450 Standard / 450 Recliner
525 Standard / 525 Recliner
Bariatric Manual Wheelchair
User Manual
GD-450-525-INS-LAB-RevA21
Read this manual before operating your wheelchair.
Save this manual for future use.
The most current version of this manual can be found online at www.grahamfield.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GENDRON 450 Standard and is the answer not in the manual?

Questions and answers

Related Manuals for Graham Field GENDRON 450 Standard

Summary of Contents for Graham Field GENDRON 450 Standard

  • Page 1 450 Standard / 450 Recliner 525 Standard / 525 Recliner Bariatric Manual Wheelchair User Manual GD-450-525-INS-LAB-RevA21 Read this manual before operating your wheelchair. Save this manual for future use. The most current version of this manual can be found online at www.grahamfield.com.

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION......................................3 IMPORTANT SAFETY PRECAUTIONS ..............................4 WARNINGS ........................................4 GETTING STARTED — SETUP AND GENERAL OPERATION GUIDELINES..................6 REGENCY 450 / 525 COMPONENT IDENTIFICATION ..........................6 OPERATING THE WHEEL LOCKS ................................. 7 UNFOLDING AND FOLDING THE WHEELCHAIR ............................7 UNFOLDING THE WHEELCHAIR ................................7 OPENING THE WHEELCHAIR (ALL MODELS) ..........................

  • Page 3: Introduction

    1 INTRODUCTION Important safety, operating, and maintenance instructions that warrant your attention are included in this user manual. Read this entire manual carefully before operating your new wheelchair, keep it handy for future reference, and refer to it as often as necessary to help maintain good performance standards.

  • Page 4: Important Safety Precautions

    2 IMPORTANT SAFETY PRECAUTIONS IMPORTANT SAFETY PRECAUTIONS: ALWAYS FOLLOW THESE SAFETY PRECAUTIONS WHEN USING YOUR WHEELCHAIR. FAILURE TO DO SO COULD RESULT IN PERSONAL INJURY TO YOU OR OTHERS OR DAMAGE TO YOUR WHEELCHAIR. Safety requires the constant attention of the wheelchair user and the attendant. It is extremely important to learn and always use safe methods of performing basic daily activities.
  • Page 5 WARNING: When folding or unfolding the wheelchair, do not place your fingers or hands under the seat rail or between the seat rail and side panel. WARNING: Do not lift the wheelchair by the arms, footrests or legrests, or any other detachable parts.

  • Page 6: Getting Started - Setup And General Operation Guidelines

    3 GETTING STARTED — SETUP AND GENERAL OPERATION GUIDELINES REGENCY 450 / 525 COMPONENT IDENTIFICATION Familiarize yourself with main components, identified in Regency 450 / 525 illustrations below. backpost / push handle handgrip back upholstery armpad rear wheel seat upholstery footrest handrim footplate...

  • Page 7: Operating The Wheel Locks

    OPERATING THE WHEEL LOCKS The Regency 450 / 525 has two wheel locks — one on each rear wheel. To engage the wheel locks, push the levers forward until they lock into place. To disengage, pull back on the levers until the wheels roll freely.

  • Page 8: Installing The Headrest And Pushbar (Reclining Models Only)

    Installing the Headrest and Pushbar (Reclining Models Only) After the wheelchair has been fully unfolded and opened: 1. Install headrest as shown at above left: slide headrest down onto headrest support assembly as shown. WARNING: Ensure headrest is fully seated and securely installed before use. 2 Install headrest cover, shown at above right.

  • Page 9: Folding The Wheelchair For Transportation Or Storage

    FOLDING THE WHEELCHAIR FOR TRANSPORTATION OR STORAGE Removing the Headrest and Pushbar (Reclining Models Only) 1. Press both pushbar spring buttons and pull pushbar out away from receivers. 2 Remove headrest cover, shown at above left. 3. Remove headrest as shown at above right: slide headrest up and off headrest support assembly as shown.

  • Page 10: Handling Tips

    4 HANDLING TIPS The Gendron Regency 450 / 525 has been designed and engineered to perform as a stable and well balanced unit when used for its intended purpose. However, it is possible to tip the Regency 450 / 525 over if it is used improperly or if you move beyond the center of gravity. You may want to consider the use of a positioning belt, available from your distributor or www.grahamfield.com, to maintain proper weight distribution.

  • Page 11: Reaching / Bending

    REACHING / BENDING WARNING: Always turn the casters frontward to provide stability while reaching. If in doubt, ask for assistance or use a device that will extend your reach without requiring you to shift your weight. Although it is not recommended, you may find it occasionally necessary to lean or reach from your wheelchair.

  • Page 12: Ramps And Inclines

    RAMPS AND INCLINES WARNING: During descent, the footplates' lowest point should be no closer to the ground than 2 1/2 inches to permit proper clearance. WARNING: Do not attempt any incline or decline of more than 6 degrees (10% grade, or one foot of rise or fall per ten feet of ramp length).

  • Page 13: Curbs - With Attendant

    CURBS — WITH ATTENDANT Going up (Method 1) Going Up (Method 2) (Going Down) WARNING: When approaching a curb, ensure the hand grips are securely fastened and do not turn or slip off. Curbs should only be negotiated with the assistance of an attendant. The following are suggestions only for curb negotiation.

  • Page 14: Adjustments

    5 ADJUSTMENTS The Regency 450 / 525 offers several adjustments to make it easier and more comfortable to drive. The MAINTENANCE section offers preventive maintenance suggestions for keeping your wheelchair in excellent condition; ensure that all components are in excellent condition before adjusting.

  • Page 15: Swingaway Footrest / Elevating Legrest

    SWINGAWAY FOOTREST / ELEVATING LEGREST Swingaway Footrest Elevating Legrest WARNING: Avoid potential pinch points while swinging the Footrest or Elevating Legrest in or out. WARNING: The footplates' lowest point should be no closer to the ground than 2 inches, to permit proper clearance. WARNING: Do not stand on the footplates;...

  • Page 16: Elevating Legrest: Raise Legrest

    ELEVATING LEGREST: RAISE LEGREST Elevating Legrest WARNING: Avoid potential pinch points while adjusting Elevating Legrest angle. To raise the Elevating Legrest (adjust the legrest rotation angle): 1. Grasp the legrest near the footplate while holding the Legrest Height release lever (shown above).

  • Page 17: Recliner (525 Reclining Model Only)

    RECLINER (525 RECLINING MODEL ONLY) ADJUSTING THE BACK ANGLE (525 RECLINING MODEL ONLY) 1. See picture above: to adjust the back angle, grasp both ends of push bar securely and simultaneously pull up on both release levers (use your hands to squeeze the end of push handles and release levers together).

  • Page 18: Transporting The Gendron Regency 450 / 525

    6 TRANSPORTING THE GENDRON REGENCY 450 / 525 WARNING: This wheelchair does not offer seating or occupant restraint equivalent to the seat provided in a motor vehicle! To increase your safety while traveling in a motor vehicle, always transfer to the vehicle seat and use the restraint provided by the vehicle manufacturer.

  • Page 19: Maintenance

    7 MAINTENANCE Protect your Gendron Regency 450 / 525 by having it serviced regularly. Proper care and maintenance are essential to keep your wheelchair in safe working condition. Periodic inspection, adjustment, and replacement of worn parts will provide many years of superb performance.

  • Page 20: List Of Tools

    LIST OF TOOLS The tools and cleaning supplies listed will assist in the following procedures. 30 weight oil (available at most auto parts stores) Phillips screwdriver soft cloth mild soap and water solution GENERAL CARE Always evaluate the overall operation of your wheelchair. It should function with ease and should travel straight without excessive drag or pull to one side.

  • Page 21: Check Upholstery

    CHECK UPHOLSTERY Check upholstery at least once a month. Inspect for rips, tears and worn spots. Ensure that all upholstery-attaching screws are present, properly aligned, and well-secured. Use a Phillips screwdriver to tighten upholstery mounting screws. Check attaching screws for sharp edges or stripped screws, and replace if found.

  • Page 22: Check Casters

    CHECK CASTERS Check the caster stems for proper rotation at least every three months. The caster forks must swivel freely to facilitate steering and handling. Adjusting the stem nut varies the amount of force required to turn the caster. If the nut is too loose, the caster will flutter or shimmy; if too tight, the wheelchair will be difficult to steer.

  • Page 23: Troubleshooting

    8 TROUBLESHOOTING Continual use of your Regency 450 / 525 necessitates maintenance, especially if the factory- set adjustments have been altered. The following troubleshooting guide lists several common problems that may occur, and offers corrective actions for each. If you are unsure of the solution or unable to diagnose the problem, do not hesitate to ask your Graham-Field authorized distributor for assistance.

  • Page 24: Specifications

    9 SPECIFICATIONS Specification Model 450 Standard 450 Recliner 525 Standard 525 Recliner Overall Depth 43.5" (110.5 cm) 52.5" (133.4 cm) 43.5" (110.5 cm) 52.5" (133.4 cm) Overall Height 37" (94.0 cm) 52.5" (133.4 cm) 37" (94.0 cm) 52.5" (133.4 cm) Overall Width 33", 35", 37", or 39"...

  • Page 25: Limited Warranty

    10 LIMITED WARRANTY SCOPE OF WARRANTY GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and maintenance.
  • Page 26 ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. GF MAKES NO IMPLIED WARRANTIES OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IF ANY MODEL OR SAMPLE WAS SHOWN TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO ILLUSTRATE THE GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT THE PRODUCT WOULD NECESSARILY CONFORM TO THE MODEL OR...

  • Page 27: Index

    11 INDEX Adjustments 14 Ramps and Inclines 12 Anti-tippers, check 20 Reaching / bending 11 Arm, install 14 Rear wheel adjustment, check 21 Arm, remove 14 Rear wheels 14 Arms 14 Regency 450, illustration 6 Arms, check 21 Removing the headrest and pushbar (reclining models only) 9 Backposts, check 21 Safety precautions 4...
  • Page 28 1.770.368.4700 Information contained herein is subject to change. The most current and complete product information can be found on our website. www.grahamfield.com / www.gendroninc.com © 2021, GF Health Products, Inc. All Rights Reserved. Gendron is a trademark of GF Health Products, Inc. GF Health Products, Inc.
