CP345

1.3.2 Frontpanels

Figure 1-2: CP345 Frontpanels
Legend:
N o n - o p t o i s o l a t e d v a r i a n t ( l e f t ) ,
optoisolated variant (center), rear
I/O-capable variant (right).
Note...
The frontpanels of the CP345 rear-I/O modules are identical to
those of the non-optoisolated or, respectively, of the optoisolated
mainboard variants except for the fact that their lower ends are
fastened to the rack by means of screws.
Page 1 - 8
0
1
2
3
© PEP Modular Computers GmbH
Introduction
CP 345
CP 345
Rx Tx
Rx Tx
0
1
2
3
CP 345
Rx Tx
0
0
1
1
2
2
3
3
ID 19979, Rev. 03
