Connectors of RJ45-to-D-Sub Frontpanel Adapter
In order to comply with standard PC interface technology, a single-channel RJ45-to-
DSub frontpanel adapter (CP-ADAP-RJ45-D5009/PC) can be connected to the frontend
interface of each channel of the of the non-optoisolated board variant. This adapter ter-
minates on the user side with a 9-pin male D-Sub connector which includes the signals
of the relating channel. The pinouts of the adapter's RJ45 and 9-pin DSub connectors
are shown in the following table.
Warning!
Where signals are not indicated in the below table, please do not
connect external wiring to the connector pins. Failure to comply
may result in damage to your board.
Table 3-2: Pinouts of RJ45-to-D-Sub Frontpanel Adapter Connectors
RJ45
Connector
1
2
3
4
5
6
7
8
—
Page 2 - 10
RS422/RS485
RS232
Half Duplex
DSR
—
RTS
—
GND
GND
TxD
TRxD+
RxD
—
DCD
—
CTS
TRxD-
DTR
—
—
—
© PEP Modular Computers GmbH
Functional Description
RS422/RS485
9-Pin Row
Full Duplex
Connector
RxD-
6
—
7
GND
5
TxD+
3
—
2
RxD+
1
TxD-
8
—
4
—
9
Channel
n with
n = 0..3
ID 19979, Rev. 03
