OPERATOR'S MANUAL & PARTS LIST
PAS20B
(Base Unit Only)
PAS20BA-BC
(with Batteries and Charger)
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE OPERATING THIS EQUIPMENT.
©
Tacony Corporation, All rights reserved
PAS20BA-BC-Man 10/2017

Save These Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAS20B and is the answer not in the manual?

Questions and answers

Related Manuals for Powr-Flite PAS20B

Summary of Contents for Powr-Flite PAS20B

  • Page 1: Save These Instructions

    OPERATOR’S MANUAL & PARTS LIST PAS20B (Base Unit Only) PAS20BA-BC (with Batteries and Charger) WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. © Tacony Corporation, All rights reserved PAS20BA-BC-Man 10/2017 Save These Instructions...
  • Page 2 TABLE OF CONTENTS Warranty ......................3 Safety Instructions ..................3 Machine Set-Up ....................4 Machine Specification ..................4 Daily Operation and Maintenance ..............5 How to Install Batteries ................5 How to Charge the Batteries ..............5 How to Install the Squeegee ............... 5 How to Install Pad Holder and Brush ............

  • Page 3: Warranty

    2 years motors, 1 year parts and workmanship (excludes normal wear items). In case you as our customer, meet any trouble with your machine, contact your Powr-Flite representative who will be happy to be of service to you and will take care of the warranty settlement.

  • Page 4: Machine Set-Up

    Machine Set-Up Handle Bar 10. Battery Control Panel 11. Valve, Solution Volume Control a ..Hour Meter 12. Frame b ..Battery Condition Indicator 13. Wheel c ..Brush Motor Switch 14. Brush/Pad Holder d ..Vacuum Motor Switch 15. Strap, Splash Guard e..Solution Switch 16.

  • Page 5: Daily Operation And Maintenance

    Daily Operation and Maintenance How to Install Batteries Caution: Batteries are heavy. Install (2) 12-volt deep cycle batteries. New Batteries should be given a full charge before first use. 1. Unplug the hoses (20, 21) from the recovery tank (19). 2.

  • Page 6: How To Operate The Machine

    How To Operate The Machine 1. To turn the power on, turn the key switch (22). The power/battery indicator (b) will light up. 2. Check the battery capacity to see if it is full – all indicators are lit up when batteries are fully charged.

  • Page 7: What To Do When You're Operating The Machine

    What to Do When You’re Operating The Machine Vacuuming Up Solution 1. Make sure the squeegee is in the down position. 2. As the machine moves forward and solution is dispensed, the squeegee will vacuum it up into the recovery tank. 3.

  • Page 8: Replacement Parts

    Replacement Parts PART DESCRIPTION Brush SF219 Poly Scrub Brush (Optional) PFLG19 Lite Grit Scrub Brush (Optional) PFMG19 Medium Grit Scrub Brush (Optional) PFHG16 Heavy Grit Scrub Brush (Optional) Clutch Plate UP2P Clutch Plate (must be used with all scrub brushes) Pad Holder PAS20PD 20”...

  • Page 9: Chassis Assembly

    Chassis Assembly REF. PART NO. DESCRIPTION 33668 Chassis 33669 Bracket 33670 Screw 33671 33672 Castor 33673 Screw 33674 Washer 33675 Bearing 33676 Wheel 33677 Spacer 33678 33679 Bolt 33680 Screw 33681 Spring Washer Valve Assembly REF. PART NO. DESCRIPTION QTY. REF.

  • Page 10: Brush Assembly

    Brush Assembly REF. PART NO. DESCRIPTION 33682 Brush Motor 33683 33684 Bolt 33732 Cover 33733 Skirt 33687 Strap 33688 Bracket 33689 Water Drain Out 33690 Washer 33691 Bolt Brush SF219 (See “Replacement Parts”) 33692 Brush Driver 33693 Screw 33694 Bolt 33695 33696 Spacer...

  • Page 11: Vacuum Motor Assembly

    Vacuum Motor Assembly REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION 33711 Muffler 33703 Elbow 33712 Sponge 33704 Bracket 33713 Core 33705 Connector 33714 Screw 33706 Gasket 33715 Bolt 33707 Vacuum Motor 33716 Spacer Ring 33708 33717 Bolt 33709 Hose 33718 Bolt 33710...

  • Page 12: Lift Assembly

    Lift Assembly REF. PART NO. DESCRIPTION 33732 Lift 33733 Washer 33734 Eccentricity 33735 Bushing 33736 Washer 33737 Screw 33738 33739 Pedal Cover 33740 Pedal 33741 Spring Pin 33742 Bolt 33743 Pin Shaft 33744 Washer 33745 Cotter Pin 33746 33747 33748 Pin Shaft Squeegee Assembly REF.

  • Page 13: Squeegee Lift Assembly

    Squeegee Lift Assembly REF. PART NO. DESCRIPTION 33749 Bolt 33750 Plate Right 33751 Pipe 33752 Handle 33753 Plate Left 33754 Screw 33755 Washer 33756 Screw 33757 33758 Liner 33759 Rope Assembly 33760 Hang Ring 33761 33762 Balance Frame 33763 Shaft 33764 Cotter Pin 33765...

  • Page 14: Vacuum Hose Assembly

    Vacuum Hose Assembly Recovery Drain Hose Assembly Water Level Sight Tube REF. PART NO. DESCRIPTION QTY. Vacuum Hose Assembly 33829 Sleeve 33830 Hose 33831 Sleeve 33832 O-Ring Recovery Drain Hose Assembly PAS700 Drain Out Plug 33834 Screw 33835 Hose Clamp 33838 Clamp 33839...

  • Page 15: Troubleshooting

    Troubleshooting Problem: Possible Cause: Solution is not being Vacuum motor is not running picked up Water filter is clogged Recovery tank is full Squeegee or vacuum hose is clogged, broken or disconnected Bad seal at tank cover, vacuum motor or squeegee Worn or misaligned squeegee blades.
  • Page 16 Powr-Flite will repair or exchange parts for your vacuum in the event of a This warranty covers normal use and does not cover damage which occurs in manufacturing defect as follows: shipment or failure resulting from alteration, accident, misuse, abuse, neglect, or improper maintenance.
