721770217 01BD Owner’s Manual & Assembly Guide www.arrowsheds.com Gloves must be worn Model No. LO1010 DW1010HGH6 at all times to reduce risk of injury! 10’ x 10’ Nominal Size Customer Service: 1-800-851-1085 Base 121” x 114 1/2” assist@arrowsheds.com Size 307,3 cm x 290,8 cm BUILDING DIMENSIONS †...
Page 2
SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.
ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.
FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
Page 5
What kind of base do I use? You can: •Use an Arrow Base Kit •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl...
What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
Page 7
HARDWARE LIST... 07BD Hardware Views by Key No. Part Part Qty. Description #2 Phillips List 11/32 Hex. 65103 Hex Nut (#8-32) 65923 Small Bolt (#8-32 x 3/8) (10 mm) 65004 Small Screw (#8AB x 5/16) (8 mm) 65900A Black Screw (#10B X 1/2) (13 mm) #2 Phillips #2 Phillips 66846...
Page 8
PARTS LIST... 08BD Part Part Qty. Description List Selected End Views by Key No. 3719 Door Handle Brace 2&3 6635 Gable Brace 9009 Gable Brace 9204 Roof Beam Brace 9365 Front Wall Channel 10497 Horizontal Door Brace 5986 Rear Wall Angle 6015 Side Roof Trim 6278...
ASSEMBLY OVERVIEW 11BD Install Corners, Wall Angles, and Door Build the Floor Frame Track Attach Gables and Roof Beams Install Wall Panels, Wall Channels, and Door Jambs Install Roof Panels, Ridge Cap, Side Install Doors Trim, and Corner Cap Shed is now complete.
Page 12
CONSTRUCTING A BASE... 12AY No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
Page 13
Step 1: Floor Frames 13AY Washers are to be used on painted parts only. You will need for this page: Washers are not necessary on unpainted parts 9299 and there are not enough to use on every screw and bolt. Side Floor (QTY: 10) Frame...
Page 14
Step 1: Continued You will need for this page: 8936 Rear Floor (QTY: 5) Frame 8936 Assemble the Rear Floor Frames. Overlap two (2) Rear Floor Frames as shown and secure with fi ve (5) bolts. Two (2) bolts must enter from bottom. Check that the fi...
Page 15
Step 1: Continued You will need for this page: 119 3/8” 303,2 cm 9367 8934 Finished Length Front Floor Ramp (QTY: 8) Frame Overlap Length 7 3/8” 18,7 cm 9367 Overlap the Ramp and two (2) Front Floor 8934 Frames so that four (4) holes align at each end as shown.
Page 16
Step 2: Wall Frames You will need for this page: 5986 9917 Rear Wall Rear Wall Angle (QTY: 2) Channel 5986 9917 5986 Overlap two (2) Rear Wall Channels so that three (3) holes align as shown. Insert a bolt 9917 and nut through the center hole.
Page 17
Step 2: Continued 17BD You will need for this page: 9923 10521 111 5/8” 283,5 cm Finished Length Side Wall Side Wall Angle (QTY: 4) Channel Overlap two (2) Side Wall Channels so that three (3) holes align as shown. Insert a bolt and nut through the center hole.
Page 18
Step 3: Roof Beams 18AY You will need for this page: 10518 10518 BUILD TWO (2) BEAMS Roof Beam (QTY: 16) Overlap two (2) Roof Beams so that the bottom slots align as shown. Insert six (6) bolts and nuts as shown below. Insert two (2) bolts and nuts into slots on bottom of the Beam as shown.
Page 19
Step 3: Continued 19AY You will need for this page: 113 7/16” 288,1 cm 10518 Finished Length Roof Beam (QTY: 14) Overlap two (2) Roof Beams so that bottom slots align but DO NOT INSERT BOLTS. Next, overlap two (2) more Roof Beams to form a second Roof Beam Assembly.
Step 4: Door Track You will need for this page: END VIEW 6403 9366 CORRECT INCORRECT Long Leg Track Splice (QTY: 4) Door Slide Door Track on top. (Painted) Insert screws into bottom side only. The Gables will fasten to the Door Track using the holes on the top side. Door Slide Align two (2) Door Tracks with the four (4) holes in the bottom of the Door Track Splice...
Step 5: Frame Assembly You will need for this page: Assemblies from Step 1: • Front Floor Assembly (1) • Side Floor Assembly (2) • Rear Floor Assembly (1) (QTY: 8) (QTY: 2) Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building after it is erected.
Page 22
Step 6: Corners 22BD You will need for this page: 6515 9373 6514 (QTY: 38) (QTY: 4) Corner Panel Wall Panel Front Panel Place washers on all bolts and screws used 6515 6515 on painted parts. 6514 6514 Use one person to support the Corner while another secures the Panels.
Page 23
Step 7: Wall Framing 23AW You will need for this page: Assemblies from Step 2 and Step 4: • Rear Wall Angle Assembly (1) • Side Wall Angle Assemblies (2) • Door Track Assembly (1) (QTY: 30) • Install one Side Wall Angle Assembly fi rst. •...
Page 24
Step 8: Wall Panels 24BD FASTEN TO WALL ANGLES You will need for this page: 6515 [ NO HARDWARE NEEDED FOR THIS STEP ] Wall Panel Lay out all Panels in the positions shown below. FASTEN TO WALL CHANNELS (STEP 10) Use the diagram to the right when attaching Wall Panels.
Page 25
Step 8: Continued 25AY You will need for this page: (QTY: 66) (QTY: 15) Working one side at a time, lift the Panels into Use bolts to attach Wall Panels where Wall Angles overlap. place and secure top and bottom of Panels with screws.
Page 26
Step 9: Door Jambs 26BD You will need for this page: 9369 Door Jamb (QTY: 8) (QTY: 4) Secure Door Jambs with two (2) screws in the top and bottom of each Panel as shown. Insert two (2) bolts and nuts into the back side of each Panel as shown below.
Page 27
Step 10: Wall Channels 27AY You will need for this page: Assemblies from Step 2: 9365 • Rear Wall Channel Assembly (1) • Side Wall Channel Assemblies (2) Front Channel (QTY: 58) (QTY: 2) Install Rear Wall Channel by placing screws through all remaining holes in Wall Panels.
Page 28
Step 11: Gables You will need for this page: 69835 8577 8576 6635 (QTY: 8) Edge Trim Left Gable Right Gable Gable Brace GABLES ARE STACKED TOGETHER DURING SHIPPING AND MAY BE MIS- TAKEN FOR ONE GABLE! SEPARATE GABLES BEFORE CONTINUING. Edge Trim (Plastic) Edge Trim MUST cover Gable edge.
Page 29
Step 11: Continued 29BD You will need for this page: 9009 (QTY: 14) (QTY: 3) Gable Brace Gable must fi t UNDER Side Wall Angle at corner. Working with one Gable at a time, attach the Rear Gables to the Rear Wall Angle with screws.
Page 30
Step 11: Continued 30BD You will need for this page: 9009 (QTY: 18) (QTY: 2) Gable Brace Track Sup. Leave two (2) holes open on each side of the Gable Working with one Gable at a time, peak to attach Track Support. attach the front Gables to the Door Track with screws.
Page 31
Step 12: Roof Framing You will need for this page: Assemblies from Step 3: • Main Roof Beam Assembly (1) • Single Roof Beam Assemblies (2) (QTY: 12) Tape should wrap around gap between Gables. Top View of Gables Seal the gap between the Gables using the weather stripping tape as shown.
Page 32
Step 12: Continued You will need for this page: 9204 Beam Brace (QTY: 4) In the front, attach the Roof Beam Brace to the Track Support with one (1) bolt and nut as shown and rotate to align with Roof Beam. Secure to Roof Beam with one (1) bolt and nut as shown.
Page 33
Roof Install Prep Page 33BD Use the information on this page to complete steps 13 thru 14. If Roof Beam holes do not line up with Roof Panel holes, shift the building from left to right. If this does not help, your building may not be level. Shim the corners until holes line up.
Step 13: Roof Assembly 34BD You will need for this page: 9087 9086 67545 Right Roof Weather Left Roof (QTY: 16) (QTY: 12) Stripping Panel Panel Attach Back Right Roof Panel to Top Roof Beam only using four (4) screws. Remove Edge Trim from the Left Gable under the Roof Panel.
Page 35
Step 13: Continued 35BD You will need for this page: 7743 6869 Roof Panel Ridge Cap (QTY: 16) (QTY: 4) Continue to apply weather stripping. FASTEN TO RIDGE CAP (NEXT TWO PAGES) Attach two (2) Roof Panels using the diagram to the right while assembling the roof.
Page 36
Step 13: Continued 36BD You will need for this page: 7743 Roof Panel (QTY: 16) (QTY: 2) FASTEN TO RIDGE CAP (NEXT TWO PAGES) Continue to apply weather stripping. Attach two (2) Roof Panels using the diagram while FASTEN TO ROOF BEAMS WITH SCREWS assembling the roof.
Page 37
Step 13: Continued 37BD You will need for this page: 6869 9087 9086 Left Roof Right Roof (QTY: 44) (QTY: 22) Ridge Cap Panel Panel Continue to apply weather stripping. Attach Front Left and Right Roof Panels, one at a time, to Roof Beams using eight (8) screws per Panel.
Page 38
Step 14: Roof Trim 38BD You will need for this page: 6015 (QTY: 4) (QTY: 6) (QTY: 4) Roof Trim Trim Cap (L) Trim Cap (R) Peak Cap Slide Peak Cap legs under Ridge Cap and secure with two (2) bolts and nuts on each end.
Step 16: Door Assembly 39BD You will need for this page: 10475 3719 6278 Door Handle Brace Vert. Brace (QTY: 3) (QTY: 2) Handle Do not fully tighten the bolts that hold on the Door Attach the Door Handle and Door Handle until the Vertical Door Brace is in place.
Page 40
Step 16: Continued You will need for this page: 10497 Horiz. Brace (QTY: 6) Door Guide Slide Horizontal Brace over Door edge and secure with one (1) bolt and nut in top and bottom. Secure the Door Guides and Lower Horizontal Door Brace as shown below.
Step 17: Door Install You will need for this page: Assemblies from Step 16: • Right Door Assembly (1) • Left Door Assembly (1) (QTY: 8) Gable Door Slide From inside the building, place the bottom of the Door into the Front Floor Frame track at about the half- Door Track open position.
Page 42
ANCHORING OPTIONS... IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
Page 43
CARE & MAINTENANCE... Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.
ARROW ACCESSORIES... ROOF STRENGTHENING FLOOR FRAME KITS (heavy snow load) KITS Extra roof beams and gable braces MODELS FB47410, FB5465, designed for added protection against FB106-A, FB109-A and FB1014-A heavy snow accumulation. Increases the strength of your roof. A simple fl oor frame system made of heavy-duty, hot-dipped BEFORE AFTER galvanized steel.
