swisherinc.com

OWNER'S

MANUAL

MODEL NO.

LS11528HPF

STARTING SERIAL #:

L110-165001

LS87522HPF

STARTING SERIAL #

L110-165001

IMPORTANT

Read and follow all Safety

Precautions and Instructions

before operating this

equipment.

Rev. 11-048

1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093

Manufacturing quality lawn care equipment since 1945

18166

SPLITTER

Safety

Assembly

Operation

Service and Adjustment

Repair Parts

PHONE 660-747-8183 FAX 660-747-8650

Model LS87522HPF shown

LOG

Made In The

USA

Table of Contents

Need help?

Do you have a question about the LS11528HPF and is the answer not in the manual?

Questions and answers

Summary of Contents for Swisher LS11528HPF

Page 1 OWNER’S MANUAL MODEL NO. LS11528HPF STARTING SERIAL #: L110-165001 LS87522HPF STARTING SERIAL # L110-165001 Model LS87522HPF shown SPLITTER Safety IMPORTANT Assembly Read and follow all Safety Precautions and Instructions Operation before operating this equipment. Service and Adjustment Rev. 11-048...
Page 2: Table Of Contents
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed.
Page 3: Warranty
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death.
Page 4 SAFETY PRECAUTIONS • NEVER operate your splitter near a flame or spark. Hydraulic oil and gasoline are flammable and can explode. • NEVER fill gas tank while the engine is hot or running. Allow the engine to cool before refueling. •...
Page 5: Safety
TOWING SAFETY • Do not allow persons to ride on splitter. Do not carry any cargo or wood on your splitter. It may fall off and endanger vehicles that are following you. • Be sure support leg is in the travel position and coupling secure. This must also be retracted so not to interfere while towing.
Page 6: Operation
ASSEMBLY This log splitter has been mostly assembled at the factory. Refer to uncrating and assembly instructions to complete the final assembly step. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts.
Page 7 OPERATION SPLITTER OPERATION Set up the log splitter in a clear, level area and block the wheels. The suction port on the tank should always be on the lower side of the log splitter. Place a log on the beam, against the foot plate. Make sure the log is securely on the foot plate and up against the beam.
Page 8: Maintenance
Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware and ect may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.
Page 9: Decals
SAFETY DECALS Replace decals immediately if damaged. 17943 – COLD WEATHER DECAL OD16 – FUEL SHUT OFF DECAL 12494 – HYDRAULIC FILL PLUG 12549 – DO NOT EXCEED 45 MPH DECAL DECAL 12492 – OPERATOR INSTRUCTION DECAL 11427 – DANGER DECAL...
Page 10: Parts Breakdown
SEE DETAIL BEAM ASSEMBLY SEE DETAIL 7346 Hose - Suct ion, 20" Shown 14921 Hose - Supply, 1" ID X 16-7/8" Long (LS11528HPF) 16637 Hose - Return, 3/4" X 18.5" Shown 16067 Hose - Return, 3/4 X 55 Shown 7289 Hose - Hyd.
Page 11 Bolt - 3/8-16 X 1 3/4 HCC GR5 ZY PUMP DETAIL ITEM NO. QTY. PART NO. DESCRIPTION 1 16625TK Mount - Pump; Textured Black (LS87522HPF) 1 16641TK Mount - Pump; Txt Blk (LS11528HPF) 1 17904 HYDRAULIC PUMP (LS11528HPF) 1 16254 HYDRAULIC PUMP (LS87522HPF) 8 NB596 BOLT - 5/16"...
Page 12 PARTS BREAKDOWN NOTE: The directional flow arrows on the filter head (LS1112) should be pointing away from the hydraulic tank on the 22 Ton models. FILTER DETAIL ITEM NO. QTY. PART NO. DESCRIPTION 1 17627 MOUNT - FILTER 2 NB250 1/4-20 X 3/4 GR5 ZP 2 NB135 Washer - 1/4 Split Lock, Medium Dut y...
Page 13 1/2 USS Flat Washer ZP 1 7284TK CYLINDER 4" X 24" X 1 3/4" (LS87522HPF) 1 7354TK Cylinder - 4 1/2 X 24 X 1.75, Paint ed (LS11528HPF) 1 7287TK Valve Cont rol Split terAssy 1 7292 Pipe Nipple 24SA-08...
Page 14 TONGUE DETAIL ITEM NO. QTY. PART NO. DESCRIPTION 3 NB649 BOLT - HEX, 3/8-16 X 3 1/2 GR5 ZP 12 NB272 3/8 SAE WASHER 4 NB182 3/8-16 NYLOC NUT 1 7365 2" Ball Coupler 1 14924TK St and - Folding 2 7840Z Lat ch Pin Guide Bushing 2 7366...
Page 15 BOLT - 5/16-18 X 1 1/4 HCC GR5 ZY NB138 BOLT - 5/16-18 X 2 1/2 HCC GR5 ZY NB170 NUT - SERR FLANGE 5/16-18 ZY CASE HRD ENGINE DETAIL LS11528HPF ITEM NO. QTY . PART NO. DESCRIPTION 1 N/A ENGINE 1 NB238N...
Page 16 BELT ROUTING DIAGRAM (VIEWED FROM UNDERSIDE OF SPLITTER) IDLER PULLEY ENGINE PUMP PULLEY PULLEY TROUBLESHOOTING Problem Cause Remedy Engine fails to start. 1. Spark plug wire disconnected. 1. Connect wire to spark plug. 2. Fuel tank not full enough or stale fuel. 2.
Page 17 MAINTENANCE LOG NOTE: For repairs beyond those listed here, contact your nearest authorized service center. * Flushing the reservoir tank and hoses with kerosene whenever service is performed on the tank, hydraulic pump or valve is recommended. Contact an authorized service center. Date of Service Service Performed Notes...
Page 18: Specifications
SPECIFICATIONS LS87522HPF LS11528HPF Splitting Force 22 Tons Splitting Force 8.75 Torque Engine Engine 11.5 HP B&S B&S Splitting Horizontal and Splitting Horizontal and Positions Vertical Positions Vertical Cylinder Size ø4" X 24" Cylinder Size ø4.5" X 24" Pump 2 Stage...
Page 19 SWISHER HISTORY Back before electricity came to rural Missouri Max Swisher was producing lawn mowers from his mother’s chicken house. Max never liked to mow grass. He installed a gearbox on his family’s lawn mower creating a self-propelled unit. By tying one end of a rope to the mower and the other end to a tree in the center of the yard the mower circled the tree, shortening the rope and guiding the mower in concentric circles.
Page 20 The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher, your nearest Swisher dealer, or from our MODEL NO. website.
