CANYON MULTI UNIT ASSEMBLY INSTRUCTIONS
Fittings (to scale)
Code
Long Cam Bolt
A
(38mm overall)
B
Large Cam Lock
C
Dowel (8x30mm)
Short Cam Bolt
D
(26mm overall
for Drawer)
Small Cam Lock
E
(for Drawer)
Connection Bolt
F
(M6x25mm)
Screw for fitting
Runner, Hinge and
G
Anti-tilt Strap
(3 x12mm)
Screw for fitting
Drawer Uprights
H
to Base Panel
(4x35mm)
General Hints & Tips
A or D
Item
Quantity
18
18
30
34
34
6
33
4
Stop when
B or E
10
20
A
28mm
17.5mm
D
level
Version 1 - 210818
Page 5 of 16
30
40
50
60
A or D
Tighten
70
80
