A C – C
PPeNDIx ONNeCTOr
AeS/eBU Inputs/Outputs (1–8, 9–16)
Location:
Connector Type:
Pin
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
AeS 11 In (DArS)
Location:
Connector Type:
Pin
1
2
3
Page 18
P
INOUTS
Rear Panel
25-way D-type female
Description
Out channels 7/8 +
Out channels 7/8 -
Ground
Out channels 5/6 +
Out channels 5/6 -
Ground
Out channels 3/4 +
Out channels 3/4 -
Ground
Out channels 1/2 +
Out channels 1/2 -
Ground
In channels 7/8 +
In channels 7/8 -
Ground
In channels 5/6 +
In channels 5/6 -
Ground
In channels 3/4 +
In channels 3/4 -
Ground
In channels 1/2 +
In channels 1/2 -
Ground
n/c
Rear Panel
XLR 3-pin female
Description
Chassis (Screen)
+ve Signal
-ve Signal
Notes:
Outputs
Inputs
Notes:
