CP345

2.4 Board Interfaces

2.4.1 Front-End Serial I/O Interfaces

Figure 2-3: Orientation of Serial I/O Connector Block (left) and Connector (right)
Legend
4 x R J 4 5 c o n n e c t o r b l o c k o f
n o n - o p t o i s o l a t e d s t a n d a r d
b o a r d v a r i a n t ( l e f t ) a n d D -
S u b c o n n e c t o r o f o p t o i s o -
lated board variant (right).
Note...
This section includes pinout tables of the optoisolated variant's 50-
pin D-Sub frontend connector as well as of the 50-pin and 9-pin D-
Sub connectors of the four-channel frontpanel adapter CP-ADAP-
CP345-DSUB50.
For a description of the board interfaces of the CP-RIO-345 rear I/O
modules please refer instead to the Rear I/O Modules chapter of
this manual.
ID 19979, Rev. 03
0
1
2
3
© PEP Modular Computers GmbH
Functional Description
1
1
8
1
8
1
8
1
25
8
26
50
Page 2 - 7
