swisherinc.com
OWNER'S
MANUAL
MODEL NO.
LSED14534
STARTING SERIAL #:
L122-265001
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
REV 22-265
9/22/2022
Manufacturing quality lawn care equipment since 1945
20404
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE 660-747-8183 TOLL FREE 800-222-8183 FAX 660-747-8650
LOG
Made In The
USA
of US and Global Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L122-265001 and is the answer not in the manual?

Questions and answers

Related Manuals for Swisher L122-265001

Summary of Contents for Swisher L122-265001

  • Page 1 Repair Parts REV 22-265 Made In The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093 PHONE 660-747-8183 TOLL FREE 800-222-8183 FAX 660-747-8650 9/22/2022 of US and Global Parts Manufacturing quality lawn care equipment since 1945...

  • Page 2: Limited Warranty

    Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death.
  • Page 4  NEVER operate your splitter near a flame or spark. Hydraulic oil and gasoline are flammable and can explode. NEVER fill gas tank while the engine is hot or running. Allow the engine to cool before refueling.  This unit is equipped with an internal combustion engine and should not be used on or near any ...

  • Page 5: Towing Safety

    TOWING SAFETY Do not allow persons to ride on splitter. Do not carry any cargo or wood on your  splitter. It may fall off and endanger vehicles that are following you. Be sure support leg is in the travel position and coupling secure. This must also be ...

  • Page 6: Operation

    ASSEMBLY Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts. Inspect all components for damage. If you believe you have a damaged part please contact customer service immediately at 1-800-222-8183. WARNING: Exercise extreme caution, as parts are very heavy.

  • Page 7: Hydraulic Safety

    4-WAY WEDGE OPERATION: See 18851 Owners Manual in parts bag. SPLITTER OPERATION Set up the log splitter in a clear, level area and block the wheels. The suction port on the tank should always be on the lower side of the log splitter. Place a log on the beam, against the foot plate.

  • Page 8: Maintenance And Storage

    Exercise extreme caution, as some parts are very heavy and will require sufficient persons or mechanical handling equipment. Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware and ect may look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.

  • Page 9: Safety Decals

    SAFETY DECALS Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL 12494 – HYDRAULIC FILL PLUG 12549 – DO NOT EXCEED 45 MPH DECAL DECAL 12532 – HYDRAULIC OIL DECAL 12492 – OPERATOR INSTRUCTION DECAL 11427 – DANGER DECAL...

  • Page 10: Assembly Detail

    ASSEMBLY DETAIL ASSEMBLY DETAIL Item # Part # Description 7296K Tire/Wheel, Log Splitter; Blk NB179 Washer - 3/4 ID X 1 1/4 OD 18 GA ZY 2203CN Nut - Castle 3/4-16, .625 Tall, Grade 2 NB633 Pin - Cotter, 1/8 X 2(Ext Prng Crbn Stl) 2203DC Cover - Dust, Wheel Hub NB151 Bolt - 1/2-13 X 6 HCC GR5 ZP NB555 Washer - USS Flat, 1/2 ZY...
  • Page 11 FILTER DETAIL Item # Part # Description LS1112 Head - Filter (FPC3012NXXR4X) LS1113 Filter - Element 7329 Fitting - Line Return (4501-12-12) YZ PUMP DETAIL Item # Part # Description 9031 Key Stock - 1/4 X 1 712127 Screw - Set 1/4-20 X 1/2 14903 Coupler - 1"...
  • Page 12 BEAM DETAIL Item # Part # Description 19581TK Weldment - Beam, LSEK14534; Txt Blk 7288TK Line - Asy Stationary, Splitter; Txt Blk 7291 Elbow - Hydraulic (2501-8-8) YZ 7355TK Cylinder - 5 X 24 X 2 Painted 7293 Pin - Cylinder to Beam Zp NB642 Cotter - Hairpin #23-09 .093 X 1-13/16 7292...
  • Page 13 TONGUE DETAIL Item # Part # Description NB649 Bolt - 3/8-16 X 3 1/2 GR5 ZY NB272 Washer - SAE Flat 3/8 ZY Carbon Steel NB182 Nut - Nyloc 3/8-16 ZY 19183TK Weldment - Tongue, LS; Txt Blk 10177 Washer - Fender 3/8 X 1.5, Crbn Stl GR 2 NB150 Bolt - 3/8-16 X 3 HCC GR5 ZY NB126...
  • Page 14 ENGINE DETAIL (Kawasaki) Item # Part # Description Engine - KAW 14.5HP, LS 16000 Valve - Oil Drain 18810 Adapter - Oil Drain, Kawasaki NB711 Washer - Split Lock, 3/8 ZY, Medium NB618 Bolt - 3/8-16 X 1 1/4 GR5 ZY NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5 19181...
  • Page 15 12 VOLT ACCESORIES ITEM NO. PART # DESCRIPTION ITEM NO. PART # DESCRIPTION 23318TK Plate- Front, Console 20142TK Plate- Right side, Console 9088 WASHER - LOCK KEY SWITCH 24206 BOLT - 12 x 1/2 Hex Self Tap 9087 NUT - KEY SWITCH 1002004 SOLENOID - 3 POLE 20148TK...

  • Page 16: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 17: Troubleshooting

    TROUBLESHOOTING Engine is hard to start or runs erratically. 1. Spark plug w ire loose. 1. Connect and tighten spark plug w ire. 2. Clean fuel line; fill tank w ith clean, fresh 2. Blocked fuel line or stale fuel. gasoline 3.

  • Page 18: Maintenance Log

    MAINTENANCE LOG Date of Service Service Performed Notes...

  • Page 19: Specifications

    SPECIFICATIONS Splitting Force 34 Tons* Engine 14.5 HP Kawasaki, 603CC Battery 12V Type U1L (not included) Splitting Positions Horizontal and Vertical Cylinder Size 5" X 24" Pump 2 Stage with Heavy Duty Bearings Pump Specs 22 Gallons Per Minute Valve Auto Return Drive System Heavy Duty Direct Drive Coupling...

  • Page 20: Log Splitter

    The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher, your nearest Swisher dealer, or from our MODEL NO. website.
