EJ87X-1 Transport Chair
Operation Manual
EJ87X-1-INS-LAB-RevA17
EJ87X-1 Transport Chair user and attendant:
Read this manual before operating the Transport Chair.
Save this manual for future reference.
The most current version of this manual can be found online at
www.grahamfield.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Everest & Jennings EJ87X-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Graham Field Everest & Jennings EJ87X-1

Summary of Contents for Graham Field Everest & Jennings EJ87X-1

  • Page 1 EJ87X-1 Transport Chair Operation Manual EJ87X-1-INS-LAB-RevA17 EJ87X-1 Transport Chair user and attendant: Read this manual before operating the Transport Chair. Save this manual for future reference. The most current version of this manual can be found online at www.grahamfield.com.

  • Page 2: Table Of Contents

    WARNING: EJ87X-1 Transport Chair user and attendant: Do not operate the transport chair without first reading and understanding this manual. If you do not understand the warnings, cautions, and instructions provided herein, contact your healthcare professional, GF authorized distributor, or technical representative before proceeding with the use of this product;...

  • Page 3: Introduction

    1 INTRODUCTION Thank you for choosing an Everest & Jennings product. We at GF Health Products, Inc. (“Graham-Field”) wish to assure you of our continuing commitment to provide innovation and quality in our products. Important safety, operating, and maintenance instructions that warrant the attention of both user and attendant are included in this operation manual.

  • Page 4: Important Safety Precautions

    2 IMPORTANT SAFETY PRECAUTIONS IMPORTANT SAFETY PRECAUTIONS: ALWAYS FOLLOW THESE SAFETY PRECAUTIONS WHEN USING YOUR EJ87X-1 TRANSPORT CHAIR. FAILURE TO DO SO COULD RESULT IN PERSONAL INJURY TO YOU OR OTHERS OR DAMAGE TO YOUR TRANSPORT CHAIR. Safety requires the constant attention of the Transport Chair user and the attendant. It is extremely important to learn and always use safe methods of performing basic daily activities.
  • Page 5 WARNING: Doing a "wheelie" (tilting the Transport Chair backward until it reaches its balance point) is dangerous and could result in personal injury to the user. WARNING: Do not stand or step on the footplates while transferring to or from your Transport Chair.

  • Page 6: Operation

    3 OPERATION COMPONENT IDENTIFICATION Familiarize yourself with main components, identified in EJ87X-1 Transport Chair illustration below. armpad upper back release seat upholstery attendant wheel lock cable attendant wheel lock shoe caster tipping lever socket caster rear wheel fork caster wheel push handle back upholstery...

  • Page 7: Operation Of Attendant Wheel Locks

    OPERATION OF ATTENDANT WHEEL LOCKS WARNING: Wheel locks are not brakes. Do not use the wheel locks to slow down the Transport Chair, or while the Transport Chair is moving. Wheel locks are only intended to keep the Transport Chair in place when it is at a complete stop. push handle hand grip lower grip...

  • Page 8: To Attendant

    TO ATTENDANT WARNING: To avoid possible tilt hazard, do not leave user unattended. Attendant must always be behind and in control of Transport Chair when user is being positioned or Transport Chair is in use. 1. Work with your medical professionals to learn the best methods of assistance. 2.

  • Page 9: For Attendant: Tilting

    FOR ATTENDANT: TILTING Tilting the Transport Chair backward is generally required to negotiate such obstacles as ramps, inclines, curbs, stairs and door sills. Tilting should only be performed by an attendant. To tilt the Transport Chair backward: 1. Grasp the push handles securely and ensure the hand grips are firmly attached. 2.

  • Page 10: Curbs And Steps

    CURBS AND STEPS WARNING: Never attempt to negotiate curbs or steps in your Transport Chair without the assistance of an attendant. WARNING: Never attempt to negotiate stairs or escalators in your Transport Chair under any circumstances. Curbs, steps and stairways are dangerous obstacles that may confront the Transport Chair user.
  • Page 11 For attendant: curb descent 1. Ensure the hand grips are securely fastened and do not turn or slip. 2. Stand behind the Transport Chair, holding the hand grips, with your back to the curb. 3. Look over your shoulder and step down carefully. 4.

  • Page 12: Adjustments

    4 ADJUSTMENTS The EJ87X-1 Transport Chair offers several adjustments to make it easier and more comfortable to operate. Section 7, MAINTENANCE, offers preventive maintenance suggestions for keeping your Transport Chair in excellent condition; ensure that all components are in excellent condition before adjusting.

  • Page 13: Footrest-Detachable, Swingaway

    FOOTREST—DETACHABLE, SWINGAWAY WARNING: Do not stand on the footplates; this could cause the Transport Chair to tip. Remove footrest for transfer (see picture at right) hinge plate 1. Pull swingaway release lever toward front of Transport Chair and swing footrest outward. 2.

  • Page 14: Transporting The Ej87X-1 Transport Chair

    5 TRANSPORTING THE EJ87X-1 TRANSPORT CHAIR PREPARING THE EJ87X-1 FOR TRANSPORT WARNING: This Transport Chair does not offer seating or occupant restraint equivalent to the seat provided in a motor vehicle! To increase your safety while traveling in a motor vehicle, always transfer to the vehicle seat and use the restraint provided by the vehicle manufacturer.
  • Page 15 Store Transport Chair in car's back seat 1. Move the car's front seat as far forward as possible. 2. Holding the folded Transport Chair by the carrying straps, lift it into the car and place it on the back seat floorboard. Stow the footrests alongside. DO NOT put any articles on top of the Transport Chair.

  • Page 16: Maintenance

    6 MAINTENANCE Protect your E&J EJ87X-1 Transport Chair by having it serviced regularly. Proper care and maintenance are essential to keep your Transport Chair in safe working condition. Periodic inspection, adjustment, and replacement of worn parts will provide many years of superb performance.
  • Page 17 List of tools The tools and cleaning supplies listed will assist in the procedures outlined in this section. 30 weight oil (available at most auto parts stores) Phillips screwdriver soft cloth mild soap and water solution General care Always evaluate the overall operation of your Transport Chair. It should function with ease and should travel straight without excessive drag or pull to one side.
  • Page 18 Check rear wheel adjustment Inspect the wheels at least once a month. Check alignment by elevating the rear of the Transport Chair on a stable object until the rear wheels clear the ground, or placing the Transport Chair upside down in a stable position such that the wheels can spin freely. Spin the wheels;...

  • Page 19: Troubleshooting

    7 TROUBLESHOOTING Continual use of your Transport Chair necessitates maintenance, especially if the factory-set adjustments have been altered. The following troubleshooting guide lists several common problems that may occur, and offers corrective actions for each. If you are unsure of the solution or unable to diagnose the problem, do not hesitate to ask your GF authorized distributor for assistance.

  • Page 20: Specifications

    8 SPECIFICATIONS The Everest & Jennings EJ87X-1 Transport Chair has the following parameters: Seat width 19" (48.3 cm) Seat depth 16" (40.6 cm) Seat to floor height 18" (45.7 cm) Back height 18" (45.7 cm) Overall length (81.3 cm) not including footrests "...

  • Page 21: Limited Warranty

    9 LIMITED WARRANTY SCOPE OF WARRANTY GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and maintenance.
  • Page 22 ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. GF MAKES NO IMPLIED WARRANTIES OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IF ANY MODEL OR SAMPLE WAS SHOWN TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO ILLUSTRATE THE GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT THE PRODUCT WOULD NECESSARILY CONFORM TO THE MODEL...

  • Page 23: Index

    10 INDEX Adjustments 12 Tires, check 17 Arms, check 18 Tools, for maintenance, list 17 Attendant wheel locks, adjust 7 Transfer activities 8 Transporting the EJ87X-1 Transport Chair 14 Troubleshooting 19 Backposts, check 18 Balance 8 Upholstery, check 17 Casters, adjust 12 Caster stems, check 18 Warnings 4 CAUTION statement, significance 3...
  • Page 24 1.770.368.4700 Information contained herein is subject to change. The most current and complete product information can be found on our website. www.grahamfield.com © 2017, GF Health Products, Inc. All Rights Reserved. E&J, Everest & Jennings, and Graham-Field are trademarks of GF Health Products, Inc. GF Health Products, Inc.
