OWNER'S
MANUAL
MODEL NO.
LSER11534
STARTING SERIAL #:
L116-336001
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
REV 16-336
8/23/2019
Manufacturing quality lawn care equipment since 1945
19453
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE 660-747-8183 TOLL FREE 800-222-8183 FAX 660-747-8650
LOG
ade I The
USA
of US and Global Parts
Advertisement
Table of Contents
Related Manuals for Swisher LSER11534
Summary of Contents for Swisher LSER11534
- Page 1 Service and Adjustment equipment. Repair Parts REV 16-336 ade I The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093 PHONE 660-747-8183 TOLL FREE 800-222-8183 FAX 660-747-8650 8/23/2019 of US and Global Parts Manufacturing quality lawn care equipment since 1945...
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death. - Page 4 • NEVER operate your splitter near a flame or spark. Hydraulic oil and gasoline are flammable and can explode. • NEVER fill gas tank while the engine is hot or running. Allow the engine to cool before refueling. • This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
-
Page 5: Towing Safety
TOWING SAFETY • Do not allow persons to ride on splitter. Do not carry any cargo or wood on your splitter. It may fall off and endanger vehicles that are following you. • Be sure support leg is in the travel position and coupling secure. This must also be retracted so not to interfere while towing. -
Page 6: Operation
ASSEMBLY This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts. Inspect all components for damage. If you believe you have a damaged part please contact customer service immediately at 1-800-222-8183. - Page 7 COLD WEATHER START UP The Cold Weather Clutch enables the engine to be started without having to pull through cold, thickened hydraulic fluid. Simply push the handle in to the locked position. Start engine, let it warm up, and release Cold Weather Clutch.
- Page 8 Exercise extreme caution, as some parts are very heavy and will require sufficient persons or mechanical handling equipment. Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware and ect may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.
-
Page 9: Safety Decals
SAFETY DECALS Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL 12493 – COLD WEATHER DECAL 12494 – HYDRAULIC FILL PLUG 12549 – DO NOT EXCEED 45 MPH DECAL DECAL 12532 – HYDRAULIC OIL DECAL 12492 – OPERATOR INSTRUCTION DECAL 11427 –... -
Page 10: Assembly Detail
ASSEMBLY DETAIL... -
Page 11: Service Parts
SERVICE PARTS ITEM NUMBER DESCRIPTION PART NUMBER Motor Base & Reservoir 18827TK Hose - Hydraulic 1"ID X 36" 12362 Clamp - Hose No. 12 LS4999 Head - Filter LS1112 Filter - Element LS1113 Fitting - Line Return 7329 Breather Cap 12379 Seal - Wheel Hub Bearing 2203S... - Page 12 BEAM DETAIL ITEM NUMBER DESCRIPTION PART NUMBER Beam Weldment 12440GT Wedge Weldment 7233TK Thick GIB Plate 7237TK Thin GIB Plate 7388TK Bottom GIB Plate 7333TK 1/2-13 X 2 1/2 GR5 Carriage Bolt NB643 1/2 Lock Washer NB508 1/2-13 Nut NB213Z Bolt 1/2-13 X 3 1/4 12669 Washer - USS Flat, 1/2...
- Page 13 TONGUE DETAIL ITEM NUMBER DESCRIPTION PART NUMBER Tongue Weldment 12353TK 2" Ball Coupler 7365 Stand - Folding 14924TK Safety Chain w/Hook 7366 Bolt 3/8-16 X 4 GR5 NB645 Bolt 3/8-16 X 3 1/2 GR5 NB649 Bolt 3/8-16 X 3 GR5 NB150 Latch Pin Guide Bushing 7840Z...
-
Page 14: Engine Detail
ENGINE DETAIL ITEM # DESCRIPTION PART # Engine - B&S 11.5HP 12V Bolt - Serr Flange, 5/16-18 X1 1/4 NB253 Bolt - Serr Flange,5/16-18 X1 3/4 NB515 Nut - Serr Flange 5/16-18 NB170 Spacer - Short, Engine Pulley 689S Pulley - Engine BB105 Key Stock - 1/4 X 1 9031... - Page 15 12 Volt Accessories 12 Volt Accessories ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # Bracket - LS Throttle & Key Swtch 12491TK Pad - Battery BATPAD Cable - Throttle Assy 686N Screw - Sheet Metal #8 X 3/8 NB137 Knob - Throttle 686K...
-
Page 16: Troubleshooting
TROUBLESHOOTING Problem Cause Remedy Engine fails to start. 1. Spark plug wire disconnected. 1. Connect wire to spark plug. 2. Fuel tank not full enough or stale fuel. 2. Fill tank full with clean, fresh gasoline. 3. Throttle control lever not in correct 3. -
Page 17: Maintenance Log
MAINTENANCE LOG Date of Service Service Performed Notes... -
Page 18: Specifications
SPECIFICATIONS Splitting Force 34 Tons* Engine 11.5 HP Briggs and Stratton I/C Battery 12V Type U1L (not included) Splitting Positions Horizontal and Vertical Cylinder Size 5" X 24" Pump 2 Stage with Heavy Duty Bearings Pump Specs 16 Gallons Per Minute Valve Auto Return Belt Drive 1:1 Ratio with Clutch for... -
Page 19: Swisher History
SWISHER HISTORY Back before electricity came to rural Missouri Max Swisher was producing lawn mowers from his mother’s chicken house. Max never liked to mow grass. He installed a gearbox on his family’s lawn mower creating a self-propelled unit. By tying one end of a rope to the mower and the other end to a tree in the center of the yard the mower circled the tree, shortening the rope and guiding the mower in concentric circles. -
Page 20: Log Splitter
The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher, your nearest Swisher dealer, or from our MODEL NO. website.
