hose 33837...

  • Page 15: Troubleshooting

    Troubleshooting Problem: Possible Cause: Solution is not being Vacuum motor is not running picked up Water filter is clogged Recovery tank is full Squeegee or vacuum hose is clogged, broken or disconnected Bad seal at tank cover, vacuum motor or squeegee Worn or misaligned squeegee blades.
