2000 AIR CONDITIONING & HEAT PUMP
MACHINERY HANDBOOK

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Heavy Industries SRK25GZ-L1

Summary of Contents for Mitsubishi Heavy Industries SRK25GZ-L1

  • Page 1 2000 AIR CONDITIONING & HEAT PUMP MACHINERY HANDBOOK...

  • Page 2: Table Of Contents

    TABLE CONTENTS WALL MOUNTED TYPE ROOM AIR-CONDITIONER (INVERTER TYPE) (Split system, Air to air heat pump type) [SRK-GZ] WALL MOUNTED TYPE ROOM AIR-CONDITIONER (Split system, Air to air heat pump type) [SRK-H] WALL MOUNTED TYPE ROOM AIR-CONDITIONER (Split system, Air cooled cooling only type) [SRK-C] SCM-HG INVERTER MULTI-SPLIT SYSTEM ROOM AIR-CONDITIONER...

  • Page 3: Wall Mounted Type Room Air-Conditioner

    SRK-GZ SRK-GZ 1. WALL MOUNTED TYPE ROOM AIR-CONDITIONER Split system, Air to air heat pump type SRK25GZ-L1, SRK35GZ-L1, SRK502Z-L...
  • Page 4 SRK-GZ CONTENTS GENERAL INFORMATION................ 3 1.1.1 Specific features ................. 3 1.1.2 How to read the model name ............. 3 SELECTION DATA ..................4 1.2.1 Specifications ..................4 1.2.2 Range of usage & limitations ............7 1.2.3 Exterior dimensions ................8 1.2.4 Piping system ..................

  • Page 5: General Information

    1.1.1 Specific features The “Mitsubishi Daiya” room air-conditioner: SRK series are of split and wall mounted type and the unit consists of indoor unit and outdoor unit with refrigerant precharged in factory. The indoor unit is composed of room air cooling or heating equipment with opera- tion control switch and the outdoor unit is composed of condensing unit with compressor.

  • Page 6: Selection Data

    SRK-GZ SELECTION DATA 1.2.1 Specifications Model SRK25GZ-L1 (Indoor unit) SRC25GZ-L1 (Outdoor unit) Model SRK25GZ-L1 SRC25GZ-L1 Item Cooling capacity 2500 [900~2900] Heating capacity 3400 [900~4000] Power source 1 Phase, 220/240V, 50Hz Cooling input 0.96 [0.31~1.22] Running current (Cooling) Heating input 1.17 [0.28~1.35]...
  • Page 7 SRK-GZ Model SRK35GZ-L1 (Indoor unit) SRC35GZ-L1 (Outdoor unit) Model SRK35GZ-L1 SRC35GZ-L1 Item Cooling capacity 3650 [900~3900] Heating capacity 4800 [900~6100] Power source 1 Phase, 220/240V, 50Hz Cooling input 1.24 [0.35~1.60] Running current (Cooling) Heating input 1.52 [0.35~2.10] Running current (Heating) Inrush current COP (Cooling) 2.94...
  • Page 8 SRK-GZ Model SRK502Z-L (Indoor unit) SRC502Z-L (Outdoor unit) Model SRK502Z-L SRC502Z-L Item Cooling capacity 5000 [900~5600] Heating capacity 6700 [900~7900] Power source 1 Phase, 220/240V, 50Hz Cooling input 2.22 [0.17~2.65] Running current (Cooling) 10.2 Heating input 2.50 [0.145~2.55] Running current (Heating) 11.5 Inrush current 11.5...

  • Page 9: Range Of Usage & Limitations

    (2) Total one way piping length and vertical height difference. Model SRK25GZ-L1 SRK502Z-L Item SRK35GZ-L1 Total one way piping length (m) Outdoor unit is higher...

  • Page 10: Exterior Dimensions

    SRK-GZ 1.2.3 Exterior dimensions (1) Indoor unit Unit: mm Model SRK25GZ-L1 Room temp. thermistor Piping hole right (left) Terminal block Remote controller 746.9 Piping for Gas ( 9.52) 370 Ø Piping for Liquid ( 6.35) 420 Ø Piping hole Piping hole Ø...
  • Page 11 SRK-GZ Unit: mm Model SRK502Z-L Remote controller (2) Outdoor unit Model SRC25GZ-L1 Unit: mm 192.5 Drain holes 372.5 82.5 82.5 Terminal Ø block 61.5 33.3 127.7 Service valve (Liquid) Flare connecting 6.35 (1/4˝) Ø 40˚ 40˚ Service valve (Gas) Flare connecting 9.52 (3/8˝) Ø...
  • Page 12 SRK-GZ Model SRC35GZ-L1 Unit : mm Drain holes MAX.80 Terminal block 45° 16 12 (Oval holes) 45° for unit fixing 2 places Drain holes Service Service Valve 142.5 142.5 Valve (Gas) (Liquid) Flare connecting Flare connecting Ø6.35 (1/4¨) Ø12.7 (1/2¨) Model SRC502Z-L Unit: mm...

  • Page 13: Piping System

    SRK-GZ 1.2.4 Piping system Model SRK25GZ-L1 Indoor unit Outdoor unit Cooling cycle Heating cycle Outdoor air Flare connecting Service valve temp. thermistor (Gas) Piping Check joint (Gas) ø9.52 4 way valve Accumulator Discharge temp. Room temp. Heat thermistor Heat thermistor...

  • Page 14: Electrical Data

    SRK-GZ Model SRK502Z-L ELECTRICAL DATA 1.3.1 Electrical wiring Meaning of marks Symbol Parts name Symbol Parts name Symbol Parts name Capacitor for FMI Reactor Transformer Compressor motor Flap motor Varistor Fuse Room temp. thermistor 4 way valve (coil) Fan motor (Indoor) Heat exchanger thermistor (Indoor unit) Magnetic contactor Fan motor (Outdoor)
  • Page 15 SRK-GZ Model SRK25GZ-L1...
  • Page 16 SRK-GZ Model SRK35GZ-L1...
  • Page 17 SRK-GZ Model SRK502Z-L...
  • Page 18 ¡ Above figure shows all indications for the purpose of explanation, but practically only the pertinent parts are indicated. Indoor unit indicator Model SRK25GZ-L1 RUN (HOT KEEP) lamp (green) ¡ Illuminates during operation. ¡ Flashes at stop blowing due to the hot keep.
  • Page 19 Illuminates during HI POWER operation. Illuminates during ECONOMY operation. (2) Back-up switch Model SRK25GZ-L1 When the remote controller become weak, or if the remote controller is lost or mal- functioning, this switch may be used to turn the unit on and off.
  • Page 20 Control the flap by AIRFLOW button on the wireless remote control. (a) Natural flow (AUTO) The flap will be automatically set to the angle of air flow best to operation. Starting time of operation Models SRK25GZ-L1, 35GZ-L1 In case of heating operation In case of cooling...
  • Page 21 5 min. Setting time earlier earlier earlier (5) Outline of heating operation (a) Air flow selection Frequency of inverter changes within the range of selected air flow. Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L Air flow selection Auto Frequency 34~110Hz 34~110Hz 14~150rps Air flow Depends on frequency.
  • Page 22 SRK-GZ (iii) Continuous mode operation (Temperature setting button on remote controller: Continuous) Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L Item AUTO AUTO AUTO Inverter frequency 104Hz 98Hz 50Hz 98Hz 94Hz 58Hz 144rps 110rps 50rps Indoor fan 6th speed 5th speed 4th speed 7th speed...
  • Page 23 SRK-GZ (v) Defrosting operation S Models SRK25GZ-L1, 35GZ-L1 1) Starting conditions (Defrosting operation can be started only when all of the following conditions are met.) ¡ Model SRK25GZ-L1 After start of heating operation → When it elapsed 40 minutes. (Accumulated operation time) After end of defrosting operation →...
  • Page 24 Operation is maintained for 15 minutes with a higher blow out air temperature. ¡ Detail of operation Notes (1) When the hot keep fan speed and the fan speed Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L corresponding to the frequency command are Item not matched, the fan is operated with the fan speed whichever lower.
  • Page 25 SRK-GZ (6) Outline of cooling operation (a) Air capacity selection Frequency of inverter changes within the range of selected air flow. Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L Air flow selection AUTO Frequency 34~92Hz 34~102Hz 18~118rps Air flow Depends on frequency. Frequency 34~92Hz...
  • Page 26 SRK-GZ (b) Outline of control Cooling oriented dehumidifying S SRK25, 35GZ-L1 Room temperature is checked at 3-minute intervals after selecting the cooling or heating oriented dehumidifying in order to determine the operation range. Operation range –1 Hight Room temperature – Setting temperature (deg) Operating pattern D range C range...
  • Page 27 3 min. 3 min. 3 min. Determination of heating oriented dehumidifying operation range Temperature check (iii) Continuous dehumidifying operation (Temperature setting button on remote controller: Continuous) Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L Item Inverter frequency 36Hz 44Hz 40rps Indoor fan 2nd speed...
  • Page 28 SRK-GZ (9) Economical operation (ECONO button on remote controller: ON) Pressing the economy button initiates a soft operation with the power suppressed in order to avoid an excessive cooling or heating. The unit operates 1.5ºC higher than the setting temperature for the LO air flow during cooling or 2.5ºC lower than that during heating.
  • Page 29 (i) Operating conditions: When the unit is operating with the outdoor unit frequency other than 0 Hz(rps) or when the outdoor temperature sensor temperature rose beyond 41ºC for 2 minutes continuously. (ii) Detail of operation S SRK25GZ-L1 Indoor fan speed is raised forcibly by 1 step. However, the maximum speed is the 3rd speed. 10A current safe operation Taking the lower limit of control frequency at 34 Hz, if the output frequency obtained with the fuzzy calculation reaches this value, the operation changes to the thermostat operation.
  • Page 30 0 Hz. [When 0 Hz is commanded from the indoor unit controller, when an outdoor protective function is actuated] (ii) Detail of operation S SRK25GZ-L1, 35GZ-L1 When stopped by indoor unit controller When stopped or reset by outdoor unit protective function...
  • Page 31 SRK-GZ S SRK502Z-L When stopped by indoor unit controller When stopped or reset by outdoor unit protective function Function Operation Heating, heating Cooling, cooling Heating, heating Cooling, cooling oriented dehumidifying oriented dehumidifying oriented dehumidifying oriented dehumidifying 2 min. 2 min. 3 min.

  • Page 32: Safety Precautions

    SRK-GZ APPLICATION DATA SAFETY PRECAUTIONS ¡ Please read these “Safety Precautions” first then accurately execute the installation work. ¡ Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.
  • Page 33 (ii) Design the base higher than possible snow deposit. (3) Limitations for one way piping length and vertical height difference. Model SRK25GZ-L1 SRK502Z-L Item SRK35GZ-L1 One way piping length (R) 15 m 25 m...
  • Page 34 SRK-GZ 1.5.2 Installation of indoor unit (1) Installation of installation board (a) Fixing of installation board Lock for the inside wall structures (Intermediate support or pillar) and fairly install the unit after level surface has been Adjustment of the installation checked.
  • Page 35 SRK-GZ (3) Preparation of indoor unit (a) Mounting of connecting wires S SRK25, 35GZ-L1 Remove lid Earth (ii) Remove cover, terminal block cover Wiring Terminal Connecting Wiring (iii) Insert connecting wire to terminal block securely. Terminal Block Wiring Clamp 1 Insert connecting wire up to the terminal block securely. If poor insertion of conductor may result in imperfect contact Terminal Block Cover between the conductor and the terminal causing heat genera-...
  • Page 36 SRK-GZ ¡ When arranging the pipe through a hole opened at the cen- ter, open the knockout hole using nippers, etc. Chute Wall Note (1) It is designed to collect moisture ac- cumulated on the rear face in the drain pan.
  • Page 37 SRK-GZ 1.5.4 Refrigerant piping (1) Preparation Keep the openings of the pipes covered with tapes etc. to prevent dust, sand, etc. from entering them. Indoor unit side Outdoor unit side Dimension A Liquid side (φ6.35): 9-9.5 dia Press Gas side (Do not (φ9.52): 13.2-14 dia...
  • Page 38 It is very important to be careful of above when plugging in the unit to an already furnished electrical outlet. (4) Explain to the customer on the correct usage of the air conditioner in simple layman’s terms. (5) Make sure that drain flows properly. (6) Standard operation data Model SRK25GZ-L1 SRK35GZ-L1 SRK502Z-L Item Cooling –...
  • Page 39 SRK-GZ 1.5.6 Precautions for wireless remote controller installation and operation (1) Wireless remote controller covers the following distances: (a) When operating facing the air conditioner: Notes (1) The remote controller is correctly facing the sensing element of the air conditioner when being manipulated.
  • Page 40 SRK-GZ MAINTENANCE DATA 1.6.1 Trouble shooting (1) Trouble shooting to be performed prior to exchanging PCB, (Printed circuit board) [Common to all models] All the models described in this chapter are controlled by a microcomputer. When providing maintenance service to customers it is necessary to understand the function controlled by a micro computer thoroughly, so as not to mistakenly identify correct opera- tions as mis-operations.
  • Page 41 SRK-GZ (2) Self diagnosis display on indoor unit...

  • Page 42: Thermistor Error

    SRK-GZ (3) Inspection procedures corresponding to detail of trouble [Broken thermistor wire, Thermistor error connector poor connection] Is connector connection good? Correct connection. Is thermistor resistance value good? Replace thermistor. Replace PCB. Discharge pipe (Comp. dome) thermistor temperature char- Thermistor temperature characteristics acteristics (Room temperature, indoor unit heat ex- changer temperature, outdoor unit heat...

  • Page 43: Outdoor Unit Error

    SRK-GZ [Broken power transistor Outdoor unit error broken compressor wire] Is output voltage applied to all 3 Defective inverter phases of power transistor? Is compressor wiring connected Connect securely. securely? Inspect compressor. [Overload operation, compressor Current safe stop lock, overcharge] Discharge refrigerant.
  • Page 44 SRK-GZ [Wiring error including power cable, defective indoor/ Serial signal transmission error outdoor unit PCB, error on power supply system] Does error persist after power Trouble by transient cause, not unit trouble. reset? Is there any wrong connection on Correct improper wire connection on indoor/ outdoor unit.
  • Page 45 SRK-GZ (4) Phenomenon observed after shortcircuit, wire breakage on thermistor. (a) Indoor unit Phenomenon Operation Sensor mode Shortcircuit Broken wire Cooling Release of continuous compressor operation command Continuous compressor operation command is not released. Room temperature thermistor Heating Continuous compressor operation command is not released. Release of continuous compressor operation command Continuous compressor operation command is not released.
  • Page 46 SRK-GZ (6) Inspection procedures of indoor electrical equipment Replace fuse. Is fuse (3.15A) blown? Notes (1) Since the communication timing signal is transmitted only when the 52C is turned ON, check it under the operating condition. (2) Check the voltage on the terminal block. ¡...
  • Page 47 SRK-GZ...
  • Page 48 SRK-GZ...
  • Page 49 SRK-GZ...
  • Page 50 SRK-GZ 1.6.2 Servicing (1) Evacuation The evacuation is an procedure to purge impurities..noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R22 is very insoluble in water, even a small amount of moisture left in the refrigerant equipment will freeze, causing what is called water clogging.
  • Page 51 (manufacturer: Matsushita, Manufac- ture type No.: MA165) to “Remote” part on the PCB in the direction as shown in the diagram below. This diagram shows SRK25GZ-L1 and although the other units have different layout on the PCB, their concepts are some.
  • Page 52 SRK-GZ MEMO...

  • Page 53: Srk-H

    SRK-H SRK-H 2. WALL MOUNTED TYPE ROOM AIR-CONDITIONER Split system, Air to air heat pump type SRK328HENF-L2, SRK408HENF-L2 SRK501HENF-L, SRK561HENF-L...
  • Page 54 SRK-H CONTENTS 2.1 GENERAL INFORMATION ................ 53 2.1.1 Specific features ................. 53 2.1.2 How to read the model name ............. 53 2.2 SELECTION DATA..................54 2.2.1 Specifications ..................54 2.2.2 Range of usage & limitations ............. 58 2.2.3 Exterior dimensions................59 2.2.4 Piping system ..................
  • Page 55 2.1.1 Specific features The “Mitsubishi Daiya” room air conditioner: SRK series are of split and wall mounted type and the unit consists of indoor unit and outdoor unit with refrigerant precharged in factory. The indoor unit is composed of room air cooling or heating equipment with opera- tion control switch and the outdoor unit is composed of condensing unit with compressor.
  • Page 56 SRK-H SELECTION DATA 2.2.1 Specifications Model SRK328HENF-L2 (Indoor unit) SRC328HENF-L2 (Outdoor unit) Model SRK328HENF–L2 SRC328HENF–L2 Item Cooling capacity 3000/3000 Heating capacity 3800/3800 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.39/1.49 Running current (Cooling) 6.9/6.9 Heating input 1.19/1.32 Running current (Heating) 6.1/6.1 Inrush current 33.6/36.6...
  • Page 57 SRK-H Model SRK408HENF-L2 (Indoor unit) SRC408HENF-L2 (Outdoor unit) Model SRK408HENF-L2 SRC408HENF-L2 Item Cooling capacity 3500/3500 Heating capacity 4100/4100 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.320/1.405 Running current (Cooling) 6.4/6.4 Heating input 1.335/1.460 Running current (Heating) 6.5/6.5 Inrush current 33.6/36.6 COP (In cooling) 2.65/2.49...
  • Page 58 SRK-H Model SRK501HENF-L (Indoor unit) SRC501HENF-L (Outdoor unit) Model SRK501HENF–L SRC501HENF–L Item Cooling capacity 4500/4500 Heating capacity 5700/5800 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.78/1.88 Running current (Cooling) 8.4/8.2 Heating input 1.76/1.89 Running current (Heating) 8.5/8.3 Inrush current 39/42 COP (In cooling) 2.53/2.39...
  • Page 59 SRK-H Model SRK561HENF-L (Indoor unit) SRC561HENF-L (Outdoor unit) Model SRK561HENF–L SRC561HENF–L Item Cooling capacity 5000/5000 Heating capacity 6200/6300 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.08/2.18 Running current (Cooling) 10.2/9.53 Heating input 2.02/2.15 Running current (Heating) 10.5/9.95 Inrush current 44/48 COP (In cooling) 2.40/2.29...
  • Page 60 SRK-H 2.2.2 Range of usage & limitations (1) Inlet air temperature (a) Cooling operation (b) Heating operating Applicable temp. range Applicable temp. range JIS-Cooling JIS-Heating Indoor air temp. ºC W. B. Note: The chart is the result from the continu- ous operation under constant air tempera- ture conditions, however, excludes the initial pull-down stage.
  • Page 61 SRK-H 2.2.3 Exterior dimensions (1) Indoor unit Models SRK328HENF-L2, 408HENF-L2 Unit: mm Room temp. sensor Piping hole right (left) Terminal block Piping for Gas (Ø12.7) 390 Piping for Liquid (Ø6.35) 440 Drain hose 600 (Ø16) Piping hole Piping hole (Ø65) (Ø65) VIEW A Models SRK501HENF-L, 561HENF-L...
  • Page 62 SRK-H (2) Outdoor unit Unit: mm Models SRC328HENF-L2, 408HENF-L2 Drain holes MAX 80 Terminal block 45˚ 16 x12 (Oval holes) for unit fixing 45˚ 2 places Drain holes Service Service 142.5 142.5 valve (Liquid) valve (Gas) Flare fitting Flare fitting 6.35 (1/4˝) Ø...
  • Page 63 SRK-H 2.2.4 Piping system Model SRK328HENF-L2 Cooling cycle Heating cycle Outdoor unit Indoor unit Service valve (Gas) High pressure switch (63H) (for fan motor control) Flare connecting Piping (Gas) Ø12.7 Check joint Discharge Room temperature sensor Compressor Accumulator Heat exchanger Heat Heat exchanger 4way valve...
  • Page 64 SRK-H Models SRK501HENF-L, 561HENF-L Cooling cycle Heating cycle Indoor unit Outdoor unit Service valve (Gas) Flare connecting High pressure switch(63H) (for fan motor control) Piping (Gas) Ø12.7 Check joint 4way valve Heat exchanger Heat Discharge exchanger Room Accumulator thermistor temperature Deicer thermistor thermostat...
  • Page 65 SRK-H ELECTRICAL DATA 2.3.1 Electrical wiring Models SRK328HENF-L2, 408HENF-L2 Indoor unit Outdoor unit Y/GN Power source 1 Phase 220/240V 50Hz Y/GN 52C3 52C4 20S 23D 250V 3.15A Wireless R-Amp Display Printed circuit board Color symbol Black Blue Brown Orange White Y/GN Yellow/Green Meaning of marks...
  • Page 66 SRK-H Models SRK501HENF-L, 561HENF-L Power source Indoor unit Outdoor unit 1 Phase 220/240V 50Hz Y/GN Y/GN RD 63H 52C-4 52C-3 S 52X1 250V 3.15A Wireless R-Amp OR CF Display Printed circuit board Color symbol Black Blue Brown Orange White Yellow Light blue Y/GN Yellow/Green...

  • Page 67: Outline Of Operation Control By Microcomputer

    SRK-H OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER 2.4.1 Table for operation control Refering page Functions Content High efficiency, low input rotary – Low input rotary compressor with high efficiency is equipped. compressor All operation modes can be operated from distance place by the wire- less remote control.
  • Page 68 SRK-H 2.4.2 Details of operation control (1) Flap control Control the flap by the flap button on the wireless remote control (a) AUTO (Natural flow) The flap will be automatically set to the angle of air flow best to operation mode Starting time of operation In case of cooling and In case of heating...
  • Page 69 SRK-H (2) Back-up Switch When the remote controller batteries become weak, or if the remote controller is lost or malfunctioning, this switch may be used to turn the unit on and off. (a) Operation Push the switch once to place the unit in the automatic mode. Push it once more to turn the unit off. (b) Details of operation The unit will go into the automatic mode in which it automatically determines, from room temperature (as detected by sensor), whether to go into the cooling, thermal dry or heating modes.

  • Page 70: Operation Section

    SRK-H (4) Operation control function by remote control switch ¡ 32, 40 models Remote control switch OPERATION MOOD select button S Operation section Each time the button is pushed, the • indicator is switched over in turn. CONT AUTO ON/OFF button Press for starting operation, press again for stopping.

  • Page 71: Heat Pump Model

    SRK-H ¡ 50, 56 models The diagram below shows the heat pump type. The cooling only type does not have the items relating to heating. Remote control switch Air flow indicator HI POWER operation indicator Indicaters the selected air flow rate. Indicators during HI POWER operation.
  • Page 72 SRK-H (a) Comfort timer settings Temperature is checked beginning 1 hour before the set time, and the power is turned on before the timer setting as necessary to bring the temperature to the proper level by the set time. Operating start time (amount of time Operation mode Room temperature sensor (Th previous to set time that operation begins)
  • Page 73 SRK-H (e) Fan control Fan speed change Mode COOL HEAT Fan speed knob AUTO See below Speed 1 (Speed 1) Speed 2 (Speed 2) Speed 1 (Speed 1) Speed 2 (Speed 2) Speed 3 (Speed 3) Speed 2 (Speed 2) HIGH Speed 3 (Speed 4) Speed 4 (Speed 5)
  • Page 74 SRK-H Function The indoor fan motor is controlled in accordance with the temperature of the indoor heat exchanger to send warm air from the start. When the air flow increases at heating starting as shown below, the temperature of the indoor heat exchanger become lower since the intake air temperature is still low.
  • Page 75 SRK-H (6) DRY operation (a) Choose the appropriate operation block area by the difference between room temperature and thermo- stat setting temperature as shown below. ¡Operation block area D Block C Block B Block A Block –2 Room temp. – Setting temp.(deg) (b) Start up operation C.D Block A.B Block...
  • Page 76 SRK-H (7) Dew condensation prevention control for cooling operation This prevents dew condensation, in the indoor unit, from occurring. Operating condition: when 52C is kept ON for 30 min. after the unit starts operation. Operation content: forces the indoor fan to change from Speed 1 to Speed 2. Resetting condition: When 52C is off, or when dew condensation prevention control has been operating continuously for 30 minutes.
  • Page 77 SRK-H (10) Forced defrosting (Heat pump type only) To test forced defrosting in the operation test mode, the unit may be operated once in the forced defrost mode as shown below. S32, 40 models Temporarily turn off the power source and then perform the following operation using the remote controller within 20 seconds after the power is turned back on.
  • Page 78 SRK-H (14) High power operation (Remote controller “HI POWER” button on) [50, 56 model only] The indoor unit fan rotates at speed 4 for 15 minutes, and carries out continuous cooling and heating. (15) Economy operation (Remote controller “ECONO” button on) [50, 56 model only] (a) Cooling economy operation The indoor unit fan operates 2ºC higher than the set temperature at speed 1.

  • Page 79: Application Data

    SRK-H APPLICATION DATA SAFETY PRECAUTIONS ¡ Please read these “Safety Precautions” first then accurately execute the installation work. ¡ Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.

  • Page 80: Selection Of Location For Installation

    SRK-H 2.5.1 Selection of location for installation (1) Indoor unit Where there is no obstructions to the air flow and where the cooled air can be evenly distributed. Right side A solid place where the unit or the wall will not vibrate. Left A place where there will be enough space for servicing.

  • Page 81: Installation Of Indoor Unit

    SRK-H 2.5.2 Installation of indoor unit (1) Installation if installation board (a) Fixing of installation board Lock for the inside wall structures (Intermediate support or pillar) Adjustment of the installation and firmly install the unit after level surface has been checked. board in the horizontal direction is to be conducted with lour screws in a temporary tightened state.
  • Page 82 SRK-H (3) Preparation of indoor unit (a) Mounting of connecting wires S 32, 40 models Remove lid. (ii) Remove cover, terminal block cover. Earth Wiring (iii) Connect the connection wire securely to the terminal block. Terminal Connecting Wiring Terminal Block Affix the connection wire securely to the terminal block.

  • Page 83: Installation Of Outdoor Unit

    SRK-H [When the pipe is extended to left and taken out from the rear center] (Drain pipe relocation procedure) 1. Remove the drain pipe. 2. Remove the drain cap. 3. Insert the drain cap. 4. Connect the drain pipe. ¡ Loosen the spring clamp to ¡...

  • Page 84: Refrigerant Piping

    SRK-H 2.5.4 Refrigerant piping (1) Preparation Keep the openings of the pipes covered with tapes etc. to prevent dust, sand, etc. from entering them. Indoor unit side Outdoor unit side Dimension A Liquid side (φ6.35): 9-9.5 dia Gas side Press Press (Do not (φ9.52):...

  • Page 85: Test Run

    SRK-H Additional refrigerant charge When refrigerant piping exceeds 7.5m conduct additional refrigerant charge after refrigerant sweeping. Max. 10m Additional charge amount per meter = 20g/m* 10m over 15m Additional charge amount per meter = 30g/m *In case of cooling only unit charge amount is 10g/m [Example for heat pump units] How much amount of additional charge for 10m piping? (10 –...

  • Page 86: Precautions For Wireless Remote Controller Installation And Operation

    SRK-H (220/240V) Model SRK501HENF-L SRK561HENF-L Item Cooling – – High pressure MPa(kgf/cm Heating 1.67~1.86 (17 ~ 19) 1.76 ~ 1.96 (18 ~ 20) Cooling 0.39 ~ 0.49 (4 ~ 5) 0.34 ~0.44 (3.5 ~ 4.5) Low pressure MPa(kgf/cm Heating – –...

  • Page 87: Maintenance Data

    SRK-H MAINTENANCE DATA 2.6.1 Trouble shooting (1) Trouble shooting to be performed prior to exchanging PCB, (Printed circuit board) [Common to all models] All the models described in this chapter are controlled by a microcomputer. When providing maintenance service to customers it is necessary to understand the function controlled by a micro computer thoroughly, so as not to mistakenly identify correct opera- tions as mis-operations.
  • Page 88 SRK-H (2) Indication of Self Diagnosis (Indoor unit) Connect of Defect Place of defect RUN lamp is flashing. Abnormality of heat ¡ Disconnection of heat exchanger thermistor. exchanger thermistor. (1 Time flash.) TIMER lamp RUN lamp is flashing. Abnormality of room ¡...
  • Page 89 SRK-H Anormality of thermistor Disconnection of thermistor and defective connection of connector Chart for thermistor temperature resistance characteristics Is connection to connector Repair connector. good? (Disconnection) Is thermistor resistance Replace thermistor. value normal? (kΩ) Replace PCB. (Short circuit) Temperature (°C) (4) Trouble Diagnostic Procedures Remove receptacle.
  • Page 90 SRK-H (5) Trouble shooting chart for the room temperature thermistor (Th ), heat exchanger thermistor (Th ) and defrost thermostat (23DH) Function Unit Thermistor Operation Short circuit Broken connection Continuous Cooling operation Cooling will not operate ¡ Cannot be turned ON/OFF by thermostat ¡...

  • Page 91: Servicing

    SRK-H 2.6.2 Servicing (1) Evacuation The evacuation is an procedure to purge impurities ..noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R407C is very insoluble in water, even a small amount of moisture left in the refrigerant equipment will freeze, causing what is called water clogging.

  • Page 92: Power Supply Remote Operation

    SRK-H 2.6.3 Power supply remote operation When the remote part on indoor unit PCB is modified, the air conditioner is turned ON-OFF by power supply ON-OFF operation without using remote control switch. After the power supply remote operation, the operation contents can be modified by the remote controller. (1) Operation contents (a) Heat pump type Operation change...
  • Page 93 SRK-H S50,56 models Cut the jumper wire for the “REMOTE” section on the printed circuit board. Carefully position the jumper wire so that it does not come in contact with other parts. 52X1 (FMI)
  • Page 94 SRK-H MEMO...

  • Page 95: Srk-C

    SRK-C SRK-C 3. WALL MOUNTED TYPE ROOM AIR-CONDITIONER Split system, Air cooled cooling only type SRK501CENF-L, SRK561CENF-L...
  • Page 96 SRK-C CONTENTS 3.1 GENERAL INFORMATION ............... 95 3.1.1 Specific features ................95 3.1.2 How to read the model name ............95 3.2 SELECTION DATA..................96 3.2.1 Specifications ..................96 3.2.2 Range of usage & limitations ............98 3.2.3 Exterior dimensions................99 3.2.4 Piping system ..................

  • Page 97: General Information

    3.1.1 Specific features The “Mitsubishi Daiya” room air conditioner: SRK series are of split and wall mounted type and the unit consists of indoor unit and outdoor unit with refrigerant precharged in factory. The indoor unit is composed of room air cooling or heating equipment with operation control switch and the outdoor unit is composed of condensing unit with compressor.

  • Page 98: Selection Data

    SRK-C SELECTION DATA 3.2.1 Specifications Model SRK501CENF-L (Indoor unit) SRC501CENF-L (Outdoor unit) Model SRK501CENF-L SRC501CENF-L Item Cooling capacity 4500/4500 Power source 1 Phase, 220/240V, 50 Hz Cooling input 1.78/1.88 Running current (Cooling) 8.4/8.2 Inrush current 39/42 COP (In cooling) 2.53/2.39 Noise level dB (A) 44/44...
  • Page 99 SRK-C Model SRK561CENF-L (Indoor unit) SRC561CENF-L (Outdoor unit) Model SRK561CENF-L SRC561CENF-L Item Cooling capacity 5000/5000 Power source 1 Phase, 220/240V, 50 Hz Cooling input 2.08/2.18 Running current (Cooling) 10.2/9.53 Inrush current 44/48 COP (In cooling) 2.40/2.29 Noise level dB (A) 45/45 53/54 Exterior dimensions...

  • Page 100: Range Of Usage & Limitations

    SRK-C 3.2.2 Range of usage & limitations lnlet air temperature range Applicable temp. range JIS-Cooling Indoor air temp.˚CW.B. Note: The chart is the result from the continuous opera- tion under constant air temperature conditions, how- ever, excludes the initial pull-down stage. (2) Total one way piping length and vertical height difference.

  • Page 101: Exterior Dimensions

    SRK-C 3.2.3 Exterior dimensions (1) Indoor unit Models SRK501CENF-L, 561CENF-L (2) Outdoor unit Models SRC501CENF-L, 561CENF-L Unit: mm Oval (M10x4) holes for Anchor bolt 70.5 Service Lebel model valve (Gas) name Ø12.7 (1/2˝) Drain pipe Service valve (Liquid) Ø6.35 (1/4˝)
  • Page 102 SRK-C 3.2.4 Piping system Models SRK501CENF-L, 561CENF-L Indoor unit Outdoor unit Service valve (Gas) Flare connecting Cooling cycle Discharge Piping (Gas) ø12.7 Check joint Room temperature thermistor Accumulator Heat Heat Heat exchanger exchanger exchanger thermistor Suction Compressor Capillary tube Piping (Liquid) ø6.35 Service valve (Liquid) Flare connecting...

  • Page 103: Application Data

    SRK-C ELECTRICAL DATA 3.3.1 Electrical wiring Models SRK501CENF-L, 561CENF-L Meaning of marks Color symbol Symbol Parts name Symbol Parts name Black Capacitor for CM Louver motor Blue Capacitor for FM Thermistor Brown Compressor motor Varistor Fuse Motor protector for CM Orange Fan motor (Indoor unit) Magnetic contactor for CM...
  • Page 104 SRK-C MEMO...

  • Page 105: Inverter Multi-Split System Room Air-Conditioner

    SCM-HG SCM-HG (4 room) (4 room) 4. INVERTER MULTI-SPLIT SYSTEM ROOM AIR-CONDITIONER[4 room] (Air to air heat pump type) (OUTDOOR UNIT) SCM802HENG-L, SCM1002HENG-L (INDOOR UNIT) SKM222HENG-L, SKM252HENG-L SKM282HENG-L, SKM322HENG-L SKM402HENG-L, SKM502HENG-L SRRM40HENG-L...

  • Page 106: Refrigerant Piping

    SCM-HG (4 room) CONTENTS 4.1 GENERAL INFORMATION ................ 105 4.1.1 Specific features ................. 105 4.1.2 How to read the model name ............. 105 4.2 SELECTION DATA ..................106 4.2.1 Specifications ..................106 4.2.2 Range of usage & limitations ............. 121 4.2.3 Exterior dimensions................

  • Page 107: General Information

    SCM-HG (4 room) GENERAL INFORMATION 4.1.1 Specific features (1) Equipped with an inverter scroll compressor. ¡ Low noise. Low vibration and compact. (2) The long piping makes the location of the inside and units flexible. ¡ No need for additional charge of refrigerant : 50 m ¡...

  • Page 108: Selection Data

    SCM-HG (4 room) SELECTION DATA 4.2.1 Specifications (1) Indoor unit (a) Wall mounted type Models SKM222HENG-L, 252HENG-L, 282HENG-L Models SKM222HENG-L SKM252HENG-L SKM282HENG-L Item Cooling capacity 2200 2500 2800 Heating capacity 3200 3400 4000 Cooling Noise level dB (A) Heating Exterior dimensions 250 ×...
  • Page 109 SCM-HG (4 room) Models SKM322HENG-L, 402HENG-L, 502HENG-L Models SKM322HENG-L SKM402HENG-L SKM502HENG-L Item Cooling capacity 3200 4000 5000 Heating capacity 4500 5400 6700 Cooling Noise level dB (A) Heating Exterior dimensions 275 × 790 × 174 275 × 790 × 189 Height ×...
  • Page 110 SCM-HG (4 room) (b) Ceiling recessed type Model SRRM40HENG-L Model SRRM40HENG-L Item Cooling capacity 4000 Heating capacity 6000 Cooling Noise level dB (A) Heating Exterior dimensions 230 × 740 × 455 Height × Width × Depth Color — Net weight Air handling equipment Multiblede centrifugal fan ×...
  • Page 111 SCM-HG (4 room) (2) Outdoor unit Models SCM802HENG-L, 1002HENG-L Models SCM802HENG-L SCM1002HENG-L Item Cooling capacity 8000 (1500 ~ 8400) 10000 (1500 ~ 10300) Heating capacity 10500 (1500 ~ 11000) 12000 (1500 ~ 12200) Power source 1 Phase 50Hz Cooling 2990 (610 ~ 3240) 4200 (610 ~ 4570) Power consumption Heating...
  • Page 112 SCM-HG (4 room) (3) Operation data ¡ The combinations of the indoor units is indicated by numbers. They are read as follows. (Example) SKM222HENG / 22 SKM502HENG / 50 ¡ The capacity of the indoor units is shown by rooms. If this exceeds the maximum capacity of the outdoor unit, the demand capacity will be proportionally distributed.
  • Page 113 SCM-HG (4 room) Running Heating capacity (kW) Power consumption (W) Indoor unit current (A) combination Room heating capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+40+40 22+40+50 25+25+25 25+25+28 25+25+32 25+25+40...
  • Page 114 SCM-HG (4 room) Running Heating capacity (kW) Power consumption (W) Indoor unit current (A) combination Room heating capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+28+28+28 22+28+28+32 22+28+28+40 22+28+32+32 22+32+32+32 25+25+25+25...
  • Page 115 SCM-HG (4 room) Running Cooling capacity (kW) Power consumption (W) Indoor unit current (A) combination Room cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+22+22 22+22+25 22+22+28 22+22+32 22+22+40 22+22+50...
  • Page 116 SCM-HG (4 room) Running Cooling capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+22+22+22 22+22+22+25 22+22+22+28 22+22+22+32 22+22+22+40 22+22+22+50...
  • Page 117 SCM-HG (4 room) (b) SCM1002HENG-L Heating Running Heating capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Heating capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. room 22+22 22+25...
  • Page 118 SCM-HG (4 room) Running Heating capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Heating capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 25+25+50 25+28+28 25+28+32 25+28+40 25+28+50 25+32+32...
  • Page 119 SCM-HG (4 room) Running Heating capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Heating capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+25+28+28 22+25+28+32 22+25+28+40 22+25+28+50 22+25+32+32 22+25+32+40...
  • Page 120 SCM-HG (4 room) (ii) Cooling Running Cooling capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. room 22+22 22+25 22+28...
  • Page 121 SCM-HG (4 room) Running Cooling capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 25+28+32 25+28+40 25+28+50 25+32+32 25+32+40 25+32+50...
  • Page 122 SCM-HG (4 room) Running Cooling capacity (kW) Power consumption (W) Indoor unit current (A) combination Room Cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room C room D room Min. Standard Max. 22+25+32+32 22+25+32+40 22+25+32+50 22+25+40+40 22+28+28+28 22+28+28+32...

  • Page 123: Range Of Usage & Limitations

    SCM-HG (4 room) 4.2.2 Range of usage & limitations (1) Inlet air temperature (a) Cooling operation (b) Heating operation Applicable temp. range Applicable temp. range JIS-Cooling JIS-Heating Indoor air temp. ˚C. W. B Note: The chart is result from the continuous opera- tion under constant air temperature conditions, however, excludes the initial pull-down stage.

  • Page 124: Exterior Dimensions

    SCM-HG (4 room) 4.2.3 Exterior dimensions (1) Indoor unit Models SKM222HENG-L, 252HENG-L, 222CENG-L, 252CENG-L Unit: mm Room temp. thermistor Piping hole right (left) Terminal block 746.9 Piping for Gas ( 9.52) 370 Ø Piping for Liquid ( 6.35) 420 Ø Piping hole Piping hole Ø...
  • Page 125 SCM-HG (4 room) Models SKM322HENG-L, 402HENG-L Unit: mm Room temp. thermistor Piping hole right (left) Terminal block Piping for Gas 12.7) 390 Ø Piping for Liquid ( 6.35) 440 Ø Drain hose 600 ( Ø Piping hole Piping hole Ø Ø...
  • Page 126 SCM-HG (4 room) Model SRRM40HENG-L Unit: mm Suspension bolts (M8 × 4) (Procured by customer) Controller 670 (Suspension bolts pitch) Terminal block Air outlet Gas piping (ø 12.7) Drain hose Liquid piping (ø 6.35) (Connection opening diameter ø 16) • Details of air outlet ø...
  • Page 127 SCM-HG (4 room) (2) Outdoor unit Models SCM802HENG-L, 1002HENG-L Unit: mm Service valve Service valve (Gas ø 12.7) (Liquid ø 6.35) Service valve Service valve (Gas ø 9.52) (Liquid ø 6.35) Service valve Service valve (Liquid ø 6.35) (Gas ø 12.7) Service valve (Liquid ø...

  • Page 128: Piping System

    SCM-HG (4 room) 4.2.4 Piping system Models SCM802HENG-L, 1002HENG-L ELECTRICAL DATA Meaning of marks • Outdoor Unit Symbol Parts name Symbol Parts name Compressor motor 4 way valve (coil) Capacitor High pressure switch (for protection) Fan motor Tho-A Thermistor (outdoor air temp.) 01,2 Reactor Tho-R...

  • Page 129: Electrical Wiring

    SCM-HG (4 room) 4.3.1 Electrical wiring (1) Indoor unit Models SKM222HENG-L, 252HENG-L, 282HENG-L, 322HENG-L, 402HENG-L Power line (Outdoor unit) Y/GN RD RD BK BK Color symbol Black F (250V · 3.15A) Blue Gray Yellow White Purple Y/GN Yellow/Green Printed circuit board Back up switch A Th...
  • Page 130 SCM-HG (4 room) Power line (Outdoor unit) Model SRRM40HENG-L Y/GN (250V · 3.15A) Color symbol Black COMI Blue Brown Orange White Y/GN Yellow/Green (Option) Printed circuit board Wireless Display R-Amp (Option) (2) Outdoor unit Models SCM802HENG-L, 1002HENG-L UNIT A UNIT B UNIT C UNIT D 1 2 3...
  • Page 131 SCM-HG (4 room) 4.4. OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER (1) Remote Control Switch HI POWER operation indicator Indicators during HI POWER operation. FAN SPEED indicator ECONOMY operation indicator Indicators the ¡ for the fan speed which has been set. Indicators during ECONOMY operation.
  • Page 132 SCM-HG (4 room) ¡ SKM50 model RUN (HOT KEEP) lamp (green) • Illuminates during operation. • Flashing at stop blowing due to the hot keep. HI POWER lamp (green) Illuminates during HI POWER operation. RUN HI POWER TIMER ECONO TIMER lamp (yellow) Illuminates during TIMER operation.
  • Page 133 SCM-HG (4 room) (4) Flap control Control the flap by AIRFLOW button on the wireless remote control. (a) AUTO The flap will be automatically set to the angle of air flow best to operation. 1) Starting time of operation ¡ SKM22, 25, 28, 32, 40 models In case of cooling In case of heating and dry operation...
  • Page 134 SCM-HG (4 room) (b) Memory flap (Excepted 22, 25models) While the flap is operating if the AIRFLOW button is pushed once, it stops swinging at an angle. As this angle is memorized in the microcomputer, the flap will be automatically set to the angle when next operation is started.
  • Page 135 SCM-HG (4 room) (6) Cooling operation (a) Summary 1) Capacity control Model SCM802HENG-L SCM1002HENG-L Capacity 1.5 ~ 8.4 kW 1.5 ~ 10.3 kW Capacity control is within the range shown above. If demand capacity of the indoor units exceeds the maximum capacity of the outdoor unit, the demand capacity will be proportionally distributed.
  • Page 136 SCM-HG (4 room) (b) Mode switching Within the selected mode, the unit operates using the values shown below which were obtained by multiplying a conversion coefficient to the indoor unit demand frequency. Model (Indoor) Operation Mode Automatic 28 ~ 40 28 ~ 42 28 ~ 46 28 ~ 80...
  • Page 137 SCM-HG (4 room) (e) Hot keep operation If the hot keep operation is selected during the heating operation, the indoor blower is controlled based on the temperature of the indoor unit heat exchanger (detected with Th2, indoor unit heat exchanger thermistor) to prevent blowing of cool wind. SKM22, 25, 32, 40 models ¡Normal mode (Normal heating operation, operation after HI POWER completion) 7th speed...
  • Page 138 SCM-HG (4 room) Defrosting When the following conditions are met, the defrosting operation will start. 1) During normal operation When 30 minutes has passed since the start of heating or 30 minutes after the last defrosting (Cumulative actual operating time of compressor at outdoor unit frequency of 16 Hz or more). When the outdoor heat exchanger thermistor temperature is -3 °C or less for 3 continuous minutes after 27 minutes have passed.
  • Page 139 SCM-HG (4 room) (8) Determining the operating mode The cooling and heating operating modes are the remote control switch mode that have been previously determined. If a mode differing from these is selected after this, the selected mode will appear in the display of the remote control, but only the fan will operate.
  • Page 140 SCM-HG (4 room) (d) Refrigerant pooling protection control This function prevents the pooling of refrigerant in the indoor unit when stopped during heating operation. 1) Operating conditions (When all of the following conditions are met, the refrigerant pooling protection control operation will start.) 1 When heating.
  • Page 141 SCM-HG (4 room) 2) If multiple indoor units are going to be added. Stopped unit ON 3 Stopped unit ON 1 Stopped unit ON 2 Between 2 minutes and 2 minutes (Within 2 minutes of 1 ON) 30 seconds after 1 ON Decision frequency Outdoor unit frequency 16 Hz...
  • Page 142 SCM-HG (4 room) High pressure cut protection control 1) The high pressure cut protection control operates when 1 or 2 units are stopped when heating with multiple units. 2) The operation of functional components is as follows. 1 When 1 unit is stopped from among multiple operating units. Functional component Description of operation 0 Hz...
  • Page 143 SCM-HG (4 room) 2 When 2 units are stopped from among 3 or 4 operating units. Functional component Description of operation 0 Hz command 2 minutes Calculated Hz 0 Hz Indoor unit command frequency 0 Hz command 2 minutes Calculated Hz 0 Hz Decision frequency Outdoor unit frequency...
  • Page 144 SCM-HG (4 room) 3 When the decision frequency becomes 0 Hz when high pressure cut protection control is in operation. Functional component Description of operation 0 Hz command 1 0 Hz command 2 0 Hz command 3 Calculated Hz 0 Hz Calculated Hz Indoor unit command frequency 0 Hz...
  • Page 145 SCM-HG (4 room) (g) Low Hz continuous operation protection control The following controls are performed to return the oil to the compressor when the outdoor frequency is less than 34 Hz and other than 0 Hz for 20 continuous minutes or more. Forced operation at outdoor frequency of 34 Hz is performed for 2 minutes.
  • Page 146 SCM-HG (4 room) (m) Outdoor unit abnormal stop and compressor motor protection If the air conditioner is operating at an inverter frequency 28 Hz or more and an input current of 1 A or less is detected for 30 continuous seconds or more, a abnormal stop is performed. At the same time, LED 2 on the printed circuit board for the outdoor unit will flash 2 times at a 0.5 second interval every 8 seconds.
  • Page 147 SCM-HG (4 room) (s) Stop mode : When the decision frequency is 0 Hz; during switching mode, during protection function operation. If stopped by indoor unit control. If permanent stop. If stopped by outdoor protection function. If restarted by operation switching. Functional Operation components...

  • Page 148: Application Data

    SCM-HG (4 room) APPLICATION DATA SAFETY PRECAUTIONS ¡ Please read these “Safety Precautions” first then accurately execute the installation work. ¡ Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.
  • Page 149 SCM-HG (4 room) 4.5.1 Installation of indoor unit (1) Wall mounted type (SKM) (a) Caution for installation 1) The system should be applied to places as households, residences and the like. 2) The equipment shall be installed in accordance with national wiring regulations. 3) The connection to the fixed wiring of the mains supply must be made via a double pole isolating switch with a contact gap of at least 3mm in each pole.
  • Page 150 SCM-HG (4 room) 3) Mounting of interconnecting wires (Field wiring) ¡ SKM22, 25, 32, 40 models. SKM22, 25, 28, 32, 40 models. a) Remove the lid. b) Remove the terminal block cover. c) Connect the connection wire securely to the terminal block. 1 Connect the connection wire securely to the terminal block.
  • Page 151 SCM-HG (4 room) [Procedure for exchanging the drain hose.] 1. Remove the drain hose. 2. Remove the drain cap. 3. Insert the drain cap. 4. Connect the drain hose. ¡ Loosen the spring-type clamp and ¡ Loosen and remove the spring- ¡...
  • Page 152 SCM-HG (4 room) (2) Ceiling recessed type (SRRM) These instructions are for the installation of the main unit. If this unit is to be used in combination with a separately sold compo- nent, also refer to the installation procedures for that component. (See page 158.) (a) Caution for installation The safety precautions for installation are the same as the SKM type.
  • Page 153 SCM-HG (4 room) 5) Connecting the drain pipes Tapping screw Bumps Opposite Note (1) Conduct the installation correctly, and ensure that the water is draining correctly. It may lead to water leaks. Traps Drain hose Clamp a) Insert the drain hose as far as possible through the lower section of the side of the unit, and secure it with clamps. b) The drain pipes should be set in a downward slope (over 1/100), and it should not have any bumps or traps along its route.
  • Page 154 SCM-HG (4 room) 4.5.3 Installation of outdoor unit (1) Selection of installation location (Please install with the customer’s consent in a location that follows the conditions listed below.) Where the following installation space is available, and where air does not gather. (b) Where rain and sunlight do not directly hit the unit, and where there is enough air circulation.

  • Page 155: Electric Wiring

    SCM-HG (4 room) Securing the Unit ¡ Locations to secure the bolts. Unit: mm ¡ Use M10-M12 for the retaining bolts. ¡ Secure it firmly so the unit will not fall during earthquakes and from sudden gusts of wind. Drainage ¡...
  • Page 156 SCM-HG (4 room) (d) Use the power supply wires specified below. Different wires may cause heat generation and fire. Do not to use unspecified wires. Never bundle, wind or treat the power wires. Otherwise, heat or fire may be generated. SCM802HENG-L SCM1002HENG-L Use cables for interconnection wiring to avoid loosening of the wires.
  • Page 157 SCM-HG (4 room) (2) Connection of refrigerant piping ¡ The service valve corresponding to each indoor unit is as illustrated in the right figure. ¡ Regarding the change in the sizes of gas side pipes (usage of the variable joints); if a 3.2/ 4.0/5.0 kW class indoor unit (gas side pipe 12.7) is going to be connected to the rooms A Earth screw and C service valves (9.52), or if a 2.2-2.8 kW class indoor unit (gas side pipe 9.52) is...
  • Page 158 SCM-HG (4 room) Procedure 1 Secure all flare nuts on both indoor and outdoor sides to prevent leaks from the Compound Pressure pipes. pressure gauge gauge Manifold 2 Connect the service valves, charge hose, manifold valve and vacuum pump as valve -0.1 MPa (-76cmHg)
  • Page 159 SCM-HG (4 room) 4.5.6 Test run and handling instruction (1) Inspection Check according to the following check items. (2) Test run (1) Conduct the test run after turning on the power for 20 minutes. (Run electricity for 20 minutes with a hot stand-by to prevent compression of the compressor liquid.) (2) If the compressor does not operate after the operation has started, wait for 5 ~ 10 minutes.
  • Page 160 SCM-HG (4 room) 4.5.7 Installation of optional parts (Ceiling recessed type) Table of optional parts Air outlet duct Air outlet grille for Bottom air inlet grille set Air outlet unit for ceiling RFD12 suspended ceiling RTS12 (1 opening) RKB12 RTB12 Flexible duct ø150 Duct joint for air outlet plate Drain up kit...
  • Page 161 SCM-HG (4 room) (c) Installation The following is the procedure for installing the air outlet grille for suspended ceiling (RKB12). (d) Installation procedure 1) Mount the air outlet duct to the indoor unit Tapping screw (ø 4 × 16) using the eight tapping screws. Motor cover Tapping screw (ø...
  • Page 162 SCM-HG (4 room) (2) Air outlet grille for suspended ceiling (a) Part Number: RKB12 The air outlet grill for suspended ceiling is for mounting on the air outlet duct (RFD12) directly attached to the indoor unit. (b) Parts list Name Qty.
  • Page 163 SCM-HG (4 room) (3) Bottom air inlet grille set (a) Part number: RTS12 (b) Parts list Name Qty. Air inlet grille Duct for air inlet grille Tapping screw Pan-head screws Unit: mm (c) Installation 11.5 Indoor unit Indoor unit 762 (Ceiling opening dimensions) 258 (Ceiling opening dimensions) 278 (Ceiling opening dimensions) 782 (Panel dimensions)
  • Page 164 SCM-HG (4 room) (c) Installation 357 (Suspension bolt pitch) Unit: mm Suspension bolt M8 × 2 166.5 166.5 (Procured by customer) Round duct connection port 45.5 45.5 Air outlet chamber 52.5 52.5 Ceiling Air outlet panel 377 (Ceiling opening dimension) (Ceiling opening dimension) (d) Installation procedure Use the bolts (M8 ×...
  • Page 165 SCM-HG (4 room) (5) Flexible duct Part number Length (m) Diameter (ø mm) Parts provided S97682 • Connecting bands (2) S97683 –2 • Soft tape (2) S98223 S97684 (6) Duct joint for air outlet plate (a) Part number: RFJ22 The duct joint is to be used when connecting the flexible duct (ø 150 mm) to the indoor unit. (b) Part list Name Qty.
  • Page 166 SCM-HG (4 room) Air flow and external static pressure characteristics (Heating:HI) SRRM40HENG-L Air flow (m /min) Air outlet unit air flow and friction loss characteristics Air inlet grille air flow and friction loss characteristics ● Air outlet unit (Part number: RTB12) (Part number: RTS12) (Air outlet chamber + Air outlet panel) Air flow (m...
  • Page 167 SCM-HG (4 room) (7) Drain up kit (a) Part No. : RDU12E (b) Accessories Name Qty. Drain pump Drain hose Hose clamp Tapping screw (c) Installation of drain up kit Unit: mm Indoor unit Control VIEW A Fitting for drain hose Vinyl chloride pipe VP-25 (d) Installation of drain up kit 4 Tapping screw...
  • Page 168 SCM-HG (4 room) Use hard PVC general purpose pipes VP-25 sold on the market 3 Hose clamp for drain pipes after draining up. Tighten the PVC pipe securely with the attached clamp after inserting it in the drain socket. Drain hose The drain pipe must have downward inclination gradient of 1/ 100 or more, and take care not to make a trap or uphill pass.
  • Page 169 SCM-HG (4 room) MAINTENANCE DATA 4.6.1 Trouble shooting (1) Trouble shooting to be performed prior to exchanging PCB, (Printed circuit board) [Common to all models] All the models described in this chapter are controlled by a microcomputer. When providing maintenance service to customers it is necessary to understand the function controlled by a micro computer thoroughly, so as not to mistakenly identify correct operations as mis-operations.
  • Page 170 SCM-HG (4 room) (2) Indication of self diagnosis Indoor unit indicator Outdoor unit indicator Description Cause Conditions of flashing of trouble (LED2) RUN lamp TIMER lamp When heat exchanger thermistor temperature ● Broken heat exchanger of –20 °C or under continued for more than Heat exchanger 1 time flash thermistor wire...
  • Page 171 SCM-HG (4 room) (3) Inspection procedures corresponding to detail of trouble [Broken thermistor wire, Thermistor error connector poor connection] Is connector connection good? Correct connection. Is sensor resistance value good? Replace thermistor. Replace PCB. Discharge pipe thermistor temperature characteristics Thermistor temperature characteristics (Room temperature, indoor unit heat Temperature (˚C) Resistance (kΩ)
  • Page 172 SCM-HG (4 room) [Broken power transistor, Outdoor unit e rror broken compressor wire] Is output voltage applied to all 3 Defective inverter phases of power transistor? Is compressor wiring connected Connect securely. securely? Inspect compressor. (Broken coil wire) [Overload operation, compressor Over current lock, overcharge] Discharge refrigerant.
  • Page 173 SCM-HG (4 room) [Indoor/outdoor printed circuit board defect Serial signal transmission abnormality Outdoor power source abnormality] Does the voltage between 2 and 3 The indoor printed circuit board is defective. Are receiving lamps (LEDs 3 to 5) on? on the indoor side oscillate between (Flashing) 0 and 12V? Does the voltage between 2 and 3...
  • Page 174 SCM-HG (4 room) (4) Phenomenon observed after shortcircuit, wire breakage on thermistors, etc. (a) Indoor unit Phenomenon Operation Sensor mode Shortcircuit Broken wire Cooling Release of continuous compressor operation command Continuous compressor operation command is not released. Room temperature thermistor Heating Continuous compressor operation command is not released.
  • Page 175 SCM-HG (4 room) (6) Indoor electrical components inspection flow-chart Is there voltage between terminal Inspect power source blocks 1 and 2 ? (AC 220 V) for outdoor unit. Is the noise filter good? Inspect noise filter. Is the fuse burnt out? (3.15 A) Replace fuse.
  • Page 176 SCM-HG (4 room) (7) Inverter failure diagnosis If the results of the diagnosis in Item (3) indicate that the inverter is defective, perform the following inspection on the inverter. (a) Diagnosis procedure High voltage is created inside the controller box. When performing operations other than inspecting the voltage system, stop operation and wait until LED7 on the printed circuit board of the outdoor unit has gone out (approx.
  • Page 177 SCM-HG (4 room) White Black White Black White Black...
  • Page 178 SCM-HG (4 room) 4.6.2 Servicing (1) Evacuation The evacuation is an procedure to purge impurities..noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R22 is very insoluble in water, even a small amount of moisture left in the refriger- ant equipment will freeze, causing what is called water clogging.
  • Page 179 SCM-HG (4 room) 4.6.3 Standard operating data ¡SCM802HENG-L, 1002HENG-L ¡SCM802HENG-L, 1002HENG-L (Cooling Rating Conditions) (Heating Rating Conditions) (24) (22) 1 Unit (22) (20) 2 Units (20) (18) 3 Units (18) (16) (16) (14) 4 Unit Due to Current Save (CT) Control Due to Current Save (CT) Control 14000 12000...
  • Page 180 SCM-HG (4 room) MEMO...
  • Page 181 SCM-HG SCM-HG (2 room) (2 room) 5. INVERTER MULTI-SPLIT SYSTEM ROOM AIR-CONDITIONER (Air to air heat pump type) (OUTDOOR UNIT) SCM452HENG-L (INDOOR UNIT) SKM222HENG-L SKM252HENG-L SKM282HENG-L SKM322HENG-L SKM402HENG-L...
  • Page 182 SCM-HG (2 room) CONTENTS 5.1 GENERAL INFORMATION ................. 181 5.1.1 Specific features .................. 181 5.1.2 How to read the model name .............. 181 5.2 SELECTION DATA ..................182 5.2.1 Specifications ..................182 5.2.2 Range of usage & limitations ............. 186 5.2.3 Exterior dimensions ................

  • Page 183: General Information

    SCM-HG (2 room) GENERAL INFORMATION 5.1.1 Specific features (1) Equipped with an inverter scroll compressor. ¡Low noise. Low vibration and compact. (2) The long piping makes the location of the inside and units flexible. ¡No need for additional charge of refrigerant : 20 m ¡Maximum piping length : 30 m (3) Connectable indoor capacity Number of connectable units : 1 to 2 units...

  • Page 184: Selection Data

    SCM-HG (2 room) SELECTION DATA 5.2.1 Specifications (1) Indoor unit Models SKM222HENG-L, 252HENG-L, 282HENG-L, 322HENG-L, 402HENG-L Models SKM222HENG-L SKM252HENG-L SKM282HENG-L SKM322HENG-L SKM402HENG-L Item Cooling capacity 2200 2500 2800 3200 4000 Heating capacity 3200 3400 4000 4500 5400 Cooling Noise level dB (A) Heating Exterior dimensions...
  • Page 185 SCM-HG (2 room) (2) Outdoor unit Model SCM452HENG-L Model SCM452HENG-L Item Cooling capacity 4500 (2000 ~ 5100) Heating capacity 5600 (2200 ~ 6000) Power source 1 Phase 220/240V 50Hz Cooling 1820 (680 ~ 2050) Power consumption Heating 1950 (650 ~ 2190) Cooling 8.4/7.7 Running current...
  • Page 186 SCM-HG (2 room) (3) Operation data ¡ The combinations of the indoor units is indicated by numbers. They are read as follows. (Example) SKM222HENG / 22 SKM402HENG / 40 ¡ The capacity of the indoor units is shown by rooms. If this exceeds the maximum capacity of the outdoor unit, the demand capacity will be proportionally distributed.
  • Page 187 SCM-HG (2 room) (b) Cooling Running Cooling capacity (kW) Power consumption (W) current (A) Indoor unit combination Room cooling capacity (kW) Total capacity (kW) Min. Standard Max. Standard A room B room Min. Standard Max. 3.44/3.16 1040 4.13/3.79 1040 1150 4.78/4.38 room 1200...

  • Page 188: Range Of Usage & Limitations

    SCM-HG (2 room) 5.2.2 Range of usage & limitations (1) Inlet air temperature (a) Cooling operation (b) Heating operation Applicable temp. range Applicable temp. range JIS-Cooling JIS-Heating Indoor air temp. ˚C. W. B Note: The chart is result from the continuous operation under constant air temperature conditions, however, excludes the initial pull- down stage.

  • Page 189: Exterior Dimensions

    SCM-HG (2 room) 5.2.3 Exterior dimensions (1) Indoor unit Unit: mm Models SKM222HENG-L, 252HENG-L Room temp. thermistor Piping hole right (left) Terminal block 746.9 Piping for Gas ( 9.52) 370 Ø Piping for Liquid ( 6.35) 420 Ø Piping hole Piping hole Ø...
  • Page 190 SCM-HG (2 room) Models SKM322HENG-L, 402HENG-L Unit: mm Room temp. thermistor Piping hole right (left) Terminal block Piping for Gas 12.7) 390 Ø Piping for Liquid ( 6.35) 440 Ø Drain hose 600 ( Ø Piping hole Piping hole Ø Ø...

  • Page 191: Piping System

    SCM-HG (2 room) 5.2.4 Piping system Model SCM452HENG-L Cooling cycle Outdoor unit Heating cycle Thermistor Service valve (Gas) Gas line (ø9.52) (ø9.52) Indoor unit 4 way valve Check joint Muffler Thermistor Discharge Heat exchanger Compressor Thermistor Accumulator Thermistor Thermistor Suction Strainer Electric Service valve...

  • Page 192: Electrical Data

    SCM-HG (2 room) ELECTRICAL DATA Meaning of marks • Outdoor Unit Symbol Parts name Symbol Parts name Compressor motor Tho-A Thermistor (outdoor air temp.) Fan motor Tho-R Thermistor (outdoor H.X temp.) Reactor Tho-D Thermistor (comp. dome temp.) Diode stack LED2 Warning lamp (Red) EEVA, B Electric expansion valve...
  • Page 193 SCM-HG (2 room) (2) Outdoor unit Model SCM452HENG-L UNIT A Serial A Power transistor AC·R 52X2-4 UNIT B Serial B AC·S S. OUT – Fuse 250V 25A R. IN Power source 1 Phase S. IN 220/240V Y/GN LED1 LED3 LED2 50Hz (Green) (Red)

  • Page 194: Outline Of Operation Control By Microcomputer

    SCM-HG (2 room) OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER (1) Remote Control Switch HI POWER operation indicator Indicators during HI POWER operation. FAN SPEED indicator ECONOMY operation indicator Indicators the ¡ for the fan speed which has been set. Indicators during ECONOMY operation. Operation switch over indicator Indicators the ¡...
  • Page 195 SCM-HG (2 room) (3) Back-up switch When the remote controller become weak, or if the remote controller is lost or malfunctioning, this switch may be used to turn the unit on and off. (a) Operation Push the switch once to place the unit in the automatic mode. Push it once more to turn the unit off. (b) Detail of operation Operation starts in the same way as the previous operation.
  • Page 196 SCM-HG (2 room) (5) Comfort timer setting If the timer is set at ON when the operation select switch is set at the cooling or heating, or the cooling or heating in auto mode operation is selected, the comfort timer starts and determines the starting time of next operation based on the initial value of 15 minutes and the relationship between the room temperature at the setting time (temperature of room temperature thermistor) and the setting temperature.
  • Page 197 SCM-HG (2 room) (c) Operation of Major Functional Components in Cooling Mode Operation Thermostat OFF Thermostat OFF Fan, stop, abnormal stop Failure Functional Cooling (All indoor units) (Some of indoor units) (Some of indoor units) (Outdoor Unit) components Instruction speed See preceding table (All indoor units) (Thermostat off units)
  • Page 198 SCM-HG (2 room) (d) Hot keep operation If the hot keep operation is selected during the heating operation, the indoor fan is controlled based on the temperature of the indoor unit heat exchanger (detected with Th -R, indoor unit heat exchanger thermistor) to prevent blowing of cool wind. ¡...
  • Page 199 SCM-HG (2 room) Operation of function component in defrosting 80 rps Notes (1) Indoor unit fan is Outdoor unit speed Decision speed Decision speed in response to Hot Keep. 0 rps Outdoor unit fan starts 6 seconds af- ter the start of the According to rps compressor.
  • Page 200 SCM-HG (2 room) (9) Control and protection functions (a) Start of protection for compressor When the decision speed becomes a speed other than 0 rps and when the compressor is starting operation, an inverter decision speed of 40 rps or less indicates four-way valve switching protection and a speed of 40 rps or more indicates that protection of the compressor has started.
  • Page 201 SCM-HG (2 room) (e) High pressure cut protection control The high pressure cut protection operates during heating operations when a “heating 0 rps” serial signal is received from one of the two operating indoor units. 1 When only one of two operating units sends a “heating 0 rps”signal. Functional components Operation of each functional components Remarks...
  • Page 202 SCM-HG (2 room) Low Hz continuous operation protection control The following controls are performed to return oil to the compressor when the outdoor unit speed of 28 rps or more to 40 rps or less is continuously operated for 20 minutes. The decision speed is forced to operate at 40 rps for 2 minutes.
  • Page 203 SCM-HG (2 room) Compressor lock If the motor for the compressor does not turn a half a turn approximately 0.3 seconds after it has been started, it is determined that a compressor lock has occurred and the inverter is stopped. (m) Compressor dome thermistor broken wire protection control When the outdoor unit speed is other than 0 rps and after the compressor has started to operate, if after 10 minutes there is a compressor dome thermistor temperature10-second interrupt signal (less than 7 °C), it is immediately placed in...

  • Page 204: Application Data

    SCM-HG (2 room) APPLICATION DATA SAFETY PRECAUTIONS ¡ Please read these “Safety Precautions” first then accurately execute the installation work. ¡ Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.

  • Page 205: Installation Of Indoor Unit

    SCM-HG (2 room) 5.5.1 Installation of indoor unit (a) Caution for installation The system should be applied to places as households, residences and the like. The equipment shall be installed in accordance with national wiring regulations. The connection to the fixed wiring of the mains supply must be made via a double pole isolating switch with a contact gap of at least 3mm in each pole.
  • Page 206 SCM-HG (2 room) Mounting of interconnecting wires (Field wiring) Remove the lid. Remove the terminal block cover. Connect the connection wire securely to the terminal block. Use cables for interconnection wiring to avoid loosening of the wires. CENELEC code for cables Required field cables. RNR4G1.5 (Example) H Harmonized cable type 05 300/500 volts...

  • Page 207: Installation Of Remote Controller

    SCM-HG (2 room) Drainage ¡ The drain hose must be fit with a downward slope. ¡ Do not set the drain hose like the following illustrations. under 5 cm Smell from sewerage drains. Too high It curves like a wave. The end of the The gap to the The end of the...

  • Page 208: Installation Of Outdoor Unit

    SCM-HG (2 room) 5.5.3 Installation of outdoor unit (1) Selection of installation location (Please install with the customer’s consent in a location that follows the conditions listed below.) Where the following installation space is available, and where air does not gather. Where rain and sunlight do not directly hit the unit, and where there is enough air circulation.

  • Page 209: Electrical Wiring

    SCM-HG (2 room) 5.5.4 Electrical wiring Power source UNIT A UNIT B 1 2 3 Out side Circuit breaker Earth leakage breaker 1 2 3 1 2 3 In side UNIT A UNIT B (1) Connection of the power lines This multi-type room air conditioner receives its power from outside.

  • Page 210: Refrigerant Piping

    SCM-HG (2 room) 5.5.5 Refrigerant Piping (1) Limit The maximum permissible length of the refrigerant pipes for the outdoor units, and the maximum permissible height difference for the outdoor units are as shown below. Length for one indoor unit Under 25m Total length for all rooms Under 30m Lower installation spot of the indoor unit A...
  • Page 211 SCM-HG (2 room) Connection Indoor Outdoor Gas side Liquid side Liquid side Gas side ¡ Secure the nut with a specified tightening ¡ Secure the nut with a specified tightening ¡ When air purging with a vacuum pump, torque to avoid any gas leaks. torque to avoid any gas leaks.

  • Page 212: Test Run And Handling Instruction

    SCM-HG (2 room) (5) Heat insulation for joint Heat insulation for joints Finish and fixing Cover the joint with Pipe clamp Apply exterior tape and shape along insulation material Position so Vinyl tape Pipes for the indoor unit the place where the pipes will be rout- the slit Crossover wires and tape it.

  • Page 213: Maintenance Data

    SCM-HG (2 room) MAINTENANCE DATA 5.6.1 Trouble shooting (1) Trouble shooting to be performed prior to exchanging PCB, (Printed circuit board) [Common to all models] All the models described in this chapter are controlled by a microcomputer. When providing maintenance service to customers it is necessary to understand the function controlled by a micro computer thoroughly, so as not to mistakenly identify correct opera- tions as mis-operations.
  • Page 214 SCM-HG (2 room) (2) Indication of self diagnosis Indoor unit indicator Outdoor unit Description of indicator Cause Conditions of flashing trouble (LED 2) RUN lamp TIMER lamp When heat exchanger thermistor temperature of • Broken heat exchanger thermistor –20 °C or under continued for more than 3 Heat exchanger ther- wire 1 time flash...
  • Page 215 SCM-HG (2 room) (3) Inspection procedures corresponding to detail of trouble [Broken thermistor wire, Thermistor error connector poor connection] Is connector connection good? Correct connection. Is sensor resistance value good? Replace thermistor. Replace PCB. Comp. dome thermistor temperature characteristics Thermistor temperature characteristics (Room temperature, indoor unit heat ex- Temperature (˚C) Resistance (kΩ)
  • Page 216 SCM-HG (2 room) [Broken power transistor, Outdoor unit e rror broken compressor wire] Is output voltage applied to all 3 Defective inverter phases of power transistor? Is compressor wiring connected Connect securely. securely? Inspect compressor. (Broken coil wire) [Overload operation, compressor Current safe stop lock, overcharge] Discharge refrigerant.

  • Page 217: Compressor Lock

    SCM-HG (2 room) [Defective fan motor, Outdoor fan motor error defective outdoor PCB] Correct connector Is connector connection good? connection. Is voltage applied to fan motor? Defective outdoor unit (DC) Defective fan motor [Indoor/outdoor printed circuit board defect Serial signal transmission abnormality Outdoor power source abnormality] Possible causes include interference This is due to a tempo-...
  • Page 218 SCM-HG (2 room) (4) Phenomenon observed after shortcircuit, wire breakage on thermistors. (a) Indoor unit Phenomenon Operation Sensor mode Shortcircuit Broken wire Cooling Release of continuous compressor operation command Continuous compressor operation command is not released. Room temperature thermistor Heating Continuous compressor operation command is not released.
  • Page 219 SCM-HG (2 room) (6) Indoor electrical components inspection flowchart Is there voltage between terminal Inspect power source blocks 1 and 2 ? (AC 220/240 V) for outdoor unit. Is the fuse burnt out? (3.15 A) Replace fuse. Is there voltage between CNC (1) Replace the transformer.
  • Page 220 SCM-HG (2 room) (7) Outdoor unit inspection points CAUTION – HIGH VOLTAGE ¡Display lamp inspection • LED 2 (Abnormality display lamp - Red) ON or flashing: Protection function operating High voltage is produced in the control box. Don't touch • LED 1, 3 to 6: (Light display for each ON when there is a serial signal being electrical parts in the control box for 5 minutes after the unit is room - Green)

  • Page 221: Servicing

    SCM-HG (2 room) 5.6.2 Servicing (1) Evacuation The evacuation is an procedure to purge impurities ..noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R22 is very insoluble in water, even a small amount of moisture left in the refrigerant equipment will freeze, causing what is called water clogging.
  • Page 222 SCM-HG (2 room) MEMO...
  • Page 223 SCM-CG SCM-CG (2 room) (2 room) 6. INVERTER MULTI-SPLIT SYSTEM ROOM AIR-CONDITIONER (Air cooled cooling only type) (OUTDOOR UNIT) SCM452CENG-L (INDOOR UNIT) SKM222CENG-L SKM252CENG-L SKM402CENG-L...
  • Page 224 SCM-CG (2 room) CONTENTS GENERAL INFORMATION................ 223 6.1.1 Specific features ................. 223 6.1.2 How to read the model name ............. 223 SELECTION DATA ..................224 6.2.1 Specifications ..................224 6.2.2 Range of usage & limitations ............227 6.2.3 Exterior dimensions ................228 6.2.4 Piping system ..................

  • Page 225: General Information

    SCM-CG (2 room) GENERAL INFORMATION 6.1.1 Specific features (1) Equipped with an inverter scroll compressor. ¡Low noise. Low vibration and compact. (2) The long piping makes the location of the inside and units flexible. ¡No need for additional charge of refrigerant : 20 m ¡Maximum piping length : 30 m (3) Connectable indoor capacity Number of connectable units : 1 to 2 units...

  • Page 226: Selection Data

    SCM-CG (2 room) SELECTION DATA 6.2.1 Specifications (1) Indoor unit Models SKM222CENG-L, 252CENG-L, 402CENG-L Models SKM222CENG-L SKM252CENG-L SKM402CENG-L Item Cooling capacity 2200 2500 4000 Noise level dB (A) Exterior dimensions 250 × 750 × 178 275 × 790 × 174 Height ×...
  • Page 227 SCM-CG (2 room) (2) Outdoor unit Model SCM452CENG-L Model SCM452CENG-L Item Cooling capacity 4500 (2000 ~ 5100) Power source 1 Phase 220/240V 50Hz Power consumption 1820 (680~2050) Running current 8.4/7.7 Noise level dB (A) Exterior dimensions 595 × 720 × 290 Height ×...
  • Page 228 SCM-CG (2 room) (3) Operation data ¡ The combinations of the indoor units is indicated by numbers. They are read as follows. (Example) SKM222CENG / 22 SKM402CENG / 40 ¡ The capacity of the indoor units is shown by rooms. If this exceeds the maximum capacity of the outdoor unit, the demand capacity will be proportionally distributed.

  • Page 229: Range Of Usage & Limitations

    SCM-CG (2 room) 6.2.2 Range of usage & limitations (1) Inlet air temperature (a) Cooling operation Applicable temp. range JIS-Cooling Indoor air temp. ˚C. W. B Note: The chart is result from the continuous operation under constant air temperature conditions, however, excludes the initial pull- down stage.

  • Page 230: Exterior Dimensions

    SCM-CG (2 room) 6.2.3 Exterior dimensions (1) Indoor unit Unit: mm Models SKM222CENG-L, 252CENG-L Room temp. thermistor Piping hole right (left) Terminal block 746.9 Piping for Gas ( 9.52) 370 Ø Piping for Liquid ( 6.35) 420 Ø Piping hole Piping hole Ø...

  • Page 231: Piping System

    SCM-CG (2 room) (2) Outdoor unit Model SCM452CENG-L Drain hole 411.5 2-16×12 Elongated hole Terminal block 88.2 29.7 Liquid line service Gas line service valve B Unit valve B Unit Liquid line service valve A Unit Ground Gas line service terminal valve A Unit 6.2.4 Piping system...

  • Page 232: Electrical Data

    SCM-CG (2 room) ELECTRICAL DATA Meaning of marks • Outdoor Unit Symbol Parts name Symbol Parts name Compressor motor Tho-A Thermistor (outdoor air temp.) Fan motor Tho-R Thermistor (outdoor H.X temp.) Reactor Tho-D Thermistor (comp. dome temp.) Diode stack LED2 Warning lamp (Red) EEVA, B Electric expansion valve...

  • Page 233: Outline Of Operation Control By Microcomputer

    SCM-CG (2 room) (2) Outdoor unit Model SCM452CENG-L UNIT A Serial A Power transistor • 52X2-4 UNIT B Serial B • S. OUT – Fuse 250V 25A R. IN Power source 1 Phase S. IN 220/240V Y/GN LED1 LED3 LED2 50Hz (Green) (Red)
  • Page 234 SCM-CG (2 room) MEMO...

  • Page 235: Scm-C

    SCM-C SCM-C 7. WALL MOUNTED TYPE ROOM AIR- CONDITIONER SPLIT SYSTEM, MULTIPLE TYPE Split system, Air cooled cooling only type SCM328CENF-L1 [SKM258CENF-L] SCM338CENF-L1 [SKM258CENF-L, SKM328CENF-L]...
  • Page 236 SCM-C CONTENTS 7.1 GENERAL INFORMATION ................ 235 7.1.1 Specific features ................. 235 7.1.2 How to read the model name ............. 235 7.2 SELECTION DATA ..................236 7.2.1 Specifications ..................236 7.2.2 Range of usage & limitations ............. 239 7.2.3 Exterior dimensions................240 7.2.4 Piping system ..................

  • Page 237: General Information

    7.1.1 Specific features The “Mitsubishi Daiya” room air conditioner: SKM series are of split and wall mounted type and the unit consists of indoor unit and outdoor unit with refrigerant precharged in factory. The indoor unit is composed of room air cooling equipment with operation control switch and the outdoor unit is composed of condensing unit with compressor.

  • Page 238: Selection Data

    SCM-C SELECTION DATA 7.2.1 Specifications (1) Indoor Unit Models SKM258CENF-L, 328CENF-L Model SKM258CENF-L SKM328CENF-L Item Cooling capacity 2200/2200 2600/2600 Power source 1 Phase, 220/240V, 50Hz Noise level dB (A) 38/39 40/42 Exterior dimensions 275 × 790 × 174 Height × Width × Depth Color Ivory white Net weight...
  • Page 239 SCM-C (2) Outdoor Unit Models SCM328CENF-L1, 338CENF-L1 Model SCM328CENF-L1 SCM338CENF-L1 Item Cooling capacity 2800/2800 2900/2900 Power source 1 Phase, 220/240V, 50Hz Inrush current 16/17 16/17 Noise level dB (A) 44/44 44/44 Exterior dimensions 542 × 795 × 255 Height × Width × Depth Color Polar white Net weight...
  • Page 240 SCM-C (3) Operation data Model SCM328CENF-L1 Cooling Indoor Unit Cooling capacity (kW) Cooling Running input (W) current (A) Total 2.2/2.2 2.2/2.2 730/770 3.4/3.3 3.01/2.86 25 + 25 1.4 + 1.4/1.4 + 1.4 2.8/2.8 770/800 3.6/3.4 3.64/3.50 Model SCM338CENF-L1 Cooling Indoor Unit Cooling capacity (kW) Cooling Running...
  • Page 241 SCM-C 7.2.2 Range of usage & limitations (1) Inlet air temperature (a) Cooling operation Applicable temp. range JIS-Cooling Indoor air temp. ˚C W. B. Note: The chart is result from the continuous operation under constant air temperature conditions. However, excludes the initial pull-down stage. (2) Total one way piping length and vertical height difference.

  • Page 242: Exterior Dimensions

    SCM-C 7.2.3 Exterior dimensions (1) Indoor unit Models SKM258CENF-L, 328CENF-L Unit: mm Room temp. sensor Piping hole right (left) Terminal block Piping for Gas (ø9.52) 390 Piping for Liquid (ø6.35) 440 Drain hose 600 (ø16) Piping hole Piping hole (ø65) VIEW A (ø65) Note (1) Model 25 have no inlet opening...

  • Page 243: Piping System

    SCM-C 7.2.4 Piping system Model SCM328CENF-L1 Indoor B unit Indoor A unit Outdoor unit Cooling cycle Service valve Flare connecting ø9.52 (Gas) (Gas) Discharge Check Thermistor joint Suction ø6.35 Flare connecting (Liquid) Flare connecting Service valve (Liquid) Capillary tube Solenoid valve Model SCM338CENF-L1 SKM258 SKM258...

  • Page 244: Electrical Wiring

    SCM-C 7.3.1 Electrical wiring Model SCM328CENF-L1 Color symbol Indoor unit B Black Blue Brown Orenge Y/GN Yellow/Green White Purple Wireless R-amp Display Printed circuit board Outdoor unit 52X1 Indoor unit A 52RA 52RB 52RB 52RA Power Source 1 Phase 220/240V 50Hz 52X1 20RA...
  • Page 245 SCM-C Model SCM338CENF-L1 Indoor unit A F(3.15A) Wireless R-amp Display Printed circuit board Indoor unit B Indoor unit C MKCE338 52XB 52XC Color symbol 52XC 52XB Black 52XC Blue Brown Orenge 52XB 20RC 52XC 52XC 20RB Y/GN Yellow/Green White Purple Outdoor unit 52X1 52RA...

  • Page 246: Outline Of Operation Control By Microcomputer

    SCM-C OUTLINE OF OPERATION CONTROL BY MICROCOMPUER 7.4.1 Table for operation control Refering page Functions Content – High efficiency, low input rotary compressor Low input rotary compressor with high efficiency is equipped. All operation modes can be operated from distance place by the wireless remote control.
  • Page 247 SCM-C (b) Memory flap • Recommendable stopping angle of the flap While the flap is operating if the AIRFLOW button is pushed once, it stops swinging at an angle. As this angle is memorized in the microcomputer, the flap will be automatically COOL DRY Horizontal blowing...
  • Page 248 SCM-C (4) Operation control function by remote control switch Remote control switch S Operation section OPERATION MODE select button Each time the button is pushed, the ¡ indicator is switched over in turn. ON/OFF button Press for starting operation, press again for stopping.
  • Page 249 SCM-C (a) Comfort timer settings Temperature is checked beginning 1 hour before the set time, and the power is turned on before the timer setting as necessary to bring the temperature to the proper level by the set time. Operating time (amount of time Operation mode Room temp.
  • Page 250 SCM-C (5) DRY operation (a) Choose the appropriate operation block area by the difference between room temperature and thermo- stat setting temperature as shown below. • Operation block area D Block C Block B Block A Block –2 Room temp. – Setting temp.(deg) (b) Start up operation C.D Block A.B Block...
  • Page 251 SCM-C (6) Dew condensation prevention control for cooling operation This prevents dew condensation, in the indoor unit, from occurring. Operating condition: when 52C is kept ON for 30 min, after the unit starts operation. (b) Operation content: forces the indoor fan to change from Speed 1 to Speed 2. Reseting condition: When 52C is off, or when dew condensation prevention control has operating continuously for 30 minutes.

  • Page 252: Application Data

    SCM-C APPLICATION DATA SAFETY PRECAUTIONS ¡ Please read these “Safety Precautions” first then accurately execute the installation work. ¡ Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.

  • Page 253: Selection Of Location For Installation

    SCM-C Remark per EMC Directive 89/336/EEC For to prevent flicker impressions during the start of the compressor (technical proc- ess) following installation conditions do apply. 1. The power connection for the air conditioner has to be done at the main power distribution.

  • Page 254: Installation Of Indoor Unit

    SCM-C (3) Limitations for one way piping length and vertical height difference ¡ SCM328CENF-L1 Outdoor Indoor = 15m max unit unit 5m max Indoor Outdoor unit height Indoor unit 5m max unit Indoor height height unit 5m max 5m max Indoor Outdoor Indoor...
  • Page 255 SCM-C (2) Drilling of holes and fixture sleeve (Option parts) (b) Adjusting sleeve length (a) Drill a hole with ø65 whole core drill Cut off the sleeve collar in case of drawing piping out to rear. Cut off the sleeve coolar that can be Wall thickness seen from beneath...

  • Page 256: Installation Of Outdoor Unit

    SCM-C [When the pipe is extended to left and taken out from the rear center] (Drain pipe relocation procedure) 1. Remove the drain pipe. 2. Remove the drain cap. 3. Insert the drain cap. 4. Connect the drain pipe. ¡ Loosen the spring clamp to ¡...
  • Page 257 SCM-C Installation directions auto selector kit (only for SCM338 model) (1) Selection of installation location (Install at location that meets the following conditions after getting the approval from the customer). Do not install the auto selector kit indoors. A location where rain and snow will not directly strike the kit. A location where servicing space is available.
  • Page 258 SCM-C (3) Mounting of interconnecting wires (Field wiring) Use cable for interconnection wiring to avoid loosening of the wires. CENELEC code for cables required field cables. H05 RNR3AG1.5 Connect the connection wire securely to the terminal block. In wiring, make sure that the wire terminal numbers are matched to the wire terminal numbers of indoor unit terminal block.

  • Page 259: Refrigerant Piping

    SCM-C 7.5.4 Refrigerant piping (1) Preparation Keep the openings of the pipes covered with tapes etc. to prevent dust, sand, etc. from entering them. Indoor unit side Outdoor unit side Dimension A Liquid side (φ6.35): 9-9.5 dia Press Gas side Press (Do not (φ9.52): 13.2-14 dia...

  • Page 260: Test Run

    SCM-C (5) Insulation of connecting portion 1) Cover the connecting portion of the refrigerant piping with the pipe cover and seal them. If neglecting to do so, moisture occurs on the piping and water will drip out. Cover the coupling with insulator Place the slit and then cover it with tape upward...

  • Page 261: Precautions For Wireless Remote Controller Installation And Operation

    SCM-C 7.5.6 Precautions for wireless remote controller installation and operation (1) Wireless remote controller covers the following distances: (a) When operating facing the air conditioner: Notes (1) The remote controller is correctly facing the sensing element of the air conditioner when being manipulated.

  • Page 262: Maintenance Data

    SCM-C MAINTENANCE DATA 7.6.1 Trouble shooting (1) Trouble shooting to be performed prior to exchanging PCB, (Printed circuit board) [Common to all models] All the models described in this chapter are controlled by a microcomputer. When providing maintenance service to customers it is necessary to understand the function controlled by a micro computer thoroughly, so as not to mistakenly identify correct operations as mis-operations.
  • Page 263 SCM-C (2) Indication of Self Diagnosis (Indoor unit) Connect of Defect Place of defect Abnormality of heat RUN lamp is flashing. ¡ Disconnection of heat exchanger thermistor. exchanger thermistor. (1 Time/8 sec.) TIMER lamp RUN lamp is flashing. Abnormality of room ¡...
  • Page 264 SCM-C (4) Trouble shooting chart for the room temperature thermistor (Th ), heat exchanger thermistor (Th Function Unit Sensor Operation Short circuit Broken connection Room temperature Cooling will not operate Continuous Cooling operation • FM1: continuous operation thermistor ) except for •...

  • Page 265: Servicing

    SCM-C 7.6.2 Servicing (1) Evacuation The evacuation is an procedure to purge impurities……noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R22 is very insoluble in water, even a small amount of moisture left in the refriger- ant equipment will freeze, causing what is called water clogging.
  • Page 266 SCM-C MEMO...

  • Page 267: Ceiling Recessed Type Packaged Air-Conditioner

    FDT ( N ) -H FDT ( N ) -H 8. CEILING RECESSED TYPE PACKAGED AIR-CONDITIONER Split system, Air to air heat pump type Refrigerant R22 use models FDTN208HEN-S1 FDT208HEN-SA FDT308HEN-A 308HES-A 258HEN-S1 258HEN-SA 308HEN-SA 408HES-A 308HES-SA 508HES-A 408HES-SA 508HES-SA Alternative refrigerant R407C use models FDTNP208HEN-S 258HEN-S...
  • Page 268 FDT ( N ) -H CONTENTS 8.1 GENERAL INFORMATION ................ 267 8.1.1 Specific features ................. 267 8.1.2 How to read the model name ............. 267 8.2 SELECTION DATA..................268 8.2.1 Specifications ..................268 8.2.2 Range of usage & limitations ............. 286 8.2.3 Exterior dimensions................

  • Page 269: General Information

    FDT ( N ) -H GENERAL INFORMATION 8.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 270: Selection Data

    FDT ( N ) -H SELECTION DATA 8.2.1 Specifications (1) Refrgerant R22 use models (a) Wireless remote controller type Model FDTN208HEN-S1 FDTN208HEN-S1 Model Item FDTN208H FDC208HEN3A Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.78/1.87 Running current (Cooling)
  • Page 271 FDT ( N ) -H Model FDTN258HEN-S1 FDTN258HEN-S1 Model Item FDTN258H FDC258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.05/2.16 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/96 Heating input 1.95/2.10 Running current (Heating) 9.1/9.2 Power factor (Heating)
  • Page 272 FDT ( N ) -H (b) Wired remote controller type Model FDT208HEN-SA FDT208HEN-SA Model Item FDT208-A FDC208HEN3A Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.78/1.87 Running current (Cooling) 8.3/8.1 Power factor (Cooling) 97/96 Heating input 1.74/1.84...
  • Page 273 FDT ( N ) -H Model FDT258HEN-SA FDT258HEN-SA Model Item FDT258-A FDC258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.05/2.16 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/96 Heating input 1.95/2.10 Running current (Heating) 9.1/9.2 Power factor (Heating)
  • Page 274 FDT ( N ) -H Model FDT308HEN-SA FDT308HEN-SA Model Item FDT308-A FDC308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.98/3.18 Running current (Cooling) 13.9/14.4 Power factor (Cooling) 97/92 Heating input 2.84/3.00 Running current (Heating) 13.3/13.7 Power factor (Heating)
  • Page 275 FDT ( N ) -H Model FDT308HES-SA FDT308HES-SA Model Item FDT308-A FDC308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V 50Hz Cooling input 2.90/2.96 Running current (Cooling) 5.1/5.5 Power factor (Cooling) 86/75 Heating input 2.54/2.60 Running current (Heating) 4.6/4.8 Power factor (Heating)
  • Page 276 FDT ( N ) -H Model FDT408HES-SA FDT408HES-SA Model Item FDT408-A FDC408HES3 Nominal cooling capacity 10000 Nominal heating capacity 11200 Power source 3 Phase, 380/415V 50Hz Cooling input 4.50/4.60 Running current (Cooling) 7.8/8.1 Power factor (Cooling) 88/79 Heating input 3.88/3.92 Running current (Heating) 7.1/7.5 Power factor (Heating)
  • Page 277 FDT ( N ) -H Model FDT508HES-SA FDT508HES-SA Model Item FDT508-A FDC508HES3 Nominal cooling capacity 12500 Nominal heating capacity 14000 Power source 3 Phase, 380/415V 50Hz Cooling input 5.30/5.55 Running current (Cooling) 9.5/10.3 Power factor (Cooling) 85/75 Heating input 4.85/4.98 Running current (Heating) 9.0/9.9 Power factor (Heating)
  • Page 278 FDT ( N ) -H Model FDT308HEN-A FDT308HEN-A Model Item FDT308-A FDC306HEN3 Nominal cooling capacity 7100 Nominal heating capacity 7300 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.07/3.11 Running current (Cooling) 15.6/16.3 Power factor (Cooling) 89/79 Heating input 2.82/2.86 Running current (Heating) 14.5/15.2 Power factor (Heating)
  • Page 279 FDT ( N ) -H Model FDT308HES-A FDT308HES-A Model Item FDT308-A FDC306HES3 Nominal cooling capacity ISO-T1 7100/7700 ISO-T3 6000 Nominal heating capacity ISO-T1 7300/7900 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 2.83/2.84/3.35 Running current (Cooling) 5.3/5.3/6.0 Power factor (Cooling) 81/75/85...
  • Page 280 FDT ( N ) -H Model FDT408HES-A FDT408HES-A Model Item FDT408-A FDC406HES3 Nominal cooling capacity ISO-T1 10200/11300 ISO-T3 9900 Nominal heating capacity ISO-T1 10500/11600 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 3.78/3.78/4.65 Runningcurrent (Cooling) 7.5/7.5/8.8 Power factor (Cooling) 77/70/80...
  • Page 281 FDT ( N ) -H Model FDT508HES-A FDT508HES-A Model Item FDT508-A FDC506HES3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 11900 Nominal heating capacity ISO-T1 12800/14400 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 4.87/4.87/5.83 Running current (Cooling) 10.0/10.0/11.0 Power factor (Cooling) 74/68/81...
  • Page 282 FDT ( N ) -H (2) Alternative refrigerant R407C use models (a) Wireless remote controller type Model FDTNP208HEN-S FDTNP208HEN-S Model Item FDTN208H FDCP208HEN3A Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.09/2.16 Running current (Cooling) 9.6/9.7 Power factor (Cooling)
  • Page 283 FDT ( N ) -H Model FDTNP258HEN-S FDTNP258HEN-S Model Item FDTN258H FDCP258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.36/2.56 Running current (Cooling) 11.4/12.6 Power factor (Cooling) 94/85 Heating input 2.10/2.35 Running current (Heating) 10.5/12.0 Power factor (Heating)
  • Page 284 FDT ( N ) -H Model FDTNP308HEN-S FDTNP308HEN-S Model Item FDTN308H FDCP308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.21/3.36 Running current (Cooling) 14.9/15.3 Power factor (Cooling) 98/92 Heating input 2.96/3.10 Running current (Heating) 13.9/14.3 Power factor (Heating)
  • Page 285 FDT ( N ) -H Model FDTNP308HES-S FDTNP308HES-S Model Item FDTN308H FDCP308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V 50Hz Cooling input 3.13/3.28 Running current (Cooling) 5.5/5.8 Power factor (Cooling) 86/79 Heating input 2.98/3.12 Running current (Heating) 5.5/5.8 Power factor (Heating)
  • Page 286 FDT ( N ) -H Model FDTNP408HES-S FDTNP408HES-S Model Item FDTN408H FDCP408HES3 Nominal cooling capacity 10000 Nominal heating capacity 11200 Power source 3 Phase, 380/415V 50Hz Cooling input 4.55/4.67 Running current (Cooling) 8.0/8.4 Power factor (Cooling) 86/77 Heating input 4.39/4.51 Running current (Heating) 7.6/8.4 Power factor (Heating)
  • Page 287 FDT ( N ) -H Model FDTNP508HES-S FDTNP508HES-S Model Item FDTN508H FDCP508HES3 Nominal cooling capacity 12500 Nominal heating capacity 14000 Power source 3 Phase, 380/415V 50Hz Cooling input 5.41/5.48 Running current (Cooling) 9.7/10.0 Power factor (Cooling) 84/76 Heating input 5.29/5.36 Running current (Heating) 9.6/9.9 Power factor (Heating)

  • Page 288: Range Of Usage & Limitations

    FDT ( N ) -H 8.2.2 Range of usage & limitations Models FDTN208, 258 (FDC208, 258 type), FDTNP208~508 (FDCP208~508 type) FDT208~508 (FDC208~508 type) Models FDTN208, 258 (FDC208, 258 type) FDT308~508 (FDC308~508 type) FDT208, 258 (FDC208, 258 type) FDTNP308~508 (FDCP308~508 type) Item FDTNP208, 258 (FDCP208, 258 type) Indoor return air temperature...

  • Page 289: Exterior Dimensions

    FDT ( N ) -H 8.2.3 Exterior dimensions (1) Indoor unit Models FDTN208H, FDT208-A Unit : mm (Ceiling hole size) Decorative Panel Fresh air opening (Suspension bolts for ducting pitch) Exhaust air opening for ducting B→ Indication board Air inlet grille (Only case of FDTN type) Air outlet Drain hose(Accessories)
  • Page 290 FDT ( N ) -H Models FDTN258H, 308H FDT258-A, 308-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille Indication boad (Only case of FDTN type) VIEW A Drain hose (Accessories)
  • Page 291 FDT ( N ) -H Models FDTN408H, 508H FDT408-A, 508-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille Indication board (Only case of FDTN type) VIEW A Drain hose (Accessories)
  • Page 292 FDT ( N ) -H (2) Remote controller (a) Wireless remote controller Unit: mm FILTER AUTO COOL DRY FAN HEAT ¡ Indcation board of indoor unit FAN HI LO ° C MODE TEMP ON/OFF 20.5 (b) Wired remote controller Unit: mm Remote controller mounting dimensions Wall 0.3mm...
  • Page 293 FDT ( N ) -H (3) Outdoor unit Models FDC208HEN3A Unit: mm FDCP208HEN3A Liquid piping: φ 6.35 (1/4") (Flare connecting) Gas piping: φ 15.88 (5/8") (Flare connecting) Liquid piping: φ 6.35 (1/4") (Flare connecting) Terminal block Gas piping: φ 15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for piping and...
  • Page 294 FDT ( N ) -H Models FDC258HEN3A, 308HEN3, 308HES3 FDCP258HEN3A, 308HEN3, 308HES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for...
  • Page 295 FDT ( N ) -H Models FDC408HES3, 508HES3 Unit: mm FDCP408HES3, 508HES3 Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for...
  • Page 296 FDT ( N ) -H Models FDC306HEN3, 306HES3 Unit: mm Anchor bolts (M10 × 4 pcs) Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.
  • Page 297 FDT ( N ) -H Models FDC406HES3, 506HES3 Unit: mm Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.

  • Page 298: Exterior Appearance

    FDT ( N ) -H 8.2.4 Exterior appearance (1) Indoor unit Models All models Item Panel model Remarks Type FDTN208H TN-PSC-22W-E For wireless FDTNP208H remote controller FDTN258H~508H TN-PSC-32W-E FDTNP258H~508H With Auto swing FDT208-A T-PSA-22W-E For wired remote controller FDT258~508-A T-PSA-32W-E Pearl white (Decorative panel) (2) Outdoor unit...

  • Page 299: Piping System

    FDT ( N ) -H 8.2.5 Piping system Models FDTN208HEN-S1, 258HEN-S1, FDTNP208HEN-S, 258HEN-S FDT208HEN-SA, 258HEN-SA Cooling cycle Heating cycle Indoor unit Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer (ø15.88) (Flare connecting) High pressure switch (63H (Only case of FDTNP type)
  • Page 300 FDT ( N ) -H Models FDTNP508HES-S, FDT508HES-SA High pressure switch (63H Cooling cycle (For fan motor control) Indoor unit Outdoor unit Heating cycle 4way valve Thermistor Gas line Strainer Service valve (ø19.05) (Flare connecting) High pressure switch (63H Check joint (Only case of FDTNP type) Heat exchanger...
  • Page 301 FDT ( N ) -H Models FDT408HES-A, 508HES-A Service valve Cooling cycle (Flare connecting) Heating cycle Indoor unit Outdoor unit Check joint High pressure switch (For fan motor control) Strainer Strainer Gas line (ø19.05) 4way valve Check joint Heat Thermistor exchanger Accumlator Heat exchanger...

  • Page 302: Selection Chart

    FDT ( N ) -H 8.2.6 Selection chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures (a) Only case of ISO-T1 models (FDC (P) 208, 258, FDC306~506 type) Indoor air W.B.
  • Page 303 FDT ( N ) -H (C) Only case of ISO-T3 and SASO models Indoor air W.B. temperature (˚CW.B.) ISO-T1 Standard condition ISO-T1 Standard condition Outdoor air W.B. temperature (˚CW.B.) Table of bypass factor Model 208 type 258 type 308 type 408 type 508 type Item...
  • Page 304 FDT ( N ) -H (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 305: Noise Level

    FDT ( N ) -H 8.2.7 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Outdoor unit Indoor unit Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position: at highest noise level Mike position as below...
  • Page 306 FDT ( N ) -H FDC306HEN3 FDC306HES3 FDC408HES3 Model Model Models FDCP408HES3 Noise level 56 dB (A) Noise level 56 dB (A) Noise level 54 dB (A) 1000 2000 4000 8000 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Mid octave band frequency (Hz) FDC406HES3...

  • Page 307: Electrical Data

    FDT ( N ) -H ELECTRICAL DATA 8.3.1 Electrical wiring Models FDTN208HEN-S1, 258HEN-S1...
  • Page 308 FDT ( N ) -H Models FDT208HEN-SA, 258HEN-SA...
  • Page 309 FDT ( N ) -H Model FDT308HEN-SA...
  • Page 310 FDT ( N ) -H Model FDT308HES-SA...
  • Page 311 FDT ( N ) -H Models FDT408HES-SA, 508HES-SA...
  • Page 312 FDT ( N ) -H Model FDT308HEN-A...
  • Page 313 FDT ( N ) -H Model FDT308HES-A...
  • Page 314 FDT ( N ) -H Models FDT408HES-A, 508HES-A...
  • Page 315 FDT ( N ) -H Models FDTNP208HEN-S, 258HEN-S...
  • Page 316 FDT ( N ) -H Model FDTNP308HEN-S...
  • Page 317 FDT ( N ) -H Model FDTNP308HES-S...
  • Page 318 FDT ( N ) -H Models FDTNP408HES-S, 508HES-S...

  • Page 319: Outline Of Operation Control By Microcomputer

    FDT ( N ) -H OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER (1) Wireless remote controller Models FDTN (P), FDEN (P), FDKN (P) series (a) Remote controller Signal sender OPERATION MODE indicator Signals are sent to the air conditioner Indicates selected operation mode CAUTION from here.
  • Page 320 FDT ( N ) -H Model FDEN (P) series Heavy Duty RUN CHECK ON/OFF Remote controller signal receiver RUN LAMP (GREEN) BACK UP SWITCH When the remote controller is miss- Illuminates during operation. ing or defective, this switch can start and stop the air conditioner.
  • Page 321 FDT ( N ) -H (3) Outline of microcomputer control function (a) Operation control function by the indoor controller Automatic operation (Only heat pump type) If the Auto mode is selected on the remote control device, the selection of cooling or heating can be made automatically depending on the room temperature (and the temperature of indoor heat exchanger).
  • Page 322 FDT ( N ) -H Dehumidifying operation (“THERMAL DRY”) The compressor, the indoor fan motor and the outdoor fan motor Operation block are operated intermittently under thermistor (ThI-A) control ac- cording to the appropriate operation block, to provide cooling op- eration for the dehumidifying.
  • Page 323 FDT ( N ) -H FM control with the heating thermostat turned off (For cold draft prevention) (Only heat pump type) In order to prevent a cold draft while the heating thermostat is turned off, the indoor blower is controlled in response to the temperature of the indoor heat exchanger as illustrated below.
  • Page 324 FDT ( N ) -H Condensate pump motor (DM) control (Only FDTN (P), FDT, FDR models) During the cooling or Dehumidifying operation, the condensate pump motor (DM) is synchronized with the start of compressor operation. If the operation is switched from the operation stop, error stop, thermostat stop and the cooling of defrosting operation to the fan or heating operation, the drain motor continues to operate for 2 minutes after the switching.
  • Page 325 FDT ( N ) -H 13) Compressor inching prevention control Compressor 3 minutes delay control The compressor will remain in stop state for three minutes. When the compressor is stopped by thermostat, ON/OFF switch, and/or by occurrence of trouble. When the power source is turned ON, the three-minute delay timer is cancelled. Compressor 3 minutes forced operation control Compressor cannot be stopped for 3 minutes after it started.
  • Page 326 FDT ( N ) -H 17) Drain detection (Only FDTN(P), FDT, FDR models) If there is detection of a drain abnormality during cooling operation, the drain pump goes ON for 5 minutes and the compres- sor which had been running comes to a stop. Overflow detection is carried out at all times with the float switch regardless of operational mode.
  • Page 327 FDT ( N ) -H ¡ At shipping from factory [FDTN (P), FDEN (P), FDKN (P) models : J3 (SW5-3), FDT, FDR, FDU, FDFL models : J5 (SW5-2) ] on PCB OFF] ¡ Input signal to CnT OFF → ON [Edge input] ... Air conditioner ON ¡...
  • Page 328 FDT ( N ) -H ¡ Keeping the louvers horizontal during heating (Only heat pump type) While HOT KEEP is displayed (during hot start operation or when the thermostat has turned off during heating operation), the louvers stay in the horizontal position to prevent cold drafts, independent of the setting of the AUTO SWING key (auto swing or stop).
  • Page 329 FDT ( N ) -H (b) Operation control function by the wired remote controller The following is the sequence of operation for the remote controller operation mode switch. COOL HEAT AUTO (ii) CPU reset This functions when the " inspection " and " filter reset switch " on the remote controller are pushed simultaneously. It operates in the same manner as the power reset.
  • Page 330 FDT ( N ) -H (c) Operation control function by the outdoor controller (Only FDC(P)208~508 type, FDC808, 1008 type) Control for outdoor unit fan a) Cooling Operation The speed of the fan for the outdoor unit is controlled by the temperature of the heat exchanger (Tho-R detection) and the outdoor air temperature (Tho-A).
  • Page 331 FDT ( N ) -H Control of fan for outdoor unit for de-icing Outdoor fan If DIP switch SW5-2 on the printed circuit board for the outdoor unit is set to on, the Outdoor fan stopped operates fan on the outdoor unit which has been stopped will operate for 10 seconds at Hi speed at Hi speed every 10 minutes when the outdoor air temperature is 3 °C or less.
  • Page 332 FDT ( N ) -H Compressor protecting function (Microcomputer and phase protection relay) Overcurrent control When a 52C secondary L -phase continues for 0.5 seconds and when it is more than the set value (detection at current sensor CT), the compressor is stopped. The compressor is restarted after a 3-minute delay if the detection current is less than 1.5 to 2A.
  • Page 333 FDT ( N ) -H High-pressure protection by high-pressure make-or-break device (63H (Only case of FDCP208~508 and FDC808, 1008 type) If the pressure rises and 63H is operated (opened), the compressor is stopped. After a 3-minute delay, the compressor is is opened five times within 60 minutes of the first operation.

  • Page 334: Application Data

    FDT ( N ) -H APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. WARNING and CAUTION , those • Though the precautionary points indicated herein are divided under two headings. points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the WARNING section.

  • Page 335: Installation Of Indoor Unit

    All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATIONS. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or should particular problems occur, the matter should be referred to Mitsubishi Heavy Industries, Ltd. through your local distributor. WARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION.
  • Page 336 FDT ( N ) -H Refrigerant piping (3) Hanging ¡ Arrange four sets of a hang bolt (M10 or M8) , a nut for it, a plain Drain washer and a spring washer on site. Hang bolt When there is the ceiling Washer Main body...
  • Page 337 FDT ( N ) -H Drainage Test Conduct a drainage test after completion of the electrical work. During the trial, make sure that drain flows properly through the piping and that no water leaks from connections. In case of a new building, conduct the test before it is furnished with the ceiling. Be sure to conduct this test even when the unit is installed in the heating season.
  • Page 338 FDT ( N ) -H (6) Cautions for wireless remote conntroller operation As wireless remote controller is operated by infrared rays as a signal, make sure to explain to customers the following matters regarding the operating distance and protection from jamming. ¡...
  • Page 339 FDT ( N ) -H 1) Set necessary functions in accordance with the model of indoor 5) Couple the upper case with the lower case as it was to unit. finish up the installation. Refer to (c) for the setting of functions. 2) Couple the upper case with the lower case as they were.

  • Page 340: Installation Of Outdoor Unit

    FDT ( N ) -H 8.5.3 Installation of outdoor unit OWARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGIN- NING INSTALLATION. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD CAUSE SERIOUS INJURY OR DEATH, EQUIPMENT MALFUNCTION AND/ OR PROPERTY DAMAGE. Models : FDC(P)208~508 type, FDC808, 1008 type (1) Installation (a) Accessories Confirm accessories shown below are attached in the bag with this installation manual.
  • Page 341 FDT ( N ) -H (d) Location where strong wind blows against the unit Install the unit directing the Install the unit directing the Where the foundation is not stable, secure the discharge air port to the wall. discharge air port at a right unit with wire, etc.
  • Page 342 FDT ( N ) -H (3) Refrigerant piping work Select the piping specification to fit the specification of Indoor unit and installation location. (a) Decision of piping specification Piping specification Unit : mm Indoor unit Outdoor unit model Gas pipe Liquid pipe ø...
  • Page 343 FDT ( N ) -H ¡ Take care so that the piping to be worked does not contact the parts contained in the unit. IMPORTANT If it contacts the inner parts, abnormal sound or vibration may occur. (c) Leak test and air purge Perform the procedure according to the following instructions.
  • Page 344 FDT ( N ) -H (e) Refrigerant charge 1) Outdoor unit is pre-charged R-22 and R407C refrigerant at a factory as shown in Table 1. 2) Indoor unit is pre-charged only a small amount of nitrogen gas for prevention of the air entry. 3) Additional charge on site is required when the pipe length is longer than that of restricted value (Which is varied wirh the type of Indoor unit) as shown in Table 1.
  • Page 345 FDT ( N ) -H Following precautions must be observed when the model is adapted to R407C. (1) Tools and related components should be changed when handling a different kind of refrigerant in order to prevent mixing of different oils. Gauge manifold and charge hose, particularly, should never be used after using them for R22.
  • Page 346 FDT ( N ) -H Power source and ground terminal block Wiring clamp ™ Secure the wiring so that no external force is applied to the connecting portion of terminal. Take out direction of wiring ™ Same as the refrigerant piping, 4 directions are allowed, which are right, front, rear and down.
  • Page 347 FDT ( N ) -H Installation where the area with strong winds. Install the unit so that the air outlet section of the unit must not be faced toward wind direction. (c) Installation of outdoor unit Installation Fix the unit in a proper way according to the condition of a place where it is installed by referring to the following. a) Concrete foundation b) Foundation Unit...
  • Page 348 FDT ( N ) -H Air purge Carry out the air purge of the indoor unit and refrigerant piping by vacuuming. Procedures. 1) Tighten all the flare nuts of the piping on the side of indoor and outdoor units so that there is no leakage. 2) Carry out vacuuming from the service valve charge port with the service valves (both liquid and gas side) of the outdoor unit fully closed.
  • Page 349 FDT ( N ) -H Select wire sizes and circuit protection from table below. (This table shows 20 m length wires with less than 2% voltage drop.) Item Circuit breaker Interconnecting and Power source wire size grounding wires (minumum) Switch breaker Overcurrent Protector Phase (minimum)

  • Page 350: Maintenance Data

    FDT ( N ) -H MAINTENANCE DATA 8.6.1 Servicing (1) Evacuation The evacuation is a procedure to purge impurities, such as noncondensable gas, air, moisture from the refrigerant equipment by using a vacuum pump. Since the refrigerant R22 and R407C is very insoluble in water, even a small amount of moisture left in the refrigerant equipment will freeze, causing what is called ice clogging.

  • Page 351: Trouble Shooting For Refrigerant Circuit

    FDT ( N ) -H (2) Refrigerant charging After the evacuation shown in the above, change the connection of the charge hose A to the refrigerant cylinder. Purge air from the charge hose A . First loosen the connecting portion of the charge hose at the gauge manifold side and open valve 3 for a few seconds, and then immediately retighten it after observing that gas has blown out from loosened connecting portion.

  • Page 352: Diagnosing Of Microcomputer Circuit

    FDT ( N ) -H 8.6.3 Diagnosing of microcomputer circuit (1) Selfdiagnosis function (a) Indoor unit side Only case of wireless remote control model. Check indicator table Failure mode on the indoor unit indicated by flashing Yellow LED and Green LED. Indoor unit LED Failure at: Contents of the failure...
  • Page 353 FDT ( N ) -H (3) Error diagnosis procedures at the indoor unit side To diagnose the error, measure the voltage (AC, DC), resistance, etc. at each connector around the circuit board of indoor unit based on the inspection display or the operation state of unit (no operation of compressor or blower, no switching of 4-way valve, etc.).
  • Page 354 FDT ( N ) -H • Function of jumper wires • Function of DIP switched (SW3) Name Function Switch Function With 1 Phase model Power off guaranteed J1(SW5-1) SW3-1 None 3 Phase model No power off guaranteed With Cooling only type With low-voltage detection J2(SW5-2) None...
  • Page 355 FDT ( N ) -H (c) Inspection method when there are fault lamps (display lamps on indoor unit). Only case of wireless remote control model Return air thermistor (Th Indoor unit heat exchanger thermistor Defective indoor unit heat exchanger thermistor Resistance temperature characteristics Indoor unit Defective indoor unit PCB...
  • Page 356 FDT ( N ) -H Abnormality casued by insufficient refrigerant. Are the characteristic values for Replace heat exchanger thermistor. the heat exchanger Indoor unit thermistor OK? Check Lamp (yellow) 5 time flashes Is the amount of refrigerant Charge with refrigerant. circulation good? (If refrige- rant is insufficient, the ca- Replace capillary tubes.
  • Page 357 FDT ( N ) -H [Defective indoor unit heat exchanger thermistor] Error display : Return air thermistor (Th Indoor unit heat exchanger thermistor Resistance temperature characteristics Defective indoor unit PCB Replace- ment (Defective indoor unit heat exchanger thermistor input circuit) Are characteristics Is the indoor of indoor unit heat...
  • Page 358 FDT ( N ) -H [Failure in drainage] Error display : Defective indoor unit PCB Replace- ment (Defective condensate motor output circuit) Is the angle of Is there output Is there any drain piping good. Is there for condensate motor overflow? any problem? (DM)?
  • Page 359 FDT ( N ) -H (4) Outdoor unit side (FDC(P)208~508 type, FDC808, 1008 type) Check Indicator Table Failure mode on the outdoor unit is indicated by flashing both Green LED (LED-G) and Red LED (LED-R) on the printed circuit board. Outdoor unit LED Failure at: Contents of the failure...
  • Page 360 FDT ( N ) -H PCB power supply connector Parts layout on the outdoor unit PCB (Primary side) 63H1 63H1 63H2 63H2 Inspection display lamp CNA1 (LED·Red) Inspection display lamp CNA2 (LED·Green) PCB power supply connector (Secondary side) • Function of DIP switched (SW4) •...
  • Page 361 FDT ( N ) -H (b) Inspection method when there are fault lamps (outdoor unit LED) Open phase at L phase (Primary side) Outdoor unit phase at Red LED 1 time flash Correction primary side at open Green LED Stays OFF phase Defective outdoor unit PCB Replacement...
  • Page 362 FDT ( N ) -H The outdoor heat exchanger temperature is too high (70°C or over) Check the unit side closely Are the heat Outdoor unit Cooling, overload exchanger thermistor • Is outdoor fan motor operating? Red LED 4 time flashes operation? Charateristisc •...
  • Page 363 FDT ( N ) -H Defective outdoor temperature thermistor Outdoor unit Red LED 2 time flashes Green LED 1 time flash Is the outdoor Defective outdoor unit PCB Is the outdoor temperature thermistor Replacement (Defective outdoor air temperature thermistor characteristics OK, is there temperature thermistor input connector connection no broken wire?
  • Page 364 FDT ( N ) -H High pressure error [63H ] (Only case of FDCP208~508 type) Outdoor unit Red LED 4 time flashes Green LED 1 time flash At 63H1 opration • Is the outdoor unit fan motor operating? • Is there no shortcircuit in the outdoor unit? Did 63H operate? •...

  • Page 365: Fdt(N)-C

    FDT ( N ) -C FDT ( N ) -C 9. CEILING RECESSED TYPE PACKAGED AIR-CONDITIONER Split system, Air cooled Cooling only type Refrigerant R22 use models FDT208CEN-SA 258CEN-SA 308CEN-A 308CES-A 408CES-A 508CES-A Alternative refrigerant R407C use models FDTNP208CEN-S 258CEN-S 308CEN-S 308CES-S 408CES-S...
  • Page 366 FDT ( N ) -C CONTENTS 9.1 GENERAL INFORMATION ................ 365 9.1.1 Specific features ................. 365 9.1.2 How to read the model name ............. 365 9.2 SELECTION DATA..................366 9.2.1 Specifications ..................366 9.2.2 Range of usage & limitations ............. 378 9.2.3 Exterior dimensions................

  • Page 367: General Information

    FDT ( N ) -C GENERAL INFORMATION 9.1.1 Specific features Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit.

  • Page 368: Selection Data

    FDT ( N ) -C SELECTION DATA 9.2.1 Specifications (1) Refrigerant R22 use models (a) Wired remote controller type Model FDT208CEN-SA FDT208CEN-SA Model Item FDT208-A FDC208CEN3 Nominal cooling capacity 5000 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.78/1.87 Running current (Cooling) 8.3/8.1 Power factor (Cooling) 97/96...
  • Page 369 FDT ( N ) -C Model FDT258CEN-SA FDT258CEN-SA Model Item FDT258-A FDC258CEN3 Nominal cooling capacity 5700 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.05/2.16 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/96 Inrush current (L.R.A) Noise level dB(A) Hi:39 Lo:35 Unit 260 ×...
  • Page 370 FDT ( N ) -C Model FDT308CEN-A FDT308CEN-A Model Item FDT308-A FDC306CEN3 Nominal cooling capacity ISO-T1 7100 ISO-T3 5700 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.07/3.11 Running current (Cooling) 15.6/16.3 Power factor (Cooling) 89/79 Cooling input 3.26/3.30 Running current (Cooling) 16.6/17.3 Power factor (Cooling) 89/79...
  • Page 371 FDT ( N ) -C Model FDT308CES-A FDT308CES-A Model Item FDT308-A FDC306CES3 Nominal cooling capacity ISO-T1 7100/7700 ISO-T3 5700/6000 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 2.83/2.84/3.35 Running current (Cooling) 5.3/5.3/6.0 Power factor (Cooling) 81/75/85 Cooling input 3.02/3.03/3.58...
  • Page 372 FDT ( N ) -C Model FDT408CES-A FDT408CES-A Model Item FDT408-A FDC406CES3 Nominal cooling capacity ISO-T1 10200/11300 ISO-T3 8900/9900 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 3.78/3.78/4.65 Running current (Cooling) 7.5/7.5/8.8 Power factor (Cooling) 77/70/80 Cooling input 4.12/4.12/5.15...
  • Page 373 FDT ( N ) -C Model FDT508CES-A FDT508CES-A Model Item FDT508-A FDC506CES3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 10600/11900 Power source 3 Phase, 380-415V 50Hz or 380V 50Hz/415V 50Hz, 380V 60Hz Cooling input 4.87/4.87/5.83 Running current (Cooling) 10.0/10.0/11.0 Power factor (Cooling) 74/68/81 Cooling input 5.42/5.42/6.43...
  • Page 374 FDT ( N ) -C (2) Alternative refrigerant R407C use models (a) Wireless remote controller type Model FDTNP208CEN-S FDTNP208CEN-S Model Item FDTN208C FDCP208CEN3 Nominal cooling capacity 5000 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.05/2.11 Running current (Cooling) 9.5/9.6 Power factor (Cooling) 98/92 Inrush current (L.R.A)
  • Page 375 FDT ( N ) -C Model FDTNP258CEN-S FDTNP258CEN-S Model Item FDTN258C FDCP258CEN3 Nominal cooling capacity 5700 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.36/2.55 Running current (Cooling) 11.3/12.4 Power factor (Cooling) 95/86 Inrush current (L.R.A) Noise level dB(A) Hi:39 Lo:35 Unit 260 ×...
  • Page 376 FDT ( N ) -C Model FDTNP308CEN-S FDTNP308CEN-S Model Item FDTN308C FDCP308CEN3 Nominal cooling capacity 7100 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.21/3.36 Running current (Cooling) 14.9/15.3 Power factor (Cooling) 98/92 Inrush current (L.R.A) Noise level dB(A) Hi:41 Lo:35 Unit 260 ×...
  • Page 377 FDT ( N ) -C Model FDTNP308CES-S FDTNP308CES-S Model Item FDTN308C FDCP308CES3 Nominal cooling capacity 7100 Power source 3 Phase, 380/415V, 50Hz Cooling input 3.13/3.28 Running current (Cooling) 5.5/5.8 Power factor (Cooling) 86/79 Inrush current (L.R.A) Noise level dB(A) Hi:41 Lo:35 Unit 260 ×...
  • Page 378 FDT ( N ) -C Model FDTNP408CES-S FDTNP408CES-S Model Item FDTN408C FDCP408CES3 Nominal cooling capacity 10000 Power source 3 Phase, 380/415V, 50Hz Cooling input 4.55/4.67 Running current (Cooling) 8.0/8.4 Power factor (Cooling) 86/77 Inrush current (L.R.A) Noise level dB(A) Hi:48 Lo:40 Unit 320 ×...
  • Page 379 FDT ( N ) -C Model FDTNP508CES-S FDTNP508CES-S Model Item FDTN508C FDCP508CES3 Nominal cooling capacity 12500 Power source 3 Phase, 380/415V, 50Hz Cooling input 5.41/5.48 Running current (Cooling) 9.7/10.0 Power factor (Cooling) 85/76 Inrush current (L.R.A) Noise level dB(A) Hi:49 Lo:43 Unit 320 ×...

  • Page 380: Range Of Usage & Limitations

    FDT ( N ) -C 9.2.2 Range of usage & limitations Models FDT208, 258 (FDC208, 258 type), FDTNP208~508 (FDCP208~508 type) Models FDT208, 258 (FDC208, 258 type) FDTNP308~508 (FDC308~508 type) Item FDTNP208, 258 (FDC208, 258 type) Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits)

  • Page 381: Exterior Dimensions

    FDT ( N ) -C 9.2.3 Exterior dimensions (1) Indoor unit Models FDTN208C FDT208-A Unit : mm (Ceiling hole size) Decorative Panel Fresh air opening (Suspension bolts for ducting pitch) Exhaust air opening for ducting B→ Indication board Air inlet grille (Only case of FDTN type) Air outlet grille Drain hose(Accessories)
  • Page 382 FDT ( N ) -C Models FDTN258C, 308C FDT258-A, 308-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille Indication boad (Only case of FDTN type) VIEW A Drain hose (Accessories)
  • Page 383 FDT ( N ) -C Models FDTN408C, 508C FDT408-A, 508-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille Indication boad (Only case of FDTN type) VIEW A Drain hose (Accessories)
  • Page 384 FDT ( N ) -C (2) Remote controller (a) Wireless remote controller Unit: mm FILTER AUTO COOL DRY FAN HEAT FAN HI LO ° C Indication board of indoor unit MODE TEMP ON/OFF 20.5 Unit: mm (b) Wired remote controller(Optional parts) Wall 0.3mm , 3cores (O.D.φ5.6)
  • Page 385 FDT ( N ) -C (3) Outdoor unit Models FDC208CEN3, FDCP208CEN3 Unit: mm Liquid piping: φ6.35 (1/4˝) (Flare connecting) Gas piping: φ15.88 (3/8˝) (Flare connecting) Liquid piping: φ6.35 (1/4˝) (Flare connecting) Terminal block Gas piping: φ15.88 (3/8˝) (Flare connecting) Opening for electric wiring Opening for piping and electric wiring Opening for piping and...
  • Page 386 FDT ( N ) -C Models FDC258CEN3, FDCP258CEN3, 308CEN3, 308CES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring...
  • Page 387 FDT ( N ) -C Models FDCP408CES3, 508CES3 Unit: mm Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring...
  • Page 388 FDT ( N ) -C Models FDC306CEN3, 306CES3 Unit: mm Minimum allowable space to the obstacles Required space for maintenance and air flow Unit:mm inlet Installation type 500 mm Obstacles Mark Open Open inlet Open Maintenance outlet space Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.
  • Page 389 FDT ( N ) -C Models FDC406CES3, 506CES3 Unit: mm Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet. (3) Free space over the unit must be larger than 1 m.

  • Page 390: Exterior Appearance

    FDT ( N ) -C 9.2.4 Exterior appearance (1) Indoor unit Models All models Item Panel model Remarks Type FDTN208C TN-PSC-22W-E For wireless remote controller FDTN258C~508C TN-PSC-32W-E Without swing FDT208-A T-PSA-22W-E For wired remote controller FDT258-A~508-A T-PSA-32W-E Pearl white (Decorative panel) (2) Outdoor unit Models FDC258CEN3 Models FDC208CEN3, FDCP208CEN3...

  • Page 391: Piping System

    FDT ( N ) -C 9.2.5 Piping system Models FDT208CEN-SA, 258CEN-SA FDTNP208CEN-S, 258CEN-S Check joint Service valve Indoor unit Outdoor unit (Flare connecting) Thermistat (Tho-A) High pressure Gas line (φ15.88) switch (63H1) Only case of FDTNP type Thermistor –A) Thermistat Heat Caillary tabe exchanger...
  • Page 392 FDT ( N ) -C Models FDT308CEN-A, 308CES-A, 408CES-A, 508CES-A Indoor unit Outdoor unit 308: ø15.88 408, 508: ø19.05 (ø9.52) Model FDTNP508CES-S Indoor unit Outdoor unit High pressure switch (63H1) Check joint Thermistor (Tho-A) Oil separator Gas line Service valve ( ø19.05) (Flare connecing) Caillary...

  • Page 393: Selection Chart

    FDT ( N ) -C 9.2.6 Selection chart Correct the cooling capacity in accordance with the conditions as follows. The net cooling capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling capacity in relation to temperatures (a) Only case of ISO-T1 models (FDT208~508, FDTNP208, 258 type) Applicable range...
  • Page 394 FDT ( N ) -C (b) Only case of ISO-T3 and SASO models ISO-T1 Standard condition Indoor air W.B. temperature (˚CW.B.) Table of bypass factor Model 208 type 258 type 308 type 408 type 508 type Item 0.112 0.050 0.065 0.076 0.025 Air flow...
  • Page 395 FDT ( N ) -C (3) Correction of cooling capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 396: Noise Level

    FDT ( N ) -C 9.2.7 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Outdoor unit Indoor unit Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position: at highest noise level Mike position as below...
  • Page 397 FDT ( N ) -C FDC306CES3 FDC406CES3 FDC506CES3 Model Model Model Noise level 59 dB (A) Noise level 57dB (A) Noise level 59 dB (A) 1000 2000 4000 8000 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Mid octave band frequency (Hz) Model...

  • Page 398: Electrical Data

    FDT ( N ) -C ELECTRICAL DATA 9.3.1 Electrical wiring Models FDT208CEN-SA, 258CEN-SA...
  • Page 399 FDT ( N ) -C Model FDT308CEN-A...
  • Page 400 FDT ( N ) -C Model FDT308CES-A...
  • Page 401 FDT ( N ) -C Models FDT408CES-A, 508CES-A...
  • Page 402 FDT ( N ) -C Models FDTNP208CEN-S, 258CEN-S, 308CEN-S...
  • Page 403 FDT ( N ) -C Model FDTNP308CES-S...
  • Page 404 FDT ( N ) -C Models FDTNP408CES-S, 508CES-S...

  • Page 405: Outline Of Operation Control By Microcomputer

    FDT ( N ) -C OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Except for function relating to heating, same at the unit for FDT(N) heat pump type. See page 317. APPLICATION DATA The application data for the cooling only models are similar to those for the heat pump models. (See page 332.) MAINTENANCE DATA Same at the cooling /heating equipment FDT(N) heat pump type.
  • Page 406 FDT ( N ) -C MEMO...

  • Page 407: Fden-H

    FDEN-H FDEN-H SRK-H 2. WALL MOUNTED TYPE ROOM 10. CEILING SUSPENSION TYPE AIR-CONDITIONER PACKAGED AIR-CONDITIONER Split system, Air to air Split system, Air to air heat pump type heat pump type SRK328HENF-L2, SRK408HENF-L2 Refrigerant R22 use models SRK501HENF-L, SRK561HENF-L FDEN 208HEN-S1 258HEN-S1 Alternative refrigerant R407C use models FDENP208HEN-S...
  • Page 408 FDEN-H CONTENTS 10.1 GENERAL INFORMATION ................ 407 10.1.1 Specific features ................. 407 10.1.2 How to read the model name ............. 407 10.2 SELECTION DATA..................408 10.2.1 Specifications ..................408 10.2.2 Range of usage & limitations ............. 416 10.2.3 Exterior dimensions................417 10.2.4 Exterior appearance................

  • Page 409: General Information

    FDEN-H 10.1 GENERAL INFORMATION 10.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 410: Selection Data

    FDEN-H 10.2 SELECTION DATA 10.2.1 Specifications (1) Refrigerant R22 use models Model FDEN208HEN-S1 FDEN208HEN-S1 Model Item FDEN208H FDC208HEN3A Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.77/1.86 Running current (Cooling) 8.2/8.0 Power factor (Cooling) 98/97 Heating input 1.73/1.83...
  • Page 411 FDEN-H Model FDEN258HEN-S1 FDEN258HEN-S1 Model Item FDEN258H FDC258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.04/2.15 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/95 Heating input 1.94/2.09 Running current (Heating) 9.1/9.2 Power factor (Heating) 97/95 Inrush current (L.R.A)
  • Page 412 FDEN-H (2) Alternative refrigerant R407C use models Model FDENP208HEN-S FDENP208HEN-S Model Item FDEN208H FDCP208HEN3A Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.08/2.15 Running current (Cooling) 9.5/9.6 Power factor (Cooling) 99/93 Heating input 1.98/2.12 Running current (Heating) 9.3/9.5...
  • Page 413 FDEN-H Model FDENP258HEN-S FDENP258HEN-S Model Item FDEN258H FDCP258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.35/2.55 Running current (Cooling) 11.4/12.6 Power factor (Cooling) 94/84 Heating input 2.09/2.34 Running current (Heating) 10.5/12.0 Power factor (Heating) 90/81 Inrush current (L.R.A)
  • Page 414 FDEN-H Model FDENP308HEN-S FDENP308HEN-S Model Item FDEN308H FDCP308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.22/3.37 Running current (Cooling) 14.9/15.3 Power factor (Cooling) 98/92 Heating input 2.97/3.11 Running current (Heating) 13.9/14.3 Power factor (Heating) 97/91 Inrush current (L.R.A)
  • Page 415 FDEN-H Model FDENP308HES-S FDENP308HES-S Model Item FDEN308H FDCP308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V 50Hz Cooling input 3.14/3.29 Running current (Cooling) 5.5/5.8 Power factor (Cooling) 87/79 Heating input 2.99/3.13 Running current (Heating) 5.5/5.8 Power factor (Heating) 83/75 Inrush current (L.R.A)
  • Page 416 FDEN-H Model FDENP408HES-S FDENP408HES-S Model Item FDEN408H FDCP408HES3 Nominal cooling capacity 10000 Nominal heating capacity 11200 Power source 3 Phase, 380/415V 50Hz Cooling input 4.51/4.63 Running current (Cooling) 7.8/8.2 Power factor (Cooling) 88/79 Heating input 4.35/4.47 Running current (Heating) 7.8/8.2 Power factor (Heating) 85/76 Inrush current (L.R.A)
  • Page 417 FDEN-H Model FDENP508HES-S FDENP508HES-S Model Item FDEN508H FDCP508HES3 Nominal cooling capacity 12500 Nominal heating capacity 14000 Power source 3 Phase, 380/415V 50Hz Cooling input 5.36/5.43 Running current (Cooling) 9.5/9.8 Power factor (Cooling) 86/77 Heating input 5.24/5.31 Running current (Heating) 9.4/9.7 Power factor (Heating) 84/76 Inrush current (L.R.A)

  • Page 418: Range Of Usage & Limitations

    FDEN-H 10.2.2 Range of usage & limitations Models FDENP208, 258 type FDENP308~508 type Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Max. 30 m Max. 50 m Refrigerant line (one way) length Max.

  • Page 419: Exterior Dimensions

    FDEN-H 10.2.3 Exterior dimensions (1) Indoor unit Models FDEN208H, 258H, 308H Unit: mm Holes for suspension bolts When the unit is half (12 × 17 × 4 pcs.) recessed above the ceiling When the unit is suspended beneath the ceiling (Automatic louver) Indication board Drain (Connectable with VP20)
  • Page 420 FDEN-H Unit: mm Models FDEN408H, 508H 1451 [1244] The brackets face out Holes for When the unit is half suspension bolts recessed above the ceiling (12 × 17 × 4pcs.) 1370 [1160] The brackets face interior When the unit is sus- pended beneath the ceiling 1410 [1200] Side panel...
  • Page 421 FDEN-H (2) Remote controller (a) Wireless remote controller Unit: mm FILTER AUTO COOL DRY FAN HEAT FAN HI LO ° C MODE TEMP ON/OFF 20.5 (b) Indication board of indoor unit Remote controller signal receiver...
  • Page 422 FDEN-H (3) Outdoor unit Models, FDC208HEN3A, FDCP208HEN3A Unit: mm Liquid piping:ø6.35 (1/4") (Flare connecting) Gas piping:ø15.88 (5/8") (Flare connecting) Liquid piping:ø6.35 (1/4") (Flare connecting) Terminal block Gas piping:ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for piping and Opening for piping electric wiring and electric wiring Electric wiring...
  • Page 423 FDEN-H Models FDC258HEN3A, FDCP258HEN3A, 308HEN3, 308HES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping...
  • Page 424 FDEN-H Models FDCP408HES3, 508HES3 Unit: mm Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...

  • Page 425: Exterior Appearance

    FDEN-H 10.2.4 Exterior appearance (1) Indoor unit Model All models Gray Ceramic white Ceramic white (Vertical lins) (Front panel) (Side panel) Gray Ceramic white Ceramic white (Frame) (Air inlet louver) (Front panel) (2) Outdoor unit Models FDC208HEN3A Models FDC258HEN3A Models FDCP408HES3 FDCP208HEN3A FDCP258HEN3A 508HES3...

  • Page 426: Piping System

    FDEN-H 10.2.5 Piping system Models FDEN208HEN-S1, 258HEN-S1 FDENP208HEN-S, 258HEN-S Cooling cycle Heating cycle Indoor unit Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer (ø15.88) (Flare connecting) High pressure switch (63H (Only case Heat exchanger of FDENP model)
  • Page 427 FDEN-H Model FDENP508HES-S High pressure switch (63H Cooling cycle (For fan motor control) Indoor unit Outdoor unit Heating cycle 4 way valve Thermistor Gas line Service valve Strainer (Flare connecting) (ø19.05) High pressure switch (63H Check joint Heat exchanger Capillary tube Thermistor Check joint Oil separator...
  • Page 428 FDEN-H 10.2.6 Selsction chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification ¥ Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures Models FDEN208HEN-S1, 258HEN-S1, FDENP208HEN-S, 258HEN-S Indoor air W.B.
  • Page 429 FDEN-H Table of bypass factor Model FDEN (P) 208 type FDEN (P) 258 type FDENP308 type FDENP408,508 type Item 0.031 0.030 0.036 0.018 Air flow 0.016 0.013 0.018 0.010 (2) Correction of cooling and heating capacity in relation to air flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor...

  • Page 430: Noise Level

    FDEN-H 10.2.7 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Outdoor unit Indoor unit Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position: at highest noise level Mike position as below in position as below...
  • Page 431 FDEN-H Model FDCP208HEN3A Model FDCP258HEN3A Models FDCP308HEN3, 308HES3 Noise level 52dB (A) Noise level Noise level 52dB (A) 52dB (A) 1000 2000 4000 8000 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Mid octave band frequency (Hz) Model FDCP408HES3 Model FDCP508HES3...

  • Page 432: Electrical Data

    FDEN-H 10.3 ELECTRICAL DATA 10.3.1 Electrical wiring Models FDEN208HEN-S1, 258HEN-S1...
  • Page 433 FDEN-H Models FDENP208HEN-S, 258HEN-S...
  • Page 434 FDEN-H Model FDENP308HEN-S...
  • Page 435 FDEN-H Model FDENP308HES-S...
  • Page 436 FDEN-H Model FDENP408HES-S, 508HES-S...

  • Page 437: Outline Of Operation Control By Microcomputer

    FDEN-H 10.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Same as the cooling/heating equipment for FDT(N) heat pump type. Refer to page 317. 10.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. •...

  • Page 438: Installation Of Indoor Unit

    All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATIONS. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or should particular problems occur, the matter should be referred to Mitsubishi Heavy Industries. Ltd. through your local distributor.
  • Page 439 FDEN-H (3) Installation of indoor unit (a) Detach the inside panel and suspension bracket. Remove a fixing bolt of the side panel. Unhook four hooks (marked ) by sliding the side panel in front side about 10 mm, and detach the side panel from the unit.
  • Page 440 FDEN-H Mount the unit using suspension bolts. Suspension bolts Flat washer (accessory parts) Hexagonal nuts (accessory parts) Securely tighten the nuts and fix the indoor unit in place. Attach the side panels and fit in ceiling board in the space around the unit and the work is finished. Fit in ceiling boards here (d) Gradient for drainage Mounting with proper gradient for drainage is needed as shown below.

  • Page 441: Installation Of Outdoor Unit

    FDEN-H 10.5.2 Installation of outdoor unit This is same as FDT(N) heat pump series. Refer to page 338. 10.6 MAINTENANCE DATA This is same as FDT(N) heat pump series. Refer to page 348.
  • Page 442 FDEN-H MEMO...

  • Page 443: Ceiling Suspension Type Packaged Air-Conditioner

    FDEN-C FDEN-C 11. CEILING SUSPENSION TYPE PACKAGED AIR-CONDITIONER Split system, Air cooled cooling only type Alternative refrigerant R407C use models FDENP208CEN-S 258CEN-S 308CEN-S 308CES-S 408CES-S 508CES-S...
  • Page 444 FDEN-C CONTENTS 11.1 GENERAL INFORMATION ............... 443 11.1.1 Specific features ................443 11.1.2 How to read the model name ............443 11.2 SELECTION DATA..................444 11.2.1 Specifications ..................444 11.2.2 Range of usage & limitations ............450 11.2.3 Exterior dimensions ................451 11.2.4 Exterior appearance ................

  • Page 445: General Information

    FDEN-C 11.1 GENERAL INFORMATION 11.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 446: Selection Data

    FDEN-C 11.2 SELECTION DATA 11.2.1 Specifications Model FDENP208CEN-S FDENP208CEN-S Model Item FDEN208C FDCP208CEN3 Nominal cooling capacity 5000 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.04/2.10 Running current (Cooling) 9.4/9.5 Power factor (Cooling) 99/92 Inrush current (L.R.A) Noise level dB(A) Hi:43 Lo:38 Exterior dimensions 184 ×...
  • Page 447 FDEN-C Model FDENP258CEN-S FDENP258CEN-S Model Item FDEN258C FDCP258CEN3 Nominal cooling capacity 5700 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.35/2.54 Running current (Cooling) 11.3/12.4 Power factor (Cooling) 95/85 Inrush current (L.R.A) Noise level dB(A) Hi:44 Lo:39 Exterior dimensions 184 × 1260 × 650 845 ×...
  • Page 448 FDEN-C Model FDENP308CEN-S FDENP308CEN-S Model Item FDEN308C FDCP308CEN3 Nominal cooling capacity 7100 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.22/3.37 Running current (Cooling) 14.9/15.3 Power factor (Cooling) 98/92 Inrush current (L.R.A) Noise level dB(A) Hi:45 Lo:39 Unit 260 × 840 × 840 Exterior dimensions 184 ×...
  • Page 449 FDEN-C Model FDENP308CES-S FDENP308CES-S Model Item FDEN308C FDCP308CES3 Nominal cooling capacity 7100 Power source 3 Phase, 380/415V, 50Hz Cooling input 3.14/3.29 Running current (Cooling) 5.5/5.8 Power factor (Cooling) 87/79 Inrush current (L.R.A) Noise level dB(A) Hi:45 Lo:39 Unit 260 × 840 × 840 Exterior dimensions 184 ×...
  • Page 450 FDEN-C Model FDENP408CES-S FDENP408CES-S Model Item FDEN408C FDCP408CES3 Nominal cooling capacity 10000 Power source 3 Phase, 380/415V, 50Hz Cooling input 4.51/4.63 Running current (Cooling) 7.8/8.2 Power factor (Cooling) 88/79 Inrush current (L.R.A) Noise level dB(A) Hi:49 Lo:43 Unit 260 × 840 × 840 Exterior dimensions 239 ×...
  • Page 451 FDEN-C Model FDENP508CES-S FDENP508CES-S Model Item FDEN508C FDCP508CES3 Nominal cooling capacity 12500 Power source 3 Phase, 380/415V, 50Hz Cooling input 5.36/5.43 Running current (Cooling) 9.5/9.8 Power factor (Cooling) 86/77 Inrush current (L.R.A) Noise level dB(A) Hi:50 Lo:44 Unit 260 × 840 × 840 Exterior dimensions 239 ×...

  • Page 452: Range Of Usage & Limitations

    FDEN-C 11.2.2 Range of usage & limitations Models FDENP208, 258 type FDENP308, 408, 508 type Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Refrigerant line (one way) length Max. 30m Max.

  • Page 453: Exterior Dimensions

    FDEN-C 11.2.3 Exterior dimensions (1) Indoor unit Models FDEN208C, 258C, 308C Unit: mm Holes for suspension bolts When the unit is half (12 × 17 × 4 pcs.) recessed above the ceiling When the unit is suspended beneath the ceiling (Automatic louver) Indication board Drain (Connectable with VP20)
  • Page 454 FDEN-C Unit: mm Models FDEN408C, 508C 1451 [1244] The brackets face out Holes for When the unit is half suspension bolts recessed above the ceiling (12 × 17 × 4pcs.) 1370 [1160] The brackets face interior When the unit is sus- pended beneath the ceiling 1410 [1200] Side panel...
  • Page 455 FDEN-C Unit: mm (2) Remote controller (a) Wireless remote controller FILTER COOL DRY FAN FAN HI LO ° C MODE TEMP ON/OFF 20.5 (b) Indication board of indoor unit Remote controller signal receiver...
  • Page 456 FDEN-C (3) Outdoor unit Model FDCP208CEN3 Unit: mm Liquid piping: φ 6.35 (1/4") (Flare connecting) Gas piping: φ 15.88 (5/8") (Flare connecting) Liquid piping: φ 6.35 (1/4") (Flare connecting) Terminal block Gas piping: φ 15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for piping and electric wiring Opening for piping...
  • Page 457 FDEN-C Models FDCP258CEN3, 308CEN3, 308CES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping and electric wiring...
  • Page 458 FDEN-C Unit: mm Models FDCP408CES3, 508CES3 Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...

  • Page 459: Exterior Appearance

    FDEN-C 11.2.4 Exterior appearance (1) Indoor unit Models All models Gray Ceramic white Ceramic white (Vertical lins) (Front panel) (Side panel) Gray Ceramic white Ceramic white (Frame) (Air inlet grill) (Front panel) (2) Outdoor unit Model FDCP208CEN3 Models FDCP258CEN3, 308CEN3, Models FDCP408CES3, 508CES3 308CES3 Polar white...

  • Page 460: Piping System

    FDEN-C 11.2.5 Piping system Models FDENP208CEN-S, 258CEN-S Check joint Service valve Indoor unit Outdoor unit (Flare connecting) Thermistat (Tho-A) High pressure Gas line (φ15.88) switch (63H1) Thermistor –A) Thermistat Heat Caillary tabe (Tho-D) exchanger Heat exchanger Thermistor Solenoid Thermistat valve (Tho-R) –R) Compressor...
  • Page 461 FDEN-C Model FDENP508CES-S Otutdoor unit Indoor unit Check joint High pressure switch (63H1) Thermistor (Tho-A) Oil separator Gas line Service valve ( ø19.05) (Flare connecing) Caillary Heat tube exchanger Thermistor Thermistor (Tho-D) Thermistor Heat (Tho-R) exchanger Accumulator Compressor Capillary Thermistor Solenoid valve tube Liquid line...

  • Page 462: Selection Chart

    FDEN-C 11.2.6 Selection chart Correct the cooling capacity in accordance with the conditions as follows. The net cooling capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling capacity in relation to temperatures Models FDENP208CEN-S, 258CEN-S Applicable range ISO-T1 Standard condition...
  • Page 463 FDEN-C Table of bypass factor Model FDEN208C FDEN258C FDEN308C FDEN408,508C Item 0.031 0.030 0.036 0.018 Air flow 0.016 0.013 0.018 0.010 (2) Correction of cooling capacity in relation to flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 464: Noise Level

    FDEN-C 11.2.7 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Outdoor unit Indoor unit Unit Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position: at highest noise level Mike position as below in position as below...

  • Page 465: Electrical Data

    FDEN-C 11.3 ELECTRICAL DATA 11.3.1 Electrical wiring Model FDENP208CEN-S...
  • Page 466 FDEN-C Models FDENP258CEN-S, 308CEN-S...
  • Page 467 FDEN-C Model FDENP308CES-S...
  • Page 468 FDEN-C Models FDENP408CES-S, 508CES-S...

  • Page 469: Outline Of Operation Control By Microcomputer

    FDEN-C 11.4 OUTLINE OF OPERATION CONTROL BY MICROCOM- PUTER Except for function relating to heating, same as the unit for FDT(N) heat pump type. See page 317. 11.5 APPLICATION DATA The application data for the cooling only models are similar to those for the heat pump models. (See page 435.) 11.6 MAINTENANCE DATA Same as the cooling /heating equipment for FDT(N) heat pump type.
  • Page 470 FDEN-C MEMO...

  • Page 471: Wall Mounted Type Packaged Air-Conditioner

    FDKN-H FDKN-H FDKN-H 12. WALL MOUNTED TYPE PACKAGED AIR-CONDITIONER Split system, Air to air heat pump type Refrigerant R22 use models FDKN208HEN-S1 258HEN-S1 Alternative refrigerant R407C use models FDKNP208HEN-S 258HEN-S 308HEN-S 308HES-S...
  • Page 472 FDKN-H CONTENTS 12.1 GENERAL INFORMATION ................ 471 12.1.1 Specific features ................. 471 12.1.2 How to read the model name ............. 471 12.2 SELECTION DATA..................472 12.2.1 Specifications ..................472 12.2.2 Range of usage & limitations ............. 478 12.2.3 Exterior dimensions................479 12.2.4 Exterior appearance................

  • Page 473: General Information

    FDKN-H 12.1 GENERAL INFORMATION 12.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 474: Selection Data

    FDKN-H 12.2 SELECTION DATA 12.2.1 Specifications (1) Refrigent R22 use models Model FDKN208HEN-S1 FDKN208HEN-S1 Model Item FDKN208H FDC208HEN3A Nominal cooling capacity 4850 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.76/1.85 Running current (Cooling) 8.2/8.0 Power factor (Cooling) 98/96 Heating input 1.72/1.82...
  • Page 475 FDKN-H Model FDKN258HEN-S1 FDKN258HEN-S1 Model Item FDKN258H FDC258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.03/2.14 Running current (Cooling) 9.3/9.3 Power factor (Cooling) 99/96 Heating input 1.93/2.08 Running current (Heating) 9.0/9.1 Power factor (Heating) 97/95 Inrush current (L.R.A)
  • Page 476 FDKN-H (2) Alternative refrigerant R407C use models Model FDKNP208HEN-S FDKNP208HEN-S Model Item FDKN208H FDCP208HEN3A Nominal cooling capacity 4850 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.07/2.14 Running current (Cooling) 9.5/9.6 Power factor (Cooling) 99/93 Heating input 1.97/2.11 Running current (Heating) 9.3/9.5...
  • Page 477 FDKN-H Model FDKNP258HEN-S FDKNP258HEN-S Model Item FDKN258H FDCP258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.34/2.54 Running current (Cooling) 11.3/12.5 Power factor (Cooling) 94/85 Heating input 2.08/2.33 Running current (Heating) 10.4/11.9 Power factor (Heating) 91/82 Inrush current (L.R.A)
  • Page 478 FDKN-H Model FDKNP308HEN-S FDKNP308HEN-S Model Item FDKN308H FDCP308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.18/3.33 Running current (Cooling) 14.8/15.2 Power factor (Cooling) 98/91 Heating input 2.93/3.07 Running current (Heating) 13.8/14.2 Power factor (Heating) 97/90 Inrush current (L.R.A)
  • Page 479 FDKN-H Model FDKNP308HES-S FDKNP308HES-S Model Item FDKN308H FDCP308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V, 50Hz Cooling input 3.10/3.25 Running current (Cooling) 5.4/5.7 Power factor (Cooling) 87/79 Heating input 2.95/3.09 Running current (Heating) 5.4/5.7 Power factor (Heating) 82/75 Inrush current (L.R.A)
  • Page 480 FDKN-H 12.2.2 Renge of usage & limitations Models FDKN (P) 208, 258 type FDKNP308 type Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Refrigerant line (one way) length Max. 30 m Max.

  • Page 481: Exterior Dimensions

    FDKN-H 12.2.3 Exterior dimensions (1) Indoor unit Unit : mm Model FDKN208H Mounting plate Outer for electric wiring Remote controller Lower piping outlet signal receives (Refer to the top view.) Outlet for piping (On both side) Indoor unit Mounting plate 50 50 50 50 Gas piping...
  • Page 482 FDKN-H Model FDKN258H Unit: mm Mounting plate Outer for electric wiring Remote controller Lower piping outlet signal receives (Refer to the top view.) Outlet for piping (On both side) Indoor unit Mounting plate 50 50 50 50 Drain hose (VP16) Hole on wall for Liquid piping Hole on wall for...
  • Page 483 FDKN-H Model FDKN308H Unit : mm 1145 1155 Mounting plate Outlet for electric wiring Lower piping outlet Remote controller (Refer to the top view) signal receives Outlet for piping Indoor unit Mounting plate (On both side) 1047 4 - 5.5 8 - 12 (Long hole) (Long hole)
  • Page 484 FDKN-H (2) Wireless remote controller Unit: mm FILTER AUTO COOL DRY FAN HEAT FAN HI LO ° C MODE TEMP ON/OFF 20.5 (3) Indication board of indoor unit...
  • Page 485 FDKN-H (4) Outdoor unit Models FDC208HEN3A Unit : mm FDCP208HEN3A Liquid piping φ6.35 (1/4˝) (Flare connecting) Gas piping: φ15.88 (5/8˝) (Flare connecting) Liquid piping: φ6.35 (1/4˝) (Flare connecting) Terminal block Gas piping: φ15.88 (5/8˝) (Flare connecting) Opening for electric wiring Opening for piping and electric wiring Opening for piping...
  • Page 486 FDKN-H Models FDC258HEN3A FDCP258HEN3A, 308HEN3, 308HES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping...

  • Page 487: Exterior Appearance

    FDKN-H 12.2.4 Exterior appearance (1) Indoor unit Models All models Ivory white (Front panel) Ivory white (Air inlet grill) Ivory white (Base) Ivory white (Louver) (2) Outdoor unit Models FDC208HEN3A Models FDC258HEN3A FDCP208HEN3A FDCP258HEN3A, 308HEN3, 308HES3 Polar white Polar white...

  • Page 488: Piping System

    FDKN-H 12.2.5 Piping system Models FDKN208HEN-S1, 258HEN-S1, FDKNP208HEN-S, 258HEN-S Cooling cycle Heating cycle Indoor unit Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer (ø15.88) (Flare connecting) High pressure switch (63H Only case of Heat exchanger FDKNP model...
  • Page 489 FDKN-H Preset point of the protective devices Parts name Mark Equipped unit FDKN208, 258 type FDKNP208~308 type Thermistor 68 °C (for protection over loading in 61 °C heating) Indoor unit 2.5 °C Thermistor 10 °C (for frost prevention) Thermistor 135 °C (for detecting discharge pipe Outdoor unit 90 °C...

  • Page 490: Selection Chart

    FDKN-H 12.2.6 Selection chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures Models FDKN208HEN-S1, 258HENS-1, FDKNP208HEN-S, 258HEN-S Indoor air W.B.
  • Page 491 FDKN-H Table of bypass factor Model FDKN (P) 208 type FDKN (P) 258 type FDKNP308 type Item Air flow 0.03 0.03 0.04 (2) Correction of cooling and heating capacity in relation to air flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 492: Noise Level

    FDKN-H 12.2.7 Noise level Notes (1) The data are based on the following conditions. Indoor unit Outdoor unit Ambient air temperature: Measured based on JIS B 8616 Measured based on JIS B 8616 Indoor unit 27°C DB, 19°C WB Mike position as below Mike position: at highest noise level Outdoor unit 35°C DB, in position as below...

  • Page 493: Electrical Data

    FDKN-H 12.3 ELECTRICAL DATA 12.3.1 Electrical wiring Model FDKN208HEN-S1...
  • Page 494 FDKN-H Model FDKN258HEN-S1...
  • Page 495 FDKN-H Model FDKNP208HEN-S...
  • Page 496 FDKN-H Model FDKNP258HEN-S...
  • Page 497 FDKN-H Model FDKNP308HEN-S...
  • Page 498 FDKN-H Model FDKNP308HES-S...

  • Page 499: Outline Of Operation Control By Microcomputer

    FDKN-H 12.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Same as the cooling/heating equipment for FDT (N) heat pump type. Refer to page 317. 12.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. •...

  • Page 500: Installation Of Indoor Unit

    All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATIONS. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or should particular problems occur, the matter should be referred to Mitsubishi Heavy Industries, Ltd. through your local distributor. WARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION.
  • Page 501 FDKN-H (3) Carry-in and installation of unit Carry-in When carrying in the unit, carry it in as packed to the installation site as near as possible. If you are compelled to carry in the unit unpacked, cover it with a nylon sling so that it is not damaged.
  • Page 502 FDKN-H Installation work procedure Claw (2 places) Installation of unit (FDKN308: 3 places) Indoor unit Mounting plate (1) Hang the upper portion of in- door unit on the mounting plate. Lid (right hand) • To remove the unit from the mounting plate, remove the Mounting plate right and left lids then remove...

  • Page 503: Installation Of Outdoor Unit

    FDKN-H Removal order of the panel Open the return air grill. (Pull both lower ends of the return air grill, raise the grill until the reaction is felt after disengaging the latch. The return air grill will stop at approx. 60° open position.) Remove the air filter.
  • Page 504 FDKN-H MEMO...

  • Page 505: Fdkn-C

    FDKN-C FDKN-C 13. WALL MOUNTED TYPE PACKAGED AIR-CONDITIONER Split system, Air cooled cooling only type Alternative refrigerant R407C use models FDKNP208CEN-S 258CEN-S 308CEN-S 308CES-S...
  • Page 506 FDKN-C CONTENTS 13.1 GENERAL INFORMATION..............505 13.1.1 Specific features ................505 13.1.2 How to read the model name ............505 13.2 SELECTION DATA .................. 506 13.2.1 Specifications ................... 506 13.2.2 Range of usage & limitations ............510 13.2.3 Exterior dimensions ................. 511 13.2.4 Exterior appearance .................

  • Page 507: General Information

    FDKN-C 13.1 GENERAL INFORMATION 13.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 508: Selection Data

    FDKN-C 13.2 SELECTION DATA 13.2.1 Specifications Model FDKNP208CEN-S FDKNP208CEN-S Model Item FDKN208C FDCP208CEN3 Nominal cooling capacity 4850 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.03/2.09 Running current (Cooling) 9.4/9.5 Power factor (Cooling) 98/92 Inrush current (L.R.A) Noise level dB(A) Hi:45 Lo:38 Exterior dimensions 275 ×...
  • Page 509 FDKN-C Model FDKNP258CEN-S FDKNP258CEN-S Model Item FDKN258C FDCP258CEN3 Nominal cooling capacity 5700 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.34/2.53 Running current (Cooling) 11.2/12.3 Power factor (Cooling) 95/86 Inrush current (L.R.A) Noise level dB(A) Hi:45 Lo:38 Exterior dimensions 298 × 940 × 196 845 ×...
  • Page 510 FDKN-C Model FDKNP308CEN-S FDKNP308CEN-S Model Item FDKN308C FDCP308CEN3 Nominal cooling capacity 7100 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.18/3.33 Running current (Cooling) 14.8/15.2 Power factor (Cooling) 98/91 Inrush current (L.R.A) Noise level dB(A) Hi:46 Lo:40 Exterior dimensions 298 × 1155 × 196 845 ×...
  • Page 511 FDKN-C Model FDKNP308CES-S FDKNP308CES-S Model Item FDKN308C FDCP308CES3 Nominal cooling capacity 7100 Power source 3 Phase, 380/415V, 50Hz Cooling input 3.10/3.25 Running current (Cooling) 5.4/5.7 Power factor (Cooling) 87/79 Inrush current (L.R.A) Noise level dB(A) Hi:46 Lo:40 Exterior dimensions 298 × 1150 × 196 845 ×...

  • Page 512: Range Of Usage & Limitations

    FDKN-C 13.2.2 Range of usage & limitations Models FDKNP208, 258 type FDKNP308 type Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Refrigerant line (one way) length Max. 30m Max. 50m Max.

  • Page 513: Exterior Dimensions

    FDKN-C 13.2.3 Exterior dimensions (1) Indoor unit Unit: mm Model FDKN208C Mounting plate Outer for electric wiring Remote controller Lower piping outlet signal receives (Refer to the top view.) Outlet for piping (On both side) Indoor unit Mounting plate 50 50 50 50 Gas piping φ15.
  • Page 514 FDKN-C Model FDKN258C Unit: mm Mounting plate Outer for electric wiring Remote controller Lower piping outlet signal receives (Refer to the top view.) Outlet for piping (On both side) Indoor unit Mounting plate Drain hose (VP16) Liquid piping Hole on wall for Hole on wall for rear connecting φ9.52(3/8˝)
  • Page 515 FDKN-C Model FDKN308C Unit : mm 1145 1155 Mounting plate Outlet for electric wiring Lower piping outlet Remote controller (Refer to the top view) signal receives Outlet for piping (On both side) Indoor unit Mounting plate 1047 4 - 5.5 8 - 12 (Long hole) (Long hole)
  • Page 516 FDKN-C (2) Wireless remote controller Unit : mm FILTER COOL DRY FAN FAN HI LO ° C MODE TEMP ON/OFF 20.5 (3) Indication board of indoor unit...
  • Page 517 FDKN-C (4) Outdoor unit Unit: mm Model FDCP208CEN3 Liquid piping: φ6.35 (1/4˝) (Flare connecting) Gas piping: φ15.88 (5/8˝) (Flare connecting) Liquid piping: φ6.35 (1/4˝) (Flare connecting) Terminal block Gas piping: φ15.88 (5/8˝) (Flare connecting) Opening for electric wiring Opening for piping and electric wiring Opening for piping and electric wiring...
  • Page 518 FDKN-C Models FDCP258CEN3, 308CEN3, 308CES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping and electric wiring...
  • Page 519 FDKN-C 13.2.4 Exterior appearance (1) Indoor unit Models All models Ivory white (Front panel) Ivory white (Air inlet grill) Ivory white (Base) Ivory white (Louver) (2) Outdoor unit Models FDCP258CEN3, 308CEN3 Model FDCP208CEN3 308CES3 Polar white Polar white...
  • Page 520 FDKN-C 13.2.5 Piping system Models FDKNP208CEN-S, 258CEN-S Check joint Service valve Outdoor unit Indoor unit (Flare connecting) Thermistat (Tho-A) High pressure Gas line (φ15.88) switch (63H1) Thermistor –A) Thermistat Heat Caillary tabe (Tho-D) exchanger Heat exchanger Thermistor Solenoid Thermistat valve (Tho-R) –R) Compressor...
  • Page 521 FDKN-C Preset point of the protective devices Equipped Parts name Mark All models unit OFF 2.5˚C Thermistor Indoor unit (for frost prevention) ON 10˚C Thermistor OFF 135˚C (for detecting dis- Tho-D Outdoor unit ON 90˚C charge pipe temp.) Thermistor OFF 70˚C (for detecting heat Tho-R Outdoor unit...
  • Page 522 FDKN-C 13.2.6 Selection chart Correct the cooling capacity in accordance with the conditions as follows. The net cooling capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling capacity in relation to temperatures Models FDKNP208CEN-S, 258CEN-S Applicable range ISO-T1 Standard condition...
  • Page 523 FDKN-C Table of bypass factor Model FDKN208C FDKN258C FDKN308C Item Air flow 0.03 0.03 0.04 (2) Correction of cooling capacity in relation to flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling capacity in relation to the one way equivalent piping length between the indoor and outdoor units.
  • Page 524 FDKN-C 13.2.7 Noise level Notes (1) The data are based on the following conditions. Indoor unit Outdoor unit Ambient air temperature: Measured based on JIS B 8616 Measured based on JIS B 8616 Indoor unit 27°C DB, 19°C WB Mike position as below Mike position: at highest noise level Outdoor unit 35°C DB, in position as below...
  • Page 525 FDKN-C 13.3 ELECTRICAL DATA 13.3.1 Electrical wiring Model FDKNP208CEN-S...
  • Page 526 FDKN-C Models FDKNP258CEN-S, 308CEN-S...
  • Page 527 FDKN-C Model FDKNP308CES-S...
  • Page 528 FDKN-C 13.4 OUTLINE OF OPERATION CONTROL BY MICROCOM- PUTER Except for function relating to heating, same as the unit for FDT(N) heat pump type. See page 317. 13.5 APPLICATION DATA The application data for the cooling only models are similar to those for the heat pump models. (See page 497.) 13.6 MAINTENANCE DATA Same as the cooling/heating equipment for FDT(N) heat pump type.

  • Page 529: Ceiling Recessed Type Cassetteria Models

    FDR-H FDR-H 14. CEILING RECESSED TYPE CASSETTERIA MODELS Split system, Air to air heat pump type FDR208HEN-SA FDR308HEN-A 258HEN-SA 308HES-A 308HEN-SA 408HES-A 308HES-SA 508HES-A 408HES-SA 508HES-SA...
  • Page 530 FDR-H CONTENTS 14.1 GENERAL INFORMATION ..............529 14.1.1 Specific features ................529 14.1.2 How to read the model name............529 14.2 SELECTION DATA ................... 530 14.2.1 Specifications ..................530 14.2.2 Range of usage & limitations ............540 14.2.3 Exterior dimensions ................541 14.2.4 Exterior appearance ................
  • Page 531 FDR-H 14.1 GENERAL INFORMATION 14.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.
  • Page 532 FDR-H 14.2 SELECTION DATA 14.2.1 Specifications Model FDR208HEN-SA FDR208HEN-SA Model Item FDR208-A FDC208HEN3A Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E Nominal cooling capacity 5000 Nominal heating capacity 5400 Power source 1 Phase, 220/240V, 50Hz Cooling input 1.78/1.87 Running current (Cooling) 8.3/8.1...
  • Page 533 FDR-H Model FDR258HEN-SA FDR258HEN-SA Model Item FDR258-A FDC258HEN3A Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.06/2.17 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/96 Heating input...
  • Page 534 FDR-H Model FDR308HEN-SA FDR308HEN-SA Model Item FDR308-A FDC308HEN3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.02/3.22 Running current (Cooling) 14.0/14.5 Power factor (Cooling) 98/93 Heating input...
  • Page 535 FDR-H Model FDR308HES-SA FDR308HES-SA Model Item FDR308-A FDC308HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V, 50Hz Cooling input 2.94/3.00 Running current (Cooling) 5.2/5.6 Power factor (Cooling) 86/75 Heating input...
  • Page 536 FDR-H Model FDR408HES-SA FDR408HES-SA Model Item FDR408-A FDC408HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity 10000 Nominal heating capacity 11200 Power source 3 Phase, 380/415V, 50Hz Cooling input 4.48/4.58 Running current (Cooling) 7.6/7.9 Power factor (Cooling) 90/81 Heating input...
  • Page 537 FDR-H Model FDR508HES-SA FDR508HES-SA Model Item FDR508-A FDC508HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity 12500 Nominal heating capacity 14000 Power source 3 Phase, 380/415V, 50Hz Cooling input 5.27/5.52 Running current (Cooling) 9.4/10.2 Power factor (Cooling) 85/75 Heating input...
  • Page 538 FDR-H Model FDR308HEN-A FDR308HEN-A Model Item FDR308-A FDC306HEN3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity 7100 Nominal heating capacity 7300 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.11/3.15 Running current (Cooling) 15.7/16.4 Power factor (Cooling) 90/80 Heating input...
  • Page 539 FDR-H Model FDR308HES-A FDR308HES-A Model Item FDR308-A FDC306HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity 7100 Nominal heating capacity 7300 Power source 3 Phase, 380/415V, 50Hz Cooling input 2.87/2.88 Running current (Cooling) 5.4/5.4 Power factor (Cooling) 81/74 Heating input...
  • Page 540 FDR-H Model FDR408HES-A FDR408HES-A Model Item FDR408-A FDC406HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity 10200 Nominal heating capacity 10500 Power source 3 Phase, 380/415V, 50Hz Cooling input 3.76/3.76 Running current (Cooling) 7.3/7.3 Power factor (Cooling) 78/72 Heating input...
  • Page 541 FDR-H Model FDR508HES-A FDR508HES-A Model Item FDR508-A FDC506HES3 Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity 12500 Nominal heating capacity 12800 Power source 3 Phase, 380/415V, 50Hz Cooling input 4.84/4.84 Running current (Cooling) 9.9/9.9 Power factor (Cooling) 74/68 Heating input...
  • Page 542 FDR-H 14.2.2 Range of usage & limitations Models FDR208~508 (FDC208~508 type) Models FDR208, 258 (FDC208, 258 type) FDR308~508 (FDC308~508 type) Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Indoor unit atmosphere (behind ceiling) Dew point temperature: 28˚C or less, relative humidity: 80% or less temperature and humidity Max.
  • Page 543 FDR-H 14.2.3 Exterior dimentions (1) Indoor unit Silent Panel (Model: R-PNLS-26W-E) Unit : mm Model FDR208-A (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Locality) Fresh air opening (Knock out hole) C↓ Control box Panel center VIEW C Drain Air outlet duct (Connectable with VP25) Liquid piping...
  • Page 544 FDR-H Model FDR208-A Canvas Panel (Model: R-PNLC-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Local Locality) (Suspension bolts pitch) Fresh air opening C↓ (Knock out hole) Drain (Connectable with VP25) Control box Panel center Liquid piping φ6.35 (1/4") VIEW C Air outlet duct Gas piping...
  • Page 545 FDR-H Models FDR258-A, 308-A Unit : mm Silent Panel (Model: R-PNLS-36W-E) (Ceiling hole size) 1180 Drain hose (Accessories) (Suspension bolts pitch) (Locality) Fresh air opening (Knock out hole) C↓ Control box Panel center VIEW C Air outlet duct Suspension bolts 295~325 (M10 ×...
  • Page 546 FDR-H Models FDR258-A, 308-A Canvas Panel (Model: R-PNLC-36W-E) Unit : mm Drain hose (Accessories) (Ceiling hole size) 1004 (Locality) (Suspension bolts pitch) Fresh air opening C ↑ (Knock out hole) Panel center Control box VIEW C Air outlet duct Hole for Suspension bolts humidifier piping (M10 ×...
  • Page 547 FDR-H Models FDR408-A, 508-A Unit : mm Silent Panel (Model: R-PNLS-46W-E) 1600(Ceiling hole size) Drain hose(Accessories) 1406(Suspension bolts pictch) (Locality) Fresh air opening (Knock out hole) Control box Panel center VIEW C Air outlet duct Drain Suspension bolts (Connectable (M10 × 4 pcs.) 1370 295~325 with VP25)
  • Page 548 FDR-H Models FDR408-A, 508-A Unit : mm Canvas Panel (Model: R-PNLC-46W-E) Drain hose(Accessories) 1424(Ceiling hole size) Fresh air opening (Locality) 1406(Suspension bolts pictch) (Knock out hole) Panel center Control box VIEW C Air outlet duct Drain (Connectable with VP25) Hole for Suspension bolts 1370 humidifier piping...
  • Page 549 FDR-H (2) Remote controller (Optional parts) Unit : mm Wall 0.3mm , 3cores (O.D.φ5.6) Wire (Recessed) LCD display Junction box (Locally Purchased) Remote controller mounting dimensions ♦ Usable JIS box, JIS C 8336 ⋅ Switch box for 1 piece (without cover) (use of the mark hole as illustrated on the left) ⋅...
  • Page 550 FDR-H (3) Outdoor unit Model FDC208HEN3A Liquid piping: φ 6.35 (1/4") Unit: mm (Flare connecting) Gas piping: φ 15.88 (5/8") (Flare connecting) Liquid piping: φ 6.35 (1/4") (Flare connecting) Terminal block Gas piping: φ 15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for piping and electric wiring Opening for piping...
  • Page 551 FDR-H Models FDC258HEN3A, 308HEN3, 308HES3 Liquid piping: ø9.52 (3/8") Unit: mm (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping and electric wiring...
  • Page 552 FDR-H Models FDC408HES3, 508HES3 Unit: mm Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...
  • Page 553 FDR-H Models FDC306HEN3, 306HES3 Unit: mm Anchor bolts (M10 × 4 pcs) Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.
  • Page 554 FDR-H Models FDC406HES3, 506HES3 Unit: mm Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.

  • Page 555: Exterior Appearance

    FDR-H 14.2.4 Exterior appearance (1) Indoor unit (Operation panel): All Models Silent panel type Canvas-duct panel type Ceramic White Ceramic White (2) Outdoor unit Model FDC208HEN3A Models FDC258HEN3A, 308HEN3, 308HES3 Polar white Polar white Models FDC306HEN3, 306HES3 Models FDC406HES3, 506HES3 Models FDC408HEN3, 508HES3 Polar white Polar white...

  • Page 556: Piping System

    FDR-H 14.2.5 Piping system Models FDR208HEN-SA, 258HEN-SA Cooling cycle Indoor unit Heating cycle Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer (ø15.88) (Flare connecting) Heat exchanger Check joint Check joint Thermistor Muffler Heat exchanger...
  • Page 557 FDR-H Model FDR508HES-SA High pressure switch (63H Cooling cycle Indoor unit (For fan motor control) Outdoor unit Heating cycle 4way valve Thermistor Gas line Strainer Service valve (ø19.05) (Flare connecting) Check joint Check joint Heat exchanger Capillary tube Thermistor Oil separator Thermistor Heat exchanger Capillary...
  • Page 558 FDR-H Models FDR408HES-A, 508HES-A Service valve Cooling cycle (Flare connecting) Heating cycle Indoor unit Outdoor unit Check joint High pressure switch (For fan motor control) Strainer Strainer Gas line (ø19.05) 4way valve Check joint Heat Thermistor exchanger Accumlator Heat exchanger Check joint Thermistor Defrost...

  • Page 559: Selection Chart

    FDR-H 14.2.6 Selection chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures (a) Only case of ISO-T1 models (Only case of FDC308~508 type) Indoor air W.B.
  • Page 560 FDR-H Table of bypass factor Model FDR 208 type FDR 258 type FDR 308 type FDR 408 type FDR 508 type Item 0.035 0.032 0.039 0.085 0.035 Air flow 0.021 0.020 0.023 0.060 0.023 (2) Correction of cooling and heating capacity in relation to air flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor...
  • Page 561 FDR-H 14.2.7 Characteristics of fan (1) Cassetteria type (FDR) How to interpret the blower characteristics table • External static pressure table Unit: Pa (mmAq) Example : Case of FDR308-A Duct specs. 1 spot closing Standard Square duct 1 2-spot blowout..... Internal resistance increases more Air flow 40(4)
  • Page 562 FDR-H Model FDR308-A Model FDR408-A 120(12) 120(12) 100(10) 100(10) 80(8) 80(8) 60(6) 60(6) 40(4) 40(4) 20(2) 20(2) 2-spot blower 3-spot blower internal resistance internal resistance 0(0) 0(0) [Standard] 4-spot blower internal resistance [Standard] 3-spot blower internal resistance Square duct blower internal resistance Square duct blower internal resistance –20(–2)

  • Page 563: Noise Level

    FDR-H 14.2.8 Noise level Note (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Indoor unit Outdoor unit Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position as below Mike position: at highest noise level in position as below...
  • Page 564 FDR-H Model FDR408-A Model FDR508-A Noise level 46 dB (A) at HIGH Noise level 47 dB (A) at HIGH 39 dB (A) at LOW 40 dB (A) at LOW 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) (2) Outdoor unit Model FDC208HEN3A...

  • Page 565: Electrical Data

    FDR-H 14.3 ELECTRICAL DATA 14.3.1 Electrical wiring Models FDR208HEN-SA, 258HEN-SA...
  • Page 566 FDR-H Model FDR308HEN-SA...
  • Page 567 FDR-H Model FDR308HES-SA...
  • Page 568 FDR-H Models FDR408HES-SA, 508HES-SA...
  • Page 569 FDR-H Model FDR308HEN-A...
  • Page 570 FDR-H Model FDR308HES-A...
  • Page 571 FDR-H Models FDR408HES-A, 508HES-A...

  • Page 572: Outline Of Operation Control By Microcomputer

    FDR-H 14.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Same as the cooling/heating equipment for FDT(N) heat pump type. Refer to page 317. 14.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. •...
  • Page 573 Should further information be desired or should particular through your local distributor. problems occur, the matter should be referred to Mitsubishi Heavy Industries, Ltd. WARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD CAUSE SERIOUS INJURY OR DEATH, EQUIPMENT MALFUNCTION AND/OR PROPERTY DAMAGE.
  • Page 574 FDR-H (4) Preparation for suspending the unit (a) Selection of hanging pattern When the unit is hanged from ceiling, select one of following patterns depending on the dimensions of the ceiling. < Combination with silent panel > Unit: mm Dimentions Models FDR208,258,308 365 or over...
  • Page 575 FDR-H Hanging bolt (5) Installation of indoor unit M10 nut M10 washer ¡ Fix the indoor unit to the hanger bolts. If required, it is possible to suspend the unit to the beam, etc. M10 spring washer Main unit Directly by use of the bolts without using the hanger bolts. Note When the dimensions of main unit and ceiling holes does not match, it can be adjusted with the slot holes of hanging bracket.
  • Page 576 FDR-H (d) When constructing drain piping for several units, posi- Secure the elevation as high as possible (approx. 100 mm) tion the common pipe about 100mm below the drain out- let of each unit as shown in the sketch. Use VP-30(11/4˝) or thicker pipe for this purpose.
  • Page 577 FDR-H (7) Installation work for air outlet ducts Air conditioner main unit. Canvas duct (Option) Heat insulation Suction hole Ceiling surface (Silent panel) Special blowout Blowout duct Suction hole (Option) (Optional or marketed item) (Canvas panel) Calculate the draft and external static pressure and select the length, shape and blowout. A Blowout duct ¡...
  • Page 578 FDR-H (9) Installation of ornament panel <Case of silent panel> Name Q'ty Position Round head set i) Accessory 4 pcs. Securing the panel screw (M5 × 35) ii) Installation procedures (a) Remove the inner frame of panel ¡ How to remove the panel inner frame 1 Detach from pins (A) in the order of arrow 1 2.

  • Page 579: Maintenance Data

    FDR-H Attachment of ceiling material Ceiling material can be attached to the panel inner frame. (Plate thickness max. 15mm) Ceiling material Ornament panel Panel inner frame Stopper Attachment procedures 1 Remove the stopper. 2 Remove the ornament plate and attach the ceiling material. 3 Hold down the ceiling material and return the stopper in position.
  • Page 580 FDR-H MEMO...

  • Page 581: Fdu-H

    FDU-H FDU-H 15. HIGH STATIC PRESSURE, DUCT TYPE PACKAGED AIR- CONDITIONER Split system, Air to air heat pump type FDU308HEN-SA FDU308HEN-A 308HES-SA 308HES-A 408HES-SA 408HES-A 508HES-SA 508HES-A 808HES-SA 508HEM-A 1008HES-SA...
  • Page 582 FDU-H CONTENTS 15.1 GENERAL INFORMATION ..............581 15.1.1 Specific features ................581 15.1.2 How to read the model name............581 15.2 SELECTION DATA ................... 582 15.2.1 Specifications ..................582 15.2.2 Range of usage & limitations ............593 15.2.3 Exterior dimensions ................594 15.2.4 Exterior appearance ................

  • Page 583: General Information

    FDU-H 15.1 GENERAL INFORMATION 15.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 584: Selection Data

    FDU-H 15.2 SELECTION DATA 15.2.1 Specifications Model FDU308HEN-SA FDU308HEN-SA Model Item FDU308-A FDC308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.20/3.40 Running current (Cooling) 14.8/15.4 Power factor (Cooling) 98/92 Heating input 3.06/3.22 Running current (Heating) 14.2/14.7...
  • Page 585 FDU-H Model FDU308HES-SA FDU308HES-SA Model Item FDU308-A FDC308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V 50Hz Cooling input 3.12/3.18 Running current (Cooling) 5.7/6.2 Power factor (Cooling) 83/72 Heating input 2.76/2.82 Running current (Heating) 5.2/5.5 Power factor (Heating) 8.1/7.2 Inrush current (L.R.A)
  • Page 586 FDU-H Model FDU408HES-SA FDU408HES-SA Model Item FDU408-A FDC408HES3 Nominal cooling capacity 10000 Nominal heating capacity 11200 Power source 3 Phase, 380/415V 50Hz Cooling input 4.68/4.78 Running current (Cooling) 8.1/8.4 Power factor (Cooling) 87/79 Heating input 4.06/4.10 Running current (Heating) 7.4/7.8 Power factor (Heating) 83/73 Inrush current (L.R.A)
  • Page 587 FDU-H Model FDU508HES-SA FDU508HES-SA Model Item FDU508-A FDC508HES3 Nominal cooling capacity 12500 Nominal heating capacity 14000 Power source 3 Phase, 380/415V 50Hz Cooling input 5.44/5.71 Running current (Cooling) 9.8/10.6 Power factor (Cooling) 84/75 Heating input 4.99/5.14 Running current (Heating) 9.3/10.2 Power factor (Heating) 82/70 Inrush current (L.R.A)
  • Page 588 FDU-H Model FDU808HES-SA FDU808HES-SA Model Item FDU808-A FDC808HES3 Nominal cooling capacity 20000 Nominal heating capacity 21200 Power source 3 Phase, 380/415V 50Hz Cooling input 9.1/9.2 Running current (Cooling) 16.2/15.5 Power factor (Cooling) 85/83 Heating input 7.1/7.3 Running current (Heating) 13.6/13.2 Power factor (Heating) 79/77 Inrush current (L.R.A)
  • Page 589 FDU-H Model FDU1008HES-SA FDU1008HES-SA Model Item FDU1008-A FDC1008HES3 Nominal cooling capacity 25000 Nominal heating capacity 28000 Power source 3 Phase, 380/415V 50Hz Cooling input 12.8/12.9 Running current (Cooling) 22.7/21.7 Power factor (Cooling) 86/83 Heating input 10.6/10.8 Running current (Heating) 19.2/18.7 Power factor (Heating) 84/80 Inrush current (L.R.A)
  • Page 590 FDU-H Model FDU308HEN-A FDU308HEN-A Model Item FDU308-A FDC306HEN3 Nominal cooling capacity 7100 Nominal heating capacity 7300 Power source 1 Phase, 220/240V, 50Hz Cooling input 3.29/3.33 Running current (Cooling) 16.5/17.3 Power factor (Cooling) 91/80 Heating input 3.04/3.08 Running current (Heating) 15.4/16.2 Power factor (Heating) 90/79 Inrush current (L.R.A)
  • Page 591 FDU-H Model FDU308HES-A FDU308HES-A Model Item FDU308-A FDC306HES3 Nominal cooling capacity ISO-T1 7100/7700 ISO-T3 6000 Nominal heating capacity ISO-T1 7300/7900 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 3.05/3.06/3.64 Running current (Cooling) 5.9/6.0/7.1 Power factor (Cooling) 79/71/78 Heating input 2.72/2.74/3.19 Running current (Heating) 5.5/5.7/6.7...
  • Page 592 FDU-H Model FDU408HES-A FDU408HES-A Model Item FDU408-A FDC406HES3 Nominal cooling capacity ISO-T1 10200/11300 ISO-T3 9900 Nominal heating capacity ISO-T1 10500/11600 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 3.96/3.96/4.88 Running current (Cooling) 7.8/7.8/9.4 Power factor (Cooling) 77/71/79 Heating input 3.66/3.66/4.51 Running current (Heating) 7.5/7.5/9.1...
  • Page 593 FDU-H Model FDU508HES-A FDU508HES-A Model Item FDU508-A FDC506HES3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 11900 Nominal heating capacity ISO-T1 12800/14400 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 5.01/5.03/6.03 Running current (Cooling) 10.3/10.3/11.5 Power factor (Cooling) 74/68/80 Heating input 4.63/4.67/5.61 Running current (Heating) 9.5/9.6/10.7...
  • Page 594 FDU-H Model FDU508HEM-A FDU508HEM-A Model Item FDU508-A FDC506HEM3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 11900 Nominal heating capacity ISO-T1 12800/14400 Power source 3 Phase, 230V 50Hz, 220V 60Hz Cooling input 5.01/6.03 Running current (Cooling) 15.1/18.5 Power factor (Cooling) 83/86 Heating input 4.70/5.61 Running current (Heating) 14.0/17.1...

  • Page 595: Range Of Usage & Limitations

    FDU-H 15.2.2 Range of usage & limitations Models FDU308~1008, (FDC308~1008 type) Models FDU308~1008(FDC308~1008 type) Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Indoor unit atmosphere (behind ceiling) Dew point temperature: 28˚C or less, relative humidity: 80% or less temperature and humidity Refrigerant line (one way) length Max.

  • Page 596: Exterior Dimensions

    FDU-H 15.2.3 Exterior dimensions (1) Indoor unit Models FDU308-A, 408-A Unit : mm 794 (Suspension bolts pitch) Holes for screws Return air duct (M5 × 12 pcs.) 750 (Duct for dimension) VIEW A Control box Liquid piping Gas piping ø9.52 (3/8") 308 type : ø15.88 (5/8") 408 type : ø19.05 (3/4") Suspension bolts...
  • Page 597 FDU-H Model FDU508-A Unit : mm 794 (Suspension bolts pitch) Holes for screws Return air duct (M5 × 16 pcs.) 4 × 200 = 800 1100 (Duct for dimension) VIEW A Control box Liquid piping Gas piping ø9.52 (3/8") ø19.05 (3/4") Suspension bolts (M10 ×...
  • Page 598 FDU-H Models FDU808-A, 1008-A Unit : mm 794 (Suspension bolts pitch) Holes for screw (M5 × 20 pcs.) Return air duct 6 × 200 = 1200 1500 (Duct for dimension) Control box Gas piping Liquid piping 808: ø25.4 (1") 808: ø12.7 (1/2") VIEW A 1008: ø15.88 (5/8") 1008: ø28.58 (1 1/8")
  • Page 599 FDU-H (2) Remote controller (Optional parts) Wall 0.3mm , 3cores (O.D.φ5.6) Wire (Recessed) LCD display Junction box (Locally Purchased) Remote controller mounting dimensions ♦ Usable JIS box, JIS C 8336 ⋅ Switch box for 1 piece (without cover) (use of the mark hole as illustrated on the left) ⋅...
  • Page 600 FDU-H (3) Outdoor unit Models FDC308HEN3, 308HES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping Opening for piping...
  • Page 601 FDU-H Models FDC408HES3, 508HES3 Unit: mm Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Terminal block Liquid piping: ø 9.52 (3/8") (Flare connecting) Gas piping: ø 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...
  • Page 602 FDU-H Unit: mm Models FDC808HES3, 1008HES3 1350 Opening for exit wiring Connect of liquid piping (ø50) 808: ø12.7 (1/2") Opening for 1008: ø15.58 (5/8") exit piping (ø88) Opening for exit wiring Power supply connecting (ø50) Connect of gas piping terminal block Opening for 808: ø25.4 (1") exit piping...
  • Page 603 FDU-H Models FDC306HEN3, 306HES3 Unit: mm Anchor bolts (M10 × 4 pcs) Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.
  • Page 604 FDU-H Models FDC406HES3, 506HES3, 506HEM3 Unit: mm Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Installation type Mark Open Open Open Notes (1) Fix the unit with anchor bolts. (2) Strong wind must not be directed to the air outlet.
  • Page 605 FDU-H 15.2.4 Exterior appearance (1) Indoor unit ..Zinc steel plate (2) Outdoor unit Models FDC308HEN3, 308HES3 Models FDC408HES3, 508HES3 Polar white Polar white Models FDC808HES3,1008HES3 Polar white Models FDC406HES3, 506HES3 Models FDC306HEN3, 306HES3 506HEM3 Polar white Polar white...
  • Page 606 FDU-H 15.2.5 Piping system Models FDU308HEN-SA, 308HES-SA, 408HES-SA Cooling cycle Indoor unit Heating cycle Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer 308:ø15.88 (Flare connecting) 408:ø19.05 Heat exchanger Check joint Check joint Thermistor Muffler...
  • Page 607 FDU-H Models FDU808HES-SA, 1008HES-SA Cooling cycle Indoor unit Outdoor unit Heating cycle Service valve High pressure switch(63H Thermistor (Brazing) (For fan motor control) Brazing Gsa line Strainer 808 : ø25.4 1008 : ø28.58 4way valve Lower Upper High pressure Thermistor Heat switch(63H exchanger...
  • Page 608 FDU-H Models FDU408HES-A, 508HES-A, 508HEM-A Cooling cycle Service valve Heating cycle Outdoor unit Indoor unit (Flare connecting) Check joint High pressure switch (For fan motor control) Strainer Strainer Gas line (ø19.05) 4way valve Check joint Heat Thermistor exchanger Accumlator Heat exchanger Check joint Thermistor Defrost...
  • Page 609 FDU-H 15.2.6 Selection chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures (a) Only case of ISO-T1 models (Only case of FDC308~1008 type) Indoor air W.B.
  • Page 610 FDU-H (C) Only case of ISO-T3 and SASO models Indoor air W.B. temperature (˚CW.B.) ISO-T1 Standard condition ISO-T1 Standard condition Outdoor air W.B. temperature (˚CW.B.) Table of bypass factor (50/60 Hz) Model FDU 308 type FDU 408 type FDU 508 type FDU 808 type FDU 1008 type Item...
  • Page 611 FDU-H (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor and outdoor units. 50/60Hz Equivalent piping length Heating...
  • Page 612 FDU-H 15.2.7 Characteristics of fan How to interpret the blower characteristics table Example ¡What is the Fan Controller’s Volume Number setting if, at the high operation speed of FDU308-A (60Hz), it is required to have 140Pa (14mmAq) outside static pressure at 24m /min airflow volume as the operation point? Move the 140Pa (14mmAq) outside static pressure point to the right as shown in the diagram below.
  • Page 613 FDU-H Model FDU408-A (50Hz) Model FDU408-A (60Hz) High • Condition of standard rating High • Condition of standard rating (Air flow : 100 (10) Pa (mmAq) (Air flow : 100 (10) Pa (mmAq) 200 (20) 200 (20) Example of duct 150 (15) 150 (15) Example...
  • Page 614 FDU-H Model FDU808-A High • Condition of standard rating (Rated air volume : 100 (10) Pa (mmAq) 200(20) Example of duct 150(15) 100(10) 50(5) 0(0) 38 40 Lower Upper Standard limit limit Air flow (m /min) Model FDU1008-A High • Condition of standard rating (Rated air volume : 100 (10) Pa (mmAq) 200(20) Example...
  • Page 615 FDU-H 15.2.8 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27°C DB, 19°C WB Outdoor unit 35°C DB, Outdoor unit Indoor unit Only case of FDC 308~508 and FDC 306~506 type. Measured based on JIS B 8616 Measured based on JIS B 8616 Mike position as below...
  • Page 616 FDU-H (2) Outdoor unit Model FDC306HES3 Models FDC308HEN3, 308HES3 Model FDC306HEN3 Noise level 52 dB (A) Noise level 56 dB (A) Noise level 56 dB (A) 1000 2000 4000 8000 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Mid octave band frequency (Hz) Model FDC408HES3...
  • Page 617 FDU-H 15.3 ELECTRICAL DATA 15.3.1 Electrical wiring Model FDU308HEN-SA...
  • Page 618 FDU-H Model FDU308HES-SA...
  • Page 619 FDU-H Models FDU408HES-SA, 508HES-SA...
  • Page 620 FDU-H Models FDU808HES-SA, 1008HES-SA...
  • Page 621 FDU-H Model FDU308HEN-A...
  • Page 622 FDU-H Model FDU308HES-A...
  • Page 623 FDU-H Models FDU408HES-A, 508HES-A...
  • Page 624 FDU-H Model FDU508HEM-A...
  • Page 625 FDU-H 15.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Same as the cooling/heating equipment for FDT(N) heat pump type. Refer to page 317. 15.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. WARNING and CAUTION , those points •...
  • Page 626 All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATION. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or through your local should particular problems occur, the matter should be referred to Mitsubishi Heavy Industries, Ltd. distributor. WARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION.
  • Page 627 FDU-H (3) Duct work 1 Air filter is not installed in the main unit of air condi- Silencer chamber (blowout) Silencer chamber (intake) Detail of section A tioner. Air filter should be installed in the suction grill (Vibration prevention of hanger) Canvas coupling Canvas coupling which allows an ample access for cleaning.
  • Page 628 FDU-H (d) When constructing drain piping for several units, position the common pipe about 100 mm below the drain outlet of each unit as shown in the sketch. Use VP-30 (11/4˝) or thicker pipe this purpose. (e) Be sure to provide heat insulation to hard PVC pipes of indoor placement. (f) Do not ever provide an air vent.

  • Page 629: Fdu-C

    FDU-C FDU-C 16. HIGH STATIC PRESSURE, DUCT TYPE PACKAGED AIR- CONDITIONER Split system, Air cooled cooling only type FDU308CEN-A 308CES-A 408CES-A 508CES-A 508CEM-A...
  • Page 630 FDU-C CONTENTS 16.1 GENERAL INFORMATION ................ 629 16.1.1 Specific features ................. 629 16.1.2 How to read the model name ............. 629 16.2 SELECTION DATA ..................630 16.2.1 Specifications ..................630 16.2.2 Range of usage & limitations ............. 635 16.2.3 Exterior dimensions................636 16.2.4 Exterior appearance................
  • Page 631 FDU-C 16.1 GENERAL INFORMATION 16.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.
  • Page 632 FDU-C 16.2 SELECTION DATA 16.2.1 Specifications Model FDU308CEN-A FDU308CEN-A Model Item FDU308-A FDC306CEN3 Nominal cooling capacity ISO-T1 7100 ISO-T3 5700 Power source 1 Phase, 220/240V 50Hz Cooling input 3.29/3.33 Running current (Cooling) 16.5/17.3 Power factor (Cooling) 91/80 Cooling input 3.48/3.52 Running current (Cooling) 17.5/18.3 Power factor (Cooling)
  • Page 633 FDU-C Model FDU308CES-A FDU308CES-A Model Item FDU308-A FDC306CES3 Nominal cooling capacity ISO-T1 7100/7700 ISO-T3 5700/6000 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 3.05/3.06/3.64 Running current (Cooling) 5.9/6.0/7.1 Power factor (Cooling) 79/71/78 Cooling input 3.24/3.25/3.87 Running current (Cooling) 6.3/6.4/7.6 Power factor (Cooling) 78/71/77...
  • Page 634 FDU-C Model FDU408CES-A FDU408CES-A Model Item FDU408-A FDC406CES3 Nominal cooling capacity ISO-T1 10200/11300 ISO-T3 8900/9900 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 3.96/3.96/4.88 Running current (Cooling) 7.8/7.8/9.4 Power factor (Cooling) 77/71/79 Cooling input 4.30/4.30/5.38 Running current (Cooling) 8.4/8.4/10.1 Power factor (Cooling) 78/71/81...
  • Page 635 FDU-C Model FDU508CES-A FDU508CES-A Model Item FDU508-A FDC506CES3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 10600/11900 Power source 3 Phase, 380-415V 50Hz, 380V 60Hz Cooling input 5.01/5.03/6.03 Running current (Cooling) 10.3/10.3/11.5 Power factor (Cooling) 74/68/80 Cooling input 5.56/5.58/6.63 Running current (Cooling) 11.6/11.6/12.5 Power factor (Cooling) 73/67/81...
  • Page 636 FDU-C Model FDU508CEM-A FDU508CEM-A Model Item FDU508-A FDC506CEM3 Nominal cooling capacity ISO-T1 12500/14000 ISO-T3 11900 Power source 3 Phase, 230V 50Hz/220V 60Hz Cooling input 4.76/5.76 Running current (Cooling) 15.2/16.9 Power factor (Cooling) 79/89 Cooling input 6.28 Running current (Cooling) 18.2 Power factor (Cooling) Inrush current (L.R.A) Noise level...
  • Page 637 FDU-C 16.2.2 Range of usage & limitations Models All models Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Indoor unit atmosphere (behind ceiling) Dew point temperature 28˚C or less, relative humidity 80% or less temperature and humidity Refrigerant line (one way) length Max.
  • Page 638 FDU-C 16.2.3 Exterior dimensions (1) Indoor unit Models FDU308-A, 408-A Unit: mm 794 (Suspension bolts pitch) Holes for screws Return air duct (M5 × 12 pcs.) 750 (Duct for dimension) VIEW A Control box Liquid piping Gas piping ø9.52 (3/8") 308 type : ø15.88 (5/8") 408 type : ø19.05 (3/4") Suspension bolts...
  • Page 639 FDU-C Model FDU508-A Unit: mm 794 (Suspension bolts pitch) Holes for screws Return air duct (M5 × 16 pcs.) 4 × 200 = 800 1100 (Duct for dimension) VIEW A Control box Liquid piping Gas piping ø9.52 (3/8") ø19.05 (3/4") Suspension bolts (M10 ×...
  • Page 640 FDU-C (2) Remote controller (Optional parts) Unit: mm Wall 0.3mm , 3cores (O.D.φ5.6) Wire (Recessed) LCD display Junction box (Locally Purchased) Remote controller mounting dimensions ♦ Usable JIS box, JIS C 8336 ⋅ Switch box for 1 piece (without cover) (use of the mark hole as illustrated on the left) ⋅...
  • Page 641 FDU-C (3) Outdoor unit Models FDC306CEN3, 306CES3 Unit: mm Anchor bolts (M10 × 4 pcs.) Terminal block Gas piping : ø15.88(5/8") (Flare connecting) Opening for electric wiring Liquid piping : ø9.52(3/8") (Flare connecting) Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Air inlet...
  • Page 642 FDU-C Models FDC406CES3, 506CES3, 506CEM3 Unit: mm Terminal block Gas piping : ø19.05(3/4") (Flare connecting) Opening for Liquid piping : ø9.52(3/8") electric wiring (Flare connecting) Required space for maintenance and air flow Minimum allowable space to the obstacles Unit:mm Air inlet Installation type Mark...
  • Page 643 FDU-C 16.2.4 Exterior appearance (1) Indoor unit ..Zinc steel plate (2) Outdoor unit Models FDC306CEN3, 306CES3 Polar white Models FDC406CES3, 506CES3, 506CEM3 Polar white...

  • Page 644: Piping System

    FDU-C 16.2.5 Piping system Models FDU308CEN-A, 308CES-A, 408CES-A, 508CES-A, 508CEM-A Service valve Check joint Outdoor unit (Flare connecting) Indoor unit Strainer Gas line Strainer Check joint 308:ø15.88 408, 508: ø19.05 Thermistor Heat exchanger Compressor Heat exchanger High Pressure regulator valve Thermistor Service valve Capillary tube...

  • Page 645: Selection Chart

    FDU-C 16.2.6 Selection chart Correct the cooling capacity in accordance with the conditions as follows. The net cooling capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling capacity in relation to temperatures (a) Only case of ISO-T1 models.
  • Page 646 FDU-C (b) Only case of ISO-T3 and SASO models. ISO-T1 Standard condition Indoor air W.B. temperature (˚CW.B.) Table of bypass factor (50/60 Hz) Model FDU308 type FDU408 type FDU508 type Item Upper limit 0.019/0.096 0.048/0.05 0.103/0.106 Air flow Standard 0.067/0.086 0.032/0.043 0.076/0.094 Lower limit...
  • Page 647 FDU-C (2) Correction of cooling capacity in relation to air flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 648: Characteristics Of Fan

    FDU-C 16.2.7 Characteristics of fan How to interpret the blower characteristics table Example ¡ What is the Fan Controller’s Volume Number setting if, at the high operation speed of FDU308CES (60Hz), it is required to have 140Pa (14mmAq) outside static pressure at 24m /min airflow volume as the operating point? Move the 140Pa (14mmAq) outside static pressure point to the right as shown in the diagram below.
  • Page 649 FDU-C Model FDU408-A (50Hz) Model FDU408-A (60Hz) High • Condition of standard rating High • Condition of standard rating (Air flow : 100 (10) Pa (mmAq) (Air flow : 100 (10) Pa (mmAq) 200 (20) 200 (20) Example of duct 150 (15) 150 (15) Example...

  • Page 650: Noise Level

    FDU-C 16.2.8 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27°C DB, 19°C WB Outdoor unit Outdoor unit 35°C DB, Measured based on JIS B 8616 Indoor unit Mike position: at highest noise level in position as below Measured based on JIS B 8616 Mike position as below...
  • Page 651 FDU-C (2) Outdoor unit Model FDC306CEN3 Model FDC306CES3 Noise level 56dB (A) Noise level 56dB (A) 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Model FDC406CES3 Models FDC506CES3, 506CEM3 Noise level 57dB (A) Noise level 59dB (A) 1000 2000...

  • Page 652: Electrical Data

    FDU-C 16.3 ELECTRICAL DATA 16.3.1 Electrical wiring Model FDU308CEN-A...
  • Page 653 FDU-C Model FDU308CES-A...
  • Page 654 FDU-C Models FDU408CES-A, 508CES-A...
  • Page 655 FDU-C Model FDU508CEM-A...

  • Page 656: Outline Of Operation Control By Microcomputer

    FDU-C 16.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Except for function relating to heating, same as the unit for FDT(N) heat pump type. See page 317. 16.5 APPLICATION DATA The application data for the cooling only models are similar to those for the heat pump models. (See page 623.) 16.6 MAINTENANCE DATA Same as the cooling /heating equipment for FDT(N) heat pump type.

  • Page 657: Floor Standing Type (Console Type

    FDFL-H FDFL-H 17. FLOOR STANDING TYPE (CONSOLE TYPE) PACKAGED AIR-CONDITIONER Split system, Air to air heat pump type FDFL258HEN-SA 308HEN-SA 308HES-SA...
  • Page 658 FDFL-H CONTENTS 17.1 GENERAL INFORMATION ..............657 17.1.1 Specific features ................657 17.1.2 How to read the model name............657 17.2 SELECTION DATA ................... 658 17.2.1 Specifications ..................658 17.2.2 Range of usage & limitations ............661 17.2.3 Exterior dimensions ................662 17.2.4 Exterior appearance ................

  • Page 659: General Information

    FDFL-H 17.1 GENERAL INFORMATION 17.1.1 Specific features (1) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been reduced by more than 50%. (2) The indoor outdoor interconnection signal wiring has been done away with. The microcomputer chip is installed in the indoor unit. There is no need for the unit to communicate between the outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction has been reduced.

  • Page 660: Selection Data

    FDFL-H 17.2 SELECTION DATA 17.2.1 Specifications Model FDFL258HEN-SA FDFL258HEN-SA Model Item FDFL258-A FDC258HEN3A Nominal cooling capacity 5700 Nominal heating capacity 6100 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.04/2.15 Running current (Cooling) 9.4/9.4 Power factor (Cooling) 99/95 Heating input 1.94/2.09 Running current (Heating) 9.1/9.2...
  • Page 661 FDFL-H Model FDFL308HEN-SA FDFL308HEN-SA Model Item FDFL308-A FDC308HEN3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 1 Phase, 220/240V, 50Hz Cooling input 2.99/3.19 Running current (Cooling) 13.9/14.4 Power factor (Cooling) 98/92 Heating input 2.85/3.01 Running current (Heating) 13.3/13.7 Power factor (Heating) 97/92 Inrush current...
  • Page 662 FDFL-H Model FDFL308HES-SA FDFL308HES-SA Model Item FDFL308-A FDC308HES3 Nominal cooling capacity 7100 Nominal heating capacity 8000 Power source 3 Phase, 380/415V, 50Hz Cooling input 2.91/2.97 Running current (Cooling) 5.1/5.5 Power factor (Cooling) 87/75 Heating input 2.55/2.61 Running current (Heating) 4.6/4.8 Power factor (Heating) 84/76 Inrush current...

  • Page 663: Range Of Usage & Limitations

    FDFL-H 17.2.2 Range of usage & limitations Models FDFL258 type FDFL308 type Item Indoor return air temperature (Upper, lower limits) Refer to the selection chart Outdoor air temperature (Upper, lower limits) Max. 30m Max. 50m Refrigerant line (one way) length Max.

  • Page 664: Exterior Dimensions

    FDFL-H 17.2.3 Exterior dimensions (1) Indoor unit Models FDFL258-A, 308-A Unit: mm 1160 Holes for wall (Holes for wall mounting bolt) mounting bolt (M10 or M8) 1200 Hole for piping & 1260 wiring (rear) Air outlet grille Liquid piping φ9.52 (3/8") Gas piping φ15.88 (5/8") Drain hose...
  • Page 665 FDFL-H (2) Outdoor unit Models FDC258HEN3A, 308HEN3, 308HES3 Unit: mm Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Terminal block Liquid piping: ø9.52 (3/8") (Flare connecting) Gas piping: ø15.88 (5/8") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...

  • Page 666: Exterior Appearance

    FDFL-H 17.2.4 Exterior appearance (1) Indoor unit Models All models Ceramic white Ceramic white (Air outlet grille) (Front panel) Ceramic white Ceramic white (Front panel) (Holder) Ceramic white (Side panel) Ceramic white (Air inlet grille) Gray (Base) (2) Outdoor unit Models FDC258HEN3A, 308HEN3, 308HES3 Polar white...

  • Page 667: Piping System

    FDFL-H 17.2.5 Piping system Model FDFL258HEN-SA Cooling cycle Heating cycle Indoor unit Outdoor unit High pressure switch (63H (For fan motor control) Thermistor 4way valve Gas line Service valve Strainer (ø15.88) (Flare connecting) Heat exchanger Check joint Check joint Thermistor Muffler Heat exchanger Thermistor...
  • Page 668 FDFL-H Preset point of the protective devices Equipped Parts name Mark All models unit Thermistor OFF 68˚C (for protection over- ON 61˚C loading in heating) Indoor unit OFF 2.5˚C Thermistor (for frost prevention) ON 10˚C Thermistor OFF 135˚C (for detecting dis- Tho-D Outdoor unit ON 90˚C...

  • Page 669: Selection Chart

    FDFL-H 17.2.6 Selection chart Correct the cooling and heating capacity in accordance with the conditions as follows. The net cooling and heating capacity can be obtained in the following way. Net capacity = Capacity shown on specification × Correction factors as follows. (1) Coefficient of cooling and heating capacity in relation to temperatures Model FDFL258HEN-SA Indoor air W.B.
  • Page 670 FDFL-H Table of bypass factor Model FDFL 258 type FDFL 308 type Item 0.030 0.036 Air flow 0.013 0.018 (2) Correction of cooling and heating capacity in relation to air flow rate control (fan speed) Coefficient: 1.00 at High, 0.95 at Low (3) Correction of cooling and heating capacity in relation to one way length of refrigerant piping It is necessary to correct the cooling and heating capacity in relation to the one way equivalent piping length between the indoor and outdoor units.

  • Page 671: Noise Level

    FDFL-H 17.2.7 Noise level Notes (1) The data are based on the following conditions. Ambient air tempetature: Outdoor unit Indoor unit 27˚C DB, 19˚C WB. Measured on JIS B 8616 Outdoor unit 35˚C DB Mike position: at highest noise level Indoor unit Measured based on JIS B 8616 in position as below...

  • Page 672: Electrical Data

    FDFL-H 17.3 ELECTRICAL DATA 17.3.1 Electrical wiring Model FDFL258HEN-SA...
  • Page 673 FDFL-H Model FDFL308HEN-SA...
  • Page 674 FDFL-H Model FDFL308HES-SA...

  • Page 675: Outline Of Operation Control By Microcomputer

    FDFL-H 17.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Same as the cooling/heating equipment for FDT(N) heat pump type. Refer to page 317. 17.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautions” first then accurately execute the installation work. WARNING and CAUTION , those •...

  • Page 676: Installation Of Indoor Unit

    All Wiring of this installation must comply with NATIONAL,STATE AND LOCAL REGULATIONS. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or through your local should particular problems occur, the matter should be referred to Mitsubishi Heavy Industries, Ltd. distributor. WARNING BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION.
  • Page 677 FDFL-H Mount the unit on the mounting brackets. Fix the unit on the floor by using the fixing brackets. Fixing bracket Fix the bracket on the Base by use of attached screws. [M8 × 8l] Mounting brackets After that fix it on the floor by use of flat washers and double nuts.

  • Page 678: Installation Of Outdoor Unit

    FDFL-H (4) Installation of remote controller (on the main unit) Attached remote controller may be installed on the main unit as shown below. The work can be done on the spot when the customer asks so or by other reasons. Refer to the next page when it is installed on the wall.

  • Page 679: V Multi

    V MULTI V MULTI 18. MULTI-TYPE(V MULTI) PACKAGED AIR-CONDITIONER Split system, Air to air heat pump type OUTDOOR UNIT FDC508HES3 808HES3 1008HES3 INDOOR UNIT FDT208-A FDR208-A 258-A 258-A 308-A 308-A 408-A 408-A 508-A 508-A...
  • Page 680 V MULTI CONTENTS 18.1 GENERAL INFORMATION ..............679 18.1.1 Specific features ................679 18.1.2 How to read the model name............679 18.1.3 Table of models ................. 680 18.1.4 Table of system combinations ............680 18.2. SELECTION DATA ................... 681 18.2.1 Specifications ..................681 18.2.2 Range of usage &...
  • Page 681 V MULTI 18.1 GENERAL INFORMATION 18.1.1 Specific features Ideal for the installation conditions characteristic of larger rooms and L-shaped or other non-standard-shaped rooms, the Multi-Type V series allows an extensive degree of flexibility in the selection of indoor units. Specifically, the selection of indoor units with differing capacities and differing or similar types is supported, as is the selection of indoor units with similar capacities and differing types.

  • Page 682: Table Of Models

    V MULTI 18.1.3 Table of models Capacity Model Ceiling recessed type (FDT) Cassetteria type (FDR) FDC508HES3 FDC808HES3 FDC1008HES3 Outdoor unit to be combined(FDC) (5 Horse Power) (8 Horse Power) (10 Horse Power) 18.1.4 Table of system combinations Branch pipe set Outdoor unit Type Indoor unit assembly capacity...
  • Page 683 V MULTI 18.2 SELECTION DATA 18.2.1 Specifications (1) Indoor unit (a) Ceiling recessed type (FDT) Models FDT208-A, 258-A Model FDT208-A FDT258-A Item ( 1) Nominal cooling capacity 5000 5700 ( 1) Nominal heating capacity 5400 6100 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 38 Lo: 33...
  • Page 684 V MULTI Models FDT308-A, 408-A, 508-A Model FDT308-A FDT408-A FDT508-A Item ( 1) Nominal cooling capacity 7100 10000 12500 ( 1) Nominal heating capacity 8000 11200 14000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Lo: 35 Hi: 48 Lo: 40 Hi: 49 Lo: 43 Unit:260...
  • Page 685 V MULTI (b) Cassetteria type (FDR) Models FDR208-A, 258-A Model FDR208-A FDR258-A Item Decorative panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E R-PNLS-36W-E R-PNLC-36W-E ( 1) Nominal cooling capacity 5000 5700 ( 1) Nominal heating capacity 5400 6100 Power source...
  • Page 686 V MULTI Models FDR308-A, 408-A Model FDR308-A FDR408-A Item Decorative panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E R-PNLS-46W-E R-PNLC-46W-E ( 1) Nominal cooling capacity 7100 10000 ( 1) Nominal heating capacity 8000 11200 Power source 1 Phase 220/240V 50Hz Noise level...
  • Page 687 V MULTI Model FDR508-A Model FDR508-A Item Decorative panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E ( 1) Nominal cooling capacity 12500 ( 1) Nominal heating capacity 14000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 46 Lo: 39 Hi: 47 Lo: 40 Exterior dimensions Unit:406...
  • Page 688 V MULTI Outdoor unit Models FDC508HES3, 808HES3, 1008HES3 Model FDC508HES3 FDC808HES3 FDC1008HES3 Item Power source 3 Phase 380/415V 50Hz ( 1) Nominal cooling capacity 12500 20000 25000 ( 1) Nominal heating capacity 14000 21200 28000 Noise level dB(A) Exterior dimensions 1250 1450 1350...
  • Page 689 V MULTI (3) Operation chart The Multi series is a system that allows for different models and capacities of indoor units to be combined so the individual operating characteristics of the indoor and outdoor are provided. Use the procedure shown in Item (c) to calculate the combined operating characteristics.
  • Page 690 V MULTI Operation characteristics of each unit (Cooling/Heating) Model FDC808HES3 FDT308-A FDT508-A Item Power input (kW) 8.44/6.44 0.11/0.11 0.27/0.27 Running current (A) 14.2/11.6 0.6/0.6 1.4/1.4 1 Total power input (kW) (Cooling) 8.44 + 0.11+ 0.27 = 8.82 (kW) (Heating) 6.44 + 0.11+ 0.27 = 6.82 (kW) 2 Total running current (A) (Cooling) 14.2 + (0.6+1.4 ×...
  • Page 691 V MULTI Height and length restrictions for refrigerant piping Models FDC508HES3 < = Outdoor unit Indoor unit • One-way pipe length (m) L +ra +rb 50 < = < = < = lra – rbl 10, ra 30, rb 30 •...

  • Page 692: Exterior Dimensions

    V MULTI 18.2.3 Exterior dimensions (1) Indoor unit (a) Ceiling recessed type (FDT) Model FDT208-A Unit : mm (Ceiling hole size) Decorative Panel Fresh air opening (Suspension bolts for ducting pitch) Exhaust air opening for ducting B→ Air inlet grille Air outlet grille Drain hose(Accessories) (Connectable with VP25)
  • Page 693 V MULTI Models FDT258-A, 308-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille VIEW A Drain hose (Accessories) Liquid piping Air outlet grille (Connectable with VP25) φ9.52(3/8")
  • Page 694 V MULTI Models FDT408-A, 508-A Unit : mm Decorative Panel (Ceiling hole size) 860~890 Fresh air (Suspension bolts pitch ) opening for ducting Exhaust air opening for ducting D→ B→ Air inlet grille VIEW A Drain hose (Accessories) Air outlet grille (Connectable with VP25) Liquid piping φ9.52(3/8")
  • Page 695 V MULTI (b) Cassetteria type (FDR) Model FDR208-A Silent Panel (Model: R-PNLS-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Locality) Fresh air opening (Knock out hole) C↓ Control box Panel center VIEW C Drain Air outlet duct (Connectable with VP25) Liquid piping Gas piping...
  • Page 696 V MULTI Model FDR208-A Canvas Panel (Model: R-PNLC-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Local Locality) (Suspension bolts pitch) Fresh air opening C↓ (Knock out hole) Drain (Connectable with VP25) Control box Panel center Liquid piping φ6.35 (1/4") VIEW C Air outlet duct Gas piping...
  • Page 697 V MULTI Models FDR258-A, 308-A Unit : mm Silent Panel (Model: R-PNLS-36W-E) (Ceiling hole size) 1180 Drain hose (Accessories) (Suspension bolts pitch) (Locality) Fresh air opening (Knock out hole) C↓ Control box Panel center VIEW C Air outlet duct Suspension bolts 295~325 (M10 ×...
  • Page 698 V MULTI Models FDR258-A, 308-A...
  • Page 699 V MULTI Models FDR408-A, 508-A Silent Panel (Model: R-PNLS-46W-E) Unit : mm 1600(Ceiling hole size) Drain hose(Accessories) 1406(Suspension bolts pictch) (Locality) Fresh air opening (Knock out hole) Control box Panel center VIEW C Air outlet duct Drain Suspension bolts (Connectable (M10 ×...
  • Page 700 V MULTI Models FDR408-A, 508-A Canvas Panel (Model: R-PNLC-46W-E) Unit : mm Drain hose(Accessories) 1424(Ceiling hole size) Fresh air opening (Locality) 1406(Suspension bolts pictch) (Knock out hole) Panel center Control box VIEW C Air outlet duct Drain (Connectable with VP25) Hole for Suspension bolts 1370...
  • Page 701 V MULTI (2) Remote controller (Optional parts) Unit : mm Wall 0.3mm , 3cores (O.D.φ5.6) Wire (Recessed) LCD display Junction box (Locally Purchased) Remote controller mounting dimensions ♦ Usable JIS box, JIS C 8336 ⋅ Switch box for 1 piece (without cover) (use of the mark hole as illustrated on the left) ⋅...
  • Page 702 V MULTI (3) Outdoor unit Model FDC508HES3 Unit: mm φ Liquid piping: 9.52 (3/8") (Flare connecting) φ Gas piping: 19.05 (3/4") (Flare connecting) Terminal block φ Liquid piping: 9.52 (3/8") (Flare connecting) φ Gas piping: 19.05 (3/4") (Flare connecting) Opening for electric wiring Opening for electric wiring Opening for piping...
  • Page 703 V MULTI Models FDC808HES3, 1008HES3 Unit: mm 1350 Opening for Connect of liquid piping exit wiring 808: ø12.7 (1/2") (ø50) 1008: ø15.58 (5/8") Opening for exit piping (ø88) Opening for exit wiring Power supply connecting (ø50) Connect of gas piping terminal block 808: ø25.4 (1") Opening for...

  • Page 704: Exterior Appearance

    V MULTI 18.2.4 Exterior appearance (1) Indoor unit (a) Ceiling recessed type (FDT) Models All models Item Panel model Remarks Type FDT208-A T-PSA-22W-E Without swing FDT258-A~508-A T-PSA-32W-E Pearl white (Decorative panel) (b) Cassetteria type (FDR) Models All models Silent panel type Canvas-duct panel type Ceramic White Ceramic White...
  • Page 705 V MULTI 18.2.5 Piping system (1) Twin type Model FDC508HES3 High pressure switch (63H Cooling cycle Indoor unit Indoor unit Outdoor unit (For fan motor control) Heating cycle 4way valve Thermistor (ø15.88) (ø15.88) Gas line Strainer Strainer Service valve Branch pipe (ø19.05) (Flare connecting) (Brazing)
  • Page 706 V MULTI (2) Triple type Models FDC808HES3,1008HES3 Indoor unit Indoor unit Indoor unit Outdoor unit Cooling cycle Flare Heating cycle connecting High pressure switch(63H Service valve Thermistor (Brazing) (For fan motor control) Branch pipe(Brazing) Gsa line 208~308 : ø15.88 Strainer 208~308 : ø15.88 208~308 : ø15.88 Strainer...
  • Page 707 V MULTI Preset point of the protective devices Equipped FDC508HES3 FDC808HES3, 1008HES3 Parts name Mark unit Thermistor OFF 68˚C (for protection over- ON 61˚C loading in heating) Indoor unit OFF 2.5˚C Thermistor (for frost prevention) ON 10˚C Thermistor OFF 135˚C (for detecting dis- Tho-D Outdoor unit...
  • Page 708 V MULTI Table of bypass factor FDT series Model 208 type 258 type 308 type 408 type 508 type Item 0.112 0.050 0.065 0.076 0.025 Air flow 0.073 0.030 0.030 0.050 0.013 FDR series Model 208 type 258 type 308 type 408 type 508 type Item...
  • Page 709 V MULTI 18.2.7 Characteristics of fan • External static pressure table How to interpret the blower characteristics table Unit: Pa (mmAq) Example : Case of FDR308-A Duct specs. 1 spot closing Standard Square duct 1 2-spot blowout..... Internal resistance increases more Air flow 40(4) Stan-...
  • Page 710 V MULTI Model FDR308-A Model FDR408-A 120(12) 120(12) 100(10) 100(10) 80(8) 80(8) 60(6) 60(6) 40(4) 40(4) 20(2) 20(2) 2-spot blower 3-spot blower internal resistance internal resistance 0(0) 0(0) [Standard] 4-spot blower internal resistance [Standard] 3-spot blower internal resistance Square duct blower internal resistance Square duct blower internal resistance –20(–2)
  • Page 711 V MULTI 18.2.8 Noise level Notes (1) The data are based on the following conditions. Ambient air temperature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB. Indoor unit Outdoor unit Measured based on JIS B 8616 Only case of FDC508 Mike position as below Measured based on JIS B 8616 FDR series...
  • Page 712 V MULTI Model FDR408-A Model FDR508-A Noise level 45 dB (A) at HIGH Noise level 46 dB (A) at HIGH 38 dB (A) at LOW 39 dB (A) at LOW 1000 2000 4000 8000 1000 2000 4000 8000 Mid octave band frequency (Hz) Mid octave band frequency (Hz) Canvas panel Model FDR208-A...

  • Page 713: Models All Models

    V MULTI 18.3 ELECTRICAL DATA 18.3.1 Electrical wiring (1) Indoor unit (a) Ceiling recessed type (FDT) Models All models Tr I BK RD Power wires to outdoor unit Option to outdoor unit Test ThI–A ThI–R H UH CnS2 (49F BK LS 1 2 3 4 1 2 3 4 RD WH BK...
  • Page 714 V MULTI (2) Outdoor unit Model FDC508HES3 Power source 3Phase 380-415V 50Hz RD/WH Power wires to indoor unit BK/WH BK/RD BK/WH BL/WH to indoor unit BR/WH (49F (49F Tho-R Tho-D Tho-A H L UH H L UH LED-R (Checker) (Check) CnA1 CnA2 LED-G...
  • Page 715 V MULTI 18.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Except for function relating to heating, same as the unit for FDT(N) heat pump type. See page 317. 18.5 APPLICATION DATA 18.5.1 Installation of indoor unit (1) Ceiling recessed type (FDT) Except for function relating to heating, same as the unit for FDT(N) heat pump type.
  • Page 716 V MULTI When the unit is installed at the particular location as shown below, corrosion or failure may be caused. Please consult the dealer from which you purchased the air-conditioner. a) The place where corrosive gas is generated (hot spring, etc.). b) The place where wind containing salt blows (seaside area).
  • Page 717 V MULTI Unit: mm (c) Bolt securing position Models FDC808HES3, 1008HES3 Model FDC508HES3 Intake Anchor bolt Discharge position (4 locations) (Service panel side) Anchor bolt position (4 places) Use anchor bolts (M10) to secure the unit's legs. Fasten with a Securely install the unit so that it dose not fall over during earth- bolt (M10).
  • Page 718 V MULTI • FDC808HES3 [Branch pipe set: DIS-WB] • FDC1008HES3 [Branch pipe set: DIS-WB] Indoor unit Indoor unit φ19.05 φ19.05 Outdoor unit Outdoor unit φ9.52 φ9.52 φ25.4 φ28.58 1008 φ12.7 φ15.88 φ19.05 φ19.05 φ9.52 φ9.52 Chart of shapes of branch piping parts (DIS-WB) φ15.88 Gas pipe...
  • Page 719 V MULTI (iii) Double twin • FDC808HES3 [Branch pipe set: DIS-WA × 2set, DIS-WB × 1set] Indoor unit Chart of shapes of branch piping parts DIS-WA ø15.88 • DIS-WB ø9.52 Gas pipe Mark Liquid pipe Mark Reducer Mark ø19.05 (ø6.35) ø9.52 DIS-WB OD28.58...
  • Page 720 V MULTI (b) Piping work Request ¡ Use the pipe made of following material. Moreover, it is very convenient for you to use the separately sold piping kit. Material: Phosphor deoxidized seamless copper tube (C1220T, JIS H3300) ¡ In the case of this unit, condensation water is also generated on the liquid piping. Insulate both of the liquid piping and gas piping perfectly.
  • Page 721 V MULTI Models FDC808HES3, 1008HES3 Leak test Air purge (3) After completion of (1) The unit's air-tightness test has been conducted but after completing (2) While holding the vacuuming, remove the the piping connections conduct an air-tightness test of the connected service valves (both cap nut for the valve piping and the indoor units using the outdoor gas side service valve...
  • Page 722 V MULTI Double twin specification (FDC808, 1008HES3 only) G = main piping L (m) × C + branch piping L (m) × f + branch piping L (m) × f + branch piping (m) × f (m) × f + branch piping (m) ×...
  • Page 723 V MULTI Wiring connection. ¡ Connect the same terminal number between the Indoor unit and Outdoor unit as shown in the following diagram. ¡ Make wiring to supply to the Outdoor unit, so that the power for the Indoor unit is supplied by 1 and 2 terminals. ¡...
  • Page 724 V MULTI MEMO...

  • Page 725: Fdc-Hkx

    FDC-HKX FDC-HKX 19. INVERTER DRIVEN MULTI-INDOOR UNIT CLIMATE CONTROL SYSTEM (OUTDOOR UNIT) Refrigerant R22 use models FDCJ140HKXE2B, 224HKXE2B, 280HKXE2B Alternative refrigerant R407C use models FDCP140HKXE2B, 224HKXE2B, 280HKXE2B (INDOOR UNIT) FDTJ28HKXE2 FDTWJ28HKXE2B FDTSJ22HKXE2B FDRJ22HKXE2 36HKXE2 45HKXE2B 28HKXE2B 28HKXE2 45HKXE2 56HKXE2B 36HKXE2B 45HKXE2 56HKXE2 71HKXE2B...
  • Page 726 FDC-HKX CONTENTS 19.1 GENERAL INFORMATION ..............725 19.1.1 Specific features ................725 19.1.2 How to read the model name............727 19.1.3 Table of models ................. 727 19.1.4 Table of indoor units panel (Optional) ..........727 19.2 SELECTION DATA ................... 728 19.2.1 Specifications ..................
  • Page 727 FDC-HKX 19.1 GENERAL INFORMATION 19.1.1 Specific features (1) Fuzzy control Response speed and stability are enhanced. ¡ The system automatically controls changes of return air temperature, set temperature and room temperature according to the fuzzy control. ¡ The system response speed, can keep room temperature constant, and can adjust room temperature to set temperature quickly. Inverter Hz Set temp.
  • Page 728 FDC-HKX (5) Connectable indoor capacity Capacity from 50% to 130% is possible. ¡ FDCJ(P)140 type ¡ FDCJ(P)280 type Number of connectable units : 1 to 8 units Number of connectable units : 1 to 16 units Connectable capacity : 7000 ~ 18200 W Connectable capacity : 14000 ~ 36400 W ¡...
  • Page 729 FDC-HKX 19.1.2 How to read the model name Example: CE marking model Application power source...See the specifications Multi KX series Heat pump type Nominal capacity P: R407C models J: R22 models Model name Indoor unit : FDT, FDTW, FDTS, FDR, FDUM FDE, FDK, FDFL, FDFU Outdoor unit : FDC 19.1.3 Table of models...
  • Page 730 FDC-HKX 19.2 SELECTION DATA 19.2.1 Specifications (1) Indoor unit (a) Ceiling recessed type (FDT) Models FDTJ28HKXE2, 36HKXE2 Models FDTJ28HKXE2 FDTJ36HKXE2 Item Nominal cooling capacity* 2800 3600 Nominal heating capacity* 3200 4000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 37 Me: 34 Lo: 33 Exterior dimensions Unit:260...
  • Page 731 FDC-HKX Models FDTJ45HKXE2, 56HKXE2, 71HKXE2 Models FDTJ45HKXE2 FDTJ56HKXE2 FDTJ71HKXE2 Item Nominal cooling capacity* 4500 5600 7100 Nominal heating capacity* 5000 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 38 Me: 35 Lo: 34 Hi: 40 Me: 38 Lo: 36 Exterior dimensions Unit:260 Panel:30...
  • Page 732 FDC-HKX Models FDTJ90HKXE2, 112HKXE2, 140HKXE2 Models FDTJ90HKXE2 FDTJ112HKXE2 FDTJ140HKXE2 Item Nominal cooling capacity* 9000 11200 14000 Nominal heating capacity* 10000 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 42 Me: 40 Lo: 39 Hi: 49 Me:46 Lo: 42 Hi: 50 Me: 47 Lo: 45 Exterior dimensions Unit: 260...
  • Page 733 FDC-HKX (b) 2-way outlet ceiling recessed type (FDTW) Models FDTWJ28HKXE2B, 45HKXE2B, 56HKXE2B Models FDTWJ28HKXE2B FDTWJ45HKXE2B FDTWJ56HKXE2B Item Nominal cooling capacity* 2800 4500 5600 Nominal heating capacity* 3200 5000 6300 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 39 Me:36 Lo: 33 Exterior dimensions Unit:280 817 620 Panel:8...
  • Page 734 FDC-HKX Models FDTWJ71HKXE2B, 90HKXE2B Models FDTWJ71HKXE2B FDTWJ90HKXE2B Item Nominal cooling capacity* 7100 9000 Nominal heating capacity* 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me: 38 Lo: 35 Hi: 41 Me: 39 Lo: 36 Exterior dimensions Unit:330 1054 Panel:8...
  • Page 735 FDC-HKX Models FDTWJ112HKXE2B, 140HKXE2B Models FDTWJ112HKXE2B FDTWJ140HKXE2B Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 44 Me: 41 Lo: 38 Hi: 45 Me: 42 Lo: 39 Exterior dimensions Unit:345 1524 Panel:8...
  • Page 736 FDC-HKX (c) 1-way outlet ceiling recessed type (FDTS) Models FDTSJ22HKXE2B, 28HKXE2B, 36HKXE2B Model FDTSJ22HKXE2B FDTSJ28HKXE2B FDTSJ36HKXE2B Item Nominal cooling capacity* 2200 2800 3600 Nominal heating capacity* 2500 3200 4000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 39 Lo: 38 Hi: 40 Me: 39 Lo: 38 Exterior dimensions Unit:194...
  • Page 737 FDC-HKX Models FDTSJ45HKXE2B, 71HKXE2B Model FDTSJ45HKXE2B FDTSJ71HKXE2B Item Nominal cooling capacity* 4500 7100 Nominal heating capacity* 5000 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 38 Hi: 44 Me: 40 Lo: 38 Exterior dimensions Unit:194 1040 Unit:194...
  • Page 738 FDC-HKX (d) Cassetteria type (FDR) Models FDRJ22HKXE2, 28HKXE2 Models FDRJ22HKXE2 FDRJ28HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E R-PNLS-26W-E R-PNLC-26W-E Nominal cooling capacity* 2200 2800 Nominal heating capacity* 2500 3200 Power source 1 Phase 220/240V 50Hz Noise level...
  • Page 739 FDC-HKX Models FDRJ45HKXE2, 56HKXE2 Models FDRJ45HKXE2 FDRJ56HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E R-PNLS-26W-E R-PNLC-26W-E Nominal cooling capacity* 4500 5600 Nominal heating capacity* 5000 6300 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 37...
  • Page 740 FDC-HKX Models FDRJ71HKXE2, 90HKXE2 Models FDRJ71HKXE2 FDRJ90HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity* 7100 9000 Nominal heating capacity* 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 37...
  • Page 741 FDC-HKX Models FDRJ112HKXE2, 140HKXE2 Models FDRJ112HKXE2 FDRJ140HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 45 Me: 42 Lo: 38...
  • Page 742 FDC-HKX (e) Satellite ducted type (FDUM) Models FDUMJ36HKXE2, 45HKXE2 Models FDUMJ36HKXE2 FDUMJ45HKXE2 Item Nominal cooling capacity* 3600 4500 Nominal heating capacity* 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 34 Me: 32 Lo: 29 Hi: 35 Me: 32 Lo: 29 Exterior dimensions Height Width...
  • Page 743 FDC-HKX Models FDUMJ56HKXE2, 71HKXE2, 90HKXE2 Models FDUMJ56HKXE2 FDUMJ71HKXE2 FDUMJ90HKXE2 Item Nominal cooling capacity* 5600 7100 9000 Nominal heating capacity* 6300 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 35 Me: 32 Lo: 29 Hi: 35 Me: 32 Lo: 29 Hi: 36 Me: 33 Lo: 30 Exterior dimensions Height...
  • Page 744 FDC-HKX Models FDUMJ112HKXE2, 140HKXE2 Models FDUMJ112HKXE2 FDUMJ140HKXE2 Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 38 Me: 35 Lo: 32 Hi: 39 Me: 37 Lo: 34 Exterior dimensions 1370 Height Width...
  • Page 745 FDC-HKX Ceiling suspension type (FDE) Models FDEJ36HKXE2B, 45HKXE2B Models FDEJ36HKXE2B FDEJ45HKXE2B Item Nominal cooling capacity* 3600 4500 Nominal heating capacity* 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me:40 Lo: 38 Exterior dimensions 1000 Height Width Depth Net weight...
  • Page 746 FDC-HKX Models FDEJ56HKXE2B, 71HKXE2B Models FDEJ56HKXE2B FDEJ71HKXE2B Item Nominal cooling capacity* 5600 7100 Nominal heating capacity* 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me:40 Lo: 38 Hi: 44 Me:40 Lo: 38 Exterior dimensions 1000 1260 Height Width...
  • Page 747 FDC-HKX Models FDEJ112HKXE2B, 140HKXE2B Models FDEJ112HKXE2B FDEJ140HKXE2B Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 49 Me:46 Lo: 42 Hi: 50 Me:47 Lo: 42 Exterior dimensions 1260 1470 Height Width...
  • Page 748 FDC-HKX (g) Wall mounted type (FDK) Models FDKJ22HKXE2, 28HKXE2, 36HKXE2, 45HKXE2 Models FDKJ22HKXE2 FDKJ28HKXE2 FDKJ36HKXE2 FDKJ45HKXE2 Item Nominal cooling capacity* 2200 2800 3600 4500 Nominal heating capacity* 2500 3200 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 40 Lo: 37 Hi: 42 Me:40 Lo: 37 Hi: 44 Me:41 Lo: 37...
  • Page 749 FDC-HKX Models FDKJ56HKXE2, 71HKXE2 Model FDKJ56HKXE2 FDKJ71HKXE2 Item Nominal cooling capacity* 5600 7100 Nominal heating capacity* 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 46 Me:43 Lo: 39 Hi: 47 Me:44 Lo: 40 Exterior dimensions 375 1148 1436 Height Width...
  • Page 750 FDC-HKX (h) Floor standing exposed type (FDFL) Models FDFLJ28HKXE2, 45HKXE2, 71HKXE2 Model FDFLJ28HKXE2 FDFLJ45HKXE2 FDFLJ71HKXE2 Item Nominal cooling capacity* 2800 4500 7100 Nominal heating capacity* 3200 5000 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me:38 Lo: 36 Hi: 43 Me:41 Lo: 40 Exterior dimensions 1196...
  • Page 751 FDC-HKX Floor standing hidden type (FDFU) Models FDFUJ28HKXE2, 45HKXE2, 56HKXE2, 71HKXE2 Model FDFUJ28HKXE2 FDFUJ45HKXE2 FDFUJ56HKXE2 FDFUJ71HKXE2 Item Nominal cooling capacity* 2800 4500 5600 7100 Nominal heating capacity* 3200 5000 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me:38 Lo: 36 Hi: 43 Me:41 Lo: 40 Exterior dimensions...
  • Page 752 FDC-HKX (2) Outdoor unit (a) Alternative refrigerant R407C use models Models FDCP140HKXE2B, 224HKXE2B, 280HKXE2B Models FDCP140HKXE2B FDCP224HKXE2B FDCP280HKXE2B Item Power source 3 Phase 380/415V 50Hz Nominal cooling capacity* 14000 22400 28000 Nominal heating capacity* 16000 25000 31500 Noise level dB(A) Exterior dimensions 1450 1450...
  • Page 753 FDC-HKX (b) Refrigerant R22 use models Models FDCJ140HKXE2B, 224HKXE2B, 280HKXE2B Models FDCJ140HKXE2B FDCJ224HKXE2B FDCJ280HKXE2B Item Power source 3 Phase 380/415V 50Hz Nominal cooling capacity* 14000 22400 28000 Nominal heating capacity* 16000 25000 31500 Noise level dB(A) Exterior dimensions 1450 1450 1350 Height Width...
  • Page 754 FDC-HKX (3) Operation chart Since the Multi KX series air conditioner units are free multitype to which the indoor units of different capacity and different model can be combined, the operation characteristics of all combinations are very complicated, therefore only the individual operation characteristics of indoor and outdoor units are shown.
  • Page 755 FDC-HKX FDTS Series (220 V/240 V) Models FDTS Series Item Power input (kW) 0.07/0.08 0.09/0.11 0.12/0.15 Running current (A) 0.33/0.36 0.43/0.46 0.58/0.63 FDR, FDUM Series (220 V/240 V) Models FDR, FDUM Series Item 28, 36 Power input (kW) 0.09/0.11 0.11/0.13 0.14/0.16 0.15/0.17 0.16/0.19...
  • Page 756 FDC-HKX Operation characteristics of each unit (Cooling/Heating) Models FDCJ224HKXE2B FDTJ71HKXE2 FDTJ45HKXE2 Item Power input (kW) 9.8/8.3 0.10/0.10 0.10/0.10 Running current (A) 15.7/13.0 0.47/0.47 0.45/0.45 1 Total power input (kW) (Cooling) 9.8 + (0.10 × 4) = 10.2 (kW) (Heating) 8.3 + (0.10 × 4) = 8.7 (kW) 2 Total running current (A) (Cooling) 15.7 + (0.47 ×...
  • Page 757 FDC-HKX 1) Correction factor of compressor power input Models FDCJ140HKXE2B, FDCP140HKXE2B Cooling (Rating) Heating (Rating) 22 28 Total capacity of concurrently operating indoor unit Models FDCJ224HKXE2B, FDCP224HKXE2B Cooling (Rating) Heating 40 60 80 100 120 140 160 180 200 220 240 260 280 300 22 28 (Rating) Total capacity of concurrently operating indoor unit...
  • Page 758 FDC-HKX Models FDCJ280HKXE2B, FDCP280HKXEB Cooling (Rating) Heating 22 28 (Rating) Total capacity of concurrently operating indoor unit 2) Compressor and outdoor fan power input in rated operation. (380 V/415V) Power input (kW) Compressor Outdoor fan Outdoor unit Cooling Heating 6.56/6.56 5.46/5.66 0.24/0.24 FDCJ140HKXE2B...
  • Page 759 FDC-HKX 19.2.2 Range of usage & limitations System FDCP140HKXE2B FDCP224HKXE2B FDCP280HKXE2B FDCJ 140HKXE2B FDCJ224HKXE2B FDCJ280HKXE2B Item Indoor intake air temperature (Upper, lower limits) Refer to the capacity characterstics. Outdoor air temperature (Upper, lower limits) Indoor units 1 to 8 units 1 to 13 units 1 to 16 units Number of connected units...
  • Page 760 FDC-HKX 19.2.3 Exterior dimensions (1) Indoor unit (a) Ceiling recessed type (FDT) Models FDTJ28HKXE2, 36HKXE2, 45HKXE2, 56HKXE2, 71HKXE2, 90HKXE2 Unit : mm Decorative Panel (Ceiling hole size) Holes for 860~890 Fresh air suspension bolts (Suspension bolts pitch ) opening for ducting (M10 to M8 ×4pcs.) Exhaust air opening for ducting...
  • Page 761 FDC-HKX Models FDTJ112HKXE2, 140HKXE2 Unit : mm Decorative Panel (Ceiling hole size) Holes for 860~890 Fresh air suspension bolts (Suspension bolts pitch ) opening for ducting (M10 to M8 ×4pcs.) Exhaust air opening for ducting B→ Liquid piping Air outlet Air inlet grille φ9.52(3/8") VIEW A...
  • Page 762 FDC-HKX (b) 2-way outlet ceiling recessed type (FDTW) Models FDTWJ28HKXE2B, 45HKXE2B, 56HKXE2B Unit : mm Drain hose (Ceiling hole size) 1015 (Accessories) (Suspension bolts pitch) (Local setting) Holes of tapping screws Suspension bolts 5 - φ4 (M10 × 4 pcs.) Control Hole Center of...
  • Page 763 FDC-HKX Models FDTWJ71HKXE2B, 90HKXE2B Unit : mm Drain hose 1260 (Ceiling hole size) (Accesories) Holes of (Suspension bolts pitch) 1130 (Local setting) taping screws Suspension bolts 5 – φ4 (M10 × 4 pcs.) Control Hole Center of Suspension panel fitting Fresh air opening VIEW A for ducting...
  • Page 764 FDC-HKX Models FDTWJ112HKXE2B, 140HKXE2B Unit: mm Drain hose 1730 (Ceiling hole size) (Accessories) Holes for (Local setting) 1600 (Suspension bolts pitch) tapping screws Suspension bolts 5-ø4 (M10 × 4 pcs.) Control Hole Center of panel Suspension fitting Fresh air opening VIEW A for ducting (knock out)
  • Page 765 FDC-HKX (c) 1-Way outlet ceiling recessed type (FDTS) Models FDTSJ22HKXE2B, 28HKXE2B, 36HKXE2B, 45HKXE2B Fresh air Unit : mm opening for ducting Fresh air (Knock out) Fresh air ↓ opening for ducting opening for ducting Holes for tapping screws (Ceiling hole size) 1230 (knock out) (Knock out)
  • Page 766 FDC-HKX Model FDTSJ71HKXE2B Unit : mm Fresh air Fresh air opening for ducting opening for ducting Fresh air (Ceiling hole size) 1440 (Knock out) (knock out) opening for ducting Holes for tapping screws (Suspension bolts pitch) 1250 (φ4-6pcs.) (knock out) Panel center VIEW A Drain hose(Accessories)
  • Page 767 FDC-HKX (d) Cassetteria type (FDR) Model FDRJ22HKXE2 Silent Panel (Model: R-PNLS-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Local setting) Fresh air opening for ducting ↓ (Knock out) Control box Panel center VIEW C Drain Supply air duct (Connectable with VP25) Liquid piping...
  • Page 768 FDC-HKX Model FDRJ22HKXE2 Canvas Panel (Model: R-PNLC -26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Load setting) Fresh air opening for ducting C↓ (Knock out) Control box Drain (Connectable with VP25) Panel center Liquid piping φ6.35(1/4") Gas piping φ12.7(1/2")
  • Page 769 FDC-HKX Models FDRJ28HKXE2, 45HKXE2, 56HKXE2 Silent Panel (Model: R-PNLS-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bols pitch) Fresh air (Local setting) opening for ducting (Knock out) C↓ Control box panel center VIEW C Drain Supply air duct (Connectable with VP25) Liquid piping Gas piping...
  • Page 770 FDC-HKX Models FDRJ28HKXE2, 45HKXE2, 56HKXE2 Canvas Panel (Model: R-PNLC-26W-E) Unit : mm Drain hose (Accessories) (Ceiling hole size) (Local setting) (Suspension bolts pitch) Fresh air opening for ducting C↓ (Knock out) Control box Drain (Connectable with VP25) Panel center Liquid piping 28, 45 type: φ6.35 (1/4") 56 type: φ9.52 (3/8") Gas piping...
  • Page 771 FDC-HKX Models FDRJ71HKXE2, 90HKXE2 Silent Panel (Model: R-PNLS-36W-E) Unit : mm (Ceiling hole size) 1180 Drain hose (Accessories) (Suspension bolts pitch) (Local setting) Fresh air opening for ducting (Knock out) C↓ Control box Panel center VIEW C Supply air duct Drain (Connectable with VP25) Gas piping...
  • Page 772 FDC-HKX Models FDRJ71HKXE2, 90HKXE2 Canvas Panel (Model: R-PNLC-36W-E) Unit : mm (Ceilinghole hole size) Drain hose (Accessories) 1004 (Local setting) (Suspension bolts pitch) Fresh air opening for ducting C ↑ (Knock out) Drain (Connectable Control box with VP25) Panel center Liquid piping φ9.52(3/8") Gas piping...
  • Page 773 FDC-HKX Models FDRJ112HKXE2, 140HKXE2 Silent Panel (Model: R-PNLS-46W-E) Unit : mm 1600 (Ceiling hole size) Drain hose (Accessories) 1406 (Suspension bolts pitch) (Local setting) Fresh air opening for ducting (Knock out) ↑ Control box Panerl center VIEW C Supply air duct Drain (Connectable with VP25) Liquid piping...
  • Page 774 FDC-HKX Models FDRJ112HKXE2, 140HKXE2 Canvas Panel (Model: R-PNLC-46W-E) Unit : mm (Ceiling hole size) 1424 Drain hose (Accessories) Fresh air opening for ducting (Local setting) (Suspension bolts pitch) 1406 (Knock out) ↑ Control box Drain Panel center (Connecteble with VP25) Liquid piping φ9.52(3/8") VIEW C...
  • Page 775 FDC-HKX (e) Satellite ducted type (FDUM) Models FDUMJ36HKXE2, 45HKXE2, 56HKXE2 Unit : mm (Suspension bolts pitch) Hole of tapping screws ↑ (4-φ4) φ Control box Drain hose (Accessories) (Local setting) A→ Drain (Connectable with VP25) φ φ Liquid piping 36, 45 type: φ6.35(1/4") 56 type: φ9.52(3/8") Fresh air opening Exhaust air opening for ducting...
  • Page 776 FDC-HKX Models FDUMJ71HKXE2, 90HKXE2 Unit : mm 986 (Suspension bolts pitch) ↑ Holes of φ149 tapping screws Control box 4-φ4 Drain hose (Accessories) (Local setting) A→ Drain (Connectable with VP25) φ170 φ170 Liquid piping φ9.52(3/8") Fresh air opening Gas piping for ducting Exhaust air opening for ducting φ15.88(5/8")
  • Page 777 FDC-HKX Models FDUMJ112HKXE2, 140HKXE2 Unit : mm (Suspension bolts pitch) 1406 1370 Holes of tapping screws ↑ φ (4-φ4) Control box Drain hose (Accessories) (Local setting) φ A→ Drain φ (Connectable with VP25) Fresh air opening Liquid piping for ducting Exhaust air opening for ducting φ9.52(3/8") (Knock out)
  • Page 778 FDC-HKX Ceiling suspension type (FDE) Models FDEJ36HKXE2B, 45HKXE2B, 56HKXE2B Unit : mm (Suspension bolts pitch) Holes for suspension bolts The brackets face out The brackets face out (M8 to M10 × 4 pcs. Not included) When the unit is half When the unit is half recesed a bove recesed a bove...
  • Page 779 FDC-HKX Model FDEJ112HKXE2B Unit : mm (Suspension bolts pitch) 1244 Holes for suspension bolts The brackets face out (M8 to M10 × 4pcs. Not included) When the unit is half recesed a bove Liguid piping the ceiling (Suspension bolt pitch) Gas piping 1160 The brackets face interior...
  • Page 780 FDC-HKX (g) Wall mounted type (FDK) Models FDKJ22HKXE2, 28HKXE2, 36HKXE2, 45HKXE2 Unit : mm ←A Outlet for electric wiring Detail of mounting plate Outlet for piping (On both side) 77.5 77.5 Space for installation and service 20 20 Mounting plate φ8 ×...
  • Page 781 FDC-HKX Model FDKJ71HKXE2 Unit : mm 1436 ←A Outlet for electric wiring Detail of mounting plate 1196 Outlet for piping 1306 (On both side) 377.5 377.5 Space for installation and service 20 20 Mounting plate φ8 × 48 pcs. (Holes on mounting more more...
  • Page 782 FDC-HKX Floor standing hidden type (FDFU) Models FDFUJ28HKXE2, 45HKXE2, 56HKXE2, 71HKXE2 Unit : mm Note (1) Value in ( ) indicates 71 type. Space for installation and service Slotted hole for (1071) wall mounting 4-12 x 24 Peri cover Peri cover 810(1095) 722(1007) Expansion valve box...
  • Page 783 FDC-HKX (3) Outdoor unit Models FDCP140HKXE2B Models FDCJ140HKXE2B...
  • Page 784 FDC-HKX Models FDCP224HKXE2B, 280HKXE2B Models FDCJ224HKXE2B, 280HKXE2B...
  • Page 785 FDC-HKX 19.2.4 Exterior appearance (1) Indoor unit (a) Ceiling recessed type (FDT) ¡ Decorative panel Pearl white (b) 2-way outlet ceiling recessed type (FDTW) Air outlet Air inlet ¡ Decorative panel (i) Standard type Panel part No. Type Panel color Applicable model TW-PSA-22W-E FDTW28, 45, 56 type...
  • Page 786 FDC-HKX (c) 1-way outlet ceiling recessed type (FDTS) Panel Air inlet grille Ceramic white Ceramic white ¡ Decorative panel Panel part No. Type Panel color Applicable model TS-PSA-26W-E FDTS22, 28, 36, 45 type With Auto swing Misty white TS-PSA-36W-E FDTS71 type (d) Cassetteria type (FDR) Silent panel type Canvas-duct panel type...
  • Page 787 FDC-HKX (g) Wall mounted type (FDK) Parts name Color Side plate Front panel Inlet grill Ceramic white Outlet grill Bottom plate Right and Left Light gray louvers (h) Floor standing exposed type (FDFL) Dark gray (Outlet grill) Ceramic white (Body) Black (Bottom plate) Floor standing hidden type (FDFU) ..........
  • Page 788 FDC-HKX 19.2.5 Piping system Models FDCP140HKXE2B FDCJ140HKXE2B...
  • Page 789 FDC-HKX Models FDCP224HKXE2B, 280HKXE2B FDCJ224HKXE2B, 280HKXE2B...
  • Page 790 FDC-HKX 19.2.6 Selection chart (1) Correct the cooling and heating capacity in accordance with the conditions as follows.The net cooling and heating capacity can be,obtained in the following way. Indoor unit Indoor unit capacity Each indoor unit = System performance × Indoor unit capacity when operating simultaneously.
  • Page 791 FDC-HKX (c) When the outdoor unit is located at a lower height than the indoor unit in cooling operation and when the outdoor unit is located at a higher height than the indoor unit in heating operation, the following values should be subtracvted from the values in the above table.
  • Page 792 FDC-HKX...
  • Page 793 FDC-HKX Capacity Correction Calculations (The procedure for both cooling and heating is the same.) Example Conditions • Unit (50 Hz) Outdoor unit FDCJ280HKXE2B 1 unit Indoor unit FDTJ90HKXE2 - 1 unit FDTJ140HKXE2 - 1 unit FDTWJ28HKXE2B - 1 unit Corrction when FDTSJ22HKXE2B - 1 unit cooling? •...
  • Page 794 FDC-HKX (3) Sensible heat capacity (a) FDT Series Model FDTJ28HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 2.89 2.58 2.98 2.60 3.05 2.61 3.13 2.63 3.21 2.64 3.28 2.83 2.55 2.91 2.57 2.99 2.59...
  • Page 795 FDC-HKX Model FDTJ71KHXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 7.33 5.31 7.55 5.34 7.75 5.35 7.94 5.36 8.13 5.36 8.31 7.18 5.24 7.39 5.27 7.58 5.28 7.78 5.29 7.99 5.30 8.17 7.00 5.15...
  • Page 796 FDC-HKX (b) FDTS Series Model FDTSJ22HKXE2B Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 2.27 2.04 2.34 2.06 2.40 2.08 2.46 2.09 2.52 2.10 2.57 2.11 2.22 2.02 2.29 2.04 2.35 2.06 2.41 2.07 2.48...
  • Page 797 FDC-HKX Model FDTSJ71HKXE2B Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 7.36 5.56 7.57 5.59 7.77 5.61 7.92 5.61 8.14 5.63 8.34 5.64 7.19 5.49 7.40 5.52 7.61 5.55 7.80 5.56 7.97 5.57 8.18 5.58...
  • Page 798 FDC-HKX Model FDRJ56HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 5.80 4.36 5.97 4.39 6.13 4.40 6.25 4.40 6.42 4.41 6.57 4.42 5.67 4.30 5.84 4.33 6.00 4.35 6.15 4.36 6.28 4.36 6.45 4.37...
  • Page 799 FDC-HKX Model FDRJ140HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 14.50 10.78 14.92 10.84 15.32 10.88 15.62 10.87 16.04 10.90 16.44 10.91 14.17 10.63 14.59 10.69 15.01 10.75 15.37 10.77 15.71 10.77 16.13 10.80...
  • Page 800 FDC-HKX Model FDUMJ71HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 7.36 5.56 7.57 5.59 7.77 5.61 7.92 5.61 8.14 5.63 8.34 5.64 7.19 5.49 7.40 5.52 7.61 5.55 7.80 5.56 7.97 5.57 8.18 5.58...
  • Page 801 FDC-HKX (e) FDE Series Model FDEJ36HKXE2B Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 3.73 3.34 3.84 3.36 3.94 3.39 4.02 3.40 4.13 3.42 4.23 3.44 3.64 3.30 3.75 3.33 3.86 3.36 3.95 3.38 4.04...
  • Page 802 FDC-HKX Model FDEJ112HKXE2B Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 11.60 8.72 11.94 8.77 12.25 8.80 12.50 8.80 12.84 8.83 13.15 8.84 11.33 8.60 11.67 8.66 12.01 8.70 12.30 8.72 12.57 8.72 12.90 8.75...
  • Page 803 FDC-HKX Model FDKJ36HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 3.73 2.93 3.84 2.95 3.94 2.96 4.02 2.97 4.13 2.98 4.23 2.98 3.64 2.89 3.75 2.91 3.86 2.93 3.95 2.94 4.04 2.95 4.15 2.96...
  • Page 804 FDC-HKX (g) FDFL, FDFU Series Models FDFLJ28HKXE2, FDFUJ28HKXE2 Indoor air temperature Outdoor Air flow air temp. 17.0°CWB 18.0°CWB 21.0°CWB 22.0°CWB 19.0°CWB 20.0°CWB /min) (°CDB) 2.90 2.58 2.98 2.60 3.06 2.62 3.12 2.63 3.21 2.64 3.29 2.66 2.83 2.55 2.92 2.57 3.00 2.59 3.07...
  • Page 805 FDC-HKX 19.2.7 Characteristics of fan (1) Cassetteria type (FDR) How to interpret the blower characteristics table ¡ External static pressure table Unit : Pa (mmAq) 1 2-spot blowout..... Example : Case of FDRJ71HKXE2 Duct specs. Internal resistance increases more 1 spot Standard Square duct closing...
  • Page 806 FDC-HKX Models FDRJ45HKXE2, 56HKXE2 Model FDRJ71HKXE2 120 (12) 120 (12) 100 (10) 100 (10) 80 (8) 80 (8) 60 (6) 60 (6) 40 (4) 40 (4) 20 (2) 20 (2) 2-spot blower internal resistance 0 (0) 0 (0) (0) 0 (0) 0 [Standard] [Standard] 3-spot blower internal resistance...
  • Page 807 FDC-HKX Model FDRJ140HKXE2 120 (12) 100 (10) 80 (8) 60 (6) 40 (4) 20 (2) 3-spot blower internal resistance (0) 0 0 (0) 4-spot blower internal resistance [Standard] Square duct blower internal resistance (–2) –20 Internal resistance without suction panel Internal resistance without filter Lower Upper...
  • Page 808 FDC-HKX (2) Satellite ducted type (FDUM) ¡ External static pressure table How to interpret the blower characteristics table Unit : Pa (mmAq) Duct specs. 1 spot Example : Case of FDUMJ71HKXE2 Standard Square duct closing Air flow /min) 40 (4) Stan- High Stan-...
  • Page 809 FDC-HKX Model FDUMJ71HKXE2 Model FDUMJ90HKXE2 120 (12) 120 (12) 100 (10) 100 (10) 80 (8) 80 (8) 60 (6) 60 (6) 40 (4) 40 (4) 20 (2) 20 (2) 2-spot blower internal resistance 0 (0) (0) 0 [Standard] [Standard] [Standard] (–1) –10 0 (0) 3-spot blower internal resistance...
  • Page 810 FDC-HKX 19.2.8 Noise level Note (1) The data are based on the following conditions. Ambient air tempetature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB (2) The data in the chart are measuted in an unechonic room. (3) The noise levels measured in the field are usually higher than the data because of reflection. (1) Indoor unit Measured based on JIS B 8616 (a) Ceiling recessed type (FDT)
  • Page 811 FDC-HKX Model FDTWJ90HKXE2B Model FDTWJ112HKXE2B Model FDTWJ140HKXE2B Noise level 41 dB (A) at HIGH Noise level 44 dB (A) at HIGH Noise level 45 dB (A) at HIGH 39 dB (A) at MEDIUM 41 dB (A) at MEDIUM 42 dB (A) at MEDIUM 36 dB (A) at LOW 38 dB (A) at LOW 39 dB (A) at LOW...
  • Page 812 FDC-HKX (d) Cassetteria type (FDR) Unit Measured based on JIS B 8616 Mike position as below 1.5m Mike (center & low points) (i) Canvas duct Panel type Model FDRJ22HKXE2 Model FDRJ28HKXE2 Models FDRJ45HKXE2, 56HKXE2 Noise level 42 dB (A) at HIGH Noise level 43 dB (A) at HIGH Noise level 44 dB (A) at HIGH 40 dB (A) at MEDIUM...
  • Page 813 FDC-HKX Models FDRJ71HKXE2, 90HKXE2 Model FDRJ112HKXE2 Model FDRJ140HKXE2 Noise level 43 dB (A) at HIGH Noise level 45 dB (A) at HIGH Noise level 46 dB (A) at HIGH 40 dB (A) at MEDIUM 42 dB (A) at MEDIUM 43 dB (A) at MEDIUM 37 dB (A) at LOW 38 dB (A) at LOW 39 dB (A) at LOW...
  • Page 814 FDC-HKX Ceiling suspension type (FDE) Unit Measured based on JIS B 8616 Mike (front & low point) Mike position as below Models FDEJ36HKXE2B, 45HKXE2B Model FDEJ71HKXE2B Model FDEJ112HKXE2B 56HKXE2B Noise level 44 dB (A) at HIGH Noise level 49 dB (A) at HIGH Noise level 43 dB (A) at HIGH 40 dB (A) at MEDIUM 46 dB (A) at MEDIUM...
  • Page 815 FDC-HKX Model FDKJ56HKXE2 Model FDKJ71HKXE2 Noise level 46 dB (A) at HIGH Noise level 47 dB (A) at HIGH 43 dB (A) at MEDIUM 44 dB (A) at MEDIUM 39 dB (A) at LOW 40 dB (A) at LOW Mid octave band frequency (Hz) Mid octave band frequency (Hz) (h) Floor standing type (FDFL, FDFU)) Measured based on JIS B 8616...
  • Page 816 FDC-HKX 19.3 ELECTRICAL DATA 19.3.1 Electrical wiring (1) Indoor unit (a) Ceiling recessed type (FDT) Models All models...
  • Page 817 FDC-HKX (b) 2-way outlet ceiling recessed type (FDTW) Models All models...
  • Page 818 FDC-HKX (c) 1-way outlet ceiling recessed type (FDTS) Models All models...
  • Page 819 FDC-HKX (d) Cassetteria type (FDR) Models All models...
  • Page 820 FDC-HKX (e) Satellite ducted type (FDUM) Models All models...
  • Page 821 FDC-HKX Ceiling suspension type (FDE) Models All models...
  • Page 822 FDC-HKX (g) Wall mounted type (FDK) Models All models...
  • Page 823 FDC-HKX (h) Floor standing exposed type (FDFL) Floor standing hidden type (FDFU) Models All models...
  • Page 824 FDC-HKX (2) Outdoor unit Models FDCP140HKXE2B FDCJ140HKXE2B...
  • Page 825 FDC-HKX Models FDCP224HKXE2B, 280HKXE2B FDCJ224HKXE2B, 280HKXE2B...
  • Page 826 FDC-HKX 19.4 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER Remote controller (Optional parts) FDR, FDUM, FDFL and FDFU series are not provided with AUTO SWING switch. Panel shown below will appear if you open the cover. All contents of display on the LCD are indicated simulta- neously for the purpose of explanation.
  • Page 827 FDC-HKX (2) Operations of major functional items under each operation mode Operation mode Cooling Heating Dehumidifying Thermostat ON Thermostat OFF Thermostat ON Thermostat OFF Defrosting Complete stop Functional item Remote controller Remote controller Remote controller Remote controller Intermittent opera- → × / ×...
  • Page 828 FDC-HKX Dehumidifying (Thermal dry) [Indoor unit adaptation] • This cooling operation is mainly for dehumidifying, with which the compressor, indoor and outdoor fans are operated in the patterns as listed in the following table and in accordance with operation blocks switched with the room temperature sensor. The operation blocks are selected by checking the return air temperature at 4-minute intervals.
  • Page 829 FDC-HKX (d) Defrosting Conditions for starting defrosting When all the following conditions are met, the defrosting operation will start: 1) The cumulative operating time of the compressor comes up to 48 minutes after completion of a defrosting operation, or it comes up to 33 minutes after a heating operation starts (the remote controller is turned on).
  • Page 830 FDC-HKX (e) Compressor operation frequency UP control 1) If any indoor unit demands the maximum frequency for more than 3 minutes continuously during heating operation (pro- vided either one of the following conditions is met), the compressor operation frequency will be increased by 5 Hz. Further increase of 5 Hz will repeat at each time when the maximum frequency is maintained for 3 minutes.
  • Page 831 FDC-HKX Compressor protection control (i) Start of compressor protection 1) Inverter is operated at the frequency not exceeding the upper limit of 65 Hz for 1 minute and 45 seconds after the start in order for protection of compressor and then changes the frequency to the selected frequency. CM2 (for 224, 280) is stopped for the same period of 1 minute and 45 seconds.
  • Page 832 FDC-HKX [Hz] To target frequency 5 Hz/min. Hour [Hz] 5 Hz/2-min. Note (1) If operation is stopped within 20 minutes, second and later starts are subject to this control. Under-dome temperature control Fluid bypass solenoid valve (SV1) and indoor expansion valve are controlled based on the temperature of under-dome thermistor (Tho-C) assembled on the compressor (CM1).
  • Page 833 FDC-HKX (ii) Compressor control Compressor capacity is reduced. Compressor capacity is reduced at every minute. Retention Reset 115°C 120°C Discharge pipe temperature ( Tho-D1 ) (iii) Discharge pipe temperature error • When the discharge pipe temperatures (Tho-D1, D2 detection) rise beyond 130˚C and is maintained for 2 seconds, the com- pressors (CM1, CM2) are stopped but it will be reset if the temperatures drop below 90˚C.
  • Page 834 FDC-HKX Non-inverter compressor (CM2) overcurrent protection (Only for 224, 280 models) If the T phase current at the secondary side of 52C2 is detected exceeding the setting value for approx. 0.5 second, the compressor stops. The compressor is reset automatically after a 3-minute delay. If the error is detected at second time within 40 minutes after the initial detection, the unit stops with the error stop.
  • Page 835 FDC-HKX (11) Cooling operation control at lower outdoor air temperature (down to –5˚C) (a) This control starts 1 minute after starting compressor during cooling or dehumidifying operation, controls the outdoor fan at the outdoor temperature (Tho-A) being below 22˚C and enables the cooling operation. Disabled Outdoor fan control effective Outdoor air temperature (˚C)
  • Page 836 FDC-HKX (14) Silent mode control Silent mode is selected if the CnG (equipped with short circuiting pin) is shorted during normal operation. (a) When the highest speed for the specific model of outdoor fan (140 : 3 speed, 224, 280 : 4 speed) is selected, the speed is stepped down by one step.
  • Page 837 FDC-HKX (17) FILTER sign When the operation time (time when the ON/OFF switch is turned to ON) is counted up at 600 hours , the filter sign on the remote controller flickers. This condition can be reset any time with the “Filter reset” switch. It is effective also to turn power OFF to reset. Note (1) The function is invalidated if the jumper wire (J4) is opened.
  • Page 838 FDC-HKX Notes (1) Including OFF and error stop during Indoor unit operation mode COOL, DRY, FAN and HEAT. COOL HEAT (2) Including “FAN” operation due to unmatch During compressor ON Control A of operation mode. During compressor OFF Control B •...
  • Page 839 FDC-HKX (b) Control of input signal (Make sure to connect the standard remote control unit. Control of input signal is not available without the standard remote control unit.) Control of input signal (switch input, timer input) connectors (CNT) are provided on the control circuit board of the indoor unit. However, when the operation of air conditioner is under the Center Mode, the remote control by CnT is invalid.
  • Page 840 FDC-HKX (22) External input operation External input: From CnS , operation permission/prohibition control; From CnS : Demand control/normal operation switching. • J1: Switches between CnS and CnS input method. J1 short circuit: Level input by CnS and CnS J1 open: Pulse input by CnS and CnS (a) From CnS , operation permission/prohibition control...
  • Page 841 FDC-HKX (b) From CnS , operation permission/prohibition control input method : Demand control/normal Formula switching: Input : CnS operating switching Short J1; Short circuit Demand control circuit Level input Normal operation J1; Open circuit Normal operation/Demand control switching Open Pulse input (Reversal) circuit Short...
  • Page 842 FDC-HKX 19.5 APPLICATION DATA SAFETY PRECAUTIONS • Please read these “Safety Precautios” first then accurately execute the installation work. • Though the precautionary points indicated herein are divided under two headings, WARNING and CAUTION , those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in WARNING section.
  • Page 843 FDC-HKX 19.5.1 Installation of indoor unit (1) Ceiling recessed type (FDT) (a) Selection of installation location Select location where the space above ceiling is larger than those mentioned Type Space above ceiling (h) below and perfect draining can be assured. FDT28, 36, 45, 56, 71, 90 Over 270mm Places where perfect drainage can be prepared and sufficient drainage gradient...
  • Page 844 FDC-HKX (d) Drain Piping Drain piping should always be in downhili grade (1/50 ~ 1/100) and avoid riding across and elevation or making traps. • Good piping • Improper piping Suspension Avoid riding across an elevation 1.5 m ~ 2 m bolts Air vent Keep free from traps...
  • Page 845 FDC-HKX (e) Fixing of Decorative Panel (The panel fixing bolts are attached on the panel.) Check with the accessory level gauges that indoor unit height and the size of ceiling hole are correct. • Remove the level gauges from the indoor unit before fixing the decorative panel. Screw two bolts out of four accessory bolts less than 5 mm in the indoor unit diagonally.
  • Page 846 FDC-HKX (2) 2-way outlet ceiling recessed type (FDTW) (a) Selection of installation location This unit is a ceiling surface direct return air and direct supply air type. Install the unit a place the allows air to reach every part of the room, in accordance with the shape and heigh of the room. •...
  • Page 847 FDC-HKX Places exposed to oil splashes or steam (e.g. kitchens and machine plants.) Installation and use at such places will incur deteriorations in the performance or corrosion with the heat exchanger or damage in molded synthetic resin parts. Places where corrosive gas (such as sulfurous acid gas) or inflammable gas (thinner, gasoline, etc.) is generated or remains. Installation and use at such places will cause corrosion in the heat exchanger and damage in molded synthetic resin parts.
  • Page 848 FDC-HKX A. If there is a ceiling Open the hole in the installation location to the ceiling opening dimensions. Outlet port Install the suspension bolts (procured locally) at the Pattern paper designated locations. (Use care as the center of the spacing for the suspension Ceiling surface Printed surface bolts is not at the center of the panel.)
  • Page 849 FDC-HKX When connecting the drain pipe to the unit, pay suffcient attention not to apply excess force to the piping on the unit side. Also, fix the piping at a point as close as possible to the unit. Level difference part For drain pipe, use hard PVC ganeral purpose pipe VP-25 (I.D.1'') which can Drain socket Drain hose...
  • Page 850 FDC-HKX Note (1) If the connector remains connected, drain water is discharged from the standard pipe connecting port, leading to water leakage. Clear flexible tubing (optional) Hard vinyl chloride piping. General piping VP-20 Heat insulation Rubber plug Remove CNR (Blue·2P) Natural drain port Control box Drainage Test...
  • Page 851 FDC-HKX Remove the panel from the pin (A) in the order of the arrows 1 and 2. Open the panel slightly as shown by the arrow 3 and move it to the arrow 4. Then remove it from the pin (B). Screw two bolts out of four accessory bolts less than 5mm in the panel diagonally.
  • Page 852 FDC-HKX (3) 1-way outlet ceiling recessed type (FDTS) Preparation of indoor unit It can be installed by either one of the following methods. Select the most adequate method for your particular case. A Standard installation B Higher ceiling Ceiling Ceiling Installation example and 3m ~ 4m 3m or less...
  • Page 853 FDC-HKX Where a space as shown below can be secured. Unit : mm or more or more Obstacle It should be avoided where a machine generating high frequency waves is installed. Select a place to branch the piping so that same distance will be a obtained for each of one way piping. Where humidity may exceed 80% behind the ceiling or the dew point may exceed 28°C, adhere polyurethane foam materials (t 10 or more) over the insulation materials on the external plate.
  • Page 854 FDC-HKX c) Fixing of Suspension bolt. Fix the bolts securely as shown below or by any other adequate means. Insert Hole-in anchor bolt Hole-in plug Concrete Suspension bolt, M10 d) Installation Drain pump box Unit Duct connection opening for blowing through lowered ceiling.
  • Page 855 FDC-HKX Check of levelness Check the levelness as follows. Use a level gauge or adjust the levelness with the following method. Piping side Adjust the bottom of main unit and the water level as shown Water injection below. Water level 0~3 mm Vinyl pipe Slightly lower the piping side...
  • Page 856 FDC-HKX Drain test [Perform this before installing the ornament panel] ● Perform this upon completion of electrical work. ● Gradually introduce 2,000~3,000cc of water as shown below. Drain piping connection port Fill from outlet port Pour water into a convex joint If the electrical work has not been completed, connect a convex joint in the drain pipe connection to provide a water inlet.
  • Page 857 FDC-HKX 2 Mount the two (M5 x 35) panel mounting screws to the indoor unit Detail of Section A 3 Hang the panel on the two mounting screws on the indoor unit by using the two shaped holes. Slide the panel approximately 10 mm.
  • Page 858 FDC-HKX (4) Cassetteria type (FDR) (a) Preparation of indoor unit Before of during the installation of the unit, assemble necessary optional panel, etc. depending on the specific type. (b) Select places for installation satisfying following conditions and, at the same time, obtain the consent on the part of your client user.
  • Page 859 FDC-HKX 2) Ceiling hole size and position of suspersion bolt When boring at the ceiling, use the pattern sheet included in the accessory of the unit. Leave the pattern sheet on the unit till decorative panel is installed. < Combination with silent panel > Unit : mm Mark Models...
  • Page 860 FDC-HKX 2) Adjusting the unit’s levelness 1 Adjust the out-of levelness using a level vial or by following method. ● Make adjustment so that the relation between the lower surface of the unit proper and water level in the hose becomes as given below.
  • Page 861 FDC-HKX 2 Install the panel outer frame on the Indoor unit. Indoor unit Panel outer frame Temporary setting Panel inner frame Procedures of installation 1 Secure the panel tentatively with 2 of 4 panel set screws (panel accessory) as shown above. 2 When the panel is supported with a pair of set screws, slide it in the arrow direction.
  • Page 862 FDC-HKX 2 Remove the panel inner frame. It can be removed same as the silent panel. Panel inner frame Panel outer frame Remove < How to remove the panel inner frame > Pin (B) Pin (A) Panel outer frame Panel inner frame ●...
  • Page 863 FDC-HKX ● Hook the chain of panel outer panel on the holder. Note (1) When hooking the chain. make sure to avoid slack- ness on it by pushing hard the panel outer frame against the ceiling material. Ceiling material ● Tighten 3 screw in the step 1 till the panel outer frame contacts closely with the ceiling material. ●...
  • Page 864 FDC-HKX ● Use a band, etc. to connect the indoor unit and the supply air duct flange. ● Conduct the duct installation work before finshing the ceiling. (g) Connection of air inteke and exhaust ducts. State seeing from top of unit Exhaust Port Side fresh air intake port...
  • Page 865 FDC-HKX (h) Drain piping 1) Drain piping should always be in a downhill grade (1/50-1/100) and avoid riding across an elevation or making traps. ● Improper piping ● Good piping Avoid riding across an elevation Suspension bolts 1.5 m ~ 2m Air vent Keep free from traps Do not pipe under water...
  • Page 866 FDC-HKX 9) Drainage test a) During trial operation, make sure that drainage is properly execued and check that leakage is not found at connections. b) Be sure to carry out a drainage test when installing the system during a heating season. c) When installing the system in a building under construction, carry out the drainage test before ceiling tiles are installed.
  • Page 867 FDC-HKX (5) Satellite ducted type (FDUM) (a) Selection of installation location Avoid installation and use at those places listed below. a) Places exposed to oil splashes or steam (e.g. kitchens and machine plants). Installation and use at such places will incur deteriorations in the performance or corrosion with the heat exchanger or damage in molded synthetic resin parts.
  • Page 868 FDC-HKX (b) Suspension Be sure to observe the finished length of the suspension bolts given below. Unit : mm Mark Models FDUM36, 45, 56 type FDUM71, 90 type 1406 FDUM112, 140 type 1) Fixing the suspension bolt (customer ordered parts M10) Securely fix the suspension bolt as illustrated below or in another way.
  • Page 869 FDC-HKX (c) Duct installation 1 Supply air duct 4 Return air duct (to be purchased locally) (to be purchased locally) Heat insulation 5 Return air port with canvas duct Indoor unit (to be purchased locally) Supply air port 3 Return air port (to be purchased locally) 2 Access door (to be purchased locally)
  • Page 870 FDC-HKX (d) Drain piping 1) Drain piping should always be in a downhill grade (1/50-1/100) and avoid riding across an elevation or makeing traps. ● Improper piping ● Good piping Suspension Avoid riding across an elevation bolts 1.5 m ~ 2m Air vent Keep free from traps Do not pipe under water...
  • Page 871 FDC-HKX 9) Drainage test a) During trial operation, make sure that drainage is properly execued and check that leakage is not found at connections. b) Be sure to carry out a drainage test when installing the system during a heating season. c) When installing the system in a building under construction, carry out the drainage test before ceiling tiles are installed.
  • Page 872 FDC-HKX (6) Ceiling Supension type (FDE) (a) Selection of installation location 1) A place where good air circulation and delivery can be obtained. Cold air throw Unit : m Models FDE36, 45, 56 type FDE71 type FDE112 type FDE140 type Air throw Conditions (1) Installation height: 2.4 ~ 3.0 m above the floor...
  • Page 873 FDC-HKX b) Positions of suspension bolts are as in the drawing below. ● When the suspension brackets face out ● When the suspension brackets face in outlet outlet Suspemsion Suspemsion bolt hole bolt hole Suspemsion Suspension bracket bracket Unit : mm Mark Models 1000...
  • Page 874 FDC-HKX 2) In case of exposed installation to the ceiling ( with suspension brackets facing in) a) Fix the suspension brackets to suspension bolts Ceiling boards Suspension bolt [M8~M10 (3/8¨)] Suspension bracket (accessory parts) Flat washer (accessory parts) Hexagonal nuts (accessory parts) b) Hook the unit to suspension brackers Suspension bracket Suspension bracket fixing bolts...
  • Page 875 FDC-HKX b) Installation space dimensions Unit: mm (Plug in dimensions) Unit upper side Ceiling board c) Mount the unit using suspension bolts Suspension bolts Flat washer (accessory parts) Hexagonal nuts (accessory parts) d) Securely tighten the nuts and fix the indoor unit place. e) Attach the side panels and fit in ceilling board in the space around the unit and the work is finished.
  • Page 876 FDC-HKX (7) Wall mounted type (FDK) (a) Selection of installation location 1) Select the best position and direction depending on the shape of room and height of ceiling to ensure that the cooled or warmed air will be circulated sufficiently. cooled air throw Unit : m Models...
  • Page 877 FDC-HKX (c) Installation 1) Use an attached pattern sheet and mark the position of screws to attach the mounting plate. 2) Determine the direction to lead the pipe and bore a through hole on the wall aligning with the pipe hole of unit. Wall Wall Sealing...
  • Page 878 FDC-HKX 6) Hook and install the indoor unit on the mounting plate from top. Hook slightly at left at first and return to right. 7) Fix the indoor unit on the mounting plate with a screw. 8) Install the lower panel at the original position. 9) Install the right and left side panels at their original position.
  • Page 879 FDC-HKX (8) Floor standing exposed type (FDFL) (a) Selection of installation location 1) A place where good air circulation and delivery can be obtained. Cooled (warmed) air throw Unit : m Models All models Air throw [Conditions] (1) Fan speed: Hi (2) Location: Free space without obstacles (3) Distance of reach indicates the horizontal distance after the wind touched down the floor.
  • Page 880 FDC-HKX (c) Installation of unit 1) Floor standing installation a) Position of mounting bracket fixing bolts Drill holes by referring to figures below. When fixed on the wall Bolt for wall mounting 4 places Hole for piping & wiring on wall Wall When fixed on the floor Hole for piping...
  • Page 881 FDC-HKX (d) Drain piping The drain piping can be directed to the floor or rear sides as follows. (a) Connect a drain piping to the drain outlet and fix it by use of tigghening band. (b) Indoor side drain piping must be thermally insulated. (c) After finishing the drain piping, check the drainage by pouring some water in the drain pan.
  • Page 882 FDC-HKX 4) Wiring route. a) Wire from the wiring hole through the rear side of the control box to the terminal block. Remote controller b) Any suplus wires should be tied up with a cable tie. installation section Cable tip Control box Front Side (8) Floor standing hidden type (FDFU)
  • Page 883 FDC-HKX (b) Bolt positions 1) Bolt positions for metal settings used for floor fixation. 2) Bolt positions for wall fixation • Metal fitting used for floor fixation (accessories). unit : mm 1150(1435) unit : mm 786 (1071) Bolt positions for floor mounting hardware Floor mounting hardware Accessory Front...
  • Page 884 FDC-HKX (d) Drain piping The drain piping can be directed to the floor or rear sides as follows. (a) Connect a drain piping to the drain outlet and fix it by use of tigghening band. (b) Indoor side drain piping must be thermally insulated. (c) After finishing the drain piping, check the drainage by pouring some water in the drain pan.
  • Page 885 FDC-HKX (3) Setting the functions (e) Set necessary functions in accordance with the model of indoor unit. Refer to (c) for the setting of functions. Change the setting of selector switches (WS1 SW4) (f ) Couple the upper case with the lower case as they were. and jumper wires (J1 J4) in accordance the functions of (g) Secure the remote controller cords on the wall or other using cord indoor unit and purposes of use.
  • Page 886 FDC-HKX 19.5.3 Installation of outdoor unit (1) Selection of installation location (a) A place where air will not be stagnant. (b) A place where the exhaust air will not be shortcycled. (c) A place with enough space for air flow around the unit. (d) A place where the unit will not be affected by other heat sources.
  • Page 887 FDC-HKX (b) In the case that there is a wall above the unit No. of units that can be installed are limited up to 3 units. (Example : 5HP × 3 units, 10HP × 1 units + 5HP × 1 unit) 150 and over 500 and over L1 or L2 0...
  • Page 888 FDC-HKX (3) When the wall heights H1 and H3 exceed the limited value, keep dimensions for L1 and L3 as shown below. L1 = H1 – 500 L3 = 300 + (H3–700) / 2 However, there is no limitation in wall height H3 if L3 exceeds 600. Oblique blow 1,500 and 800 and...
  • Page 889 FDC-HKX (c) Securing outdoor unit (in the case of exposure to severe weather conditions) Fix the unit in the following way. ● Use overturning prevention brackets. ● Rig with wires. Ring with wires Fix the unit using achor bolts (Use rigging wires that are resistant to corrosion and sufficient in strengh. For example SUS304-W1, wire thickness 2.9 mm) (4) Installation Fix the unit in a proper way according to the condition of a place where it is installed by referring to the following.
  • Page 890 FDC-HKX 19.5.4 Refrigerant piping (1) Precautions no refrigerant piping work for prevention against compressor lock Compressor trouble including lock and motor burn-out is due to faulty parts but mainly concerned in installation and refrigerant piping conditions, The precautions for refrigerant piping are as belows. (a) Be sure to perform brazing while flowing nitrogen.
  • Page 891 FDC-HKX (2) Table for selection of piping size FDC 140 type FDC 224 type FDC 280 type Model Item Gas line Liquid line Branch used Gas line Liquid line Branch used Gas line Liquid line Branch used φ19.05 φ9.52 φ25.4 φ12.7 φ28.58 φ12.7...
  • Page 892 FDC-HKX Example of piping Outdoor unit: FDCJ280HKXE2B Indoor unit: Combination of 8 units [Branch pipe set : DIS-2KX10-E × 1 set, DIS-2KX20-EX × 3 set, DIS-2KX30-E × 3 set] [Total capacity: 363 (36300W) ] • Selecting piping size Piping size (in) Item Selection procedure Gasline...
  • Page 893 FDC-HKX (3) Specification of unit piping (Pipe diameter, Connecting method) (a) Unit 1) Outdoor unit Unit: mm(in) Item Gas line Liquid line Model Pipe diameter Connecting method Pipe diameter Connecting method φ19.05 ( φ9.52 ( FDC140 type ") Flare ") φ25.4 (1 ") φ12.7 ( FDC224 type...
  • Page 894 FDC-HKX (b) Refrigerant connection piping. Refrigerant Connection to Connection to Electric piping rear direction left direction wing Electric Connection to wing right direction Electric Refrigerant wing Connection to piping Refrigerant front direction Connection to piping lower direction (c) Connection to rear, right and front directions. 1) See page 781 to 782 for locations of connecting holes and service valves.
  • Page 895 FDC-HKX (6) Evacuating Evacuating can be completed faster by evacuating both the check joint on the liquid side service valve and the check joint of the evacuating gas pipe (accessory) connected to the gas side operation valve at the same time. (Of course, evacuating is possible even through the liquid side check joint only.) Outdoor unit Gauge manifold...
  • Page 896 FDC-HKX 19.5.5 Electric wiring (1) Power supply wiring (a) Outdoor unit power supply • Use separate power supplies for the outdoor and indoor unit respectively. (Standard specification) • The table below shows the power specification for outdoor unit only. Circuit breaker Power Item Grounding...
  • Page 897 FDC-HKX (2) Precaution in electric wiring. (a) Use separate power supplies for the outdoor and indoor units respectiveliy (Standard specification) (b) Signal wiring (for indoor and outdoor units) • Double-core cable with a diameter 0.75 to 2 mm should be used for the signal wires. •...
  • Page 898 FDC-HKX Models FDC224, 280type Power source (outdoor unit side) 3phase 380/415V50Hz Earth leakage Outdoor unit breaker Circuit Breaker Earth Signal wire (Between outdoor and indoor units) Signal wire (Between indoor units) Indoor Circuit breaker unit Earth leakage <I> <II> <III> <IV>...
  • Page 899 FDC-HKX (4) Indoor and outdoor signal wiring (a) If only one Outdoor unit is used Outdoor signal teminal block Double cores 0.75 ~ 2 mm Total length of signal wires: 1000 m or less Indoor signal terminal block Notes (1) The indoor and outdoor signal wiring are without polarity Either of the above wiring is correct.
  • Page 900 FDC-HKX (5) Remote controller wiring (a) Wiring for controlling only one indoor unit. Red White Black Indoor unit Note (1) Cables for the remote controller have polarity. Be sure terminal blocks to connect terminal blocks with the same numbers. If mis wiring occurs, E1 is displayed and disables the Red White Black Remote controller...
  • Page 901 FDC-HKX (6) Setting of unit address Addresses can be set either with the automatic address setting, remote control address setting or manual address setting depending on the combinations of address switches (see table) of the indoor and outdoor units. Operate the address switches before turning power on.
  • Page 902 FDC-HKX Set the address switch of outdoor unit at 49. (This is set at 49 at shipment from factory.) Set the address switch of indoor unit at 49. (This is set at 49 at shipment from factory) Turn power on for the indoor and outdoor units. Addresses are set automatically. (No. in a range of 0 - 7 is set for J140H or No.
  • Page 903 FDC-HKX Detail of setting from the remote controller 1) If the power switch is turned on, the outdoor No. on the display flashes, and "--" on the return air temperature display section and "U--" on the time display section are lit. If power is not supplied to the outdoor unit, the outdoor No.
  • Page 904 FDC-HKX Using the address switch (green) on the outdoor unit PCB, set the address of the outdoor unit in a range of 00 - 47 avoiding duplication with any other outdoor unit. Using the address switch (green) on the indoor unit PCB, set the outdoor No. at the same No. as the outdoor unit which is connected with a refrigerant pipe.
  • Page 905 FDC-HKX 19.5.6 Test run (1) Before starting operation (a) Measure resistances between the electrical parts terminal blook and ground grounded area using a 500V Megger, insulator. Resistance must be higher than 1M Ω. (b) Confirm whether the power source breaker (main switch) of the unit has been turned on for over 12 hours to energize the crankcase heater in advance of operation.
  • Page 906 FDC-HKX 19.6 MAINTENANCE DATA (1) Before starting troubleshooting (a) Confirmation of the error code on the remote controller (by pressing the inspection switch) and the inspec- tion display and normal display lamps on PCBs (Printed circuit board) of indoor/outldoor units The microcomputer detects errors on electrical components, which include the microcomputer itself, errors on the power supply line and errors (overload, etc.) on the refrigerant circuit and the location of trouble is displayed (with the commbination of error symbols of remote controller, normal (green) and inspection (red) display LED on PCBs of indoor/outdoor units).
  • Page 907 FDC-HKX...
  • Page 908 FDC-HKX...
  • Page 909 FDC-HKX 3) Display sequence of error, inspection display lamp a) One kind error Display corresponding to the error is shown. b) More than one errors. Section Display section • Displays the error of higher priority (When plural errors are persisting) Error code of remote controller E¡...
  • Page 910 FDC-HKX Recording and reset of error Error display Memory Reset • Saves in memory the mode of higher • Stop the unit operation by pressing the ON/OFF switch of remote Error code priority controller. • Operation can be started again if the error has been reset. Indoor unit inspection lamp •...
  • Page 911 FDC-HKX (a) Diagnosis by the power supply reset When any error occurs, reset the power supply as described below to see if it is the result of accidental noise, etc. Check at the indoor unit side. Error Are the return air Is any errror temperature and Center/ code display...
  • Page 912 FDC-HKX (2) Reference Effect of noise ¡ When noises inturude into remote controller. Abnormal or irregular display such as the flashing of irrelevant display (lamp) (for example, LEDs of cooling and heating illumi- nated simultaneously or the like) is observed even if the remote controller is not operated or the remote or the remote controller and, as the result, the operation of units may be disabled or similar abnormal phenomenons are observed.
  • Page 913 FDC-HKX ● Function of jumper wires (ii) Parts layout on the indoor unit printed circuit board Name Function Setting of 4 position angle of louver With Transformer None Setting of 4 position angle of louver secondary side 4 position louver control : Valid With Transformer Power supply...
  • Page 914 FDC-HKX Error display : No display [Polarity determination trouble] LCD display : No display Indoor unit Outdoor unit Red LED Stays OFF Red LED Stays OFF Green LED Lights continuously Green LED Lights continuously ● When the LCD display (Center/Remote, temperature display, etc.) of remote controller flashes, it means the polarity on the unit is not yet determined.
  • Page 915 FDC-HKX Error display : No display [Power supply line error] LCD display : No display Outdoor unit Unit is normal (Malfunction by noisse) Stays OFF Red LED Stays OFF Green LED Indoor unit Indoor/outdoor unit transfomer CNW (indoor). Is it Power supply checked Stays Power supply...
  • Page 916 FDC-HKX Indoor unit Outdoor unit Red LED *3 times flash Red LED Stays OFF Green LED Keeps flashing Green LED Keeps flashing * Lamp OFF if remote controller wire is broken at power ON. Unit is normal. • Remote controller normal (Interference by temporary voltage (DC) noise on remote controller...
  • Page 917 FDC-HKX Error display [Duplicated indoor unit No. or More than 49 indoor unit are connected.] Indoor unit Outdoor unit Stays OFF Red LED 1 time flash Red LED Keeps flashing Green LED Keeps flashing Green LED Is the indoor unit Correction of unit No.
  • Page 918 FDC-HKX Error display [Drain trouble] Indoor unit Outdoor unit Defective indoor unit PCB Replacement (Defective conden- Stays OFF Red LED 1 time flash Red LED sate motor output circuit) Keeps flashing Green LED Keeps flashing Green LED Is the angle of drain Is there output for Is there any piping good.
  • Page 919 FDC-HKX [Address No. combination eroor or addressing is Error display : preformed with the following combinations.] Indoor unit Outdoor unit Stays OFF Red LED 1 time flash Red LED Keeps flashing Green LED Keeps flashing Green LED Are unit number Unit number set for see correction...
  • Page 920 FDC-HKX (ii) Parts layout on the outdoor unit PCB • Function of DIP switch Name Function PCB power supply Inspection LED reset 7-segement indicator connector (Secondary side) Normal LED (red) Backup operation - With LED (green) Backup operation - None Service Normal Unmatch check...
  • Page 921 FDC-HKX (iv) Check procedure depending on indication lamps (For the outdoor unit) Error display : [Error on the outdoor unit signal line] (Detected during operation only) Indoor unit Red LED 2 time flash Green LED Keeps flashing Outdoor unit Red LED Stays OFF Green LED Stays OFF...
  • Page 922 FDC-HKX Error display : [Outdoor unit signal line error, power supply error] Indoor unit 2 time flash Red LED Keeps flashing Green LED Did turn off Outdoor unit Power supply the power of outdoor Stays OFF Red LED unit during operatioon? Stays OFF Green LED...
  • Page 923 FDC-HKX Error display : [Connection error indoor and outdoor unit] Indoor unit Outdoor unit Red LED Stays OFF Red LED 1 time flash Green LED Keeps flashing Green LED Keeps flashing Connection of indoor and Repair outdoor unit OK? Defective outdoor unit PCB Replacement e3 1 Error display :...
  • Page 924 FDC-HKX Error display : [Or overcurrent error (CM ), motor lock (CM Indoor unit Outdoor unit Red LED Stays OFF Red LED 1 time flash Green LED Keeps flashing Green LED Keeps flashing Note (1) Single flashing of outdoor unit LED indicates CM1 and double flashing indicates CM Is AC 380V or 415V de- •...
  • Page 925 FDC-HKX Error display : [Defective outdoor unit heat exchanger thermistor] Indoor unit Outdoor unit 1 time flash Red LED Stays OFF Red LED Keeps flashing Green LED Keeps flashing Green LED Are the outdoor Defective outdoor unit PCB Is the outdoor unit heat exchanger themistor Replacement (Defective outdoor unit heat exchanger...
  • Page 926 FDC-HKX Error display : [Defective discharge gas thermistor] Indoor unit Outdoor unit 1 time flash Red LED Stays OFF Red LED Keeps flashing Green LED Keeps flashing Green LED Note (1) Single flashing of outdoor unit LED indicates Th -1 and double flashing indicates Th Is the Defective outdoor unit PCB...
  • Page 927 FDC-HKX Error display : e4 1 [Power transistor overheating] Indoor unit Outdoor unit 1 time flash Red LED Stays OFF Red LED Keeps flashing Green LED Keeps flashing Green LED Is the Does Does the outdoor unit Power transistor Defective IM (Inverter installation overheating...
  • Page 928 FDC-HKX Current cut is indicated and the compressor cannot operate Is the insullation Disconnect the compressor wiring Defective compressor resistance of the compressor proper? The compressor can operate Notes (1) when a short-circuit or ground-fault occurs in the compressor motor, the current cut function is also Is the current activated.
  • Page 929 FDC-HKX Error display : [Excessive number of indoor units connected] Indoor unit Outdoor unit 1 time flash Red LED Stays OFF Red LED Keeps flashing Green LED Keeps flashing Green LED Doesn't the number of indoor unit connected Repair exceed the specified value? Notes (1) The maximum number of connectable units of each model is as follows :...
  • Page 930 FDC-HKX Error display : Automatic address setting and manual address setting coexstents in the same network Indoor unit Outdoor unit 1 time flash Red LED Stays OFF Red LED Keeps flashing Green LED Keeps flashing Green LED Are automatic address and manual address Repair to manual address coexstent on the same network...
  • Page 931 FDC-HKX Louver motor does not operate Inspect at the indoor unit side. Does the Is LM wire Is LM Defective indoor louver operate at broken? locked? unit PCB power on? Operate more than 1 min. later Repair the wire Replace LM Is the louver operated with the remote Normal...
  • Page 932 FDC-HKX (ii) When the compressor does not operate although the remote controller display is normal (Without the check display) Take following steps first before confirming the following items: • Confirm that it is normal at the indoor unit side, LED1 (green) keeps flashing on the outdoor unit control PCB and LED2 (red) is not lit.
  • Page 933 FDC-HKX Procedure for checking the outdoor unit irrespective of indoor/outdoor transmission Turn off the outdoor unit power supply (Or pull out the connector CnA on the outdoor unit PCB) Set 45 in outdoor unit No. Turn ON the outdoor unit PCB (SW Turn ON the outdoor unit power supply (When connecting the CnA on the outdoor unit PCB)
  • Page 934 FDC-HKX Inverter inspection procedures (There is no output on the compressor (U,V,W).) Inspect control PCB at Is 52C turned ON? outdoor side. Error on the power supply system Is LED1 (green) Is DC 540V Remote controller trouble on inverter PCB detected at CNW on code E45 on display flashing?
  • Page 935 FDC-HKX 2) When the heating effect is insufficient • Check if the protective function (1) has operated and, as a result, the compressor operation frequency has dropped below the specified frequency. Note (1) The frequency drops when the high pressure control (Operated at 63H :2.50 open/2.06 close, Mpa (25.5 open/ 21close kgf/cm )[FDCP:2.79open/2.26 clope, MPa(28.5open/23 cloes kgf/cm...
  • Page 936 FDC-HKX...

  • Page 937: Fdc-Hkxr

    FDC-HKXR FDC-HKXR 20. INVERTER DRIVEN MULTI-INDOOR UNIT HEAT RECOVERY CLIMATE CONTROL SYSTEM Simultaneous heating & Cooling 3 Pipe System (OUTDOOR UNIT) Alternative refrigerant R407C use models FDCP2001HKXRE2, 2501HKXRE2 (INDOOR UNIT) FDTJ28HKXE2 FDTWJ28HKXE2B FDTSJ22HKXE2B 36HKXE2 45HKXE2B 28HKXE2B 45HKXE2 56HKXE2B 36HKXE2B 56HKXE2 71HKXE2B 45HKXE2B 71HKXE2...
  • Page 938 FDC-HKXR CONTENTS 20.1 GENERAL INFORMATION ..............937 20.1.1 Specific features ................937 20.1.2 How to read the model name ............939 20.1.3 Table of models ................. 939 20.1.4 Table of indoor units panel (Optional) ..........939 20.2 SELECTION DATA................... 940 20.2.1 Specifications ..................
  • Page 939 FDC-HKXR 20.1 GENERAL INFORMATION 20.1.1 Specific features (1) Fuzzy control (a) Response speed and stability are enhanced. • The system automatically controls changes of return air temperature, set temperature and room temperature according to the fuzzy control. • The system response speed, can keep room temperature constant, and can adjust room temperature to set temperature quickly.
  • Page 940 FDC-HKXR (3) Installation of automatic address setting function • The address setting method are divided into three types according to wiring method: “Automatic Address Setting,” “Remote control Address Setting.” and “Manual Address Setting.” In case of the Automatic Address Setting, no address needs be set as usual.

  • Page 941: Table Of Indoor Units Panel (Optional)

    FDC-HKXR 20.1.2 How to read the model name Example: P 2001 H KXR E CE marking model Application power source...See the specifications Multi KXR series Heat pump type Nominal capacity R407C models Model name Indoor unit : FDT, FDTW, FDTS, FDR, FDUM FDE, FDK, FDFL, FDFU Outdoor unit : FDC 20.1.3 Table of models...

  • Page 942: Selection Data

    FDC-HKXR 20.2 SELECTION DATA 20.2.1 Specifications (1) Indoor unit (a) Ceiling recessed type (FDT) Models FDTJ28HKXE2, 36HKXE2 Models FDTJ28HKXE2 FDTJ36HKXE2 Item Nominal cooling capacity* 2800 3600 Nominal heating capacity* 3200 4000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 37 Me: 34 Lo: 33 Exterior dimensions Unit:260...
  • Page 943 FDC-HKXR Models FDTJ45HKXE2, 56HKXE2, 71HKXE2 Models FDTJ45HKXE2 FDTJ56HKXE2 FDTJ71HKXE2 Item Nominal cooling capacity* 4500 5600 7100 Nominal heating capacity* 5000 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 38 Me: 35 Lo: 34 Hi: 40 Me: 38 Lo: 36 Exterior dimensions Unit:260 Panel:30...
  • Page 944 FDC-HKXR Models FDTJ90HKXE2, 112HKXE2, 140HKXE2 Models FDTJ90HKXE2 FDTJ112HKXE2 FDTJ140HKXE2 Item Nominal cooling capacity* 9000 11200 14000 Nominal heating capacity* 10000 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 42 Me: 40 Lo: 38 Hi: 49 Me:46 Lo: 42 Hi: 50 Me: 47 Lo: 45 Exterior dimensions Unit: 260...
  • Page 945 FDC-HKXR (b) 2-way outlet ceiling recessed type (FDTW) Models FDTWJ28HKXE2B, 45HKXE2B, 56HKXE2B Models FDTWJ28HKXE2B FDTWJ45HKXE2B FDTWJ56HKXE2B Item Nominal cooling capacity* 2800 4500 5600 Nominal heating capacity* 3200 5000 6300 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 39 Me:36 Lo: 33 Exterior dimensions Unit:280 817 620 Panel:8...
  • Page 946 FDC-HKXR Models FDTWJ71HKXE2B, 90HKXE2B Models FDTWJ71HKXE2B FDTWJ90HKXE2B Item Nominal cooling capacity* 7100 9000 Nominal heating capacity* 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me: 38 Lo: 35 Hi: 41 Me: 39 Lo: 36 Exterior dimensions Unit:330 1054 Panel:8...
  • Page 947 FDC-HKXR Models FDTWJ112HKXE2B, 140HKXE2B Models FDTWJ112HKXE2B FDTWJ140HKXE2B Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 44 Me: 41 Lo: 38 Hi: 45 Me: 42 Lo: 39 Exterior dimensions Unit:345 1524 Panel:8...
  • Page 948 FDC-HKXR (c) 1-way outlet ceiling recessed type (FDTS) Models FDTSJ22HKXE2B, 28HKXE2B, 36HKXE2B Model FDTSJ22HKXE2B FDTSJ28HKXE2B FDTSJ36HKXE2B Item Nominal cooling capacity* 2200 2800 3600 Nominal heating capacity* 2500 3200 4000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 39 Lo: 38 Hi: 40 Me: 39 Lo: 38 Exterior dimensions Unit:194...
  • Page 949 FDC-HKXR Models FDTSJ45HKXE2B, 71HKXE2B Model FDTSJ45HKXE2B FDTSJ71HKXE2B Item Nominal cooling capacity* 4500 7100 Nominal heating capacity* 5000 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 38 Hi: 44 Me: 40 Lo: 38 Exterior dimensions Unit:194 1040 Unit:194...
  • Page 950 FDC-HKXR (d) Cassetteria type (FDR) Models FDRJ22HKXE2, 28HKXE2 Models FDRJ22HKXE2 FDRJ28HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E R-PNLS-26W-E R-PNLC-26W-E Nominal cooling capacity* 2200 2800 Nominal heating capacity* 2500 3200 Power source 1 Phase 220/240V 50Hz Noise level...
  • Page 951 FDC-HKXR Models FDRJ45HKXE2, 56HKXE2 Models FDRJ45HKXE2 FDRJ56HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-26W-E R-PNLC-26W-E R-PNLS-26W-E R-PNLC-26W-E Nominal cooling capacity* 4500 5600 Nominal heating capacity* 5000 6300 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 37...
  • Page 952 FDC-HKXR Models FDRJ71HKXE2, 90HKXE2 Models FDRJ71HKXE2 FDRJ90HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-36W-E R-PNLC-36W-E R-PNLS-36W-E R-PNLC-36W-E Nominal cooling capacity* 7100 9000 Nominal heating capacity* 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me: 40 Lo: 37...
  • Page 953 FDC-HKXR Models FDRJ112HKXE2, 140HKXE2 Models FDRJ112HKXE2 FDRJ140HKXE2 Item Air inlet panel Silent panel Canvas panel Silent panel Canvas panel Panel model (Option) R-PNLS-46W-E R-PNLC-46W-E R-PNLS-46W-E R-PNLC-46W-E Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 45 Me: 42 Lo: 38...
  • Page 954 FDC-HKXR (e) Satellite ducted type (FDUM) Models FDUMJ36HKXE2, 45HKXE2 Models FDUMJ36HKXE2 FDUMJ45HKXE2 Item Nominal cooling capacity* 3600 4500 Nominal heating capacity* 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 34 Me: 32 Lo: 29 Hi: 35 Me: 32 Lo: 29 Exterior dimensions Height Width...
  • Page 955 FDC-HKXR Models FDUMJ56HKXE2, 71HKXE2, 90HKXE2 Models FDUMJ56HKXE2 FDUMJ71HKXE2 FDUMJ90HKXE2 Item Nominal cooling capacity* 5600 7100 9000 Nominal heating capacity* 6300 8000 10000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 35 Me: 32 Lo: 29 Hi: 35 Me: 32 Lo: 29 Hi: 36 Me: 33 Lo: 30 Exterior dimensions Height...
  • Page 956 FDC-HKXR Models FDUMJ112HKXE2, 140HKXE2 Models FDUMJ112HKXE2 FDUMJ140HKXE2 Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 38 Me: 35 Lo: 32 Hi: 39 Me: 37 Lo: 34 Exterior dimensions 1370 Height Width...
  • Page 957 FDC-HKXR (f) Ceiling suspension type (FDE) Models FDEJ36HKXE2B, 45HKXE2B Models FDEJ36HKXE2B FDEJ45HKXE2B Item Nominal cooling capacity* 3600 4500 Nominal heating capacity* 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me:40 Lo: 38 Exterior dimensions 1000 Height Width Depth...
  • Page 958 FDC-HKXR Models FDEJ56HKXE2B, 71HKXE2B Models FDEJ56HKXE2B FDEJ71HKXE2B Item Nominal cooling capacity* 5600 7100 Nominal heating capacity* 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 43 Me:40 Lo: 38 Hi: 44 Me:40 Lo: 38 Exterior dimensions 1000 1260 Height Width...
  • Page 959 FDC-HKXR Models FDEJ112HKXE2B, 140HKXE2B Models FDEJ112HKXE2B FDEJ140HKXE2B Item Nominal cooling capacity* 11200 14000 Nominal heating capacity* 12500 16000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 49 Me:46 Lo: 42 Hi: 50 Me:47 Lo: 42 Exterior dimensions 1260 1470 Height Width...
  • Page 960 FDC-HKXR (g) Wall mounted type (FDK) Models FDKJ22HKXE2, 28HKXE2, 36HKXE2, 45HKXE2 Models FDKJ22HKXE2 FDKJ28HKXE2 FDKJ36HKXE2 FDKJ45HKXE2 Item Nominal cooling capacity* 2200 2800 3600 4500 Nominal heating capacity* 2500 3200 4000 5000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 42 Lo: 37 Hi: 42 Me:40 Lo: 37 Hi: 44 Me:41 Lo: 37...
  • Page 961 FDC-HKXR Models FDKJ56HKXE2, 71HKXE2 Model FDKJ56HKXE2 FDKJ71HKXE2 Item Nominal cooling capacity* 5600 7100 Nominal heating capacity* 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 46 Me:43 Lo: 39 Hi: 47 Me:44 Lo: 40 Exterior dimensions 375 1148 1436 Height Width...
  • Page 962 FDC-HKXR (h) Floor standing exposed type (FDFL) Models FDFLJ28HKXE2, 45HKXE2, 71HKXE2 Model FDFLJ28HKXE2 FDFLJ45HKXE2 FDFLJ71HKXE2 Item Nominal cooling capacity* 2800 4500 7100 Nominal heating capacity* 3200 5000 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me:38 Lo: 36 Hi: 43 Me:41 Lo: 40 Exterior dimensions 1196...
  • Page 963 FDC-HKXR (i) Floor standing hidden type (FDFU) Models FDFUJ28HKXE2, 45HKXE2, 56HKXE2, 71HKXE2 Model FDFUJ28HKXE2 FDFUJ45HKXE2 FDFUJ56HKXE2 FDFUJ71HKXE2 Item Nominal cooling capacity* 2800 4500 5600 7100 Nominal heating capacity* 3200 5000 6300 8000 Power source 1 Phase 220/240V 50Hz Noise level dB(A) Hi: 41 Me:38 Lo: 36 Hi: 43 Me:41 Lo: 40...
  • Page 964 FDC-HKXR (2) Outdoor unit Models FDCP2001HKXRE2, 2501HKXRE2 Models FDCP2001HKXRE2 FDCP2501HKXRE2 Item Power source 3 Phase 380/415V 50Hz Nominal cooling capacity* 22400 28000 Nominal heating capacity* 25000 31500 Noise level dB(A) Exterior dimensions 1700 1350 Height Width Depth Net weight Refrigerant equipment RS5555HAS11 RS5570HAS11 compressor type &...
  • Page 965 FDC-HKXR (3) Operation chart Since the Multi KXR series air conditioner units are free multitype to which the indoor units of different capacity and different model can be combined, the operation characteristics of all combinations are very complicated, therefore only the individual operation characteristics of indoor and outdoor units are shown.
  • Page 966 FDC-HKXR FDK, FDFL, FDFU Series (220 V/240 V) Models FDK Series FDFL, FDFU Series Item 45,56 Power input (kW) 0.05/0.06 0.06/0.07 0.08/0.09 0.09/0.11 0.09/0.10 0.09/0.10 0.09/0.10 Running current (A) 0.26/0.28 0.31/0.33 0.36/0.39 0.41/0.48 0.41/0.42 0.40/0.41 0.40/0.41 Notes (1) This packaged air-conditioner is manufactured and tested in conformity with the following standard. JIS B8616 “UNITARY AIR-CONDITIONERS”...
  • Page 967 FDC-HKXR • Correction factor of compressor power input Model FDCP2001HKXRE2 Model FDCP2501HKXRE2 Total capacity of indoor units Total capacity of indoor units operating simulataneously operating simulataneously (Below, the coefficients (Below, the coefficients (Below, the coefficients (Below, the coefficients are the same.) are the same.) are the same.) are the same.)
  • Page 968 FDC-HKXR 20.2.2 Range of usage & limitations System FDCP2001HKXRE2 FDCP2501HKXRE2 Item Indoor intake air temperature (Upper, lower limits) Refer to the selection chart. Outdoor air temperature (Upper, lower limits) Indoor units 1 to 8 units Number of connected units that can be used in Total capacity 11000 to 29200w...

  • Page 969: Exterior Dimensions

    FDC-HKXR 20.2.3 Exterior dimensions (1) Indoor unit (a) Ceiling recessed type (FDT) Models FDTJ28HKXE2, 36HKXE2, 45HKXE2, 56HKXE2, 71HKXE2, 90HKXE2 Unit : mm Decorative Panel (Ceiling hole size) Holes for 860~890 Fresh air suspension bolts (Suspension bolts pitch ) opening for ducting (M10 to M8 ×4pcs.) Exhaust air opening for ducting...
  • Page 970 FDC-HKXR Models FDTJ112HKXE2, 140HKXE2 Unit : mm Decorative Panel (Ceiling hole size) Holes for 860~890 Fresh air suspension bolts (Suspension bolts pitch ) opening for ducting (M10 to M8 ×4pcs.) Exhaust air opening for ducting B→ Liquid piping Air outlet Air inlet grille φ9.52(3/8") VIEW A...
  • Page 971 FDC-HKXR (b) 2-way outlet ceiling recessed type (FDTW) Models FDTWJ28HKXE2B, 45HKXE2B, 56HKXE2B Unit : mm Drain hose (Ceiling hole size) 1015 (Accessories) (Suspension bolts pitch) (Local setting) Holes of tapping screws Suspension bolts 5 - φ4 (M10 × 4 pcs.) Control Hole Center of...
  • Page 972 FDC-HKXR Models FDTWJ71HKXE2B, 90HKXE2B Unit : mm Drain hose 1260 (Ceiling hole size) (Accesories) (Suspension bolts pitch) 1130 (Local setting) Holes of taping screws Suspension bolts 5 – φ4 (M10 × 4 pcs.) Control Hole Center of panel Suspension fitting Fresh air opening VIEW A for ducting...
  • Page 973 FDC-HKXR Models FDTWJ112HKXE2B, 140HKXE2B Drain hose 1730 (Ceiling hole size) (Accessories) Holes for (Local setting) 1600 (Suspension bolts pitch) tapping screws Suspension bolts 5-ø4 (M10 × 4 pcs.) Control Hole Center of panel Suspension fitting Fresh air opening for ducting (knock out) VIEW A 1524...
  • Page 974 FDC-HKXR (c) 1-Way outlet ceiling recessed type (FDTS) Models FDTSJ22HKXE2B, 28HKXE2B, 36HKXE2B, 45HKXE2B Fresh air Unit : mm opening for ducting Fresh air (Knock out) Fresh air ↓ opening for ducting opening for ducting Holes for tapping screws (Ceiling hole size) 1230 (knock out) (Knock out)
  • Page 975 FDC-HKXR Model FDTSJ71HKXE2B Unit : mm Fresh air Fresh air opening for ducting opening for ducting Fresh air (Ceiling hole size) 1440 (Knock out) (knock out) opening for ducting Holes for tapping screws (Suspension bolts pitch) 1250 (φ4-6pcs.) (knock out) Panel center VIEW A Drain hose(Accessories)
  • Page 976 FDC-HKXR Cassetteria type (FDR) Model FDRJ22HKXE2 Silent Panel (Model: R-PNLS-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Local setting) Fresh air opening for ducting ↓ (Knock out) Control box Panel center VIEW C Drain Supply air duct (Connectable with VP25) Liquid piping Gas piping...
  • Page 977 FDC-HKXR Model FDRJ22HKXE2 Canvas Panel (Model: R-PNLC -26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bolts pitch) (Load setting) Fresh air opening for ducting ↓ (Knock out) Control box Drain (Connectable with VP25) Panel center Liquid piping φ6.35(1/4") Gas piping φ12.7(1/2")
  • Page 978 FDC-HKXR Models FDRJ28HKXE2, 45HKXE2, 56HKXE2 Silent Panel (Model: R-PNLS-26W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) (Suspension bols pitch) Fresh air (Local setting) opening for ducting (Knock out) C↓ Control box panel center VIEW C Drain Supply air duct (Connectable with VP25) Liquid piping Gas piping...
  • Page 979 FDC-HKXR Models FDRJ28HKXE2, 45HKXE2, 56HKXE2 Canvas Panel (Model: R-PNLC-26W-E) Unit : mm Drain hose (Accessories) (Ceiling hole size) (Local setting) (Suspension bolts pitch) Fresh air opening for ducting C↓ (Knock out) Control box Drain (Connectable with VP25) Panel center Liquid piping 28, 45 type: φ6.35 (1/4") 56 type: φ9.52 (3/8") Gas piping...
  • Page 980 FDC-HKXR Models FDRJ71HKXE2, 90HKXE2 Silent Panel (Model: R-PNLS-36W-E) Unit : mm (Ceiling hole size) 1180 Drain hose (Accessories) (Suspension bolts pitch) (Local setting) Fresh air opening for ducting (Knock out) C↓ Control box Panel center VIEW C Supply air duct Drain (Connectable with VP25) Gas piping...
  • Page 981 FDC-HKXR Models FDRJ71HKXE2, 90HKXE2 Canvas Panel (Model: R-PNLC-36W-E) Unit : mm Drain hose (Accessories) (Ceilinghole hole size) 1004 (Local setting) (Suspension bolts pitch) Fresh air opening for ducting C ↑ (Knock out) Drain (Connectable Control box with VP25) Panel center Liquid piping φ9.52(3/8") Gas piping...
  • Page 982 FDC-HKXR Models FDRJ112HKXE2, 140HKXE2 Silent Panel (Model: R-PNLS-46W-E) Unit : mm 1600 (Ceiling hole size) Drain hose (Accessories) 1406 (Suspension bolts pitch) (Local setting) Fresh air opening for ducting (Knock out) ↑ Control box Panerl center VIEW C Supply air duct Drain (Connectable with VP25) Liquid piping...
  • Page 983 FDC-HKXR Models FDRJ112HKXE2, 140HKXE2 Canvas Panel (Model: R-PNLC-46W-E) Unit : mm (Ceiling hole size) Drain hose (Accessories) 1424 Fresh air opening for ducting (Local setting) 1406 (Suspension bolts pitch) (Knock out) C ↑ Control box Drain Panel center (Connecteble with VP25) Liquid piping φ9.52(3/8") VIEW C...
  • Page 984 FDC-HKXR (e) Satellite ducted type (FDUM) Models FDUMJ36HKXE2, 45HKXE2, 56HKXE2 Unit : mm (Suspension bolts pitch) Hole of tapping screws ↑ (4-φ4) φ Control box Drain hose (Accessories) (Local setting) A→ Drain (Connectable with VP25) φ φ Liquid piping 36, 45 type: φ6.35(1/4") 56 type: φ9.52(3/8") Fresh air opening for ducting...
  • Page 985 FDC-HKXR Models FDUMJ71HKXE2, 90HKXE2 Unit : mm 986 (Suspension bolts pitch) ↑ Holes of φ149 tapping screws Control box 4-φ4 Drain hose (Accessories) (Local setting) A→ Drain (Connectable with VP25) φ170 φ170 Liquid piping φ9.52(3/8") Fresh air opening Gas piping for ducting Exhaust air opening for ducting φ15.88(5/8")
  • Page 986 FDC-HKXR Models FDUMJ112HKXE2, 140HKXE2 Unit : mm (Suspension bolts pitch) 1406 1370 Holes of tapping screws ↑ φ (4-φ4) Control box Drain hose (Accessories) (Local setting) φ A→ Drain φ (Connectable with VP25) Fresh air opening Liquid piping for ducting Exhaust air opening for ducting φ9.52(3/8") (Knock out)
  • Page 987 FDC-HKXR Ceiling suspension type (FDE) Models FDEJ36HKXE2B, 45HKXE2B, 56HKXEB2 Unit : mm (Suspension bolts pitch) Holes for suspension bolts The brackets face out The brackets face out (M8 to M10 × 4 pcs. Not included) When the unit is half When the unit is half recesed a bove recesed a bove...
  • Page 988 FDC-HKXR Model FDEJ112HKXE2B Unit : mm (Suspension bolts pitch) 1244 Holes for suspension bolts The brackets face out (M8 to M10 × 4pcs. Not included) When the unit is half recesed a bove Liguid piping the ceiling (Suspension bolt pitch) Gas piping 1160 The brackets face interior...
  • Page 989 FDC-HKXR (g) Wall mounted type (FDK) Models FDKJ22HKXE2, 28HKXE2, 36HKXE2, 45HKXE2 Unit : mm ←A Outlet for electric wiring Detail of mounting plate Outlet for piping (On both side) 77.5 77.5 Space for installation and service 20 20 Mounting plate φ8 ×...
  • Page 990 FDC-HKXR Model FDKJ71HKXE2 Unit : mm 1436 ←A Outlet for electric wiring Detail of mounting plate 1196 Outlet for piping (On both side) 1306 377.5 377.5 Space for installation and service 20 20 Mounting plate φ8 × 48 pcs. (Holes on mounting more more...
  • Page 991 FDC-HKXR (i) Floor standing hidden type (FDFU) Models FDFUJ28HKXE2, 45HKXE2, 56HKXE2, 71HKXE2 Unit : mm Note (1) Value in ( ) indicates 71 type. Space for installation and service Slotted hole for wall mounting (1071) 4-12 x 24 Peri cover Peri cover 810(1095) 722(1007)
  • Page 992 FDC-HKXR (2) Remote controller (Optional parts) Wall 0.3mm , 3cores (O.D.φ5.6) Wire (Recessed) LCD display Junction box (Locally Purchased) Remote controller mounting dimensions ♦ Usable JIS box, JIS C 8336 ⋅ Switch box for 1 piece (without cover) (use of the mark hole as illustrated on the left) ⋅...
  • Page 993 FDC-HKXR (3) Individual flow divide controller (Optional Part) HPFD01R-E 117.5 Indoor refrigerant piping connection pipe Hanging bolt position Liquid pipe φ9.52 (3/8") flare. with in- (M10 provided at site) cluded different diameter adapter coupling φ6.35 (1/4") pipe Outdoor refrigerant piping connection pipe Indoor connection wire (length 200) Liquid pipe φ9.52 (3/8") flare.
  • Page 994 FDC-HKXR (4) Outdoor unit Models FDCP2001HKXRE2, 2501HKXRE2...

  • Page 995: Exterior Appearance

    FDC-HKXR 20.2.4 Exterior appearance (1) Indoor unit (a) Ceiling recessed type (FDT) ● Decorative panel Pearl white (b) 2-way outlet ceiling recessed type (FDTW) Air outlet Air inlet ● Decorative panel (i) Standard type Panel part No. Type Panel color Applicable model TW-PSA-22W-E FDTW28, 45, 56 type...
  • Page 996 FDC-HKXR (c) 1-way outlet ceiling recessed type (FDTS) Panel Air inlet grille Ceramic white Ceramic white ● Decorative panel Panel part No. Type Panel color Applicable model TS-PSA-26W-E FDTS22, 28, 36, 45 type With Auto swing Misty white TS-PSA-36W-E FDTS71 type (d) Cassetteria type (FDR) Silent panel type Canvas-duct panel type...
  • Page 997 FDC-HKXR (g) Wall mounted type (FDK) Parts name Color Side plate Front panel Air inlet grill Ceramic white Air outlet louver Bottom plate Right and Left Light gray louvers (h) Floor standing exposed type (FDFL) Dark gray (Air outlet grill) Ceramic white (Body) Black...

  • Page 998: Piping System

    FDC-HKXR 20.2.5 Piping System Models FDCP2001HKXRE2, 2501HKXRE2...

  • Page 999: Selection Chart

    FDC-HKXR 20.2.6 Selection chart (1) Correct the cooling and heating capacity in accordance with the conditions as follows.The net cooling and heating capacity can be,obtained in the following way. Indoor unit Indoor unit capacity Each indoor unit = System performance Indoor unit capacity when operating simultaneously.
  • Page 1000 FDC-HKXR (c) When the outdoor unit is located at a lower height than the indoor unit in cooling operation and when the outdoor unit is located at a higher height than the indoor unit in heating operation, the following values should be subtracvted from the values in the above table. Height difference between the indoor unit and 10 m 15 m...

This manual is also suitable for:

Srk35gz-l1Srk502z-l1Srk502z-lSrk328henf-l2Srk408henf-l2Srk501henf-l ... Show all

Table of Contents
