Summary of Contents for Powr-Flite Predator PAS20
- Page 1 Predator Automatic Scrubber 20 OPERATORS MANUAL AND PARTS LIST Model PAS20 WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. PAS201...
-
Page 2: Technical Characteristics
TECHNICAL CHARACTERISTICS POWR-FLITE ® PREDATOR™ 20 AUTO SCRUBBER MODEL PAS20 Technical Specifications U.S. Standard Metric Area per hour ..... . .22,000 sq. feet ............2043 sq. meters Solution Tank . - Page 3 POWR-FLITE PREDATOR AUTOMATIC SCRUBBER 20 This manual refers to a battery powered automatic floor scrubber. Designed to be simple, easy to operate and safe, with maneuver- ability and automatic variable electronic drive. Routine maintenance has been simplified and reduced to the minimum to keep equipment on the job.
- Page 4 120 Volt 60 Hz Solution Tank: The solution tank is located under the lid, at floor with a certain amount of force. After the first few the front of the machine, with the filling-funnel M1 in an acces- hours the squeegee adjusts itself to the correct angle sible position for easy re-filling.
- Page 5 The area to be scrubbed: Debris and grit must be swept up • Adjust the speed of advance by adjusting knob M11. before starting the scrubbing operation to avoid vacuum line • Finally, adjust the correct supply of the detergent blockage and to permit the detergent to perform efficiently.
- Page 6 Batteries: Check the level of the electrolyte liquid by carefully removing plugs from top of battery and top off with distilled water, when the level drops below the plates of the battery. Keep the bat- teries clean and dry with antistatic cloths. When charging the bat- teries, remove the plugs of the batteries and lift the top flap of the machine to allow the gas which is generated to escape.
- Page 7 Pos Part No. Description Pos Part No. Description Pos Part No. Description PAS1 Wheel, Bumper PAS158 Handle Lever PAS275 PAS152 Control Panel PAS18 Spring PAS104 Funnel PAS115 Screw PAS153 Screw *PAS 104B Funnel (Serial 501.038 Panel #2674 & higher) PAS109 Hinge PAS147 Screw...
- Page 8 Part No. Description Part No. Description Part No. Description PAS147 Screw PAS8 Brush, poly 430.117 PAS146 Washer PAS132 Strata Grit brush PAS188 Washer 501.086 Plate PAS95 Scrub Grit II brush PAS167 Screw PAS 3 Screen PAS10 Pad driver 430.119 Support PAS401 Solution Tank PAS135...
- Page 9 Part No. Description Part No. Description Part No. Description PAS15 Strap PAS18 Spring PAS37 Drain hose PAS330 Sleeve PAS266 Split pin PAS38 Spring 1924 Vac motor 430.194 Screw 501.184 Bracket PAS102 Gasket PAS19 PAS146 Washer PAS150 Tie rod 500.157 Washer 430.192 F909 Screen/Filter...
- Page 10 Part No. Description Part No. Description Part No. Description 501.23 Support PAS286 Ring PAS207 PAS190 Screw PAS287 Planet gear PAS51A Swivel castor PAS42 Support PAS289 Ring PAS172 Spring PAS188 Washer 501.252 Planetary PAS63 430.231 Self locking nult PAS291 PAS173 Clamp PAS189 Wheel PAS292...
- Page 11 1. BLACK 2. BLUE/WHITE 3. YELLOW/WHITE 4. RED/BLACK 5. EMPTY 6. EMPTY 7. WHITE/GREEN 8. RED 9. BLUE 10. RED/WHITE 1. WHITE/BLUE 4. WHITE/RED 2. WHITE/YELLOW 5. WHITE/GREEN 3. EMPTY 6. RED/BLACK Pos Part No. Description Pos Part No. Description Alarms on Electronic Card PAS 52 Battery gauge...
- Page 12 A Tacony Company 3101 Wichita Court • Ft. Worth, TX 76140-1755 1-800-880-2913...
