3ware Hardware Installation
troller inside the chassis. The short 4-port or 8-port Escalade ATA RAID
Controller is keyed to ensure proper installation in a full-sized PCI slot.
6 Ensure that the contacts will mate with the grooves in the slot. Press down
gently on the edge of the ATA RAID Controller directly above the slot
until it is fully seated.
7 Check that the ATA RAID Controller's metal bracket covers the hole in
the case and secure the bracket with the screw that was used to secure the
filler bracket in step 4.

Connect the drives to the interface cables

1 Be sure to use the supplied cables. With the higher speeds of UltraATA-
133 and UltraATA-100, using quality cables is important.
2 Before connecting your drives, check your drives' jumper setting. The
range of settings provided vary by manufacturer as do the method for
adjusting them. Refer to information provided with your drives for the
method required to set them. To operate properly, the Escalade Parallel
ATA RAID Controller requires that drives be set as Single (if available on
your drive) or Master.
3 If your drives are not already installed in the computer chassis, do so now.
Be sure that the drives are connected to the power supply.
4 For each drive, select the black end of an interface cable not connected to
the ATA RAID Controller and plug it into the drive or drive carrier. The
cable's colored edge denotes Pin 1 and should be adjacent to the 4-pin
power plug.
20
: Continue to page 26 "Check your installation and close
Note
the case".
3ware Escalade ATA RAID Controller User Guide
