Cretors MACH 5 M532 Service Manual

Popcorn machine 32, 48 and 60 oz
Hide thumbs Also See for MACH 5 M532:
Table of Contents

Advertisement

Quick Links

176 MITTEL DRIVE, WOOD DALE, IL 60191
MACH 5
32, 48 and 60 oz
POPCORN MACHINE
SERVICE MANUAL
120/208; 120/ 240 Volt,
Single and Three Phase, 60 Hz
230 Volt,
Single Phase and Three Phase, 50 Hz
400 Volt, 3N~,
Three Phase, 50 Hz
100/200 Volt,
Single Phase, 50 & 60 Hz
Included in this manual:
*One Pop Option
*Salt/Sugar Option
*Elevator Option – see attachment
*Ansul and Ventless options
1
