Connecting to local area network (LAN)
1. Connect one end of the RJ-45 cable to the LAN port of your myViewBoard Box.
2. Connect the other end of the RJ-45 cable to a network connection device or a
network wall connector.
Connecting a display device
3.
Use an HDMI cable (not supplied) to connect to an external display.
1. Connect one end of the HDMI cable to the HDMI port of the myViewBoard Box.
2. Connect the other end of the HDMI cable to the HDMI port of a display device.
PoE
LAN
LAN
6
