Nidec Commander C300 Power Installation Manual page 100

Table 5-8 Losses @ 50° C (122° F) ambient
Drive losses (W) taking into account any
Model
current derating for the given conditions
2
kHz* kHz
200 V
07200610 538 570
07200750 678 718
07200830 848 898
08201160 1353 1433
08201320 1640 1737
09201760 (9A) 2028 2170
09202190 (9A) 2431 2405
09201760 (9E) 1889 2031
09202190 (9E) 2241 2239
10202830 2478 2625
10203000 2666 2629
400 V
07400660 744 830
07400770 895 999
07401000 1018 1136
08401340 1480 1652
08401570 1754 1957
09402000 (9A) 2431 2710
09402240 (9A) 2837 2926
09402000 (9E) 2286 2565
09402240 (9E) 2648 2760
10402700 3210 3582
10403200 3482 3598
575 V
07500440 936 988
07500550 1161 1225
08500630 1753 1850
08500860 1980 2090
09501040 (9A) 1707 1977
09501310 (9A) 2087 2410
100
Normal Duty
3 4 6 8
kHz kHz kHz
597 650 703
751 799 750
898 805 751
1536 1741 1770
1740 1759 1771
2312 2354 2256
2368 2358 2245
2174 2240 2172
2223 2243 2161
2641 2625 2671
2643 2629 2678
907 1062 1141
1087 1163 1138
1200 1118 1074
1815 2016 1970
2114 1998 1979
2872 2799 2737
2870 2814 2737
2738 2709 2675
2735 2723 2675
3681 3765 3700
3676 3776 3694
1115 1225 1144
1228 1098 1030
2172 2540 2672
2291 2540 2684
2247 2538 2456
2734 2544 2456
Drive losses (W) taking into account any current
derating for the given conditions
12 16 2 3
kHz kHz kHz* kHz
710 717 430 466
758 765 526 570
759 766 585 634
1788 1806 1020 1105
1789 1807 1110 1202
2010 1910 1580 1701
2015 1922 2016 2063
1970 1889 1488 1609
1975 1900 1874 1932
2490 2379 2068 2240
2495 2374 2213 2394
1152 1164 616 692
1149 1161 720 808
1085 1096 821 922
1990 2010 1256 1410
1999 2019 1393 1564
2639 2652 2132 2136
2660 2665 2286 2294
2611 2638 2014 2039
2632 2651 2152 2184
3597 3591 2604 2923
3625 3589 3018 3062
1155 1167 705 817
1040 1051 797 923
2699 2726 1161 1345
2711 2738 1593 1845
2495 2699 1372 1601
2482 2676 1752 2034
Unidrive M / HS Frame 7 to 10 Power Installation Guide
Heavy Duty
4 6 8 12
kHz kHz kHz kHz
488 532 575 581
597 650 654 661
663 705 653 660
1193 1228 1277 1290
1206 1228 1278 1291
1822 1943 1867 1757
2029 1954 1868 1763
1730 1862 1808 1728
1916 1872 1810 1733
2375 2326 2271 2185
2375 2350 2275 2187
758 751 725 732
804 779 773 781
878 838 828 836
1392 1391 1432 1446
1539 1518 1531 1546
2290 2289 2305 2342
2300 2294 2300 2340
2200 2228 2262 2322
2209 2233 2258 2320
3105 3081 3125 3165
3105 3087 3131 3168
923 923 898 907
914 828 809 817
1585 2292 2242 2264
2029 2039 2047 2067
1830 2139 2122 2258
2222 2143 2128 2258
16
kHz
587
667
666
1303
1304
1700
1701
1684
1686
2141
2141
740
789
845
1461
1562
2399
2404
2389
2394
3262
3300
916
825
2287
2088
2455
2453
