USER'S MANUAL
AIR-CONDITIONER
SRR25ZS-W
SRR35ZS-W
SRR50ZS-W
SRR60ZS-W
MANUEL DE L'UTILISATEUR
ANWENDERHANDBUCH
ISTRUZIONI PER L'USO
MANUAL DEL PROPIETARIO
GEBRUIKERSHANDLEIDING
MANUAL DO UTILIZADOR
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
ORIGINAL INSTRUCTIONS
USER'S MANUAL
AIR-CONDITIONER
CLIMATISEUR
KLIMAGERA ¨ T
CONDIZIONATORE D'ARIA
ACONDICIONADOR DE AIRE
AIRCONDITIONING
APARELHO DE AR CONDICIONADO
ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ
ΚΛΙΜΑΤΙΣΤΙΚΟ
КОНДИЦИОНЕР ВОЗДУХА
KULLANIM KILAVUZU
ENGLISH
FRANÇAIS
DEUTSCH
ITALIANO
ESPAN ˜ OL
NEDERLANDS
PORTUGUÊS
ΕΛΛΗΝΙΚΑ
РУССКИЙ
TÜRKÇE
RJJ012A005B
201908

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRR25ZS-W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi Heavy Industries SRR25ZS-W

Summary of Contents for Mitsubishi Heavy Industries SRR25ZS-W

  • Page 1 AIR-CONDITIONER USER’S MANUAL ENGLISH AIR-CONDITIONER MANUEL DE L’UTILISATEUR FRANÇAIS CLIMATISEUR ANWENDERHANDBUCH DEUTSCH KLIMAGERA ¨ T ISTRUZIONI PER L’USO ITALIANO SRR25ZS-W SRR35ZS-W CONDIZIONATORE D’ARIA SRR50ZS-W MANUAL DEL PROPIETARIO ESPAN ˜ OL SRR60ZS-W ACONDICIONADOR DE AIRE GEBRUIKERSHANDLEIDING NEDERLANDS AIRCONDITIONING MANUAL DO UTILIZADOR PORTUGUÊS...

  • Page 3: Table Of Contents

    Thank you for purchasing a MITSUBISHI HEAVY INDUSTRIES THERMAL SYSTEMS, LTD. Air-Conditioner. To get the best long-lasting performance, please read and follow this User’s Manual carefully before using your air-conditioner. After reading, please store the Manual in a safe place and refer to it for operational questions or in the event of any irregularities.

  • Page 4: Safety Precautions

    Safety precautions • Before starting to use the system, please read these “Safety precautions” carefully to ensure proper operation of the system. • When you have read this user’s manual, please keep it safely. If someone else takes over as user, make sure that the manual is also passed on to the new user.
  • Page 5 ❚ Safety precautions ❚ INSTALLATION PRECAUTIONS  WARNING • The system is for domestic and residential use. If used in severe environments, such as an engineering workplace, the equipment may function poorly. • The system must be installed by your dealer or a qualified installer. It is not advisable to install the system by yourself, as faulty handling may cause leakage of water, electric shock or fire.
  • Page 6 ❚ Safety precautions ❚ OPERATION PRECAUTIONS  WARNING • Children shall not play with the • Cleaning and user maintenance shall air-conditioner. not be made by children without • Do not expose yourself to the cooling supervision. • Do not insert anything into the air air for a long period.
  • Page 7 ❚ Safety precautions  CAUTION • Do not touch the aluminum fins on the • Do not shut off the power source heat exchanger. immediately after stopping the operation. It may result in injury. • Do not place household electrical Wait at least 5 minutes, otherwise there appliances or household items under- is a risk of water leakage or breakdown.
  • Page 8 ❚ Safety precautions ❚ PRECAUTIONS FOR RELOCATION OR REPAIRS  WARNING • Do not perform any repairs or modifications by yourself. Consult the dealer if the unit requires repair. If you repair or modify the unit, it can cause water leaks, electric shocks or fire. •...

  • Page 9: Name Of Each Part And Its Function

    Name of each part and its function INDOOR UNIT Air inlet Air outlet Air blows out of here. Air fi lter Removes dust or dirt from the inlet air. Page 25 Refrigerant piping connection and electric wire Unit display section (Remote control signal receiver) Drain hose Drains water from the indoor unit.
  • Page 10 Name of each part and its function Unit display section RUN (HOT KEEP) light (green) • Illuminates during operation. Remote control signal receiver • Blinks when airfl ow stops due to the ‘HOT KEEP’ and ‘CLEAN operation’. 1.5 sec. Unit ON/OFF button HOT KEEP This button can be used for turning on/ off the unit when a remote control is not...

  • Page 11: Remote Control Handling

    Remote control handling Replacing the batteries The following cases show exhausted batteries. Replace old batteries with new ones. • Receiving beep is not emitted when a signal is transmitted. • Display fades away. NOTE Pull out the cover and take out old batteries.

  • Page 12: Installing Two Air-Conditioners In The Same Room

    Installing two air-conditioners in the same room ■ When two air-conditioners are installed in the same room, use this setting when the two air-conditioners are not operated with one remote control. Set the remote control and indoor unit. Setting the remote control Setting an indoor unit Pull out the cover and take out bat- Turn off the power source, and turn it on after 1 minute.

  • Page 13: Operation And Display Section For Remote Control

    Operation and display section for remote control Transmission section OPERATION MODE select button Each time the button is pressed, the mode changes. ON/OFF (luminous) button Page 12,14 Press to start operation, press again to stop. TEMPERATURE button FAN SPEED button This button sets the room temperature.

  • Page 14: Current Time Setting

    Current time setting ■ When inserting the batteries, the current time is automatically set to time setting mode. Mon and 13:00 are displayed as the current time. Set a correct day of the week and a time. Example: Set to Sat 10:30. Press the TIME SET UP switch.

  • Page 15: Temperature Adjustment During Auto

    Temperature adjustment during AUTO ■ Air temperature adjustment is possible even during automatic operation. There are 6 levels of adjustment possible with the button or button.During automatic operation, 24°C is preset both for heating and cooling. Press the“ or (TEMP)” button. When it is a little cold Press the button.

  • Page 16: Cool/Heat/Dry/Fan Mode Operation

    COOL/HEAT/DRY/FAN mode operation Press the MODE button. Set to a required mode. (Cool), (Heat), (Dry), (Fan) Press the ON/OFF button. Press the TEMP button. Press button for the preferred temperature. Recommendation Press the FAN SPEED button Set the fan speed as preferred. A fan speed cannot be set under Dry operation.

  • Page 17: Sleep Timer Operation

    SLEEP TIMER operation ■ The unit will stop automatically after the set time lapses. The set temperature is automatically adjusted according to the lapse time in order to avoid too much cooling or heating. Page 17 Press the SLEEP button. ■...

  • Page 18: On-Timer Operation

    ON-TIMER operation ■ Operation starts 5 to 60 minutes before the set time so that the room temperature reaches the optimum temperature at the set time. Page 17 ON-TIMER operation can be set regardless of whether the air-conditioner is running or not. Example: When the preferred room temperature is required at 8:00.

  • Page 19: On-Timer + Off-Timer Operation

    ON-TIMER + OFF-TIMER operation ■ The timer operations of the combination of ON and OFF-TIMER. Example: Present time is 21:00. The air-conditioner running. When it is prefered to stop at 22:30, and then start operation at 8:00, near the set temperature.

  • Page 20: Weekly Timer Operation

    WEEKLY TIMER operation ■ Up to 4 programs with timer operation (ON-TIMER / OFF-TIMER) are available for each day of the week. Max 28 programs per week are available. Once this has been set, the timer operation will be repeated at the same programs every week unless the WEEKLY TIMER is canceled.
  • Page 21 Setting mode <Individual setting> Set after setting the current day of the week and the time. Press the PROGRAM button. and current day of the week blink. Press the “ or (TIMER)” button. Select a day of the week to be reserved. Every time the button is pressed, the display is switched in the order of:...
  • Page 22 Press the “ or (TIMER)” button. Set a time. Every time the button is pressed, the display is switched in the order of: 0:00 0:10 0:20 1:00 1:10 (Units of ten minutes) Every time the button is pressed, the display is switched in the order of: 0:00 23:50 23:40 23:00 22:50...
  • Page 23 How to cancel the setting <Individual setting> Press the PROGRAM button. and current day of the week blink. Press the “ or (TIMER)” button. Select a day of the week to be canceled. Press the SET button. The day of the week is determined and the program number blinks. Press the “...

  • Page 24: High Power/Economy Operation

    HIGH POWER/ECONOMY operation Press the ON/OFF button. Press the HI/ECO button. • When the operating mode is AUTO, COOL or HEAT Every time the HI/ECO button is pressed, the display is switched in the order of: No display (HIGH POWER) (ECONOMY) (Normal operation) •...

  • Page 25: Night Setback Operation

    NIGHT SETBACK operation ■ During the cold season, the room temperature can be maintained at a comfortable level during the absence, at night, and while the room is unattended. The air-conditioner maintains the constant temperature at about 10°C. Press the NIGHT SETBACK button. Every time the NIGHT SETBACK button is pressed, the display is switched in the order of: No display...

  • Page 26: Self Clean Operation

    SELF CLEAN operation ■ CLEAN operation should be run after AUTO, COOL and DRY operation to remove the moisture from inside the indoor unit and control the growth of mold and bacteria. In order to active CLEAN operation, press the CLEAN switch with the tip of a ballpoint pen.

  • Page 27: Maintenance

    Maintenance Before maintenance Do not spill any liquid. Turn off the power source. Do not use the following articles: • Hot water (40°C or more) • There's a danger of It may deform or discolour the unit. electric shock. • Petrol, paint thinner, benzine or •...

  • Page 28: Proper Installation

    Proper installation Suitable installation position • Do not put any obstruction in front of the indoor unit, preventing proper ventilation and functioning. • Do not install the unit in any of the following places: • Where there is a danger of leaking fl ammable gases. •...

  • Page 29: Notice

    Notice Air fl ow Airfl ow is not blown out when starting the HEATING Airfl ow has stopped to prevent blowing out of cold air until the operation. indoor heat exchanger has warmed up. (2 to 5 min.) (HOT KEEP program) RUN light blinks slowly (1.5 sec ON, 0.5 sec OFF) Airfl...

  • Page 30: Contact Your Dealer

    Contact your dealer ■ Turn off the power switch immediately and inform your dealer in any of the following situations: The fuse or switch blows continu- The cable becomes extremely hot. ously. The covering of the cable is cracked. CAUTION Fuse often blows.

  • Page 31: Self Diagnosis Function

    Self diagnosis function ■ We are constantly trying to do better service to our customers by installing such judges that show abnormality of each function as follows: RUN light Description of trouble Cause • Broken heat exchanger sensor 1 wire, poor connector Heat exchanger sensor 1 error 1-time flash connection...
  • Page 32 5 The Square, Stockley Park, Uxbridge, Middlesex, UB11 1ET, United Kingdom Tel : +44-333-207-4072 Fax: +44-333-207-4089 http://www.mhiae.com/ MITSUBISHI HEAVY INDUSTRIES AIR-CONDITIONERS AUSTRALIA, PTY. LTD. Block E, 391 Park Road, Regents Park, NSW, 2143 PO Box 3167, Regents Park, NSW, 2143 Tel : +61-2-8774-7500 Fax: +61-2-8774-7501...
