Swisher Logger LS67526S Owner's Manual

Swisher log splitter owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S
MANUAL
MODEL NO.
LS67526S

LOG SPLITTER

IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
Rev.07.23.2003
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
ONLS03S
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
By Swisher
PHONE 660-747-8183
Made In The
USA

Advertisement

Table of Contents
loading

Related Manuals for Swisher Logger LS67526S

Summary of Contents for Swisher Logger LS67526S

  • Page 1: Log Splitter

    OWNER’S MANUAL MODEL NO. LS67526S LOG SPLITTER IMPORTANT Read and follow all Safety Precautions and Instructions before operating this equipment. Rev.07.23.2003 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 Manufacturing quality lawn care equipment since 1945 ONLS03S Safety Assembly Operation Service and Adjustment...

  • Page 2: Limited Warranty

    1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death.
  • Page 4 Fluid escaping from a very small hole can be almost invisible. Do not check for leaks with your hand. Escaping fluid under pressure can have sufficient force to penetrate skin, causing serious personal injury. Leaks can be located by passing a piece of cardboard or wood over the suspected leak and looking for discoloration.

  • Page 5: Towing Safety

    TOWING SAFETY • Do not allow persons to ride on splitter. Do not carry any cargo or wood on your splitter. It may fall off and endanger vehicles that are following you. • Be sure jack stand is in the travel position and coupling secure. This must also be retracted so not to interfere while towing.

  • Page 6: Operation

    Intended use: This log splitter is intended and designed to only split wood. NEVER use for any other purposes. Doing so can cause injury or VOID THE WARRANTY. ASSEMBLY INSTRUCTIONS This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts.

  • Page 7: Filling The Hydraulic Reservoir

    FILLING THE HYDRAULIC RESERVOIR Fill the hydraulic reservoir with at least five gallons of Dextron III Automatic Transmission fluid or 10W AW hydraulic fluid. After the hydraulic reservoir and the engine crankcase are filled correctly with their respective oils, start the engine. Remember to set the throttle and turn on the fuel shut-off valve. The hydraulic pump should prime itself.

  • Page 8: Maintenance And Storage

    REPAIR PARTS Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware, etc. may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.

  • Page 9: Engine Detail

    BEAM DETAIL ENGINE DETAIL ITEM # ITEM # 6.75 HP BRIGGS AND STRATTON ENGINE 5/16-18 X 2 1/2 GR5 BOLT 5/16-18 2-WAY LOCK NUT 5/16-18 X 1 1/4 GR5 BOLT SET SCREW W/ NYLOCK ENGINE PULLEY - LS622 MODEL ONLY BELLEVILLE WASHER 3/8-24 X 1 BOLT W/ NYLOCK DESCRIPTION...

  • Page 10: Assembly Detail

    ASSEMBLY DETAIL Parts List Page 11 SEE DETAIL Overhead Valve Engine See Detail (Page 9)

  • Page 11: Service Parts

    Please have Model and Serial Numbers ready when ordering parts. Color cannot be guaranteed on service parts. ITEM # DESCRIPTION RETURN HOSE 54" PRESSURE HOSE 48" #12 HOSE CLAMP HYDRAULIC RESERVOIR 1/2-13 X 3 1/2 GR5 BOLT 1/2-13 NYLOCK NUT RESERVOIR VENT PLUG 3/8-16 X 1 GR5 BOLT 1/2 X 3 1/2 HITCH PIN W/ HAIR PIN...

  • Page 12: Log Splitter

    All Log Splitter parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc., your nearest Swisher dealer, or from our website. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower without notice.
