OWNER'S
MANUAL
MODEL NO.
LS722H
STARTING SERIAL #:
L108-246001
LS728H
STARTING SERIAL #:
L108-246001
LS10528H
STARTING SERIAL #:
L108-246001
LS12534H
STARTING SERIAL #:
L108-246001
LS12534H12V
STARTING SERIAL #:
L108-246001
LS12534H12V-CA
STARTING SERIAL #:
L108-246001
LS12534H-CA
STARTING SERIAL #:
L108-246001
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
Rev. 08-253
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
12489
Model LS12534H Shown
LOG
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
PHONE 660-747-8183
Made In The
USA
Advertisement
Table of Contents
Related Manuals for Swisher LS12534H Shown
Summary of Contents for Swisher LS12534H Shown
- Page 1 OWNER’S MANUAL MODEL NO. Model LS12534H Shown LS722H STARTING SERIAL #: L108-246001 LS728H STARTING SERIAL #: L108-246001 LS10528H STARTING SERIAL #: L108-246001 LS12534H STARTING SERIAL #: L108-246001 SPLITTER LS12534H12V STARTING SERIAL #: L108-246001 LS12534H12V-CA STARTING SERIAL #: L108-246001 LS12534H-CA...
- Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed.
- Page 3 SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death.
- Page 4 NEVER operate your splitter near a flame or spark. Hydraulic oil and gasoline are flammable and can explode. NEVER fill gas tank while the engine is hot or running. Allow the engine to cool before refueling. This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
-
Page 5: Towing Safety
TOWING SAFETY Do not allow persons to ride on splitter. Do not carry any cargo or wood on your splitter. It may fall off and endanger vehicles that are following you. Be sure support leg is in the travel position and coupling secure. This must also be retracted so not to interfere while towing. - Page 6 ASSEMBLY This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts. Inspect all components for damage. If you believe you have a damaged part please contact customer service immediately at 1-800-222-8183.
- Page 7 COLD WEATHER START UP The Cold Weather Clutch enables the engine to be started without having to pull through cold, thickened hydraulic fluid. Simply pull the handle out into locked position. Start engine, let it warm up, and release Cold Weather Clutch. After starting, assure that the lever has reengaged. SPLITTER OPERATION Set up the log splitter in a clear, level area and block the wheels.
- Page 8 Exercise extreme caution, as some parts are very heavy and will require sufficient persons or mechanical handling equipment. Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware and ect may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.
-
Page 9: Safety Decals
SAFETY DECALS Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL 12493 – COLD WEATHER DECAL 12494 – HYDRAULIC FILL PLUG 12549 – DO NOT EXCEED 45 MPH DECAL DECAL 12532 – HYDRAULIC OIL DECAL 12492 – OPERATOR INSTRUCTION DECAL 11427 –... - Page 10 Model LS12534B12V Shown ASSEMBLY DETAIL LS722H, LS728H, LS10528H & LS12534B MODELS...
- Page 11 SERVICE PARTS Please have Model and Serial Numbers ready when ordering parts. Color cannot be guaranteed upon service parts. ITEM NUMBER DESCRIPTION PART NUMBER Motor Base/Hydraulic Tank 12350TK 36" Suction Hose 12362 #12 Hose Clamp LS5001 Not Shown Filter Head LS1112 Not Shown Filter Element...
- Page 12 Wedge Weldment 14622TK Shown Beam Weldment 14900TC Shown BEAM DETAIL ALL MODELS NOT ALL PARTS ARE ON ALL MODELS ITEM NUMBER DESCRIPTION PART NUMBER Beam Weldment - Model LS722H, LS728H & LS10528H 14900TC Beam Weldment - Model LS12534H & LS12534H12V 12440TC Eight BoltWedge Weldment (All 34 Ton Models) 7233TK...
- Page 13 TONGUE DETAIL ALL MODELS ITEM NUMBER DESCRIPTION PART NUMBER Tongue Tube 12346TK 2" Ball Coupler 7365 Folding Support Leg 14924TK Safety Chain w/Hook 7366 Bolt 3/8-16 X 4 GR5 NB645 Bolt 3/8-16 X 3 1/2 GR5 NB649 Bolt 3/8-16 X 3 GR5 NB150 Latch Pin Guide Bushing 7840Z...
- Page 14 ENGINE DETAIL MODEL LS10528H, LS12534H & LS12534H12V ITEM # DESCRIPTION PART # Engine Bolt 5/16-18 X 1 1/4 Serr. Flange NB253 NB515 Bolt 5/16-18 X 1 3/4 Serr. Flange (One Per - 12 Volt Engines) Nut 5/16-18 Serr. Flange NB170 Upper Spacer 689S Engine Pulley...
-
Page 15: Wiring Diagram
12 Volt Accessories 12 Volt Accessories BATTERY ITEM # DESCRIPTION PART # Throttle & Key Switch Bracket 12491TK Throttle Cable 686N Throttle Knob 686K Battery Hold Down Strap 12498TK Nut 1/4-20 Nyloc NB180 NOT SHOWN Washer 1/4 SAE NB274 Bolt 1/4-20 X 7 NB732 Solenoid Bracket 9913TK... -
Page 16: Troubleshooting
Idler Pulley Pump Pulley Engine Pulley BELT ROUTING DIAGRAM (VIEWED FROM UNDERSIDE OF SPLITTER) TROUBLESHOOTING Problem Cause Remedy Engine fails to start. 1. Spark plug wire disconnected. 1. Connect wire to spark plug. 2. Fuel tank not full enough or stale fuel. 2. - Page 17 TROUBLESHOOTING CONTINUED Problem Cause Remedy Leaking Cylinder 1. Broken seals. 1. See authorized service center. 2. Scored cylinder. 2. See authorized service center. 12 Volt Units Engine will not turn over 1. Weak or dead battery. 1. Recharge or replace battery. 2.
-
Page 18: Specifications
SPECIFICATIONS Models LS722H LS728H LS10528H LS12534H & LS12534H12V Splitting Force 22 Tons 28 Tons 28 Tons 34 Tons 7 HP Briggs and Stratton 7 HP Briggs and Stratton 10.5 HP Briggs and 12.5 HP Briggs and Stratton I/C Engine Quantum INTEK Stratton I/C (12 volt Start on 12V Model) - Page 19 SWISHER HISTORY Back before electricity came to rural Missouri Max Swisher was producing lawn mowers from his mother’s chicken house. Max never liked to mow grass. He installed a gearbox on his family’s lawn mower creating a self-propelled unit. By tying one end of a rope to the mower and the other end to a tree in the center of the yard the mower circled the tree, shortening the rope and guiding the mower in concentric circles.
-
Page 20: Log Splitter
The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc., your nearest MODEL NO. Swisher dealer, or from our website.
