TECHNICAL MANUAL
INVERTER RESIDENTIAL
AIR-CONDITIONERS
Wi-Fi option model (SRK only)
(Split system, air to air heat pump type)
Wall mounted type
SRK20ZS-W, -WB, -WT/SRC20ZS-WA
SRK25ZS-W, -WB, -WT/SRC25ZS-WA2
SRK35ZS-W, -WB, -WT/SRC35ZS-WA2
Floor standing type
SRF25ZS-W/SRC25ZS-WA2
SRF35ZS-W/SRC35ZS-WA2
Ceiling concealed type
SRR25ZS-W/SRC25ZS-WA2
SRR35ZS-W/SRC35ZS-WA2
4-way ceiling cassette type
FDTC25VH1/SRC25ZS-WA2
FDTC35VH1/SRC35ZS-WA2
Manual No.'21•SRK-T-299
updated December 23, 2021
Note:
•
(1) SRK series in this technical manual will have the
service code "/A".
• SRK20ZS-W, -WB, -WT SRK20ZS-W/A, -WB/A, -WT/A
• SRK25ZS-W, -WB, -WT SRK25ZS-W/A, -WB/A, -WT/A
• SRK35ZS-W, -WB, -WT SRK35ZS-W/A, -WB/A, -WT/A
(2) SRC25/35ZS-WA2 and SRC25/35ZS-WA
have the same specifications, so SRK25/35ZS-W
can also be connected to SRC25/35ZS-WA.
However, SRF/SRR/FDTC cannot be connected
to SRC25/35ZS-WA.
#
