3. Installation
3.1 Hardware Installation
The board described in this manual can be installed in any CompactPCI compatible computer
with a free bus master slot. The frontpanel of the board should be safely secured by screws to
the chassis to avoid lossening of the board through vibration and to ensure correct earth con-
nection.
Caution, Electric Shocks!
If your board type is not specifically qualified as hot-swap capable,
please switch off the CompactPCI system before installing the board in
a free CompactPCI slot. Failure to do so could endanger your life/health
and may damage your board or system.
ESD Equipment!
Your CompactPCI board contains electrostatically sensitive devices.
Please observe the necessary precautions to avoid damage to your
board:
• Discharge your clothing before touching the assembly. Tools must
be discharged before use.
• Do not touch components, connector-pins or traces.
• If working at an anti-static workbench with professional discharging
equipment, please do not omit to use it.
To install the board, please proceed as follows:
1.
Ensure that the safety requirements indicated above are observed
2.
As required, ensure that the CP345-TR1transition module is properly installed
(see appropriate documentation for configuration)
3.
Install the board in an appropriate slot and engage the retaining mechanism
4.
Connect external interfacing cables to the board as required
5.
Ensure that the board and interfacing cables are properly secured
To remove the board, please proceed as follows:
1.
Ensure that the safety requirements indicated above are observed
2.
Disconnect any interfacing cables that may be connected to the board
3.
Disengage the board retaining mechanism by first lifting the board release handle
slightly and at the same time pulling the red sliding retainer towards you as far as possi-
ble (5 mm approx.)
4.
Now press down on the board release handle disengaging the board from the back-
plane connector and pull the board out of the slot.
ID 19979, Rev. 03
® PEP Modular Computers GmbH
Installation
Page 3 - 3
