Arrow Storage Products DK1014 B1 Owner's Manual & Assembly Instructions

Hide thumbs Also See for DK1014 B1:

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
CM01a
Model No.
715830520
Storage Area: 129 Sq. Ft.
12,0 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Size
10' x 14'
121" x 160 1/4"
3,0 m x 4,3 m
307,3 cm x 407,0 cm
DK1014 B1
852 Cu. Ft.
24,1 m
3
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
123 1/4" 162 3/4"
313,1 cm 413,4 cm
LX1014 C1
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Depth
Height
Width
87 7/8"
118 1/4"
223,2 cm
300,4 cm
SG1014FB
Interior Dimensions
(Wall to Wall)
Depth
Height
157 1/2" 86 5/8"
400,1 cm 220,0 cm
Door
Opening
Width
Height
55 1/2"
60"
141,0 cm 152,4 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the DK1014 B1 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow Storage Products DK1014 B1

Summary of Contents for Arrow Storage Products DK1014 B1

  • Page 1 Owner's Manual & Assembly Instructions CM01a Model No. DK1014 B1 LX1014 C1 SG1014FB 715830520 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 129 Sq. Ft. 852 Cu. Ft. TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ...
  • Page 3 BEFORE YOU BEGIN..A03a Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..A05a Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...

  • Page 8: Special Note

    ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
  • Page 9 Base The Base For Your Building No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an e ective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 10 Anchoring Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 11 Hardware SO11a ctr Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (8) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (260) (Packed with Screws) Bolt (260) Screw (506) 65109 67468 66646...

  • Page 12: Parts List

    Parts List SO12a et ctr Assembly Part Part Quantity Check Key No. Number Description In Carton List 3719 Door Handle Brace 9373 Front Wall Panel 8470 Corner Panel 6108 Large Right Gable 6109 Large Left Gable 6114 Small Right Gable 6115 Small Left Gable 8462...
  • Page 13 Assembly by Key No. SO13a et ctr...
  • Page 14 Step 1 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Floor Frame Assemblies 8936 Rear Floor Frame (2) 11502 Side Floor Frame (4) SO14a ctr (13) 9367 The front oor frame is made up of 8934 three pieces. The side floor frames and the rear floor frame are made 9367 up of two pieces.

  • Page 15: Frame Assemblies

    5986 Rear Wall Angle (2) Step 2 Parts Needed For 10389 Rear Wall Channel (2) Frame Assemblies 11501 Side Wall Channel (4) 11503 Side Wall Angle (4) SO15a ctr Rear Wall Channel 10389 118 1/8" 300,0 cm (27) 10389 The main frame pieces reinforce the walls.
  • Page 16 Step 3 Parts Needed For 11499 Roof Beam (8) Roof Beam Assemblies SO16a ctr 11499 (30) 11499 The roof beams join the two gables Roof Beam 159 3/8" 404,8 cm and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the center.
  • Page 17 Step 4 Parts Needed For 6403 Door Track Splice (1) Door Track Assembly 9366 Door Track (2) A17 ctr NOTE: Door Track Splice (painted part) 6403 The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. Using the door track splice, (painted), join the door track (galvanized) pieces end-to-end as...
  • Page 18 Step 5 Front Floor Assembly (1) Parts Needed For Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) SO18a ctr RIGHT REAR Assemble the four corners of 11502 the oor frame using two screws at each corner as shown. At the front corners fasten bolts through from the bottom with nuts on top.
  • Page 19 6515 Wall Panel (2) Step 6 Parts Needed For 9373 Front Wall Panel (2) Corners 8470 Corner Panel (4) 10563 Wall Panel (4) SO19a ctr 8470 8470 REAR (50) 10563 10563 NOTE The remainder of the building assembly requires many hours and more than one STEP person.
  • Page 20 Step 7 Parts Needed For Rear Wall Channel Assembly (1) Mid Frames Side Wall Channel Assembly (2) SO20a ctr (28) The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.
  • Page 21 Step 8 Door Track Assembly (1) Parts Needed For Rear Wall Angle Assembly (1) Top Frames Side Wall Angle Assembly (2) SO21a ctr (34) The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
  • Page 22 Step 9 Parts Needed For 6515 Wall Panel (10) Wall Panels SO22 ctr STEP (144) (15) Crimped Rib STEP Each wall panel has a crimped rib Underneath on one side. The crimped rib should go under the rib of the panel that 6515 Detail Showing follows it.
  • Page 23 Step 10 Parts Needed For 9369 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) SO23 ctr 9365 (18) STEP The door jambs reinforce the door opening and provide an attractive INSIDE OF trim. Follow these steps for both BUILDING door jambs.
  • Page 24 6108 Large Right Gable (2) Step 11 Parts Needed For 6109 Large Left Gable (2) 6114 Small Right Gable (2) Gable Assemblies 6115 Small Left Gable (2) SO24et ctr 6085 Roof Beam Bracket (4) 69835 Green Edge Trim (Plastic Piece) (16) STEP The gables go on top of the front and...
  • Page 25 Left Gable Assemblies (2) Step 12 Parts Needed For Right Gable Assemblies (2) Gables/Roof Beams Single Roof Beam Assemblies (2) 6636 Gable Brace (2) SO25a ctr (28) (12) Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
  • Page 26 Step 13 Parts Needed For Main Roof Beam Assembly (1) Roof Beam/Braces 6227 Roof Beam Brace (2) SO26a ctr STEP Fasten the track supports to the front gable assembly only, as shown. Track Supports 6228 Wrap the weather stripping tape around the two joined edges of the large left and right gables.
  • Page 27 Step 14 Parts Needed For 8462 Right Roof Panel (1) Right Roof Panel 11504 Roof Panel (1) SO27a et ctr Washer (10) (11) Hint: Follow the fastener sequence shown for proper alignment. Bolt Installing the roof panels is best done with a step ladder.
  • Page 28 8463 Left Roof Panel (1) Step 15 Parts Needed For 11504 Roof Panel (1) Ridge Caps & Panels 6538 Roof Panel (2) 6797 Ridge Cap (3) SO28a ctr Screws To Roof Beam (25) (26) Install a left roof panel 8463 and Fasten at Fasten At 11504 at the left rear corner of the roof.
  • Page 29 Step 16 Parts Needed For 6538 Roof Panel (4) Ridge Caps & Panels 6869 Ridge Cap (3) SO29 ctr (16) (32) Install two roof panels 6538 work- ing side to side. Cover the notched areas of the roof panels with strips of NOTE weather stripping tape and continue If roof beam holes do not line up...
  • Page 30 6538 Roof Panel (2) Step 17 Parts Needed For 6797 Ridge Cap (3) 11504 Roof Panel (2) Ridge Caps & Panels 8462 Right Roof Panel (1) SO30a ctr 8463 Left Roof Panel (1) (44) (88) Install the third ridge caps 6797 over- Reducing Large Gable Bulge lapping the second ridge caps while Loosen eight bolts and nuts shown.
  • Page 31 Step 18 Parts Needed For 80257 Left Side Roof Trim (2) 11498 Right Side Roof Trim (2) Roof Trim 6015 Side Roof Trim (2) SO31a ctr (14) Attach the right, left and side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.

  • Page 32: Door Assembly

    3719 Door Handle Brace (2) Step 19 Parts Needed For 80253 Right and Left Doors (2) 10497 Horizontal Door Brace (4) Door Assembly 6278 Vertical Door Brace (2) SO32a ctr 30028 Nameplate (1) 66775 Plug (2) (12) 80253 The steps on this page tell how to assemble the right door.
  • Page 33 Step 20 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) SQ33 ctr Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the front frame track.
  • Page 34 Anchoring and Floor Frame XA34 Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
  • Page 35 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
  • Page 36 DK1014 B1 LX1014 C1 SG1014FB CM36a 715830520...
