Summary of Contents for Husqvarna LP 6500 I

  • Page 1 LP 6500 I Operator's manual 2-19...

  • Page 2: Table Of Contents

    Contents Introduction..............2 Maintenance..............11 Safety................4 Transportation, storage and disposal......16 Operation................ 8 Technical data.............. 18 Introduction Product overview 1. Vibration control, ON/OFF 12. Control panel 2. Control for forward and rearward movement 13. Type plate 3. Emergency stop button 14.
  • Page 3 Control panel overview Lift point. Tie-down bracket. Water 1. Oil pressure indicator. 2. Charging indicator. 3. Hour meter. 4. Ignition key. Product description Vibration. The product is a walk-behind double drum roller for compaction of thin layers of granular soils and asphalt. The product has a diesel fuel combustion engine.

  • Page 4: Safety

    Type plate 4. Manufacturer 5. Rated power 6. Production year Product liability Husqvarna AB 561 82 Huskvarna Sweden As referred to in the product liability laws, we are not liable for damages that our product causes if: Type Operating mass, kg...
  • Page 5 • Make sure that only approved persons are in the loss of strength, changes in skin color or work area. condition. • Keep the work area clean and bright. • Symptoms can increase in cold temperatures. Use warm clothing and keep your hands warm and dry •...
  • Page 6 Do a check of the safety devices regularly. If the where exhaust fumes can easily collect. safety devices are defective, speak to your Noise safety Husqvarna service agent. Muffler WARNING: Read the warning instructions The muffler keeps the noise levels to a minimum and that follow before you use the product.
  • Page 7 WARNING: A damaged battery can cause an explosion and cause injury. If the battery has a deformation or is damaged, speak to an approved Husqvarna service agent. 2. Push the emergency stop button (B). 3. Make sure that the product stops.

  • Page 8: Operation

    Safety instructions for maintenance • Make sure that the work area is safe. Be very careful on slopes and rough surfaces. Wet and loose soil increases the risk of an accident. • Make sure that all persons in the work area are WARNING: Read the warning instructions above the product on the slope.
  • Page 9 To start the product manually 2. Release the lock lever and lower the handle carefully. Do this procedure if the product has an engine with manual start. 1. Make sure that the control for forward and rearward movement (A) is in the neutral position. To adjust the handle height •...
  • Page 10 1. Make sure that the vibration control (A) is in the OFF 5. Let the engine operate at idle speed for 2–3 minutes. position. To operate the product • To operate the product forward, move the control for forward and rearward movement (B) forward. 2.

  • Page 11: Maintenance

    a) Turn the ignition key to the stop position. b) Remove the ignition key to prevent accidental start. Maintenance Introduction X = The instructions are given in this operator's manual. O = Refer to the instructions in the engine manual WARNING: Read and understand the safety supplied by the engine manufacturer.
  • Page 12 General product maintenance Before use, Weekly, Monthly, Yearly, each each 10 h each 100 h each 250 h 500 h Replace the hydraulic oil. Engine maintenance Before use, After the Yearly, each Each 250 h each 10 h first 20 h 500 h Do a check of the fuel level and the engine oil level.
  • Page 13 To do a check of the safety straps 1. Unscrew the drain plug from the drain hose and drain off all the oil into a container. 1. Examine the safety straps at the front and the rear of the product. 2.
  • Page 14 4. Discard the water as chemical waste. Refer to CAUTION: Always replace a damaged Disposal on page 17 . air filter, or the dust will go into the engine and cause engine damage. Air filter 7. Install the clean air filter or a new air filter into the air WARNING: Use approved respiratory filter housing.
  • Page 15 We recommend a 2-stage charger with constant voltage that automatically decreases to trickle charging when the battery is fully charged. Speak to your Husqvarna dealer for information about the correct battery charger. • Do a trickle charging 1-2 times during the winter season when the product is in storage.

  • Page 16: Transportation, Storage And Disposal

    2. Use an oil drain pump to drain the hydraulic oil from 10. Fill with hydraulic oil if it is necessary. the tank (B). To replace the hydraulic oil filter 3. Clean the opening of the hydraulic oil tank. 1. Clean the area around the hydraulic oil filter. 4.
  • Page 17 • Do not discard the battery as domestic waste. • Send the battery to a Husqvarna service agent or discard it at a disposal location for used batteries. WARNING: Do not use metal hooks, chains or other lifting equipment with rough edges that can cause damage to the lift point.

  • Page 18: Technical Data

    Technical data Technical data Engine Engine brand / type Lombardini KD441 Engine power, kW / hp 5.6 / 7.5 Rated speed, rpm 2600 Performance Operating speed, km/h / miles/h 0-3.6 / 0-2.23 Maximum tilt without vibration, ° / % 17 / 30 Maximum inclination without vibration, °...
  • Page 19 Product dimensions Pos. Description LP 6500 I Handle height, operation position, mm/in. 936/36.8 Drum diameter, mm/in. 400/15.7 Distance between front and rear drum axles, mm/in. 520/19.6 Length with handle folded, handle not included, mm/in. 1076/42.7 Length including handle, operation position, mm/in.
  • Page 20 www.husqvarnacp.com Original instructions 1142372-26 2020-11-16...
