REMOTE CONTROL
QUICK REFERENCE
This air conditioner complies
Ce climatiseur est conforme
with following directive.
aux directives suivantes :
Machinery
2006 / 42 / EC
Machinerie 2006 / 42 / EC
Low voltage 2014 / 35 / EU
Basse tension 2014 / 35 / EU
EMC
2014 / 30 / EU
EMC
RoHS
2011 / 65 / EU
RoHS
Ecodesign
2009 / 125 / EC
Conception écologique
CE making is applicable to area
of 50Hz power supply.
Le marquage CE est applicable
dans les zones d'alimentation
électrique de 50 Hz.
Diese Klimaanlage entspricht
Este aire acondicionado cumple
den folgenden Richtlinien.
con las siguientes directrices.
Maschinen 2006 / 42 / EC
Maquinaria 2006 / 42 / EC
Niederspannung 2014 / 35 / EU
Bajo voltaje 2014 / 35 / EU
EMC
2014 / 30 / EU
EMC
RoHS
2011 / 65 / EU
RoHS
Ecodesign
2009 / 125 / EC
Ecodiseño
CE Herstellung ist in Bereich
La marca CE corresponde al
mit 50 Hz Stromversorgung
área de suministro de energía
anwendbar.
de 60Hz.
Questo condizionatore è
conforme alle seguenti norme:
Macchine
2006 / 42 / EC
Bassa tensione 2014 / 35 / EU
2014 / 30 / EU
EMC
2014 / 30 / EU
2011 / 65 / EU
RoHS
2011 / 65 / EU
Ecoprogettazione 2009 / 125 / EC
2009 / 125 / EC
La marcatura CE è applicabile
all'area di alimentazione
elettrica di 50Hz.
Deze airconditioner voldoet aan
de volgende richtlijn.
Machinerie 2006 / 42 / EC
Lage spanning 2014 / 35 / EU
2014 / 30 / EU
EMC
2014 / 30 / EU
2011 / 65 / EU
RoHS
2011 / 65 / EU
2009 / 125 / EC
Ecodesign
2009 / 125 / EC
CE-markering is van
toepassing op het gebied met
een netstroom van 50 Hz.
ORIGINAL INSTRUCTIONS
RC-EXZ3A
Guida rapida di riferimento
Beknopte handleiding
Данный кондиционер
удовлетворяет нормам
следующих директив:
по машинному оборудованию
2006 / 42 / EC
по низковольтному оборудованию
2014 / 35 / EU
EMC
2014 / 30 / EU
RoHS
2011 / 65 / EU
Ecodesign
2009 / 125 / EC
Маркировка CE применима к
регионам с энергоснабжением
с частотой 50 Гц.
Quick reference
ENGLISH
Kurzanleitung
DEUTSCH
Aide-mémoire
FRANÇAIS
Consulta rápida
ESPAÑOL
ITALIANO
NEDERLANDS
Краткое руководство
PУCCКИЙ
PJZ012A180
201903
