NEWARK TV BED ASSEMBLY INSTRUCTIONS
Thank you for purchasing the NEWARK TV BED. Please read the instructions
carefully to ensure safe operation of the product.
Size: 4'6 Double 2190mm x 1445mm x 1090mm
5' King 2290mm x 1595mm x 1090mm
Colour: BLACK/ BROWN/ WHITE
Recommended size and weight of TV to fit to bracket (24'-32' /30kgs)
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
1.5 Hour
Set Up
CE:�
RoHS
2011/65/EU
Batch No. :WMI15006
Page 1 of 17

Advertisement

loading
Need help?

Need help?

Do you have a question about the NEWARK TV BED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GFW NEWARK TV BED

Summary of Contents for GFW NEWARK TV BED

  • Page 1 NEWARK TV BED ASSEMBLY INSTRUCTIONS Thank you for purchasing the NEWARK TV BED. Please read the instructions carefully to ensure safe operation of the product. Size: 4'6 Double 2190mm x 1445mm x 1090mm 5' King 2290mm x 1595mm x 1090mm...
  • Page 2 NEWARK TV BED ASSEMBLY INSTRUCTIONS IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INFORMATION This product is intended for a maximum person's weight of 100kg per side. Do not exceed this • weight. This product complies with the essential requirements of the EMC Directive 2004/108/EC and •...

  • Page 3: Care Information

    NEWARK TV BED ASSEMBLY INSTRUCTIONS CARE INFORMATION • Never use scourers, abrasives or chemical cleaners • To clean wipe with a sponge and warm soapy water. Do not use solvent based cleaners or detergents as they can bleach or damage the product ELECTRICAL COMPONENTS •...
  • Page 4 NEWARK TV BED ASSEMBLY INSTRUCTIONS Please check the pack contents before assembling the product. If any components are missing, please contact your retailer. The fittings pack contains small items that should be kept away from small children. Button @Nylon Restraint Strap �...
  • Page 5 NEWARK TV BED ASSEMBLY INSTRUCTIONS Parts HEADBOARD FOOTBOARD SIDERAIL (Left & Right) 2PCS Carton No: 1 of 3 Carton No: 2 of 3 Carton No: 3 of 3 CENTRE SUPPORT BAR SUPPORT LEG HEADBOARD LEG 2PCS 2PCS Carton No: 3 of 3...
  • Page 6 NEWARK TV BED ASSEMBLY INSTRUCTIONS Fittings (to scale) Dimensions Q ty Bolt - MS x 20 Bolt - MS x 30 Bolt - MS x 40 Bolt - MS x 50 Nut - MS Washer - ¢ 8 x 13 Washer - ¢...
  • Page 7 NEWARK TV BED ASSEMBLY INSTRUCTIONS Layout Parts on Sort Surface Lay out all 4 sides on a soft surface Le.Rug.Carpet or Packaging Carton Example image Batch No. :WMI15006 Page 7 of 17...
  • Page 8 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 1 PARTS REQUIRED K. Flat Washer x 4 D. Bolt MB x SOmm x 4 H. Allen Key MS x 1 1.Headboard x 1 6.Headboard Leg x 2 PARTS REQUIRED STEP 2 PARTS REQUIRED K.
  • Page 9 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 3 PARTS REQUIRED G. Flat Washer x 8 Fit the bolts to the headboard and footboard loosley F. Spring Washer x 8 B. Bolt MB x 30mm x 8 10mm Batch No. :WMI15006 Page 9 of 17...
  • Page 10 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 4 PARTS REQUIRED Fit all sides together, slide and hook on the side rails to the bolts on the H. Allen Key MS x 1 headboard and footboard and then tighten bolts 1.Headboard x 1 2.
  • Page 11 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 5 PARTS REQUIRED Fit all sides together, slide and hook on the side rails to the bolts on the A. Bolt MB x 20mm x 2 headboard and footboard and then tighten bolts B. Bolt MB x 30mm x 2 C.
  • Page 12 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 6 PARTS REQUIRED 0. Screw M3 x 20mm x 4 9.Button x 2 10.Nylon Restraint Strap Batch No. :WMI15006 Page 12 of 17...
  • Page 13 NEWARK TV BED ASSEMBLY INSTRUCTIONS TV Lift Up Connect the TV lift up mechanism cable to the control box and it is now ready to connect the control box to the main supply (extension lead might be needed) (already synchronized) to intall the TV.

  • Page 14: Installing Your Tv

    NEWARK TV BED ASSEMBLY INSTRUCTIONS Installing Your TV PARTS REQUIRED M. Flat Washer x 4 Before fitting your TV to bracket, please check your TV dimensions. Maximum dimensions of TV that can be used in this bed: L. Bolt M4 x 15mm x 4 •...
  • Page 15 NEWARK TV BED ASSEMBLY INSTRUCTIONS DETAIL CONNECTIONS PLAN TV Lift Mechanism AV /HDMI Ethernet Wire 1tional cable outlets for clitional electrical connections Wire thru from bottom of footboard Place the wire cable through the Cable Management Caps to prevent any damage to the wire cable (eg.other power cord) when TV Lift Mechanism is operating.
  • Page 16 NEWARK TV BED ASSEMBLY INSTRUCTIONS STEP 7 PARTS REQUIRED Fitting slats P: Single Plastic Cap 4'6 X 24 5' X 26 Q: Double Plastic Cap 8.Slats 4'6 x 24 Batch No. :WMI15006 Page 16 of 17...

  • Page 17: Complete Assembly

    NEWARK TV BED ASSEMBLY INSTRUCTIONS Complete Assembly Your Bed now completely assembled. Periodically check to ensure that the components are in their proper position, free from damage. Also, make sure the connectors are tight and secure. Keep instructions for future reference Batch No.
