pigtronix ECHOLUTION 3 User Manual page 10

MIDI CC Map:
12 Repeats Knob
13 Time Knob
14 Mix Knob
15 LFO Speed Knob
Modulation
16
Depth Knob
Time Button
Special Values:
17
3 = Short
4 = Med
5 = Long
SFX Button
Special Values:
3 = Off
18
4 = Pong
5 = Halo
6 = Pong and Halo
Taps Button
Special Values:
3 = First Tap Off
4 = First Tap 1
5 = First Tap 3/4
6 = First Tap 2/3
7 = First Tap 1/2
8 = First Tap PHI
19
9 = Second Tap Off
10 = Second Tap 1
11 = Second Tap 3/4
12 = Second Tap 2/3
13 = Second Tap 1/2
14 = Second Tap PHI
20 = Bit Crusher
9 = Crush Off
10 = Crush On
Saving: After using other midi commands to change parameters, MIDI Preset Save Command can be
used to save a preset.
Bypass Button
21
Special Values:
3 = None
LFO Mod Button
Special Values:
3 = Triangle
4 = Square
5 = Saw
24
6 = Random
7 = Super Triangle
8 = Super Square
9 = Super Saw
10 = Super Random
Tap Tempo
25
Footswitch
Engage Footswitch
Special Values:
27
3 = Explicitly Engaged
4 = Explicitly Not Engaged
Jump Footswitch /
29
Preset 1/2
Freeze Footswitch /
30
Preset 3/4
10
Loop Open Close
(1 = open; 1 = close).
Send a momentary 1 to
31
CC#31 to start a loop,
then send another to
close that loop.
Second Tap Volume
(mapped 0-127) Second
Tap Volume: Send the
76
desired value (0-127) to
MIDI CC#76 to change
the volume of the
second tap.
Enable MIDI Clock In
79
(0=off; 1=on)
