Cretors RINGMASTER LITE Manual

Cotton candy machine optional floss stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

176 MITTEL DRIVE, WOOD DALE, IL 60191
RINGMASTER
COTTON CANDY MACHINE
120 Volt,
Single Phase, 60 Cycle
230 Volt,
Single Phase, 50 Cycle
Optional Floss Stand
READ and UNDERSTAND these operating, servicing, and
safety instructions before operating or servicing this
machine
9 SEPT 2019
LITE
®
1
RML-O-S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RINGMASTER LITE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cretors RINGMASTER LITE

Summary of Contents for Cretors RINGMASTER LITE

  • Page 1 RML-O-S 176 MITTEL DRIVE, WOOD DALE, IL 60191 RINGMASTER LITE ® COTTON CANDY MACHINE 120 Volt, Single Phase, 60 Cycle 230 Volt, Single Phase, 50 Cycle Optional Floss Stand READ and UNDERSTAND these operating, servicing, and safety instructions before operating or servicing this machine 9 SEPT 2019...

  • Page 2: Safety First

    INTRODUCTION This manual is filled with timesaving and money-saving information regarding your Cretors machine. There is nothing, however, more important than the safety aids and warnings that are found throughout this document. The Safety Alert Symbol is used to identify topics of primary safety concern wherever they appear.

  • Page 3: Purpose Of Manual

    PRODUCT IDENTIFICATION CRETORS RINGMASTER LITE COTTON CANDY MACHINE ELECTRICAL SPECIFICATIONS: Ringmaster Lite Cotton Candy Machines are available in any of the following Electrical configurations: 120 Volt, Single Phase, 60 Cycle 230 Volt, Single Phase, 50 Cycle...

  • Page 4: Control Panel

    Controls heat element output. VIII. INSTALLATION INSTRUCTIONS 1. Location Choose a location for your Cretors machine to maximize the ease of operation and maintenance procedures. Check your local building and fire codes for location restrictions. 2. Unpacking After the Ringmaster is unpacked, place it on a sturdy table or counter at a height to suit the operator.
  • Page 5 OPERATING INSTRUCTIONS Do not attempt to operate your Cretors Cotton Candy machine until you have read and understood this manual. Failure to do so may result in serious injury or death. Do not attempt to operate your Cretors Cotton Candy machine unless the installation instructions have been strictly adhered to.
  • Page 6 RML-O-S Turn the HEAT Control to it’s highest position When Floss starts to flow out of the head, lower the HEAT setting until the desired consistency of floss is produced. The leather ‘floaters’ on the top of the spinner head create a draft of air, which controls where the cotton candy floss lies in the bowl.

  • Page 7: Ordering Parts

    RML-O-S 2. Cabinet and Spinner head Be certain the machine is turned ‘OFF’ and power is unplugged before sanitizing this machine. Failure to do so could result in injury or death. The cabinet base can be cleaned with any good grade household cleaner suitable for Stainless Steel or plastic and is acceptable for food contact surfaces.
  • Page 8 RML-O-S Do not attempt electrical repairs on the power supply circuit unless you are qualified to do so. The electrical shock associated with line voltages can cause serious injury or death. Unplug machine from power source Remove four screws that hold the switch plate in place. Remove switch plate.
  • Page 9 RML-O-S If there is no continuity from the top to the bottom on either side of the switch - replace the switch. Disconnect the two potentiometer two leads from the voltage control. With a Multi-meter, place the meter leads one on each of the potentiometer leads. Turn the potentiometer slowly and watch your Multi-meter.
  • Page 10 Customer Service Department at C. Cretors and Company. Additional copies of this manual can be obtained from C. Cretors and Company at the address listed below. Please provide model and serial number when requesting additional copies of this manual. There will be a nominal charge for additional copies.
  • Page 11 RML-O-S Optional Cotton Candy/ Floss Stand If equipped with optional Cretors Cotton Candy/Floss Stand, the Ringmaster body should be installed into the stand without the bowl on. Drop the feet of the RM body into the embossed dimples in the shelf. Plug the RM into the outlet located in the back of the Floss stand. Now install the bowl into the cabinet on top of the top shelf in the floss stand.
