Rear Panel I/O
In 1
Use this input for mono sound sources.
In 2
Use this input for the second input of a stereo signal. When nothing is connected to Input 2, the signal
from Input 1 is automatically passed to Input 2.
Out 1
Main audio output. This jack expects a standard (TS) ¼" instrument cable. Amp, mixer, or DI goes here.
Out 2
Second audio output. Use Out 2 for stereo instruments or when you want to split a mono signal so
that it can be output to two separate destinations.
TRS / MIDI
This ¼" TRS input allows for remote control via a passive TRS remote switch or MIDI. The slider
switch located above this jack determines the functionality of the jack.
Power
Echolution 3 runs on 9VDC at 100mA power using a standard 2.1mm negative tip power supply.
USB
Connect a micro USB cable here to perform firmware updates (if available) to the Echolution 3 using
the firmware update tool available from pigtronix.com.
