Overview Of The Assembly - SMA NR-STP-DC-CON-1012 Replacement Manual

SMA Solar Technology AG
Quantity
3
13
1
4

Overview of the Assembly

B
A
Figure 1 : Position in the inverter
C
Figure 2 : Position in the inverter
Position Designation
A EMC filter assembly (DC-EMV)
Replacement Manual
Designation
Printed circuit board mounting clip (diameter:
11 mm)
Pan head screw M4x15
Replacement Manual
DCCON-STPTL10-RM-xx-10
