2
Notes on the documentation
2.1
Observing other applicable documents
▶
You must observe all the operating and installation in-
structions included with the system components.
2.2
Storing documents
▶
Pass these instructions and all other applicable docu-
ments on to the system operator.
2.3
Validity of the instructions
These instructions apply only to:
Product article number
Applicability: Belgium
VCC_206-4-5_150
VCC_266-4-5_150
VCC_306-4-5_150
Product article number
Applicability: Germany
VCC_206-4-5_150
VCC_266-4-5_150
Product article number
Applicability: Austria
VCC_266-4-5_150
3
Product description
3.1
Serial number
The serial number is located behind a plate below the user
interface. It is also specified on the identification plate.
Note
The serial number can also be shown on
the display of the product (see the operating
instructions).
3.2
Information on the data plate
The data plate indicates the country in which the unit is to be
installed.
Information on the
Meaning
data plate
Plant number
For identification purposes; 7th to 16th
digits = product article number
VCC...
Gas-fired boiler for heating and domestic
hot water generation
ecoCOMPACT
Product designation
2H, G20 - 20 mbar
Gas group and gas connection pressure
(2 kPa)
as set at the factory
Kat. . (e.g. II
)
Approved gas category
2H3P
Condensing techno-
Efficiency of the floor-standing boiler in
logy
accordance with directive 92/42/EEC
0020181421_04 ecoCOMPACT Installation and maintenance instructions
Information on the
data plate
Type (e.g. C
PMS (e.g. 3 bar
(0.3 MPa))
230 V 50 Hz
(e.g. 100) W
IP (e.g. X4D)
Pn
P
Qn
0010014633
0010014629
Qnw
0010014630
N
L
Vs
0010015604
PMW
0010015607
NOx
D
CE marking
0010015607
3.3
The CE label shows that the products comply with the basic
requirements of the applicable directives as stated on the
identification plate.
The declaration of conformity can be viewed at the manufac-
turer's site.
Notes on the documentation 2
Meaning
)
Approved flue connections
13
Maximum water pressure in heating
mode
Electrical connection – Voltage – Fre-
quency
Max. electrical power consumption
Degree of protection against water
Heating mode
DHW mode
Nominal heat output range in heating
mode
Nominal heat output range in domestic
hot water mode
Nominal heat input range in heating
mode
Nominal heat input range in domestic hot
water mode
Output characteristic figure in accord-
ance with the standard DIN 4708
Water content in the domestic hot water
cylinder
Maximum water pressure in domestic hot
water mode
NOx class for the unit
Specific flow rate in domestic hot water
mode in accordance with EN13203-1
Product complies with European stand-
ards and directives
Recycling the product in accordance with
the relevant regulations
Note
Check whether the product is compatible with the
gas type available on site.
CE label
