T-SERIES HOT FOOD HOLDING CABINETS — INSTRUCTIONS FOR USE

SERVICE AND REPLACEMENT PARTS

WARNING: Only factory approved service agents should attempt to service, repair or replace electrical components, wiring
or power cord.
Cabinet, Door and Electrical Parts
Replacement
ITEM # Part No. Description
1 C5T-9FXSLIDE TALL CABINET FIXED SLIDES - 1 PR.
C5T-9DCFXSLIDE DUAL CAVITY CABINET FIXED SLIDES - 2 PR.
C5T-8FXSLIDE 5/6 HT CABINET FIXED SLIDES - 1 PR.
C5T-5FXSLIDE 1/2 HT CABINET FIXED SLIDES - 1PR.
2 C5T-SHELF WIRE SHELF (MUST BE USED WITH RACK UPRIGHTS)
3A
C6P 6" CASTER, SWIVEL
C6PR 6" CASTER, RIGID
C8SPN 8" CASTER, SEMI-PNEUMATIC STYLE, SWIVEL
3B
C6PB 6" CASTER, BRAKE
C8SPNB 8" CASTER, SEMI-PNEUMATIC STYLE, SWIVEL, BRAKE
4 RPC06-1011A TALL CABINET DOOR GASKET
RPC06-1011B 5/6 HT CABINET DOOR GASKET
RPC06-1011C 1/2 HT CABINET DOOR GASKET
RPC06-1011D DUAL CAVITY DOOR GASKET
5 RPC06-1039 SNAP BUSHING, .750"
6 RPC06-189 SNAP BUSHING, 1"
7 RPC07-055 BULB COVER GROMMET, DUAL CAVITY
8 RPC11-446 REAR HANDLE
9 RPC5T-5UPRT 1/2 HT CABINET RACK UPRIGHT — 1 PR.
RPC5T-8UPRT 5/6 HT CABINET RACK UPRIGHT — 1 PR.
RPC5T-9DUPRT DUAL CAVITY CABINET RACK UPRIGHT — 1 PR.
RPC5T-9UPRT TALL CABINET RACK UPRIGHT — 1 PR.
10 RPC5T-ARMR-RD MOLDED ARMOUR PANEL, RED WITH HARDWARE
11 RPC5T-BMPR STRIP BUMPER WITH INSERT AND SCREWS
12 C5T-BSLIDEPR BOTTOM LOAD SLIDE — 1 PR.
13 RPC5T-CABPKT CABINET DOOR POCKET
14 RPC5T-CRN TOP MOLDED CORNER
15 RPC5T-DRSTKR DOOR STRIKE PLATE
16 RPC5T-HDL MOLDED HANDLE WITH HARDWARE
17 C5T-LSIDEPR LIP LOAD SLIDE — 1 PR.
18 RPCORDCLIP CORD CLIP WITH HARDWARE
19 RPC06-035 REAR HANDLE CAP
20 RPC06-1032 INFO PANEL EXTRUSION
21 RPC14-329 DOOR LATCH
22 RPC14-330 DOOR HINGE
23 RPC5T5-DOOR 1/2 HT CABINET COMPLETE DOOR ASSY.
RPC5T8-DOOR 5/6 HT CABINET COMPLETE DOOR ASSY.
RPC5T9D-TOPDR TOP DUAL CAVITY CABINET COMPLETE DOOR ASSY.
RPC5T9D-BOTDR BOT. DUAL CAVITY CABINET COMPLETE DOOR ASSY.
RPC5T9-DOOR TALL CABINET COMPLETE DOOR ASSY.
Replacement
ITEM # Part No.
24 RPC5T-INFO
25 RPF04-368
26 RP-WHITEBRD
27 RPC06-746
28 RPC13-083
29 RPC13-085
30 RPC13-096*
31 RPC13-198
32 RPC13-218
RPC13-446
33 RPC13-721
RPC13-447
34 RPC13-246
35 RPC13-375
36 RPC13-440
RPC13-546
RPC13-537
37 RPC13-421
RPC13-509
38 RPC13-423
39 RPC13-424
40 RPC13-502
41 RPC5TD-SNR
42 RPC13-442
RPC13-560
43 RPC13-451
RPC13-510
44 RPC13-501
RPC13-511
45 RPC13-503
46 RPC13-507
47 RPC13-508
48 RPC13-519
49 RPC13-521
50 RPC13-557
51 RPC13-588
52 RPC5-SCLP
53 RPC13-438
54 RPF07-125
55 RPC5T-TRVL
56 C5TINFOLBL-10
14
www.metro.com
Description
COMPLETE INFO PANEL ASSY.
BINDING BARREL, DOOR LATCH
WHITE BOARD WITH CLIPS
KNOB, ANALOG
STRAIN RELIEF
WIRE JOINT, SET SCREW TYPE, ANALOG (NOT SHOWN)
TERMINAL BLOCK
THERMAL CUT OUT
SGL CAVITY THERMOMETER, ANALOG
DUAL CAVITY THERMOMETER, ANALOG
SINGLE AND TOP CAVITY THERMOSTAT, ANALOG
DUAL CAVITY BOTTOM THERMOSTAT, ANALOG
RED INDICATOR LIGHT, ANALOG CABINET
MASTER SWITCH, ANALOG CABINET
125V 15A COIL POWER CORD, RT. ANGLE PLUG
125V 15A COIL POWER CORD, STR. PLUG
250V 15A COIL POWER CORD, EXPORT
120V AC BLOWER, IMPELLER AND LH NUT — ANALOG
220-240V AC BLOWER, IMPELLER AND NUT — EXPORT
CONTROLLER, DIGITAL
BATTERY GAUGE, DIGITAL
MOTOR CONTROLLER
DIGITAL TEMP SENSOR AND HARDWARE
DUAL CAVITY WIRE HARNESS, DIGITAL
SGL CAVITY WIRE HARNESS, DIGITAL
120V 1350W, HEAT ELEMENT, SGL. CAVITY
240V 1350W, HEAT ELEMENT, EXPORT SGL. CAVITY
120V 675W, HEAT ELEMENT, DUAL CAVITY
240V 675W, HEAT ELEMENT, EXPORT DUAL CAVITY
24V DC MOTOR ASSY., DIGITAL
BATTERY, 12V DC
IMPELLER AND LH. NUT
CURRENT SENSOR, DIGITAL
POWER SUPPLY, DIGITAL
FUSE HOLDER
4A FUSE
ANALOG BULB CLAMP KIT
RELAY CONTROLLER
UPRIGHT SPRING BUTTON CLIP
TRAVEL LATCH/HSAP AND HARDWARE
INFO PANEL LABELS — 10 PK
L01-459
REV N 02/21
