swisherinc.com
OWNER'S
MANUAL
MODEL NO.
LSEK14534
LSEK14534-CA
STARTING SERIAL #:
L114-196001
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
REV 14-196
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE 660-747-8183 TOLL FREE 800-222-8183 FAX 660-747-8650
Manufacturing quality lawn care equipment since 1945
19199
LOG
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
Made In The
USA
Advertisement
Table of Contents
Related Manuals for Swisher LSEK14534
Summary of Contents for Swisher LSEK14534
- Page 1 OWNER’S MANUAL MODEL NO. LSEK14534 LSEK14534-CA STARTING SERIAL #: L114-196001 SPLITTER Safety Assembly IMPORTANT Read and follow all Safety Operation Precautions and Instructions before operating this Service and Adjustment equipment. Repair Parts REV 14-196 1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093...
-
Page 2: Table Of Contents
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed. - Page 3 SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death.
- Page 4 • NEVER operate your splitter near a flame or spark. Hydraulic oil and gasoline are flammable and can explode. • NEVER fill gas tank while the engine is hot or running. Allow the engine to cool before refueling. • This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
-
Page 5: Towing Safety
TOWING SAFETY • Do not allow persons to ride on splitter. Do not carry any cargo or wood on your splitter. It may fall off and endanger vehicles that are following you. • Be sure support leg is in the travel position and coupling secure. This must also be retracted so as not to interfere while towing. -
Page 6: Operation
ASSEMBLY This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts. Inspect all components for damage. If you believe you have a damaged part please contact customer service immediately at 1-800-222-8183. -
Page 7: Splitter Operation
COLD WEATHER START UP The Cold Weather Clutch enables the engine to be started without having to pull through cold, thickened hydraulic fluid. Simply pull the handle out to the locked position. Start engine, let it warm up, and push in the Cold Weather Clutch handle to engage pump system. -
Page 8: Maintenance
Exercise extreme caution, as some parts are very heavy and will require sufficient persons or mechanical handling equipment. Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware and ect may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials. -
Page 9: Decals
SAFETY DECALS Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL 12493 – COLD WEATHER DECAL 12494 – HYDRAULIC FILL PLUG 12549 – DO NOT EXCEED 45 MPH DECAL DECAL 12532 – HYDRAULIC OIL DECAL 12492 – OPERATOR INSTRUCTION DECAL 11427 –... -
Page 10: Parts Breakdown
ASSEMBLY DETAIL IDLER DETAIL IDLER DETAIL ASSEMBLY DETAIL IDLER DETAIL Item # Part # Description Item # Part # Description 7296K Tire/Wheel, Log Splitter; Blk 10548 Bolt - Serr Flange, 5/16-18X1GR5 ZY NB179 Washer - 3/4 ID X 1 1/4 OD 18 GA ZY BRS6 Spring - Idler Arm 2203CN Nut - Castle 3/4-16, .625 Tall, Grade 2... - Page 11 FILTER DETAIL Item # Part # Description LS1112 Head - Filter (FPC3012NXXR4X) LS1113 Filter - Element 7329 Fitting - Line Return (4501-12-12) YZ BELT ROUTING DIAGRAM (VIEWED FROM UNDERSIDE OF LOG SPLITTER ) IDLER PULLEY # 14424 BELT PART # 19198 PUMP PULLEY #19163 ENGINE PULLEY #19164 IDLER PULLEY # B527...
- Page 12 BEAM DETAIL Item # Part # Description 19581TK Weldment - Beam, LSEK14534; Txt Blk 7288TK Line - Asy Stationary, Splitter; Txt Blk 7291 Elbow - Hydraulic (2501-8-8) YZ 7355TK Cylinder - 5 X 24 X 2 Painted 7293 Pin - Cylinder to Beam Zp NB642 Cotter - Hairpin #23-09 .093 X 1-13/16...
- Page 13 TONGUE DETAIL Item # Part # Description NB649 Bolt - 3/8-16 X 3 1/2 GR5 ZY NB272 Washer - SAE Flat 3/8 ZY Carbon Steel NB182 Nut - Nyloc 3/8-16 ZY 19183TK Weldment - Tongue, LS; Txt Blk 10177 Washer - Fender 3/8 X 1.5, Crbn Stl GR 2 NB150 Bolt - 3/8-16 X 3 HCC GR5 ZY NB126...
- Page 14 ENGINE DETAIL Item # Part # Description Engine - KAW 14.5HP, LS NB711 Washer - Split Lock, 3/8 ZY, Medium NB618 Bolt - 3/8-16 X 1 1/4 GR5 ZY 689S Spacer - Short, Engine Pulley, .687 19164 Pulley - Engine 1" X 4.5" OD 9031 Key Stock - 1/4 X 1 Undr Sz Plain Fin 689L...
-
Page 15: Wiring Diagram
Nut - Serr Flange, 1/4-20 Grade 5 ZY NOT SHOWN AS084 Electrical - 5 Amp Fuse NOT SHOWN 19187 Harness - Wiring, LSEK14534 NOT SHOWN BC24 Cable - Battery, 24" Red NOT SHOWN BCBT Boot - Rubber, Small, Battery Cable NOT SHOWN Cable - Battery, 10"... -
Page 16: Troubleshooting
TROUBLESHOOTING Problem Cause Remedy Engine fails to start. 1. Spark plug wire disconnected. 1. Connect wire to spark plug. 2. Fuel tank not full enough or stale fuel. 2. Fill tank full with clean, fresh gasoline. 3. Throttle control lever not in correct 3. - Page 17 MAINTENANCE LOG Date of Service Service Performed Notes...
-
Page 18: Specifications
SPECIFICATIONS Splitting Force 34 Tons* Engine 14.5 HP Kawasaki, 603CC Battery 12V Type U1L (not included) Splitting Positions Horizontal and Vertical Cylinder Size 5" X 24" Pump 2 Stage with Heavy Duty Bearings Pump Specs 22 Gallons Per Minute Valve Auto Return Belt Drive 1:1 Ratio with Clutch for Drive System... - Page 19 SWISHER HISTORY Back before electricity came to rural Missouri Max Swisher was producing lawn mowers from his mother’s chicken house. Max never liked to mow grass. He installed a gearbox on his family’s lawn mower creating a self-propelled unit. By tying one end of a rope to the mower and the other end to a tree in the center of the yard the mower circled the tree, shortening the rope and guiding the mower in concentric circles.
-
Page 20: Log Splitter
The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher, your nearest Swisher dealer, or from our MODEL NO. website.
