Printed Matter No. 9839 2105 01
Publication Date 2020-03-12
Valid from Serial No. C1720001
ETP ST101-700-F-HAD
(210-700 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
ETP ST101-700-F-HAD
8433230271
WARNING
Electric pistol grip nutrunner
Product Instructions
Advertisement
Table of Contents
Related Manuals for Atlas Copco ETP ST101-700-F-HAD
Summary of Contents for Atlas Copco ETP ST101-700-F-HAD
- Page 1 ETP ST101-700-F-HAD Printed Matter No. 9839 2105 01 Electric pistol grip nutrunner Publication Date 2020-03-12 Valid from Serial No. C1720001 Product Instructions ETP ST101-700-F-HAD 8433230271 (210-700 Nm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Overhaul .................... 9 Lubrication Instructions................... 10 Lubricating Guide ................ 10 Lubrication ................... 10 Repair Instructions.................. 10 Repair .................... 10 Troubleshooting.................... 11 Power Focus 3000/4000................. 11 Power Focus 600/6000................... 11 If the tool becomes very hot................ 11 Recycling ....................... 12 Environmental Regulations................ 12 © Atlas Copco Industrial Technique AB - 9839 2105 01... -
Page 3: Product Information
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. © Atlas Copco Industrial Technique AB - 9839 2105 01... -
Page 4: Warranty
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 5: Country Of Origin
(>30mA) and if leakage occurs, the drive is switched off (30ms). Changing, interfering or tampering with the protection system voids all warranty and obligations from Atlas Copco. Trouble-shoot- ing and re-start of the system may only be carried out by an authorized person. Check the function of the EFP on a regular basis by pressing the trip-button. -
Page 6: Installation
POWER FOCUS/drive unit. Any changes made of these values in the POWER FOCUS while the tool is connected will be stored in the tool memory. © Atlas Copco Industrial Technique AB - 9839 2105 01... -
Page 7: Operation
The soft-start function facilitates entering the screw head and thread. The duration of the soft start is adjustable, see the manual for the drive unit. The tool is equipped with signal lights, ■ Green = OK tightening © Atlas Copco Industrial Technique AB - 9839 2105 01... - Page 8 Yellow = Warning – low torque (not for ES) ■ Red = Warning – high torque ■ Orange = Function indicator (only for SL and DL) ■ Blue = Function indicator (only for SL) © Atlas Copco Industrial Technique AB - 9839 2105 01...
-
Page 9: Service
If it is judged that the electric motor is defect or in need of service, the complete motor unit should be re- turned to Atlas Copco Industrial Technique AB for exchange. Motors which have been opened by anyone else than Atlas Copco Industrial Technique AB will not be ser- viced. -
Page 10: Lubrication Instructions
Repair Instructions Repair Repair must only be carried out by qualified authorised personnel. For further information contact your lo- cal Atlas Copco sales representative. © Atlas Copco Industrial Technique AB - 9839 2105 01... -
Page 11: Troubleshooting
To correct, look over speed, ramp time, tightening strategy. One stage and Ergoramp are most heat conserving when applicable. Please refer to the User Guide of your POWER FOCUS. If the above correc- tions are not enough, choose a tool of the next higher capacity. © Atlas Copco Industrial Technique AB - 9839 2105 01... -
Page 12: Recycling
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle the components in accordance with local legislation. Batteries shall be taken care of by your national battery recovery organization. © Atlas Copco Industrial Technique AB - 9839 2105 01... - Page 16 Original instructions © Copyright 2020, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
