- Page 1 INSTALLATION MANUAL Premier Outlast MicroShield™ Scratch-Resist Stainless Steel Undermount Kitchen Sink KBU14E / KBU22E / KBU24E www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. November 3, 2020...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. -
Page 4: Tools You Will Need
Jig Saw Scissors Tape Measure Phillips Screwdriver Pencil Screwdriver Putty Knife NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount sinks with countertop materials other than wood, marble or granite. Parts List Cut-out Template · · Mounting Hardware ·... - Page 5 R2" R 3 7/8" (50mm) (100mm) typ. typ. KBU14E KBU22E Overall Dimensions: 31 1/2" x 18 3/8" Overall Dimensions: 32 1/4" x 18" Bowl Dimensions: 29 1/2" x 16 1/4" Bowl Dimensions: 14 1/2" x 16 1/4" Bowl Depth: 9 7/8"...
- Page 6 1. Determine Reveal Type Use scissors to cut along the line of the paper template for your desired reveal type (Negative, Positive or Flushed Reveal). KRAUS Recommended Installation Type 3/8“ Positive Reveal Flushed/Zero Reveal 1/8“ Negative Reveal 3/8”POSITIVE 1/8”NEGATIVE FLUSHED/ZERO...
- Page 7 2. Position Template Check the cut-out template against the actual sink to ensure a proper · sized cut-out. · Place the cut-out template in the desired location on the countertop. NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink. 3.
- Page 8 4. Cut Countertop · Cut the opening in the countertop by carefully following the traced line. NOTE: Please use the appropriate saw that best fits your countertop material.
- Page 9 5. Set up Mounting Brackets · Turn countertop over and align sink with countertop. Decide location for mounting brackets. · Mounting holes should be 1/2" from edge of sink. 1/2" (13mm) 6. Drill Hole in Countertop · Drill 3/8" diameter x 1/2" deep hole in countertop.
- Page 10 7. Install Anchors · Insert anchors into drilled holes and lightly tap with a hammer until flush. 8. Secure Sink to Countertop · Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop. Place sink over cutout hole and press firmly.
-
Page 11: Attach Mounting Hardware
9. Attach Mounting Hardware · Attach mounting hardware to secure bowl. Remove excess sealant from inside lip. · Allow sealant to set for 30 - 60 minutes. NOTE: Use acetone or rubbing alcohol to remove any excess sealant. - Page 12 10. Install Plumbing Fixtures · Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's instructions. · Run water into sink and check for leaks. · Note: Before installation, please check that the drain kit complies with ASME A112.18.2/CSA B125.2 and with CUPC certification.
- Page 13 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 14 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to date comprehensive warranty, go to www.kraususa.com/warranty...
- Page 15 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
