Summary of Contents for KITO M3 Series

  • Page 37: Table Of Contents

    7. Parts List.............. 10 1. Introduction The KITO High Speed CB is designed to allow for quicker lifting and lowering speeds when under no load than when under a rated load. And it switches between high speed and low speed automatically.

  • Page 38: Operation

    ■Lifting switch load Rated Load Lifting Switch Load Note: 0.25 or less The construction of KITO High Speed CB models is such 0.5 or less that the switch load during lowering is higher than the 0.7 or less lifting switch load.
  • Page 39 ● If the hoist still fails to go into high speed after trying the above methods, lift a load greater than the lifting switch load (See P.2, ■Lifting Switch Load) and then lower it and remove the load. If after these operations the hoist still fails to go into high-speed mode, contact KITO.

  • Page 40: Inspections

    ■Pre-Work Inspection Confirm the following in conjunction with the separate OWNER’S(OPERATOR’S) MANUAL AND SAFETY INSTRUCTIONS FOR KITO MANUAL CHAIN HOIST M3 SERIES, section "7. INSPECTION". ● At no load, does the hoist lift smoothly in the high-speed mode? ■Periodic Inspection ・Annual Inspection...

  • Page 41: Overhaul, Assembly And Adjustment

    5. Overhaul, assembly and adjustment The brake is disassembled and reassembled as follows. For instructions on other parts, refer to the separate OWNER’S(OPERATOR’S) MANUAL AND SAFETY INSTRUCTIONS FOR KITO MANUAL CHAIN HOIST M3 SERIES, section "8.2 Overhaul, Assembly and Adjustment". CAUTION ・Do not disassemble or alter the transmission set Ⓓ...
  • Page 42 ■Brake Disassembly 1. Make sure it is in the high-speed mode before disassembly and lower it about 10cm without a load. ※If you do not do this procedure, you will not be able to pull off the transmission set Ⓓ. 2.
  • Page 43 3. While holding the two pawls Ⓛ free with your fingers, screw the parts assembled in step 2 onto the pinion Ⓙ. Ⓜ Pawl spring A This hole is not used. Pawl Ⓛ Put the end of Ⓜ Pawl spring to the hole in the right side.
  • Page 44 6. Mount the hand chain Ⓔ on the hand wheel of the transmission set Ⓓ so the side that is wider from the groove inside guide frame A Ⓒ is on the top hook side. <Guide Frame A Cross-Section> Narrow Wide 7.

  • Page 45: Troubleshooting

    6. Troubleshooting Refer to the following in conjunction with the separate OWNER’S(OPERATOR’S) MANUAL AND SAFETY INSTRUCTIONS FOR KITO MANUAL CHAIN HOIST M3 SERIES, section "9 Troubleshooting". Troubleshooting Situation Cause Remedy Hoist fails to lift ・Wipe out the debris in the gears.

  • Page 46: Parts List

    ⑥ ⑤ The following list is of parts specific to the KITO High Speed CB . For parts not in the list, refer to section "11. PARTS LIST" in OWNER’S(OPERATOR’S) MANUAL AND SAFETY INSTRUCTIONS FOR KITO MANUAL CHAIN HOIST M3 SERIES.
  • Page 48 URL. http://www.kito.co.jp...
