- Page 1 ® Ages 14+ READ THE INSTRUCTION MANUAL CAREFULLY PLEASE VISIT WWW.HUBSAN TO UPGRADE HUBSAN X4 STAR ITEM NO.: H502C ARM/DISARM MOTORS, SEE PAGE 06 RTH FUNCTION, SEE PAGE 09 COMPASS CALIBRATION, SEE PAGE 12 TRANSMITTER CALIBRATION, SEE PAGE 13...
- Page 3 Hubsan X4 Star 2016.04 V1.0 Please read the instruction manual carefully! IMPORTANT SAFETY NOTES OPERATION: Be extremely careful and responsible when using the drone. Small electronic components can be damaged by crashing or by dropping the X4 into water. To avoid further damages, please replace broken parts immediately.
- Page 4 INTRODUCTION Thank you for buying the HUBSAN product. It is designed as an easy-to-use,multi-functional RC model, capable of hovering and acrobatic flight maneuvers. Please read the manual carefully and follow all the instructions. Be sure to keep the manual for future reference.
- Page 5 The quad copter battery is a rechargeable Li-Po battery with 450mAh capacity and 7.4V voltage. The battery should only be charged with the HUBSAN charger to avoid overcharge. Please make sure the battery is fully charged before first time use.
- Page 6 1 shows. ● Make sure that the A and B propellers are installed correctly. The X4 will not fly if propellers are improperly installed. ● Hazardous moving parts keep fingers and other body part away. © 2016 Hubsan 哈博森科技 版权所有...
- Page 7 Do not stop the motors during the flight to avoid crashing. Push the sticks lightly. Release the sticks after the motors are armed or disarmed. © 2016 Hubsan 哈博森科技 版权所有...
- Page 8 Push the stick right and the X4 will fly to the right. The X4 should be horizontal and keep the Left Right current status when the stick is in the center. The angle of stick movement corresponds to the angle of tilt and flight speed. © 2016 Hubsan 哈博森科技 版权所有...
- Page 9 2.) Home Point is recorded when armed the motors with no less than 6 GPS satellites. 3.) You should be in an open place to search for the GPS satellites, it’ll take 3 mins to finish the searching, and the GPS signal strength depends on the flying environment. © 2016 Hubsan 哈博森科技 版权所有...
- Page 10 If the quantity of GPS satellites drops below six for more than 20 seconds while the X4 is returning home, the X4 will descend automatically. The X4 will not avoid obstacles automatically while in failsafe mode. © 2016 Hubsan 哈博森科技 版权所有...
- Page 11 [5] Elevator Trim [6] Aileron Trim Motor LED Switch MODE 1 [7] LCD [1] Photo/Video [8] RTH 2Throttle/Rudder Stick 9 Elevator/Aileron Stick [4] Power Switch [3] Rudder Trim Motor LED Switch [5] Elevator Trim [6] Aileron Trim MODE 2 © 2016 Hubsan 哈博森科技 版权所有...
- Page 12 Press the Elevator stick 0.5 second to shift between Normal Mode and Expert Mode, indicated by one “beep”. When it enters into Expert Mode, “Expert” will be displayed on LCD. MODE 2 MODE 1 Normal Mode Expert Mode © 2016 Hubsan 哈博森科技 版权所有...
- Page 13 Rotate the quadcopter Rotate the quadcopter vertically until horizontally until “Set Compass 2” “Set Compass 2” disappear display Calibration done Flying in the area nearby magnetic field would interfere the compass which need re-calibration as above instructed. © 2016 Hubsan 哈博森科技 版权所有...
- Page 14 The LCD will display “OH”, rotate both sticks in circles three times, release the sticks and press any trim for 1.5 seconds until one “Beep” heard which indicates a successful calibration. The transmitter mode can be shifted according to the above operation. © 2016 Hubsan 哈博森科技 版权所有...
- Page 15 EXPLODED VIEW © 2016 Hubsan 哈博森科技 版权所有...
- Page 16 Lower Body Shell Main Control Board Battery Cover Protection Cover Motor LED Lampshade Screw Li-Po Battery Screw Camera Module Screw Transmission Shaft Screw Bearing Screw Motor Holder 2.4G Attenna Motor Gear Rotary Gear Propeller A Propeller B © 2016 Hubsan 哈博森科技 版权所有...
- Page 17 The owner of old appliances is responsible to bring the appliances to thise collecting points or to similar collection points. With this little personal effort, you contribute to recycle valuable raw materials and the treatment of toxic substances. © 2016 Hubsan 哈博森科技 版权所有...
- Page 18 © 2016 Hubsan 哈博森科技 版权所有...
- Page 20 User manual is subject to change without prior notice due to unforseen product upgrades. Download the latest user manual from WWW.HUBSAN.COM VERSION 1.0 EN...
