Summary of Contents for Mercedes-Benz 2005 CL-Class

Page 1 Operator’s Manual CL-Class...
Page 2 Ê5WtCs-Ë 2155843583 Order No. 6515 2178 13 Part No. 215 584 35 83 USA Edition A, 2005...
Page 3 CL 500 CL 600 CL 55 AMG CL 65 AMG...
Page 4 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...
Page 5: Table Of Contents
Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada...
Page 6 Contents Driving safety systems... 80 ABS ... 80 BAS ... 81 ESP... 82 Anti-theft systems... 85 Immobilizer... 85 Anti-theft alarm system ... 85 Tow-away alarm ... 87 Controls in detail ... 89 Locking and unlocking ... 90 SmartKey ... 90 SmartKey with KEYLESS-GO*...
Page 7 Automatic transmission... 166 One-touch gearshifting... 168 Gear ranges ... 169 Gear selector lever position ... 170 Automatic shift program ... 172 Driving tips... 173 Steering wheel gearshift control (Speedshift) CL 55 AMG and CL 65 AMG... 174 Manual shift program CL 55 AMG and CL 65 AMG...
Page 8 Contents Operation ... 257 The first 1000 miles (1500 km) ... 258 Driving instructions... 259 Drive sensibly – save fuel ... 259 Drinking and driving ... 259 Pedals ... 259 Power assistance ... 259 Brakes ... 260 Driving off... 262 Parking ...
Page 9 Practical hints ... 325 What to do if …?... 326 Lamps in instrument cluster ... 326 Lamp in center console... 334 Vehicle status messages in the multifunction display... 335 Where will I find...? ... 365 First aid kit... 365 Vehicle jack, vehicle tool kit, luggage bowl, spare wheel ...
Page 10 Contents Fuels, coolants, lubricants, etc..411 Capacities ... 411 Engine oils... 413 Engine oil additives ... 413 Air conditioning refrigerant ... 413 Brake fluid ... 414 Premium unleaded gasoline ... 414 Fuel requirements ... 414 Gasoline additives ... 415 Coolants...
Page 11: Introduction
Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitabili- ty for Mercedes-Benz vehicles.
Page 12: Operator's Manual
Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your au- thorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...
Page 13: Retail Buyers And Lessees Of Mercedes-Benz Automobiles
30 calender days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350.
Page 14: Maintenance
(in Canada) at 1-800-387-0100. It is in your own interest that we can contact you should the need arise. If you sell your Mercedes, please leave all literature with the vehicle to make it avail- able to the next operator.
Page 15: Operating Your Vehicle Outside The Usa Or Canada
Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult your authorized Mercedes-Benz Center or...
Page 16: Where To Find It
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.
Page 17: Symbols
Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Page 18: Operating Safety
Electronic malfunctions could seri- ously impair the operating safety of your vehicle. See an authorized Mercedes-Benz Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
Page 19: Problems With Your Vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact an authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...
Page 20: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 21: Vehicle Data Recording
Vehicle data recording Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data and, if equipped with the Tele Aid system, may transmit some data in certain accidents. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety.
Page 23: At A Glance
At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Door control panel...
Page 24: Cockpit
At a glance Cockpit...
Page 25 Item Page 1 Combination switch Turn signals Windshield wipers High beam 2 Cruise control lever Cruise control Distronic* 3 Instrument cluster 4 Multifunction steering wheel 5 Steering wheel gearshift control (CL 55 AMG and CL 65 AMG only) Item Page 6 Lever for voice control sys- tem*, see separate operat- ing instructions...
Page 26: Instrument Cluster
At a glance Instrument cluster...
Page 27: Left Turn Signal
Item Page 1 Coolant temperature gauge 2 Fuel gauge with fuel tank reserve warning lamp 3 L Left turn signal indicator lamp K Right turn signal indicator lamp 4 Speedometer with: v Electronic Stability Program (ESP) warning lamp l Distance warning lamp Vehicles without Distronic*: Warning lamp without func-...
Page 28: Multifunction Steering Wheel
At a glance Multifunction steering wheel Item Page 1 Multifunction display Operating control system 2 Selecting the submenu or setting the volume: Press button æ up/to increase ç down/to decrease 3 Telephone*: Press button s to take a call to dial a call t to end a call to reject an in- coming call...
Page 29: Important Notice For California Center Console
Center console Upper part Item Page 1 Switch for rear window sunshade 2 Parktronic* deactivation button 3 Active Body Control (ABC) button 4 Level control button 5 Central locking switch Anti-theft alarm system in- dicator lamp 6 Hazard warning flasher on/off switch At a glance Center console...
Page 30: Lower Part
At a glance Center console Lower part Item Page 1 KEYLESS-GO* start/stop button 2 Gear selector lever for automatic transmission 3 Front passenger front air bag off indicator lamp 4 Thumbwheel for setting distance in Distronic* 5 Distance warning func- tion* on/off button 6 Program mode selector for automatic transmission...
Page 31: Overhead Control Panel
Overhead control panel 1 Left reading lamp on/off 2 Rear interior lighting 3 Right reading lamp on/off 4 Interior lighting control 5 Tilt/sliding sunroof 6 Hands-free microphone for 7 Rear view mirror 8 Garage door opener 9 Tele Aid (emergency call Item Page on/off...
Page 32: Door Control Panel
At a glance Door control panel Item Page 1 Door handle 2 Memory function (for stor- ing seat, exterior mirror and steering wheel set- tings) 3 Seat heating Seat ventilation* 4 Seat adjustment Item Page 5 Exterior mirror adjustment 6 Switches for opening/clos- ing front door windows 7 Override switch for rear passenger compartment...
Page 33: Getting Started
Getting started Unlocking Adjusting Driving Parking and locking...
Page 34: Unlocking
Getting started Unlocking The“Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 35: Unlocking With Keyless-Go
Unlocking with KEYLESS-GO* With KEYLESS-GO you can open and start your vehicle without using the buttons on the SmartKey. To unlock the vehicle, the SmartKey with KEYLESS-GO must be outside the vehicle, no further than approx. 3 feet (1 meter) away from the door. Opening a door causes the windows on that side of the car to open slightly.
Page 36: Starter Switch Positions
Getting started Unlocking Starter switch positions Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle.
Page 37 If the SmartKey cannot be turned in the starter switch, the battery may not be sufficiently charged. Check the battery and charge it if necessary ( page 386). Get a jump start ( page 389). To prevent accelerated battery dis- charge or a completely discharged bat- tery, always remove the SmartKey from the starter switch when the engine is...
Page 38 Getting started Unlocking Position 0 Before you press the KEYLESS-GO start/stop button 1, the vehicle’s on-board electronics have status 0 (as with SmartKey removed). Position 1 Press KEYLESS-GO start/stop button 1 once. This supplies power to some electrical consumers, such as seat adjustment. If you now press the KEYLESS-GO start/stop button once again, the ignition (position 2)
Page 39: Adjusting
Adjusting Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 40 Getting started Adjusting A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Seat adjustment The seat adjustment switches are located in each door.
Page 41 The feature below is deactivated at the factory for U.S. vehicles. If you wish to have it activated, contact an authorized Mercedes-Benz Center. The front passenger seat head restraint automatically lowers after a few sec- onds when the front passenger seat is not occupied.
Page 42 Getting started Adjusting Folding front seat backrest forward 1 Release lever Folding backrest forward Lift release lever 1 and fold the seat backrest forward. The seat will automatically slide for- ward and the head restraint will move down. Folding backrests back Lift release lever 1 and fold backrest back.
Page 43 Mercedes-Benz Center immediately. When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle.
Page 44: Steering Wheel
Getting started Adjusting Steering wheel Warning! Do not adjust the steering wheel while driv- ing. Adjusting the steering wheel while driv- ing could cause the driver to lose control of the vehicle. When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle.
Page 45: Mirrors
Mirrors Adjust the interior and exterior rear view mirrors before driving so that you have a good view of the road and traffic condi- tions. Warning! In the case of an accident, liquid electrolyte may escape the mirror housing if the mirror glass breaks.
Page 46 Getting started Adjusting The buttons are located on the driver’s door. 1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view mir- ror button 3 Adjustment button Switch on ignition ( page 34). Press button 1 for the left mirror or button 2 for the right mirror.
Page 47: Driving
( page 62). Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 48 Getting started Driving According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing positions. Infants and small children must ride in back seats and be seated in an appropriate infant or child restraint system, which is properly secured with the vehicle’s seat belt and top tether strap, or secured via lower anchors and top tether strap, fully in...
Page 49 Do not bleach or dye seat belts as this may severely weaken them. In a crash, they may not be able to provide adequate protection. Damaged seat belts or belts that were highly stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Cen- ter.
Page 50: Starting The Engine
Getting started Driving Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health. All exhaust gas contains carbon monoxide, and inhaling it can cause unconsciousness and lead to death. Do not run the engine in confined areas (such as a garage) which are not properly ventilated.
Page 51 Get a jump start ( page 389). If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center.
Page 52 Getting started Driving Parking brake 1 Parking brake pedal 2 Parking brake release handle Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle.
Page 53 Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehi- cle control. Your vehicle’s ABS will not pre- vent this type of loss of control. In order to avoid damaging the trans- mission, wait for the gear selection process to complete before setting the vehi-...
Page 54: Switching On Headlamps
Getting started Driving Switching on headlamps Low beam headlamps The exterior lamp switch is located on the dashboard to the left of the steering wheel. Exterior lamp switch 1 Off 2 Low beam headlamps on Turn the switch to B. The green indicator lamp C in the exterior lamp switch comes on.
Page 55: Turn Signals
Turn signals The combination switch is located on the left of the steering column. Combination switch 1 Turn signals, right 2 Turn signals, left Press the combination switch up 1 or The combination switch resets automati- down 2. cally after major steering wheel move- ments.
Page 56: Windshield Wipers
Getting started Driving Windshield wipers The combination switch is located on the left of the steering column. Combination switch 1 Single wipe 2 Switching on windshield wipers Switch on ignition ( page 34). Switching on windshield wipers Turn the combination switch to the de- sired position depending on the inten- sity of the rain.
Page 57 Turn the windshield wipers on again. Getting started Driving If windshield wipers fail to function at all in switch position I, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Center...
Page 58: Problems While Driving
Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is above 248°F (120°C) The coolant is too hot and is no longer cooling the engine.
Page 59: Parking And Locking
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows: Warning! With the engine not running, there is no power assistance for the brake and the steering systems. In this case, it is impor- tant to keep in mind that a considerably higher degree of effort is necessary to brake and steer the vehicle.
Page 60: Parking Brake
Getting started Parking and locking Parking brake 1 Parking brake 2 Release handle Step firmly on parking brake 1. When the engine is running, the indica- tor lamp ; (USA only) or 3 (Canada only) in the instrument cluster will be illuminated. Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO*...
Page 61: Switching Off Headlamps
Switching off headlamps Turn the exterior lamp switch to M ( page 52). For more information, see “Exterior lamp switch” ( page 125). Turning off the engine Place the gear selector lever in position P. Always set the parking brake in addi- tion to shifting to position P.
Page 62: Locking
Getting started Parking and locking Locking Warning! To prevent possible personal injury, always keep hands and fingers away from the door openings when closing the doors. Be espe- cially careful when small children are around. Before closing doors, make sure there is no possibility of someone getting caught in a door during closing.
Page 63: Safety And Security
Safety and Security Occupant safety Panic alarm Driving safety systems Anti-theft systems...
Page 64: Occupant Safety
For safety reasons, we strongly recom- mend that you visit an authorized Mercedes-Benz Center immediately to have the system checked. For more information, see “Practical hints” ( page 333).
Page 65: Air Bags
SRS self-check has detected a malfunction. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 66 If you have any prob- lems, please see an authorized Mercedes-Benz Center. Do not lean with your head or chest close to the steering wheel or dash- board.
Page 67 Mercedes-Benz Center at an additional cost. Please contact your local authorized Mercedes-Benz Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details.
Page 68 These instructions are available from your authorized Mercedes-Benz Center. Given the considerable deployment speed and the textile structure of the air bags, there is the possibility of abra- sions or other injuries resulting from air bag deployment.
Page 69 When you sell your vehicle we strongly urge you to give notice to the subsequent owner that it is equipped with an SRS by alerting them to the applicable section in the Operator’s Manual. Front air bags 1 Driver air bag 2 Passenger air bag Driver and front passenger air bags are de- ployed:...
Page 70: Seat Belts
Safety and Security Occupant safety The side impact air bags are deployed: in impacts exceeding a preset deploy- ment threshold on the impacted side of the vehicle independently of the front air bags The side impact air bags are not deployed in impacts which do not exceed the sys- tem’s deployment threshold.
Page 71 For information on infants and children traveling with you in the vehicle and re- straint systems for infants and chil- dren, see “Children in the vehicle” ( page 72). Warning! Always fasten your seat belt before driving off. Always make sure your passengers are properly restrained, even those sitting in the rear and pregnant women.
Page 72 Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation or to failure.
Page 73 When disposing of the emergency tension- ing device, our safety instructions must be followed. These are available at your autho- rized Mercedes-Benz Center. Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side...
Page 74: Children In The Vehicle
Infant and child restraint seats and infor- mation on choosing an appropriate re- straint system can be obtained from any Mercedes-Benz Center. Infant and child restraint systems Use only a BabySmart compatible child restraint for the front passenger seat in this vehicle.
Page 75 Children 12 years old and under must never Vehicle Safety Standards 213 and 225 ride in the front seat, except in a and Canadian Motor Vehicle Safety Mercedes-Benz authorized BabySmart Standards 213 and 210.2. compatible child seat, which operates with A statement by the child restraint man-...
Page 76 Corp. Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart air bag deactivation system. With the spe- cial child seat properly installed, the pas- senger front air bag will not deploy.
Page 77 Warning! The BabySmart air bag deactivation sys- tem will ONLY work with a special child seat designed to operate with it. It will not work with child seats which are not BabySmart compatible. Never place anything between seat cushion and child seat (e.g. pillow), since it reduces the effectiveness of the deactivation sys- tem.
Page 78 Safety and Security Occupant safety Installation of infant and child restraint systems This vehicle is equipped with tether an- chorages for a top tether strap at each of the rear seating positions. 1 Cover of top anchorage ring Remove cover 1 from anchorage ring. Store cover 1 in a convenient place (e.g.
Page 79 Child seat anchors – LATCH type This vehicle is equipped with two LATCH (Lower Anchors and Tethers for CHildren) type anchors (at each of the rear seats) for the installation of a LATCH child seat with the matching anchor fittings. If you have not installed a child seat, the LATCH mounting anchor fittings are cov- ered with an upholstery blend.
Page 80: Blocking Of Rear Window Operation
Safety and Security Occupant safety An incorrectly mounted child seat may come loose during an accident which could result in serious injury or death to the child. Damaged or impact damaged child seats or child seat mounting fittings must be re- placed.
Page 81: Panic Alarm
Panic alarm An audible alarm and blinking exterior lamps will operate for approximately 2½ minutes. 1 Â button Activating Press and hold button 1 for at least one second. Deactivating Press button 1 again. Insert SmartKey in the starter switch. USA only: This device complies with Part 15 of the FCC Rules.
Page 82: Driving Safety Systems
Safety and Security Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ESP (Electronic Stability Program) In winter operation, the maximum ef- fectiveness of the ABS, BAS, and the ESP is only achieved with winter tires (M+S tires), or snow chains as re- quired.
Page 83: Bas
The - indicator lamp in the instrument cluster ( page 24) comes on when you switch on the ignition ( page 34). It goes out when the engine is running. Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode.
Page 84: Esp
Safety and Security Driving safety systems Warning! The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that af- forded by the condition of the vehicle brakes and tires or the traction afforded. The BAS cannot prevent accidents, including those resulting from excessive speed in turns, fol- lowing another vehicle too closely, or hydro-...
Page 85 Warning! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, or hydroplaning. Only a safe, attentive, and skillful driver can prevent accidents.
Page 86 ESP switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Switching on the ESP Press ESP switch 1. The ESP warning lamp v in the in- strument cluster goes out.
Page 87: Anti-Theft Systems
In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada). Safety and Security Anti-theft systems Anti-theft alarm system...
Page 88 Safety and Security Anti-theft systems If the alarm stays on for more than 30 seconds, a call to the Response Center is initiated automatically by the by the Tele Aid system ( page 243) provided Tele Aid service was sub- scribed to and properly activated, and that necessary cellular service and GPS coverage are available.
Page 89: Tow-Away Alarm
Canceling the alarm To cancel the alarm: With the SmartKey Insert the SmartKey in the starter switch. Press the Œ or ‹ button on the SmartKey. The alarm is canceled. With KEYLESS-GO* Grasp the outside door handle. The SmartKey with KEYLESS-GO must be within 3 ft.
Page 90 Safety and Security Anti-theft systems The button is located on the upper part of the front center console. 1 Indicator lamp 2 Tow-away alarm off switch Switch off the ignition and remove the SmartKey from the starter switch. You cannot disarm the tow-away alarm if the ignition is switched on.
Page 91: Controls In Detail
Controls in detail Locking and unlocking Seats Memory function Lighting Instrument cluster Control system Automatic transmission Good visibility Automatic climate control Power windows Power tilt/sliding sunroof Driving systems Loading Useful features...
Page 92: Locking And Unlocking
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed in your vehicle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
Page 93 Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. It is possible for children to open a locked door from the inside, which could result in an accident and/or serious personal injury.
Page 94 Controls in detail Locking and unlocking Factory setting Global unlocking Press button Œ. All turn signal lamps flash once. The locking knobs in the doors move up. The anti-theft alarm system is dis- armed. The vehicle will lock again automatically and reactivate the anti-theft alarm system within approximately 40 seconds of un- locking if:...
Page 95 ( page 367). Have the vehicle battery and the battery connections checked ( page 386). If the SmartKey is malfunctioning, con- tact an authorized Mercedes-Benz Cen- ter. Checking the batteries Press button ‹ or Œ. Battery check lamp 5 comes on brief- ly to indicate that the SmartKey batter- ies are in order.
Page 96: Smartkey With Keyless-Go
Report the loss of the SmartKey or the mechanical key immediately to your car insurance company. If necessary, have the mechanical lock replaced. Your authorized Mercedes-Benz Center will be glad to supply you with a replace- ment. SmartKey with KEYLESS-GO* Vehicles equipped with KEYLESS-GO come...
Page 97 Warning! When leaving the vehicle, always take the SmartKey with KEYLESS-GO* with you and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment may cause an accident and/or serious personal injury.
Page 98 Controls in detail Locking and unlocking Important notes on using KEYLESS-GO You can also use the SmartKey with KEYLESS-GO like a normal SmartKey ( page 90). You can combine KEYLESS-GO func- tions with normal SmartKey functions (e.g. unlocking with KEYLESS-GO and locking with the ‹...
Page 99 If the SmartKey with KEYLESS-GO is re- Factory setting moved from the vehicle while the igni- tion is switched on (e.g. if passenger Global unlocking exits the vehicle with the SmartKey with KEYLESS-GO), the message NOT RECOGNIZED will appear in the multifunction display while driving off.
Page 100 Controls in detail Locking and unlocking Selective setting If you frequently travel alone, you may wish to reprogram the SmartKey with KEYLESS-GO so when you, grasp the driv- er’s outside door handle only the driver’s door and the fuel filler flap unlocks. Press and hold buttons Œ...
Page 101 SmartKey with KEYLESS-GO battery is discharged. Replace the battery ( page 371). You can obtain the required battery at any authorized Mercedes-Benz Center. If the battery is checked within signal range of the vehicle, pressing the button ‹ or Œ will lock or unlock the vehicle accordingly.
Page 102: Opening The Doors From The Inside
Have the mechanical lock replaced if necessary. Your authorized Mercedes-Benz Center will be glad to supply you with a replace- ment. Opening the doors from the inside You can open a locked door from the in- side.
Page 103: Opening The Trunk
Opening the trunk If the vehicle has previously been locked from the outside with the Opening the trunk from the outside SmartKey or KEYLESS-GO*, opening a A minimum height clearance of 6.3 ft door from the inside will trigger the an- (1.90 m) is required to open the trunk lid.
Page 104 Controls in detail Locking and unlocking Opening the trunk from the inside You can open the trunk from the inside if the vehicle is stationary. A minimum height clearance of 6.3 ft (1.90 m) is required to open the trunk lid. The switch is located on the driver’s door.
Page 105: Closing The Trunk
Closing the trunk Closing the trunk from the inside auto- matically* In vehicles with trunk lid opening/closing system* you can close the trunk from the inside using the remote trunk lid switch. Press remote trunk lid switch ( page 102) until the indicator lamp in the switch goes out and trunk lid is closed.
Page 106 Controls in detail Locking and unlocking Closing the trunk from the outside manually 1 Handle Lower trunk lid by pulling firmly on handle 1. Push the trunk lid closed from the out- side with hands placed flat on trunk lid. The power closing assist automatically en- sures that the lid is pulled closed com- pletely ( page 110).
Page 107 Closing the trunk from the outside (vehicles without KEYLESS-GO*) In vehicles with trunk lid opening/closing system* you can close the trunk separate- ly from the outside using the trunk lid clos- ing switch. 1 Trunk lid closing switch Press trunk lid closing switch 1 brief- The trunk lid closes.
Page 108 Controls in detail Locking and unlocking Warning! Only drive with the trunk closed as, among other dangers such as visibility blockage, exhaust fumes may enter the vehicle interi- Do not place the SmartKey in the open trunk. You may lock yourself out. If the vehicle was previously centrally locked, the trunk will lock automatical- ly after closing it.
Page 109 Warning! Monitor the closing procedure carefully to make sure no one is in danger of being in- jured. To prevent possible personal injury, always keep hands and fingers away from the trunk opening when closing the trunk. Be especially careful when small children are around.
Page 110 Controls in detail Locking and unlocking Press switch 1 briefly. The vehicle is locked and the trunk lid closes automatically. The turn signals flash three times to confirm locking. The locking knobs in the doors move down. The anti-theft alarm system is activated.
Page 111: Trunk Lid Emergency Release
Trunk lid emergency release The emergency release button is located on the inside of the trunk lid. 1 Emergency release button Briefly press emergency release button 1. The trunk unlocks and the trunk lid opens. The emergency release button unlocks and opens the trunk while the vehicle is standing still or in motion.
Page 112: Power Closing Assist For Doors And Trunk Lid
Controls in detail Locking and unlocking Power closing assist for doors and trunk lid It is not necessary to slam the door or trunk lid closed. A pneumatic power-as- sisted mechanism draws doors and trunk lid closed quietly and automatically once door and trunk lid has been latched.
Page 113: Locking And Unlocking From The Inside
Locking and unlocking from the inside You can lock or unlock the doors and the trunk from inside using the central locking or unlocking switch. This can be useful, for example, if you want to lock the vehicle be- fore starting to drive. The fuel filler flap cannot be locked or un- locked with the central locking or unlock- ing switch, respectively.
Page 114: Seats
Controls in detail Seats For more information on seat adjustment, see “Adjusting” ( page 37). Easy-entry/exit feature This feature allows for easier entry into and exit from the vehicle. The easy-entry/exit feature can be activat- ed or deactivated in the CONVENIENCE sub- menu of the control system ( page 164).
Page 115 When entering the vehicle, with the easy-entry/exit feature activated, the If the current position for the steering steering wheel or, depending on your se- wheel is in the uppermost tilt position, lection, the steering wheel and driver’s the steering wheel will no longer be seat will return to their last set memory po- able to move upward when the sition or a factory-set maximum forward...
Page 116: Removing And Installing
Controls in detail Seats Removing and installing front seat head restraints For information on head restraint adjust- ment, see “Seats” ( page 37). Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level.
Page 117: Rear Seat Head Restraints
Rear seat head restraints The rear head restraints cannot be re- moved. Folding head restraints back The rear seat head restraints and the rear seat power head restraints* can be folded backward for increased visibility. The switch is located on the upper part of the front center console.
Page 118 Controls in detail Seats Placing power head restraints* upright Switch on ignition ( page 34). Press switch 1 in the front center con- sole and hold. The rear head restraints will fold up- right. Folding back and placing upright power head restraints* with the switch in the rear center console You can fold the rear power head restraints...
Page 119: Lumbar Support
Lumbar support You can adjust the contour of the seat’s lumbar support to best support your spine. The thumbwheels for the driver’s and front passenger’s seat are located on the outer side of the seat. 1 Thumbwheel Switch on ignition ( page 34). Set the lumbar support between 0 and 5.
Page 120 Controls in detail Seats Lumbar region support Press k or j on rocker switch 4. This selects the air cushion you wish to adjust. Press æ or ç on rocker switch 4. The air cushion inflates or deflates. Side bolsters adjustment Adjust the side bolsters so that they provide good lateral support using switch 2.
Page 121: Seat Heating
Seat heating Vehicles without seat ventilation* The switch is located on the door. 1 Normal heating 2 Rapid heating Switch on ignition ( page 34). Switching on seat heating Press switch 1. A red indicator lamp above the switch comes on. Switching off seat heating Press switch 1 again.
Page 122 Controls in detail Seats Vehicles with seat ventilation* The switch is located on the door. The red indicator lamps on the switch show the heating level selected: Level No indicator lamp on One indicator lamp on Two indicator lamps on 1 Seat heating switch Switch on ignition ( page 34).
Page 123: Seat Ventilation
Seat ventilation* The switch is located on the door. Seat ventilation can be activated manually with the SmartKey in starter switch position 1 or 2. The driver’s seat ventilation can be activated automatically by the summer opening feature ( page 201). The blue indicator lamps on the switch show the ventilation level selected: Level...
Page 124: Memory Function
Controls in detail Memory function Prior to operating the vehicle, the driv- er should check and adjust the seat height, seat position fore and aft, and seat backrest angle if necessary, to en- sure adequate control, reach and com- fort. The head restraint should also be adjusted for proper height.
Page 125: Storing Positions Into Memory
The memory button and stored position switch are located on the door. 1 Stored position button 2 Memory button Switch on ignition ( page 34). Open the respective door and insert the SmartKey in the starter switch. Storing positions into memory Adjust the seats, steering wheel and exterior mirrors to the desired position ( page 37).
Page 126: Storing Exterior Rear View Mirror Parking Position
Controls in detail Memory function Storing exterior rear view mirror park- ing position For easier parking, you can adjust the pas- senger-side exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Setting parking position for exterior rear view mirror”...
Page 127: Lighting
Relevant information can be obtained at your authorized Mercedes-Benz Cen- ter. Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel.
Page 128 Controls in detail Lighting With the SmartKey removed from the starter switch or the engine turned off with KEYLESS-GO* and the driver’s door open, a warning sounds if the parking lamps or low beam headlamps are switched on. The message TURN OFF LIGHTS appears in the multifunction display.
Page 129 Turn the exterior lamp switch to U. With the SmartKey in starter switch po- sition 1 or the KEYLESS-GO* start/stop button pressed once, only the parking lamps will switch on and off automatically. When the engine is running, the low beam headlamps, the tail and parking lamps, the license plate lamps, and the side marker lamps will switch on and...
Page 130 Controls in detail Lighting Switching on fog lamps Warning! In low ambient lighting or foggy conditions, only switch from position U to B with the vehicle at a standstill. Switching from U to B will briefly switch off the head- lamps.
Page 131: Combination Switch
Combination switch The combination switch is located on the left side of the steering column. 1 High beam 2 High beam flasher High beam Turn exterior lamp switch to position B or to U ( page 125). Push the combination switch in direc- tion of arrow 1 to switch on the high beam.
Page 132: Hazard Warning Flasher
Controls in detail Lighting Hazard warning flasher The hazard warning flasher can be switched on at all times, even with the SmartKey removed from the starter switch or with the SmartKey with KEYLESS-GO* removed from the vehicle. The hazard warning flasher switches on au- tomatically when an airbag deploys.
Page 133: Interior Lighting
Interior lighting The controls are located in the overhead control panel. 1 Left reading lamp on/off 2 Rear interior lamps on/off 3 Right reading lamp on/off 4 Rocker switch for automatic control on/off Leaving an interior light switch in the ON position for extended periods of time with the engine turned off could result in a discharged battery.
Page 134 Controls in detail Lighting Manual control Front interior lighting Press the ð symbol on rocker switch 4. The front interior lighting switches on. Press the ñ symbol on rocker switch 4 again. The front interior lighting switches off. The automatic control function is acti- vated.
Page 135: Courtesy Lighting
Courtesy lighting For better orientation in the dark, courtesy lamps will illuminate the interior of your ve- hicle as follows: With parking lamps switched on: the door handles the driver and passenger footwells With the SmartKey in the starter switch position 1: the door handles the center console...
Page 136: Instrument Cluster
Controls in detail Instrument cluster A full view illustration of the instrument cluster can be found in the “At a glance” section of this manual ( page 24). 1 Reset button J The instrument cluster is activated when you: open a door turn on the ignition press the reset button J 1 switch on the exterior lamps...
Page 137: Coolant Temperature Gauge
248° F (120°C), i.e. in the red zone of the coolant temperature gauge. Doing so may cause serious engine damage which is not cov- ered by the Mercedes-Benz Limited War- ranty. Controls in detail Instrument cluster...
Page 138: Tachometer
Avoid driving at excessive engine speeds, as it may result in serious en- gine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
Page 139: Control System
Control system The control system is activated as soon as the SmartKey in the starter switch is turned to position 1 or as soon as the KEYLESS-GO start/stop button ( page 35) is in position 1. The control system enables you to: call up information about your vehicle change vehicle settings For example, you can use the control sys-...
Page 140: Multifunction Steering Wheel
Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled by the buttons on the multifunc- tion steering wheel. 1 Multifunction display in the speed- ometer Operating the control system 2 Selecting the submenu or setting the volume æ...
Page 141 Pressing any of the buttons on the multi- function steering wheel will alter what is shown in the multifunction display. The information available in the multifunc- tion display is arranged in menus, each containing a number of functions or sub- menus.
Page 142: Menus
Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
Page 143 Menus, submenus and functions Menu 1 Menu 2 Menu 3 Standard dis- AUDIO Telephone* play ( page 142) ( page 142) ( page 147) ( page 149) ( page 150) ( page 151) Call up mainte- Select radio Load phone nance service station book...
Page 144: Standard Display Menu
Controls in detail Control system The headings used in the menus table are designed to facilitate navigation within the system and are not neces- sarily identical to those shown in the control system displays. The first function displayed in each menu will automatically show you which part of the system you are in.
Page 145: Press Button J Or K Repeatedly
Additional optional satellite radio equipment and a subscription to satel- lite radio service provider are required for satellite radio operation. Contact an authorized Mercedes-Benz Center for details and availability for your vehicle. For more information, refer to separate COMAND operating instructions.
Page 146 Controls in detail Control system Select CD track Turn on COMAND and select CD. Refer to separate COMAND operating in- structions. Press button è or ÿ repeatedly until the settings for the CD currently being played appear in the multifunc- tion display.
Page 147: Cd Changer Operating Mode
CD changer operating mode General notes Should excessively high temperatures oc- cur while in CD mode, CD TEMP HIGH will appear on the multifunction display and muting will take place. The unit will then switch back to the last operating mode used until the temperature has decreased to a safe operating level.
Page 148 Controls in detail Control system Warning! The CD changer is a Class 1 laser product. There is a danger of invisible laser radiation if the cover is opened or damaged. Do not remove the cover. The CD changer does not contain any parts which can be ser- viced by the user.
Page 149: Tel Menu
TEL menu* Warning! A driver’s attention to the road and traffic conditions must always be his/her primary focus when driving. For your safety and the safety of others, we recommend that you pull over to a safe location and stop before making or taking a telephone call.
Page 150 Controls in detail Control system The following functions are available: Function Page Answering a call Ending a call Dialing a number from the phone book Redialing Answering a call When your telephone is ready to receive calls, you can answer a call at any time. In the multifunction display you will then see the message: Press button s.
Page 151: Navi Menu
Press button s. Redialing The system dials the selected phone The control system stores the most recent- number. ly dialed phone numbers. This eliminates the need to search through your entire If the connection is successful, the phone book. name of the party you called and the duration of the call will appear in the multifunction display.
Page 152: Distronic* Menu
Controls in detail Control system Distronic* menu Use the Distronic menu to display the current settings for your Distronic system. What information is shown in the multi- function display depends on whether the Distronic system is active or inactive. Please refer to the “Driving systems” sec- tion of this manual ( page 209) for in- structions on how to activate Distronic.
Page 153: Trip Computer Menu
Trip computer menu Use the trip computer menu to call up sta- tistical data on your vehicle. The following information is available: Function Page Fuel consumption statistics after start Fuel consumption statistics since last reset Resetting fuel consumption sta- tistics Call up range (distance to empty) 152 Fuel consumption statistics after start Press button è...
Page 154 Controls in detail Control system Fuel consumption since last reset Press button è or ÿ repeatedly until you see the first function of the Trip computer menu. Press button j or k repeatedly until you see this message in the multi- function display: AFTER RESET 1 Distance driven since last reset...
Page 155: Vehicle Status Message Memory Menu
Mercedes-Benz Center to address the malfunction and warning messages ( page 335). Press button è or ÿ repeatedly...
Page 156: Settings Menu
Controls in detail Control system Settings menu In the SETTINGS menu there are two func- tions: The function TO RESET PRESS R BUTTON , with which you can reset FOR 3 SEC. all settings to the original factory set- tings. A collection of submenus with which you can make individual settings for your vehicle.
Page 157 Submenus in the Settings menu Press button j or k. In the multifunction display you see the collection of the submenus. Press button æ or ç. The selection marker moves to the next submenu. The submenus are arranged by hierarchy. Scroll down with the ç...
Page 158 Controls in detail Control system The table below shows what settings can be changed within the various menus. De- tailed instructions on making individual settings can be found on the following pag- INSTRUMENT CLUSTER LIGHTING Select temperature display Set daytime running lamp mode mode (USA only) Select multifunction display...
Page 159 Instrument cluster submenu Access the INST. CLUS. submenu via the SETTINGS menu. Use the INST. CLUS. sub- menu to change the instrument cluster dis- play settings. The following functions are available: Function Page Select temperature display mode Select speedometer display mode Select language Select tire inflation pressure unit 158...
Page 160 Controls in detail Control system Selecting language Move the selection marker with the æ or ç button to the INST. CLUS. submenu. Press button j or k repeatedly until you see this message in the multi- function display: LANGUAGE The selection marker is on the current setting.
Page 161 Setting daytime running lamp mode (USA only) This function is not available in coun- tries where the daytime running lamp mode is mandatory and therefore in a constant mode. Move the selection marker with the æ or ç button to the LIGHT- submenu.
Page 162 Controls in detail Control system Setting locator lighting During darkness, the following lamps will come on when the exterior lamp switch is in position U, the locator lighting fea- ture is activated and the vehicle is un- locked by remote control: Parking lamps Tail lamps License plate lamps...
Page 163 To activate night security illumination: Select delayed switch-off period (see below). Turn the exterior lamp switch to position U before turning off the en- gine. To select delayed switch-off period: Move the selection marker with the æ or ç button to the LIGHT- submenu.
Page 164 Controls in detail Control system Press button j or k repeatedly until you see this message in the multi- function display: INTERIOR LIGHTING DELAYED SWITCH-OFF The selection marker is on the current setting. Press æ or ç to select the de- sired lamp-on time period.
Page 165 Limiting opening height of trunk lid* This function is available on vehicles with the trunk lid opening/closing system*. Use this function to activate or deactivate the limiting opening height of trunk lid. Move the selection marker with the æ or ç button to VEHICLE submenu.
Page 166 Controls in detail Control system Activating easy-entry/exit feature Use this function to activate and deacti- vate the easy-entry/exit feature ( page 112). Warning! You must make sure no one can become trapped or injured by the moving steering wheel and driver’s seat when the easy-en- try/exit feature is activated.
Page 167 Setting parking position for exterior rear view mirror Use the MIRROR SETTING WHEN PARKING function to select whether the passen- ger-side exterior rear view mirror should be turned downward during parking maneu- vers when reverse gear R is engaged. For additional information, see “Activating ex- terior rear view mirror parking position”...
Page 168: Automatic Transmission
Controls in detail Automatic transmission For more information on driving with an automatic transmission see “Automatic transmission” ( page 48). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
Page 169 Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. When the gear selector lever is in position D, you can influence transmission...
Page 170: One-Touch Gearshifting
Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the gear selector lever is in position D. Downshifting Briefly press the gear selector lever to the left in the D- direction. The transmission will shift from the current gear to the next lower gear as permitted by the shift program.
Page 171: Gear Ranges
Gear ranges With the gear selector lever in position D, you can limit the transmission’s gear range by pressing the gear selector lever to the left (D-), and reverse the gear range limit by pressing the gear selector lever to the right (D+).
Page 172: Gear Selector Lever Position
Controls in detail Automatic transmission Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
Page 173 P that is not covered by the is dangerous. Also, position P alone is not Mercedes-Benz Limited Warranty. intended to or capable of preventing your vehicle from moving, possibly hitting people or objects.
Page 174: Automatic Shift Program
Controls in detail Automatic transmission Automatic shift program The program mode selector switch is located on the lower part of the center console. 1 Program mode selector switch C Comfort For comfort driving S Sport For standard driving The current gear selector lever position and the selected program mode ( ) are indicated in the tachometer display...
Page 175: Driving Tips
Driving tips Accelerator position Your driving style influences the transmission’s shifting behavior: Less throttle Earlier upshifting More throttle Later upshifting Kickdown Use kickdown when you want maximum acceleration. Press the accelerator past the point of resistance. The transmission shifts into a lower gear.
Page 176: Steering Wheel Gearshift Control (Speedshift) Cl 55 Amg And Cl 65 Amg
Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz 1 Left button: downshift Limited Warranty. 2 Right button: upshift...
Page 177 Downshifting You cannot shift with the steering wheel gearshift buttons when the gear Warning! selector lever is in position P, N or R. On slippery road surfaces, never downshift The manual program mode M will not in order to obtain braking action. This could be stored.
Page 178: Manual Shift Program Cl 55 Amg And Cl 65 Amg
This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. The program mode selector switch is located on the lower part of the center console.
Page 179 Downshifting Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehicle control. Your vehicle’s ABS will not prevent this type of loss of control. Briefly press the gear selector lever to the left in the D- direction ( page 168).
Page 180: (Limp Home Mode)
Move gear selector lever to P. Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move gear selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.
Page 181: Good Visibility
Good visibility For information on the windshield wipers, see “Windshield wipers” ( page 54). Headlamp cleaning system The switch is located on the left side of the dashboard. 1 Headlamp washer switch Switch on ignition ( page 34). Press switch 1. The headlamps are cleaned with a high-pressure water jet.
Page 182 Controls in detail Good visibility Warning! The auto-dimming function does not react if incoming light is not aimed directly at sen- sors in the interior rear view mirror. The interior rear view mirror and the exterior rear view mirror on the driver’s side do not react, for example, if the rear window sun- shade is in raised position.
Page 183: Rear View Mirrors
1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view mirror button The exterior rear view mirror returns to its previously stored driving position: ten seconds after you put the gear se- lector lever out of position R immediately once your vehicle exceeds a speed of approximately 6 mph (10 km/h)
Page 184: Windshield Wipers
Controls in detail Good visibility Switch on ignition ( page 34). Folding in Press button 2 briefly. Both mirrors fold in. Folding out Press button 1 briefly. Both mirrors fold out. If an exterior rear view mirror housing is forcibly pushed forward (hit from the rear), reposition it manually by applying firm pressure until it snaps back into place.
Page 185: Sun Visors
Sun visors The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others. For information on vanity mirrors ( page 232) Glare from the front...
Page 186: Rear Window Sunshade
Controls in detail Good visibility Rear window sunshade* The switch is located in the upper part of the front center console. 1 Rear window sunshade switch Switch on ignition ( page 34). Press switch 1 briefly to raise the sun- shade.
Page 187: Automatic Climate Control
Automatic climate control The automatic climate control is operation- al whenever the engine is running. You can operate the climate control system in ei- ther the automatic or manual mode. The system cools or heats the interior depend- ing on the selected interior temperature and the current outside temperature.
Page 188 Controls in detail Automatic climate control...
Page 189 Item 1 Left center air vent, adjustable 2 Left air vent, fixed 3 Thumbwheel for air volume control for left center air vent 4 Thumbwheel for air temperature control for center air vents 5 Thumbwheel for air volume control for right center air vent 6 Right air vent, fixed 7 Right center air vent, adjustable 8 Side defroster vent, fixed...
Page 190 Controls in detail Automatic climate control Automatic climate control panel Item 1 Windshield defroster 2 Rear window defroster 3 Display 4 Residual engine heat utilization 5 Automatic climate control on/off 6 Air distribution, right 7 AC cooling on/off 8 Right side temperature control 9 Air volume (automatic, manual) a Left side temperature control b Air recirculation...
Page 191: Setting The Temperature
Setting the temperature Use temperature controls a and 8 ( page 188) to separately adjust the air temperature on each side of the passenger compartment. You should raise or lower the temperature setting in small incre- ments, preferably starting at 72°F (22°C). Increasing/decreasing Press button a or 8 repeatedly up or down until the display shows the de-...
Page 192 Controls in detail Automatic climate control Adjusting manually Press left or right button U. The button emerges and the h, », d and c symbols become visible. Turn the marking on the regulator to the desired symbol. The air will be directed to the vents cor- responding to this symbol.
Page 193: Adjusting Air Volume
Adjusting air volume Use air volume control 9 ( page 188) for both automatic and manual air volume ad- justment. Adjusting automatically Press A on air volume switch 9 ( page 188). The display shows “ AUTO ”. The air vol- ume is adjusted automatically.
Page 194: Air Recirculation Mode
Controls in detail Automatic climate control Air recirculation mode Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside. This setting cuts off the intake of outside air and recirculates the air in the passenger compartment. Warning! When the outside temperature is below 41°F (5°C), only switch to air recirculation...
Page 195: Charcoal Filter
If you keep button , pressed, the side windows and the sliding/pop-up roof will return to their previous posi- tion. The air recirculation mode is deactivated automatically: after five minutes if the outside temper- ature is below approximately 41°F (5°C) after five minutes if the air conditioning is turned off after 30 minutes if the outside temper-...
Page 196: Rear Window Defroster
Controls in detail Automatic climate control If you keep button e pressed, the side windows and the sliding/pop-up roof will return to their previous posi- tions. The system switches automatically to the air recirculation mode if the carbon monoxide (CO) or nitrogen oxide (NO concentration of the outside air increases beyond a predetermined level, for example in a tunnel.
Page 197: Deactivating The Climate Control System
The compressor has turned itself off. The air conditioning cannot be turned on again. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center.
Page 198: Residual Heat And Ventilation
Controls in detail Automatic climate control Residual heat and ventilation With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes. This feature makes use of the residual heat produced by the engine.
Page 199: Rear Passenger Compartment Adjustable Air Vents
Switching ventilation on Open the storage compartment in front of the armrest, see “Storage compart- ment below the front armrest” ( page 234) Push upper portion of switch. Switching ventilation off Open the storage compartment in front of the armrest, see “Storage compart- ment below the front armrest”...
Page 200: Electrically Folding Exterior Power Windows
Controls in detail Power windows Opening and closing the power windows The side windows are opened and closed electrically. The switches for all side win- dows are on the driver’s door. A switch for the front passenger window is on the re- spective door.
Page 201 Do not leave children unattended in the ve- hicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause an accident and/or serious personal injury. You can also open or close the win- dows using the SmartKey, see “Sum- mer opening feature”...
Page 202: Synchronizing The Power Windows
Controls in detail Power windows Fully closing the windows (Express-close) Press switch 1 to 4 at the symbol j past the resistance point and release. The corresponding window closes com- pletely. Warning! Driver's door only: If within five seconds you again press the switch past the resistance point and re- lease, the automatic reversal will not func- tion.
Page 203: Summer Opening Feature
Summer opening feature If the weather is warm, you can ventilate the vehicle before driving off by simulta- neously: opening the side windows opening the tilt/sliding sunroof turning on the seat ventilation* for the driver’s seat The seat ventilation* for the driver’s seat is automatically set to the highest level if activated via summer opening feature.
Page 204 Controls in detail Power windows Vehicles with KEYLESS-GO*: Press and hold button ‹ or the lock button at the outside door handle ( page 60) until the side windows and the tilt/sliding sunroof are completely closed. Release button Œ or the lock button at the outside door handle to interrupt procedure.
Page 205: Power Tilt/Sliding Sunroof
Power tilt/sliding sunroof Opening and closing the power tilt/sliding sunroof The tilt/sliding sunroof can be opened and closed electrically. The switch for the tilt/sliding sunroof is on the overhead con- trol panel. 1 Push up to raise sunroof at rear 2 Pull down to lower sunroof at rear 3 Push forward to slide sunroof closed 4 Push back to slide sunroof open...
Page 206 Controls in detail Power tilt/sliding sunroof When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle.
Page 207: Synchronizing The Power Tilt/Sliding Sunroof
Canada vehicles, but deactivated for U.S. vehicles at the factory. If you wish to have it activated, contact an au- thorized Mercedes-Benz Center. To select a tilt/sliding sunroof opening position, press the sunroof switch to the resistance point and release it...
Page 208: Driving Systems
Controls in detail Driving systems The driving systems of your vehicle are de- scribed on the following pages: Cruise control and Distronic*, with which the vehicle can maintain a preset speed. ABC with vehicle level control system, with which you can change vehicle sus- pension characteristics.
Page 209 1 Sets current or higher speed 2 Sets current or lower speed 3 Cancels cruise control 4 Resumes at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift the cruise control lever in di- rection of arrow 1 or depress in direc- tion of arrow 2.
Page 210 Controls in detail Driving systems Setting a higher speed Lift cruise control lever in direction of arrow 1 and hold it up until the de- sired speed is reached. Release cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate cruise control.
Page 211: Distronic
Distronic* When activated, the Distronic adaptive cruise control system increases driving convenience afforded by the cruise control during travel on expressways and other major roads. If the Distronic distance sensor detects a slower moving vehicle directly ahead, your vehicle speed will be reduced so that you follow that vehicle at a preset distance.
Page 212 Controls in detail Driving systems Canada only: This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: This device may not cause interfer- ence, and this device must accept any inter- ference received, including interfer- ence that may cause undesired operation of the device.
Page 213 Distronic displays in the speedometer dial Set speed If Distronic is activated, one or two seg- ments come on in the mph scale around the set speed. The vehicle speed displayed on the speedometer can briefly vary from the speed setting on the Distronic system. Segments If Distronic detects a vehicle directly ahead, the segments (representing the dif-...
Page 214: Press Button È Or Ÿ Repeatedly
Controls in detail Driving systems Warning! An intermittent warning sounds and the distance warning lamp l in the instru- ment cluster is illuminated if the Distronic system calculates that the distance to the vehicle ahead and your vehicle’s current speed indicate that Distronic will not be ca- pable of slowing the vehicle sufficiently to maintain the preset following distance, which creates a danger of a collision.
Page 215 Distronic deactivated If Distronic is deactivated, you can see the standard display of Distronic in the multi- function display. 1 Vehicle ahead, if detected 2 Actual distance to vehicle ahead 3 Preset distance threshold to vehicle ahead 4 Symbol for activated distance warning function 5 Your vehicle Distronic activated...
Page 216 Controls in detail Driving systems Activating Distronic You can activate Distronic if you are driving between 25 mph (40 km/h) and 110 mph (180 km/h) the ESP is activated ( page 82) If Distronic has not been activated after pressing the cruise control lever you will see the message in the multifunction display.
Page 217 Setting a lower speed Briefly tip the cruise control lever in di- rection of arrow 2 ( page 213) to de- crease vehicle speed in increments of 5 mph (Canada: 10 km/h). The new speed is set. The stored speed is displayed in the multifunction display for approximately five seconds ( page 213), and one or two segments around the stored speed...
Page 218 Controls in detail Driving systems Deactivating Distronic There are several ways to deactivate the Distronic system: Briefly tip the cruise control lever in di- rection of arrow 3 ( page 213). Step on the brake pedal. Distronic will be deactivated. The last speed set will be stored into memory.
Page 219 The distance warning function on/off but- ton and thumbwheel for setting distance are located on the lower part of the front center console. 1 Distance warning function on/off but- 2 Thumbwheel for setting distance Increasing distance Increasing the distance setting tells Dis- tronic to maintain a greater following dis- tance to the vehicle ahead.
Page 220 Controls in detail Driving systems Warning! If the distance warning lamp l in the in- strument cluster comes on while driving and/or an intermittent warning sounds, im- mediate attention on the part of the driver is required.As required by the traffic situation, apply the brakes and navigate around a pos- sible obstacle.
Page 221 Distronic regulates only the distance be- tween your vehicle and those directly ahead of it, but does not register stationary objects in the road, e.g.: a stopped vehicle in a traffic jam a disabled vehicle an oncoming vehicle The driver must always be on the alert, ob- serve all traffic and intercede as required by steering or braking the vehicle.
Page 222 Controls in detail Driving systems Offset driving A vehicle traveling in your lane but offset from your direct line of travel may not be detected by Distronic. There will be insuffi- cient distance to the vehicle ahead. Lane changing Distronic has not yet detected the vehicle changing lanes.
Page 223: Active Body Control (Abc)
Active Body Control (ABC) The ABC system automatically selects the optimum suspension tuning and ride height for your vehicle. Suspension tuning The suspension tuning is set according to: your driving style road surface conditions the vehicle loading your choice of suspension style, “sporty”...
Page 224 Controls in detail Driving systems Vehicle level control Your vehicle automatically adjusts its ride height to reduce fuel consumption increase vehicle safety The vehicle chassis ride height is raised or lowered according to the selected level setting and to the vehicle speed: With increasing speed, ride height is re- duced by up to approximately 0.95 in (24 mm).
Page 225 The following vehicle level settings can be selected when the vehicle is stationary: Vehicle level when Use for stationary Normal level Normal operation Raised level 1 Driving with snow chains ( page 314) Raised level 2 Very rough road surface conditions Dependent on load The button with the indicator lamps is lo-...
Page 226 Controls in detail Driving systems Pressing the button twice in quick suc- cession will cause the vehicle to imme- diately raise or lower according to the starting level. The selected vehicle level setting re- mains stored in memory even if the en- gine is turned off and restarted.
Page 227: Parktronic System* (Parking Assist)
Parktronic system* (Parking assist) Warning! Parktronic is a supplemental system. It is not intended to, nor does it replace, the need for extreme care. The responsibility during parking and other critical maneuvers always rests with the driver. Special attention must be paid to objects with smooth surfaces or low silhouettes (e.g.
Page 228 Controls in detail Driving systems Range of the sensors To function properly, the sensors must be free of dirt, ice, snow and slush. Clean the sensors regularly, being careful not to scratch or damage the sensors see “Clean- ing the Parktronic* system sensors” ( page 320).
Page 229 Minimum distance Center approx. 8 in (20 cm) Corners approx. 6 in (15 cm) If the system detects an obstacle in this range, all the distance warning segments illuminate and you hear a warning signal. If the obstacle is closer than the minimum distance, the actual distance may no long- er be indicated by the system.
Page 230 Controls in detail Driving systems As your vehicle approaches an object, one or more distance segments will illuminate, depending on the distance. When the eighth distance segment illuminates, you have reached the minimum distance. Front area: An intermittent acoustic warning will sound as the first red dis- tance segment illuminates and a con- stant acoustic warning lasting a maximum of two seconds will sound for...
Page 231 20 seconds and the indicator lamp in the Parktronic switch comes on. Have the Parktronic system checked by an authorized Mercedes-Benz Cen- ter as soon as possible. If only the red distance segments illumi- nate and no acoustic warning sounds, the...
Page 232: Loading
Controls in detail Loading Roof rack* Warning! Use only roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Preparing roof rack installation Open trim at the trim strips in the roof.
Page 233: Loading Instructions
Loading instructions The total load weight including vehicle oc- cupants and luggage/cargo should not ex- ceed the load limit or vehicle capacity weight as indicated on the corresponding placard located on the driver’s door B-pil- lar. Warning! Always fasten items being carried as secure- ly as possible.
Page 234: Useful Features
Controls in detail Useful features Sun visor Vanity mirror in the sun visor Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others. 1 Mirror lamp 2 Mirror cover 3 Document holder...
Page 235: Storage Compartments
Storage compartments Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the trunk if possible. Do not pile luggage or cargo higher than the seat backs.
Page 236 Controls in detail Useful features Storage compartment in the glove box A storage compartment is located in the cover of the glove box. It can be used to store check cards, pens, a flashlight, etc. 1 Storage compartment in glove box Lightly press the marking on the lid of storage compartment 1.
Page 237 Opening storage compartment Press button 1 and lift the armrest. The storage compartment can be heat- ed or cooled. The compartment can get very warm due to its confined space. When storing heat-sensitive objects in the compart- ment, close the air vent ( page 196) while heating the passenger compart- ment.
Page 238 Controls in detail Useful features Storage compartments under the front seats 1 Lid 2 Buttons Opening Press buttons 2 together and fold lid 1 down. Closing Close lid 1 until both buttons 2 of lock engage. Cup holder in front of seat armrest Warning! In order to help prevent spilling liquids on vehicle occupants, only use containers that...
Page 239 2 Button for folding out the second cup holder Push button 2. The second cup holder folds out in the direction indicated by the arrow. Folding in cup holder 3 Fold in the second cup holder Press the second cup holder in the di- rection of arrow 3 until it engages.
Page 240 Controls in detail Useful features Cup holder in rear seat armrest Warning! In order to help prevent spilling liquids on vehicle occupants, only use containers that fit into the cup holder. Use lids on open con- tainers and do not fill containers to a height where the contents, especially hot liquids, could spill during braking, vehicle maneu- vers, or in an accident.
Page 241: Ashtrays
Parcel net in trunk You can hang a parcel net in the trunk. The hooks and the parcel net in the trunk can hold a load of up to 29.8 lbs (13.5 kg). 1 Hook Hang the parcel net on hooks 1 on the left and right sides of the trunk.
Page 242: Cigarette Lighter
Controls in detail Useful features Rear seat ashtray 1 Latch Opening ashtray Pull at top of cover to open ashtray. Removing ashtray insert Pull latch 1 to disengage ashtray in- sert and remove it. Reinstalling the ashtray insert Install ashtray insert. Close the ashtray.
Page 243: Heated Steering Wheel
Heated steering wheel* The steering wheel heating warms up the leather area of the steering wheel. The stalk with the heated steering wheel switch is on the lower left-hand side of the steering wheel. 1 Switching on 2 Indicator lamp 3 Switching off Switching on Switch on ignition ( page 34).
Page 244: Telephone
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.
Page 245: Tele Aid
Tele Aid The initial activation of the Tele Aid sys- tem may only be performed by com- pleting the subscriber agreement and placing an acquaintance call using the Information button ¡. Failure to complete either of these steps will re- sult in a system that is not activated.
Page 246 If a malfunction is indicated as outlined above, the system may not operate as ex- pected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible. Emergency calls An emergency call is initiated...
Page 247 A voice connection between the Response Center and the occupants of the vehicle will be established automatically soon af- ter the emergency call has been initiated. The Response Center will attempt to deter- mine more precisely the nature of the acci- dent provided they can speak to an occupant of the vehicle.
Page 248: Information Button
2 Roadside Assistance button • Roadside Assistance button • Press and hold the button • (for longer than two seconds). A call to a Mercedes-Benz Roadside As- sistance dispatcher will be initiated. The button will flash while the call is in progress. The message...
Page 249 The Mercedes-Benz Roadside Assistance dispatcher will either dispatch a qualified Mercedes-Benz technician or arrange to tow your vehicle to the nearest authorized Mercedes-Benz Center. For services such as labor and/or towing, charges may ap- ply. Refer to the Roadside Assistance Man- ual for more information.
Page 250 Tele Aid system has detected a fault or the service is not currently ac- tive, and may not initiate a call. Visit an Mercedes-Benz Center and have the system checked or contact the Re- sponse Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Cana- da) as soon as possible.
Page 251 If the indicator lamp continues to flash or the system does not reset, contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada), or Mercedes-Benz Customer Assistance at 1-800-FOR-MERCedes (1-800-367-6372) in the USA or Customer Service at 1-800-387-0100 in Canada.
Page 252 In case you have locked your vehicle unin- tentionally (e.g. SmartKey inside vehicle), and the reserve SmartKey is not handy: Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
Page 253: Garage Door Opener
Garage door opener The built-in remote control is capable of operating up to three separately controlled devices, for example garage door openers, gate openers, or other devices compatible ® with HomeLink or some other systems. You can program the signal transmitter buttons.
Page 254 If you should experience diffi- culties with programming the transmit- ter, contact an authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 255 Programming or reprogramming the in- tegrated remote control Step 1: Switch on ignition ( page 34). Step 2: If you have previously programmed an integrated signal transmitter button and wish to retain its programming, proceed to step 3. Otherwise, press and hold the two outer signal transmit- ter buttons 2 and 4 and release them only when the indicator lamp 1...
Page 256 Controls in detail Useful features If the indicator lamp 1 flashes rapidly for about two seconds and then turns to a constant light, continue with pro- gramming steps 8 through 12 as your garage door opener may be equipped with the “rolling code feature”. Step 7: To program the remaining two buttons, repeat the steps above starting with...
Page 257 Step 12: Confirm the garage door operation by pressing the programmed integrated signal transmitter button (2, 3 or 4). Step 13: To program the remaining two buttons, repeat the steps above starting with step 3. Gate operator/Canadian programming Canadian radio-frequency laws require transmitter signals to “time-out”...
Page 258: Infrared Reflecting Windshield
Controls in detail Useful features Reprogramming a single integrated sig- nal transmitter button To program a device using a signal trans- mitter button previously trained, follow these steps: Press and hold the desired signal trans- mitter button (2, 3 or 4). Do not re- lease the button.
Page 259: Operation
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Page 260: The First 1000 Miles (1500 Km)
Operation The first 1000 miles (1500 km) In the “Operation” section you will find de- tailed information on operating, maintain- ing and caring for your vehicle. The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but...
Page 261: Driving Instructions
Booklet and as required by the Maintenance System (U.S. vehicles) or FSS (Canada vehicles). Contact an au- thorized Mercedes-Benz Center. Fuel consumption is also increased by driv- ing in cold weather, in stop-and-go traffic, on short trips, and in hilly area.
Page 262: Brakes
Have the brake system inspected immedi- ately. Contact an authorized Mercedes-Benz Center. All checks and service work on the brake system should be carried out by qualified technicians only. Contact an authorized Mercedes-Benz Center. Only install brake pads and brake fluid recommended by Mercedes-Benz.
Page 263 Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired. This could result in an accident. When driving down long and steep grades, relieve the load on the brakes by shifting into a lower gear to use the...
Page 264: Driving Off
ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the acceler- ator pedal and applying the brake re- duces engine performance and causes premature brake and drivetrain wear.
Page 265: Tires
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for re- pairs. Treadwear indicators (TWI) are required by law. These indicators are located in six...
Page 266: Tire Traction
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.
Page 267: Winter Driving Instructions
CL 500 Your vehicle is factory equipped with “H”-rated tires, which have a speed rating of 130 mph (210 km/h). An electronic speed limiter prevents your vehicle from exceeding a speed of 130 mph (210 km/h). CL 600 Your vehicle is factory equipped with “Y”-rated tires, which have a speed rating of 186 mph (300 km/h).
Page 268: Standing Water
Any such dam- age is not covered by the Mercedes-Benz Limited Warranty.
Page 269: Passenger Compartment
The trunk is the preferred place to carry ob- jects. Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from an authorized Mercedes-Benz Center.
Page 270: Catalytic Converter
Operation Driving instructions Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial con- trol of the pollutants in the exhaust emis- sions. Keep your vehicle in proper...
Page 271: Coolant Temperature
The engine should not be operated with the coolant temperature over 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty. Operation Driving instructions Warning! Driving when your engine is badly over-...
Page 272: At The Gas Station
Operation At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extin- guish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! The fuel filler flap is located on the right-hand side of the vehicle towards the...
Page 273: Check Regularly And Before A Long Trip
Warning! Overfilling of the fuel tank may create pres- sure in the system which could cause a gas discharge. This could cause the gas to spray back out when removing the fuel pump noz- zle, which could cause personal injury. Replace the fuel cap by turning it to the right.
Page 274 Notify an authorized Mercedes-Benz Center immediately. Do not add brake fluid as this will not solve the problem. For more information, see “Practical hints”...
Page 275: Engine Compartment
Engine compartment Hood Warning! Do not pull the release lever while the vehi- cle is in motion. Otherwise the hood could be forced open by passing air flow. Opening The hood lock release lever is located in the driver’s footwell to the left of the park- ing brake pedal.
Page 276: Engine Oil
Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz may cause damage not covered by the Mer- cedes-Benz Limited Warranty. More information on this subject is available at any Mercedes-Benz Center.
Page 277 Checking the engine oil level with the control system When checking the oil level the vehicle must be parked on level ground with the engine at operating tempera- ture, the vehicle must have been sta- tionary for at least five minutes with the engine turned off with the engine not at operating tem- perature yet, the vehicle must have...
Page 278 Excess oil must be siphoned or drained off. It could cause damage to the en- gine and catalytic converter not cov- ered by the Mercedes-Benz Limited Warranty. Perform the engine oil level check with the dipstick (CL 500, and CL 55 AMG only) if it cannot be completed with the control system.
Page 279 Checking the engine oil level with the oil dipstick (CL 500, CL 55 AMG only) When checking the oil level the vehicle must be parked on level ground with the engine at operating tempera- ture, the vehicle must have been sta- tionary for at least five minutes with the engine turned off The engine oil level can be checked by...
Page 280 Maintenance System (U.S. vehicles) or FSS (Canada Vehi- cles) will result in engine damage not covered by the Mercedes-Benz Limited Warranty. CL 500, CL 55 AMG 1 Oil dipstick 2 Filler cap Unscrew filler cap 2 from filler neck.
Page 281: Transmission Fluid Level
Excess oil must be siphoned or drained off. It could cause damage to the en- gine and catalytic converter not cov- ered by the Mercedes-Benz Limited Warranty. Screw filler cap 1 back on filler neck. For more information on engine oil, see the “Technical data”...
Page 282 Operation Engine compartment Warning! In order to avoid any possibly serious burns: Use extreme caution when opening the hood if there are any signs of steam or coolant leaking from the cooling system, or if the coolant temperature gauge indi- cates that the coolant is overheated.
Page 283: Battery
When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.
Page 284: Windshield Washer System And Headlamp Cleaning System
Operation Engine compartment Windshield washer system and headlamp cleaning system The windshield washer reservoir is located in the engine compartment. 1 Washer fluid reservoir Fluid for the windshield washer system and the headlamp cleaning system is supplied from the windshield washer reservoir. It has a capacity of approx.
Page 285: Tires And Wheels
When replacing rims, only use genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can result in the bolts loosening and possibly an accident.
Page 286: Tire Care And Maintenance
Operation Tires and wheels Tire care and maintenance Warning! Regularly check the tires for damage. Dam- aged tires can cause tire inflation pressure loss. As a result, you could lose control of your vehicle. Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage, replace them.
Page 287 Tread depth Do not allow your tires to wear down too far. Adhesion properties on wet roads are sharply reduced at tread depths under in (3 mm). Tread wear indicators (TWI) are required by law. These indicators are located in six places on the tread circumference and become visible at a tread depth of approx- imately...
Page 288: Direction Of Rotation
Operation Tires and wheels Direction of rotation Unidirectional tires offer added advan- tages, such as better hydroplaning perfor- mance. To benefit, however, you must make sure the tires rotate in the direction specified. An arrow on the sidewall indicates the intended direction of rotation (spinning) of the tire.
Page 289 1 Driver’s door B-pillar Following is a discussion on how to work with the information contained on the two placards with regards to loading your vehi- cle. Tire and Loading Information Warning! Do not overload the tires by exceeding the specified load limit or vehicle capacity weight as indicated on the placard on the driver’s door B-pillar.
Page 290 Operation Tires and wheels Placard (Example B) 1 Load limit information on the Vehicle Tire Information placard The placard showing the load limit informa- tion is located on the driver’s door B-pillar. If your vehicle is equipped with the Vehicle Tire Information placard (Example B), locate the heading “Vehicle Capacity Weight”...
Page 291 Steps for determining correct load limit The following steps have been developed as required of all manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Step 1 (Vehicles equipped with placard Example A) Locate the statement “The combined weight of occupants and cargo should...
Page 292 Operation Tires and wheels Example Combined Number of Seating weight limit occupants configura- of occu- (driver and tion pants and passengers) cargo from placard 1500 lbs front: 2 rear: 3 1500 lbs front: 1 rear: 2 1500 lbs front:1 The higher the weight of all occupants, the less cargo and luggage load capacity is available.
Page 293 The tongue load typically is ten percent of the trailer weight and every- thing loaded in it. Your Mercedes-Benz has been designed primarily to carry passengers and their cargo. Mercedes-Benz does not recom- mend trailer towing with your vehicle.
Page 294: Recommended Tire Inflation Pressure
Operation Tires and wheels Recommended tire inflation pressure Warning! Follow recommended tire inflation pressures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, adversely affect handling and fuel economy, and are more likely to fail from being over- heated. Do not overinflate tires.
Page 295 Placard (Example B) 1 Vehicle Tire Information placard with recommended cold tire inflation pressures Placard (Example B) lists the recommend- ed cold tire inflation pressures for maxi- mum loaded vehicle weight. The tire inflation pressures listed apply to the tires installed as original equipment.
Page 296: Checking Tire Inflation Pressure
Operation Tires and wheels Checking tire inflation pressure Regularly check your tire inflation pressure at least once a month. Check and adjust the tire inflation pressure when the tires are cold. The tires can be considered cold if the vehicle has been parked for at least three hours or driven less than one mile (1.6 km).
Page 297: Press Button J Or K Repeatedly
After you have reactivated the tire infla- tion pressure monitor, the current tire inflation pressures will only be shown after a few minutes’ driving time. During this time, you will see the follow- ing message in the multifunction dis- play: TIRE PRES.
Page 298 Operation Tires and wheels The recommended tire inflation pres- sures for your vehicle can be found on the tire placard located on the driver’s door B-pillar. The tire inflation pres- sures are not listed in the owner’s man- ual. Warning! The tire inflation pressure monitor does not indicate a warning for wrongly selected tire inflation pressures.
Page 299 Reactivating the tire inflation pressure monitor The tire inflation pressure monitor must be reactivated in the following situations: If you have changed the tire inflation pressure If you have replaced the wheels or tires If you have installed new wheels or tires Using the tire placard on the driver’s door B-pillar or, if available, the inside...
Page 300 Operation Tires and wheels If you wish to cancel activation: Press the ç button. If one of the following messages appears in the multifunction display: TIRE PRES. MONITOR REACTIVATE AFTER CORRECTING PRESSURE TIRE PRESSURE PLEASE CORRECT Check the tire inflation pressures and correct them if necessary.
Page 301: Tire Labeling
Tire labeling Besides tire name (sales designation) and manufacturer name, a number of markings can be found on a tire. Following are some explanations for the markings on your vehicle's tires: 1 Uniform Quality Grading Standards ( page 306) 2 DOT, Tire Identification Number (TIN) ( page 304) 3 Maximum tire load ( page 305) 4 Maximum tire inflation pressure...
Page 302 Operation Tires and wheels General: Depending on the design standards used, the tire size molded into the sidewall may have no letter or a letter preceding the tire size designation. No letter preceding the size designation (as illustrated above): Passenger car tire based on European design standards.
Page 303 Warning The tire load rating must always be at least half of the GAWR ( page 309) of your vehi- cle. Otherwise, tire failure may be the result which may cause an accident and/or seri- ous personal injury to you or others. Always replace rims and tires with the same designation, manufacturer and type as shown on the original part.
Page 304 Operation Tires and wheels Summer tires Index Speed rating up to 100 mph (160 km/h) up to 106 mph (170 km/h) up to 112 mph (180 km/h) up to 118 mph (190 km/h) up to 130 mph (210 km/h) up to 149 mph (240 km/h) up to 168 mph (270 km/h) up to 186 mph (300 km/h) above 186 mph (300 km/h)
Page 305: Load Identification
All-season and winter tires Index Speed rating Q M+S up to 100 mph (160 km/h) T M+S up to 118 mph (190 km/h) H M+S up to 130 mph (210 km/h) V M+S up to 149 mph (240 km/h) The marking “M+S” next to the service description designates tires with mud and snow capabilities.
Page 306: Dot, Tire Identification Number (Tin)
Operation Tires and wheels DOT, Tire Identification Number (TIN) U.S. tire regulations require each new tire manufacturer or tire retreader to mold a TIN into or onto a sidewall of each tire produced. The TIN is a unique identifier which facili- tates efforts by tire manufactures to notify purchasers in recall situations or other safety matters concerning tires and gives...
Page 307: Maximum Tire Load
Tire type code The code 4 ( page 304) may, at the option of the manufacturer, be used as a descriptive code for identifying significant characteristics of the tire. Date of manufacture The date of manufacture 5 ( page 304) identifies the week and year of manufac- ture.
Page 308: Maximum Tire Inflation Pressure
Operation Tires and wheels Maximum tire inflation pressure 1 Maximum permissible tire inflation pressure For illustration purposes only. Actual data on tires is specific to each vehicle and may vary from data shown in above illustration. This is the maximum permissible tire inflation pressure for the tire.
Page 309 Quality grades can be found, where appli- cable, on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear Traction Temperature All passenger car tires must conform to federal safety requirements in addition to these grades. Treadwear The treadwear grade is a comparative rat- ing based on the wear rate of the tire when tested under controlled conditions on a...
Page 310: Tire Ply Material
Operation Tires and wheels Temperature The temperature grades are A (the high- est), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 311: Tire And Loading Terminology
Tire and loading terminology Accessory weight The combined weight (in excess of those standard items which may be replaced) of automatic transmission, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment (whether installed or not).
Page 312 Operation Tires and wheels GVWR (Gross Vehicle Weight Rating) This is the maximum permissible vehicle weight of the fully loaded vehicle (weight of the vehicle including all options, passen- gers, fuel, and cargo and, if applicable, trailer tongue load). It is indicated on Certification label located on the driver's door B-pillar.
Page 313 TIN (Tire Identification Number) Unique identifier which facilitates efforts by tire manufacturers to notify purchasers in recall situations or other safety matters concerning tires and gives purchases the means to easily identify such tires. The TIN is comprised of “Manufacturer's identifica- tion mark”, “Tire size”, “Tire type code”...
Page 314: Rotating Tires
Wheels could become loose if not tightened with a torque of 110 lb-ft (150 Nm). Only use genuine Mercedes-Benz wheel bolts specified for your vehicle's rims. For information on wheel change, see the “Practical hints” section ( page 381).
Page 315: Winter Driving
Winter driving Before the onset of winter, have your vehicle winterized at an authorized Mercedes-Benz Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system. Add MB Concentrate “S”...
Page 316: Block Heater (Canada Only)
Snow chains should only be used on the rear wheels. Follow the manufac- turer's mounting instructions. Only use snow chains that are approved by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Use of snow chains may be prohibited depending on location.
Page 317: Maintenance
Maintenance We strongly recommend that you have your vehicle serviced by an authorized Mercedes-Benz Center, in accordance with the Maintenance Booklet at the times called for by the maintenance service indi- cator display. Failure to have the vehicle maintained in...
Page 318: Maintenance Service Term Exceeded
'A' SERVICE EXCEEDED BY XXX DAYS 'A' SERVICE EXCEEDED BY X DAY In addition, a signal sounds when the mes- sage appears. Any authorized Mercedes-Benz Center will reset the maintenance service indicator following a completed maintenance ser- vice. Calling up the maintenance service in- dicator Switch on ignition ( page 34).
Page 319: Vehicle Care
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others ap- plied later.
Page 320 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at an authorized Mercedes-Benz Center. Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here.
Page 321 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Only use a mild car wash detergent, such as Mercedes-Benz ap- proved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 322 1 Parktronic system sensors Clean the sensors 1 on the bumpers using a mild car wash detergent, such as Mercedes-Benz approved Car Sham- poo, with plenty of water and a soft, non-scratchy cloth. When using a steam cleaner or power...
Page 323 Warning! For safety reasons, switch off wipers and re- move SmartKey from starter switch (vehi- cles with KEYLESS-GO*: Make sure the vehicle's on-board electronics have status 0) before cleaning the wiper blades. Other- wise, the wiper motor could suddenly turn on and cause injury.
Page 324 If possible, clean wheels once a week with Mercedes-Benz approved Wheel Care, us- ing a soft bristle brush and a strong spray of water. Follow the instructions on container.
Page 325 Carefully dab nubuck leather upholstery with a dry microfiber cloth to remove oil stains. Do not use Mercedes-Benz approved Leather Care or any solvents to clean nubuck leather upholstery. Avoid hard scrubbing on nubuck leath- er upholstery.
Page 327: Practical Hints
Practical hints What to do if …? Where will I find...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing SmartKey batteries Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Page 328: What To Do If
Read and observe messages in the mul- tifunction display ( page 335). Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increas- es the risk of an accident.
Page 329 Practical hints What to do if …? Suggested solution Release the parking brake ( page 50). Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem.
Page 330 Your fuel tank is empty. Suggested solution Have the vehicle checked as soon as possible by an authorized Mercedes-Benz Center. An on-board diagnostic connector is used by the service station to link the vehicle to the shop diagnostics system. It allows the accurate identification of system malfunctions through the read- out of diagnostic trouble codes.
Page 331 Check the fuel cap ( page 270). If it is not closed properly: Close the fuel cap. If it is closed properly: Have the fuel system checked by an au- thorized Mercedes-Benz Center. Refuel at the next gas station ( page 270).
Page 332 Practical hints What to do if …? Problem Only vehicles with Distronic*: The red distance warning lamp comes on while driving. Only vehicles with Distronic*: The red distance warning lamp comes on while driving and you hear a warning sound. The yellow ESP warning lamp flashes while driving.
Page 333 Adapt your speed and driving to the pre- vailing road and weather conditions. If the ESP cannot be switched back on, have the system checked at an authorized Mercedes-Benz Center as soon as possible. Fasten your seat belt. The warning lamp goes out.
Page 334 Practical hints What to do if …? Problem The yellow warning lamp for the tire inflation pressure monitor comes on. Warning! When the tire inflation pressure monitoring system warning light is lit, one or more of your tires is significantly under-inflated. You should stop and check your tires as soon as possible, and inflate them to the proper pressure as indicated on the vehicle’s tire in-...
Page 335 SRS may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 336: Lamp In Center Console
The system is malfunctioning. The system is malfunctioning. Have the system checked as soon as possible by an authorized Mercedes-Benz Center. Make sure there is nothing between seat cushion and child seat and check installation of the child seat.
Page 337: Vehicle Status Messages In The Multifunction Display
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property dam- age or personal injury. Warning!
Page 338 Practical hints What to do if …? Switching on the ignition causes all in- strument cluster lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless acti- vated) as well as the multifunction dis- play to come on. Make sure the lamps and multifunction display are in work- ing order before starting your journey.
Page 339 What to do if …? Possible solution Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz center as soon as possible. Stop your vehicle as soon as it is safe to do Press the vehicle level control button to se- lect level 2 ( page 223).
Page 340 CHANGE CARTRIDGE VISIT WORKSHOP Possible solution Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz center as soon as possible. Continue driving with added caution. Wheels may lock during hard braking, reducing steer- ing capability.
Page 341 Try activating Distronic* again later. Clean the Distronic* cover in the radiator grille ( page 320). Restart the vehicle. Visit an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible.
Page 342 ESP. If the ESP message does not go out: Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident.
Page 343 Display Possible cause MOVE SELECTOR LEVER You have tried to turn off the engine with TO PARK the KEYLESS-GO* start/stop button ( page 35) with the gear selector lever not in P. Practical hints What to do if …? Possible solution Place the gear selector lever in position P.
Page 344 Notify an authorized Mercedes-Benz Center. Drive immediately to the nearest autho- rized Mercedes-Benz Center. Adjust driv- ing to be consistent with reduced braking responsiveness. Release the parking brake ( page 50).
Page 345 What to do if …? Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and no- tify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. Brake pad thickness must be visually...
Page 346 Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without a sufficient amount of coolant in the cooling sys- tem.
Page 347 The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Practical hints What to do if …? Stop the vehicle and turn off the engine.
Page 348 Do not continue to drive. Otherwise the engine will overheat due to an inoperative water pump which may result in damage to the engine. Notify an authorized Mercedes-Benz Cen- ter. Restart the engine only after the message disappears from the multifunction dis- play.
Page 349 Observe the coolant temperature display. Have the fan replaced as soon as possi- ble. Have cruise control or Distronic* checked by an authorized Mercedes-Benz Center. Continue driving with added caution. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 350 Practical hints What to do if …? Display USA only: ADD 1.0 QT. OIL AT FILLING STATION Canada only: ADD 1.0 LITER OIL AT FILLING STATION ENGINE OIL LEVEL STOP, ENGINE OFF ENGINE OIL LEVEL REDUCE OIL LEVEL Possible cause Possible solution The engine oil level is too low.
Page 351 Have the measuring system checked by an authorized Mercedes-Benz Center. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
Page 352 The message will disappear. Close the hood ( page 274). Remove the SmartKey from the ignition. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Remove the SmartKey from the starter switch. Replace the battery ( page 371).
Page 353 Take the SmartKey with KEYLESS-GO* out of the vehicle. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Fold back and push the seat backrest un- til the seat cushion and seat backrest au- dibly engage into the driving position.
Page 354 The left license plate lamp is malfunction- ing. The right license plate lamp is malfunc- tioning. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 355 In the control system, set lamp operation to manual ( page 157). Switch on headlamps using the exterior lamp switch. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 356 Practical hints What to do if …? Display REAR FOGLIGHT CHECK LIGHT REVERSE LIGHT, LEFT CHECK LIGHT REVERSE LIGHT, RIGHT CHECK LIGHT STANDING LIGHT, L CHECK LIGHT STANDING LIGHT, R CHECK LIGHT STANDING LIGHT, L SUBSTITUTE LAMP ON! STANDING LIGHT, R SUBSTITUTE LAMP ON! TAIL LIGHT, LEFT SUBSTITUTE LAMP ON!
Page 357 Replace the bulb as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 358 This display appears if button t or s on the multifunction steering wheel is pressed and the vehicle is not equipped with a telephone. Visit an authorized Mercedes-Benz Center as soon as possible. Close the tilt/sliding sunroof ( page 203).
Page 359 Practical hints What to do if …? Check the fuel cap ( page 270). Close the fuel cap. Have the fuel system checked by an au- thorized Mercedes-Benz Center. Close the trunk lid. Add washer fluid ( page 282).
Page 360 Observe the traffic situation around Change the damaged wheel ( page 381). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Check and correct tire inflation pressure as required ( page 294).
Page 361 Observe the traffic situation around you. Change the wheel ( page 381). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check and correct the tire inflation pres- sure ( page 294).
Page 362 Observe the traffic situation around you. Change the wheel ( page 381). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check and correct the tire inflation pres- sure ( page 294).
Page 363 Observe the traffic situation around you. Change the wheel ( page 381). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check and correct the tire inflation pres- sure ( page 294).
Page 364 Observe the traffic situation around you. Change the wheel ( page 381). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check and correct the tire inflation pres- sure ( page 294).
Page 365 Display Possible cause TIRE PRES. MONITOR There was a tire inflation pressure warning REACTIVE AFTER message. CORRECTING PRESSURE The yellow warning lamp for the tire infla- tion pressure monitor comes on and you have not reactivated the system since the last tire inflation pressure check.
Page 366 As soon as the causes of the malfunction have been removed, the tire inflation pressure moni- tor automatically becomes active again. Have the tire inflation pressure monitor checked by an authorized Mercedes-Benz Center. Have the wheels checked. You may lose control of the vehicle. Contin- ued driving with a flat tire will cause exces- sive heat build-up and possibly a fire.
Page 367: Where Will I Find
Where will I find...? First aid kit The first aid kit is stored in the rear center armrest. 1 Arm rest 2 Lid Fold rear arm rest down 1. Press handle upwards. Fold lid 2 up. Remove first aid kit. Check expiration dates and contents for completeness at least once a year and replace missing/expired items.
Page 368 Practical hints Where will I find...? Vehicle jack To prepare the vehicle jack for use Remove the vehicle jack from the spare wheel well under the trunk floor. Push the crank handle up. Turn the crank handle clockwise until it engages (operational position).
Page 369: Unlocking/Locking In An Emergency
Unlocking/locking in an emergency Unlocking the vehicle If you are unable to unlock the vehicle with the SmartKey or KEYLESS-GO*, open the driver’s door and the trunk using the me- chanical key. Unlocking the driver’s door and/or the trunk with the mechanical key will trig- ger the anti-theft alarm system.
Page 370: Locking The Vehicle
Practical hints Unlocking/locking in an emergency Unlocking the trunk A minimum height clearance of 6.3 ft (1.90 m) is required to open the trunk lid. The trunk lid lock is located next to the handle above the rear license plate recess. 1 Unlocking and opening 2 Trunk lid lock Insert the mechanical key into the...
Page 371: Fuel Filler Flap
Fuel filler flap In case the central locking system does not release the fuel filler flap, you can open it manually. 1 Release knob Open the trunk. Remove the battery cover and the trim inside the trunk on the right-hand side. Pull release knob 1 in the direction of arrow.
Page 372: Opening/Closing In An Emergency
Practical hints Opening/closing in an emergency Tilt/sliding sunroof You can open or close the tilt/sliding sun- roof manually should an electrical malfunc- tion occur. The tilt/sliding sunroof drive is located be- hind the lens of the interior overhead light. 1 Lens Pry off lens 1 using a flat blade srew- driver ( page 365).
Page 373: Replacing Smartkey Batteries
SmartKey with KEYLESS-GO* are dis- charged, the vehicle can no longer be locked or unlocked. It is recommended to have the batteries replaced at an autho- rized Mercedes-Benz Center. Warning! Batteries contain poisonous and corrosive substances. Therefore keep the batteries out of reach of children.
Page 374: Smartkey With Keyless-Go
When inserting the battery, make sure they are clean and free of lint. The required replacement battery is available at any authorized Mercedes-Benz Center. Remove mechanical key out of the SmartKey ( page 367). Replacement battery: Lithium, type CR 2025 or equivalent.
Page 375: Replacing Bulbs
Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See your autho- rized Mercedes-Benz Center for headlamp adjustment. If the headlamps or front fog lamps are fogged up on the inside as a result of...
Page 376: Bulbs
7 Low beam and high Xenon beam lamp D2S-35 W Bi-Xenon headlamps: For safety reasons (high volt- age), do not replace the Xenon bulb yourself. See your authorized Mercedes-Benz Center. Rear lamps Lamp Type 8 High mounted brake lamp 9 Brake lamp...
Page 377 Only use 12 volt bulbs of the same type Have the LEDs and bulbs for the following and with the specified watt rating. lamps replaced by an authorized Mercedes-Benz Center. Switch lights off before changing a bulb to prevent short circuits. Always use a clean lint-free cloth when handling bulbs.
Page 378: Replacing Bulbs For Front Lamps
Practical hints Replacing bulbs Replacing bulbs for front lamps Before you start to replace a bulb for a front lamp, do the following first: Turn the exterior lamp switch to M ( page 52). Open the hood ( page 273) (except for side marker lamps).
Page 379: Replacing Bulbs For Rear Lamps
High beam flasher bulb Press ends of housing cover 1 tab to- gether and remove cover. Press connector 2 downward. Remove connector 2 with the bulb. Insert the new bulb so that the base lo- cates in the recess on the holder. From below, press connector 2 with bulb upward onto the reflector.
Page 380 Practical hints Replacing bulbs Tail lamp assemblies 1 Black socket: Backup lamp 2 White socket: Turn signal lamp 3 Red socket: Tail, standing and parking lamp 4 Red socket: Driver’s side: tail, parking and rear fog lamp Passenger’s side: tail and parking lamp Turn lock counterclockwise and move License plate lamp the trim to the side.
Page 381: Replacing Wiper Blades
Replacing wiper blades To avoid damage to the hood, the wiper arms should only be folded forward when in the vertical position. Wiper blades in vertical position Removing wiper blades Turn SmartKey in starter switch to position 1. Turn combination switch to wiper setting II ( page 54).
Page 382: Installing Wiper Blades
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
Page 383: Flat Tire
Flat tire Preparing the vehicle Park the vehicle as far as possible from moving traffic on a hard surface. Turn on the hazard warning flashers. Turn the steering wheel so that the front wheels are in a straight ahead position. Set the parking brake.
Page 384 Practical hints Flat tire The dimensions of the spare wheel are dif- ferent from those of the road wheels. As a result, the vehicle handling characteristics change when driving with a mounted spare wheel. Adapt your driving style accordingly. Preparing the vehicle Take vehicle tool kit tray and vehicle jack out of trunk.
Page 385 1 Jack support tube cover Move cover 1 toward rear by pressing at point indicated by arrow. Remove cover 1 carefully to avoid damage to the locking tabs. 1 Jack arm 2 Jack support tube hole 3 Crank Insert jack arm 1 fully into tube hole 2 up to the stop.
Page 386 Damaged wheel hub threads should be re- paired immediately. Do not continue to drive under these circumstances! Contact an au- thorized Mercedes-Benz Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
Page 387 1 - 5 Wheel bolts Tighten the five wheel bolts evenly, fol- lowing the diagonal sequence illustrat- ed (1 to 5), until all bolts are tight. Observe a tightening torque of 110 lb-ft (150 Nm). Warning! Have the tightening torque checked after changing a wheel.
Page 388: Battery
Otherwise the alternator and other electronic components could be se- verely damaged. Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Maintenance Booklet for main- tenance intervals or contact your au- thorized Mercedes-Benz Center for further information.
Page 389: Disconnecting The Battery
3 Negative terminal 4 Cover over positive terminal Disconnecting the battery Turn off all electrical consumers. Open the trunk ( page 101). Use a 10 mm open-end wrench to dis- connect the battery negative lead 3. Remove cover 4 from the positive ter- minal.
Page 390: Reconnecting The Battery
Practical hints Battery Reconnecting the battery Turn off all electrical consumers. Connect the positive lead and fasten its cover 4. Connect negative lead 3. Never invert the terminal connections. The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.
Page 391: Jump Starting
Only use 12 volt battery to jump start your vehicle. Jump starting with a more powerful battery could damage the ve- hicle’s electrical system, which will not be covered by the Mercedes-Benz Lim- ited Warranty. Only use jumper cables with sufficient cross-section and insulated terminal clamps.
Page 392 Do not turn on the lights under any circumstances. Remove the jumper cables first from negative terminals 2 and 4 and then from positive terminals 1 and 3. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center.
Page 393: Towing The Vehicle
Towing the vehicle Mercedes-Benz recommends that the vehi- cle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is pref- erable to other types of towing. Use flatbed or wheel lift/dolly equip- ment with SmartKey in starter switch turned to position 0.
Page 394: Towing The Vehicle
Practical hints Towing the vehicle To be certain to avoid a possibility of damage to the drive train, however, we recommend the drive shaft be discon- nected at the rear axle drive flange for any towing beyond a short tow to a nearby garage.
Page 395: Installing Towing Eye Bolt
Installing towing eye bolt When towing the vehicle with all wheels on the ground, please note the follow- ing: With the automatic central locking acti- vated and the SmartKey in starter switch position 2, or KEYLESS-GO* start/stop button ( page 35) in position 2, the vehicle doors lock if the left front wheel as well as the right rear wheel are turning at vehicle speeds of...
Page 396: Fuses
Fuse chart. Spare fuses Special fuse extractor Warning! Only use fuses approved by Mercedes-Benz and which have the specified amperage. Us- ing other fuses may cause an overload and lead to a fire, or cause damage to electrical components and/or systems.
Page 397: Fuse Boxes In Passenger Compartment
Fuse boxes in passenger compartment There are two fuse boxes. One fuse box is located in the dashboard on the front pas- senger side. An additional fuse box is lo- cated under the right rear seat. Fuse box in dashboard 1 Cover Do not use sharp objects such as a screw driver to open the fuse box...
Page 398: Fuse Boxes In Engine Compartment
Practical hints Fuses Fuse boxes in engine compartment There are fuse boxes located in the engine compartment on the driver’s and front pas- senger side in front of the firewall (dividing wall between engine compartment and passenger compartment). 1 Fuse box cover, driver’s side 2 Slide 1 Fuse box cover, front passenger side 2 Slide...
Page 399: Technical Data
Technical data Parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and Tires Electrical system Main Dimensions and weights Fuels, coolants, lubricants, etc.
Page 400: Parts Service
The “Technical data” section provides the necessary technical data for your vehicle. All authorized Mercedes-Benz Centers maintain a stock of genuine Mercedes-Benz parts required for mainte- nance and repair work. In addition, strate- gically located parts distribution centers provide quick and reliable parts service.
Page 401: Warranty Coverage
Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Cen- ter. Technical data Warranty coverage...
Page 402: Identification Labels
Technical data Identification labels 1 Certification label (on driver’s B pillar) 2 Vehicle Identification Number (VIN) (below right rear passenger seat) 3 Engine number (engraved on engine) 4 VIN, visible (lower edge of windshield) 5 Emission control information label, includes both federal and California certification exhaust emission standards 6 Vacuum line routing diagram label...
Page 403: Layout Of Poly-V-Belt Drive
Layout of poly-V-belt drive CL 500 1 Automatic belt tensioner 2 ABC tandem pump (pump for power-steering assistance and ABC chassis) 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley CL 55 AMG The CL 55 AMG has two poly-V-belts (belt one shown in purple/belt two shown in black).
Page 404: Engine
Poly-V-belt 2380 mm The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating. CL 55 AMG (215.374) 4-stroke engine, gasoline injection 3.82 in (97.00 mm)
Page 405 Poly-V-belt 2335 mm The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating. CL 65 AMG (215.379) 4-stroke engine, gasoline injection 3.25 in (82.60 mm)
Page 406: Rims And Tires
Poor handling characteristics Increased noise Increased fuel consumption Moreover, tires and rims not approved by Mercedes-Benz may, under load, ex- hibit dimensional variations and differ- ent tire deformation characteristics that could cause them to come into contact with the vehicle body or axle parts.
Page 407: Same Size Tires
Wheel offset Summer tires (radial-ply tires) All season tires (radial-ply tires) Winter tires (radial-ply tires) For use with snow chains contact an authorized Mercedes-Benz Center CL 500 (except Sport Package* and except Appearance Package*) J x 17 H2 1.81 in (46 mm)
Page 408 Summer tires (radial-ply tires) All season tires (radial-ply tires) Winter tires (radial-ply tires) For use with snow chains contact an authorized Mercedes-Benz Center Must not be used with snow chains CL 500, CL 600 (Appearance Package*) CL 500, CL 600 (Sport Package*) 8 J x 18 H2 1.73 in (44 mm)
Page 409: Mixed Size Tires
Mixed size tires Front axle AMG light alloy rims Wheel offset Summer tires (radial-ply tires) 245/45 R18 100Y XL (Extra Load) Rear axle AMG light alloy rims Wheel offset Summer tires (radial-ply tires) 265/40 R18 101Y XL (Extra Load) Must not be used with snow chains CL 500, CL 600 (Sport Package*) CL 65 AMG CL 55 AMG...
Page 410: Spare Wheel
Technical data Rims and Tires Spare wheel CL 500 (except Sport Package* and except Appearance Package*) Rims (light alloy) J x 17 H2 Wheel offset 2.0 in (51 mm) Summer tires (radial-ply tires) All season tires (radial-ply tires) 225/55 R17 97H M+S CL 600, CL 500 (Sport Package* CL 65 AMG and Appearance Package*)
Page 411: Electrical System
Electrical system Model CL 500 Generator (alterna- 14 V/150 A tor) Starter motor 12 V/1.7 kW Battery 12 V/95 Ah Spark plugs Bosch F 8 DPP332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque 15 – 22 lb-ft (20 – 30 Nm) 18 – 22 lb-ft (25 – 30 Nm) 15 – 22 lb-ft (20 – 30 Nm) 15 – 22 lb-ft (20 – 30 Nm) CL 55 AMG CL 600 14 V/180 A...
Page 412: Main Dimensions And Weights
Technical data Main Dimensions and weights Main Dimensions Model CL 500 Overall vehicle length 196.4 in (4989 mm) Overall vehicle width 73.1 in (1857 mm) Overall vehicle height 55.4 in (1408 mm) Wheelbase 113.6 in (2885 mm) Track, front 62.1 in (1577 mm) Track, rear 62.1 in (1578 mm) Weights...
Page 413: Fuels, Coolants, Lubricants, Etc
Technical data Fuels, coolants, lubricants, etc. Please refer to the Factory Approved Ser- vice Products pamphlet, or inquire at your Mercedes-Benz Center. Fuels, coolants, lubricants, etc. Approved engine oils MB Automatic Transmission Fluid Hypoid gear oil SAE 85 W 90...
Page 414 Technical data Fuels, coolants, lubricants, etc. Model Cooling system CL 500 CL 55 AMG CL 600 CL 65 AMG Low temperature cooling system CL 600 CL 65 AMG Fuel tank including a reserve of CL 500 and CL 600 including a reserve of CL 55 AMG and CL 65 AMG 3.7 US gal (14.0 l) Air conditioning system Windshield washer and headlamp cleaning system...
Page 415: Engine Oils
System (U.S. vehicles) or FSS (Canada vehicles). For a listing of approved engine oils and oil filters, refer to the Factory Approved Service Products pamphlet, or contact an authorized Mercedes-Benz Center. Using engine oils and oil filters of specification other than those expressly required for the Maintenance System (U.S.
Page 416: Brake Fluid
Therefore, the brake fluid must be re- placed every two years, preferably in the spring.Only brake fluid approved by Mercedes-Benz is recommended. Your au- thorized Mercedes-Benz Center will pro- vide you with additional information. Premium unleaded gasoline To maintain the engine’s durability and performance, premium unleaded gaso- line must be used.
Page 417: Gasoline Additives
Mer- cedes-Benz vehicles listed in the Factory Approved Service Products Pamphlet are not covered by the Mercedes-Benz Limited Warranty. Technical data Fuels, coolants, lubricants, etc. Coolants...
Page 418 The replacement interval published in the Maintenance Booklet is only applicable if MB 325.0 anticorrosion/antifreeze solu- tion or other Mercedes-Benz approved products of equal specification (see Factory Approved Service Products pam- phlet) are used to renew the coolant con- centration or bring it back up to the proper level.
Page 419 Anticorrosion/antifreeze quantity Model CL 500 CL 600 (main cooling system) CL 600 (low temperature cooling system) CL 55 AMG CL 65 AMG (main cooling system) CL 65 AMG (low temperature cooling system) 1.53 US qt (1.45 l) Fuels, coolants, lubricants, etc. Approx.
Page 420: Windshield And Headlamp Washer System
Technical data Fuels, coolants, lubricants, etc. Windshield and headlamp washer system Both the windshield and headlamp washer systems are supplied from the windshield washer fluid reservoir. The windshield and headlamp washer fluid reservoir has a capacity of approx. 7.1 US qt (6.7 l). Refill the reservoir with MB Windshield Washer Concentrate and water (or con- centrate and commercially available...
Page 421: Technical Terms
(the 58 indicator lamp in the center console comes on). See an authorized Mercedes-Benz Center for availability. BabySmart compatible child seats Special restraint system for children. The sensor system for the passenger...
Page 422 Technical terms CAN system (Controller Area Network) Data bus network serving to control ve- hicle functions such as door locking or windshield wiping. Cockpit All instruments, switches, buttons and indicator/warning lamps in the passen- ger compartment needed for vehicle operation and monitoring. COMAND (Cockpit Management and Data Sys- tem)
Page 423 Engine number The number set by the manufacturer and placed on the cylinder block to uniquely identify each engine pro- duced. Engine oil viscosity Measurement for the inner friction (vis- cosity) of the oil at different tempera- tures. The higher the temperature an oil can tolerate without becoming thin, or the lower the temperature it can tol- erate without becoming viscous, the...
Page 424 Engine speeds within the red marking of the tachometer dial. Avoid this en- gine speed range, as it may result in se- rious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Parktronic system (Parking assist)* System which uses visual and acoustic signals to assist the driver during park- ing maneuvers.
Page 425 Power train Collective term designating all compo- nents used to generate and transmit motive power to the drive axles, includ- ing: Engine Clutch/torque converter Transmission Transfer case Drive shaft Differential Axle shafts/axles Program mode selector switch Used to switch the automatic transmis- sion between standard operation S and comfort operation C.
Page 426 Technical terms Tele Aid System (Telematic Alarm Identification on De- mand) The Tele Aid system consists of three types of response: automatic and man- ual emergency, roadside assistance and information. Tele Aid is initially ac- tivated by completing a subscriber agreement and placing an acquain- tance call.
Page 427: Index
ABC 220, 419 Messages in display 337 Setting vehicle level 221 ABS 25, 80, 419 Malfunction indicator lamp 326 Messages in display 338 Warning lamp 326 Accelerator position, automatic transmission 172 Accessory weight 309 Accident In case of 56 Activating Air conditioner (cooling) 194 Air recirculation mode 190 Anti-theft alarm system 86...
Page 428 Index Seat height 38 Seat in the lumbar region 118 Seat in the shoulder region 117 Seats 37 Steering column height 42 Steering column in or out 42 Steering column up or down 42 Steering wheel 42 Air bags 63 Air conditioner (cooling) Turning off 194 Air pressure 309...
Page 429 AUDIO menu 141 Selecting CD track 143 Selecting MP3-CD track 143 Selecting radio station 142 Selecting satellite radio* station 142 Audio system CD mode 144 Auto-dimming for rear view mirror 178 Automatic central locking Activating/deactivating (control system) 161 Automatic climate control 184 Air recirculation mode 190 Defrosting 190 Rear window defroster 193...
Page 430 Index Battery, SmartKey with KEYLESS-GO* Check lamp 99 Checking the battery 99 Replacing 372 Battery, vehicle 281, 386 Charging 387 Disconnecting 387 Reconnecting 388 Reinstalling 387 Removing 387 Bead 309 Bi-Xenon headlamps 419 Block heater (Canada only) 314 Blocking Rear window operation 78 Brake assist system (BAS) 419 Brake fluid 271, 414 Brake lamp bulbs 374...
Page 431 Central locking Automatic 110 From inside 111 Switch 111 Switching on/off (control system) 161 Unlocking from inside 111 Central locking switch 111 Change of address or ownership 12 Changing Key setting 162 Vehicle level 222 Changing CDs 144 Charcoal filter 192 Activating 192 Deactivating 192 Charging...
Page 432 Index Clock 25 Closing Cup holder 237 Glove box 232 Hood 274 Power tilt/sliding sunroof 202 Side windows 198, 199 Trunk 103 Windows 197 Closing from the inside* Trunk 103 Closing in an emergency Tilt/sliding sunroof 370 Closing tilt/sliding sunroof In an emergency 370 Cockpit 22, 420 Cockpit management and data system...
Page 433 Courtesy lighting 132 Cruise control 205, 420 Canceling 206 Driving downhill 206 Driving uphill 206 Fine adjustment 207 Lever 212 Setting current speed 206 Setting to last stored speed ("Resume" function) 207 Cruise control lever 205 Cup holder Cleaning 322 Closing 237 In front seat armrest 235 In rear seat armrest 237...
Page 434 Index Digital speedometer 141 Direction of rotation (tires) 286 Discharged battery Jump starting 389 Disconnecting Vehicle battery 387 Displays Digital speedometer 141 Distronic* 210 Messages 276 Service indicator 315 Showing malfunctions 152 Vehicle status messages 335 Distance Decreasing in Distronic* 216 Increasing in Distronic* 216 Setting in Distronic* 215 Warning function 216...
Page 435 Doors Message in display 347 Opening from inside vehicle 100 Opening from outside 92, 97 DOT 309 Downhill driving Cruise control 206 Downshifting 167 Drink holder see Cup holder 235 Drinking and driving 259 Driving Abroad 267 General instructions 45, 259 Hydroplaning 263 In winter 265 Problems 56...
Page 436 Index Engine cleaning 319 Engine compartment 273 Fuse box in 396 Hood 273 Engine malfunction indicator lamp 25, 328, 329 Engine number 400, 421 Engine oil 274 Adding 278 Additives 413 Checking level 274 Consumption 274 Display messages 348 Filler neck 278, 279 Messages in display 276, 348 Viscosity 421 Engine oil level see Oil level 272...
Page 437 Front lamps Messages in display 352–355 Replacing bulbs 374, 376 Switching on 125 Front passenger front air bag off indicator lamp 334 Front seat Head restraints 114 Head restraints installing 114 Head restraints removing 114 FSS (Flexible Service System) 315 FSS (Flexible Service System) (Canada vehicles) 421 Fuel 271...
Page 438 Index Gloves (vehicle tool kit) 365 Good visibility 178 GPS 242, 421 Gross Axle Weight Rating see GAWR Gross Vehicle Weight Rating see GVWR Gross Vehicle Weight see GVW GVW 309 GVWR 310 Hand-held transmitter Programming integrated remote control 252 Hands-free microphone 29 Hard plastic trim items Cleaning 322...
Page 439 Indicator lamps see Lamps, indicator and warning Infant and child restraint systems 72 Installing 76 LATCH child seat mounts 77 Information About service and warranty 10 Button for Tele Aid* 246 Inside rear view mirror Auto-dimming 178 Installing Infant and child restraint systems 76 Wiper blades 380 Instrument cluster 23, 24, 133, 421 Cleaning 322...
Page 440 Index Keys 90 Kickdown 172, 421 Kilometers/miles in speedometer 156 Kilopascal 310 Km/h or mph in speedometer 156 Lamp bulbs, exterior 373 Lamps, exterior Front 374 Light sensor 353 Messages in display 353 Rear 374 Lamps, indicator and warning ABS 326 Air bag Off 67 Air bag off indicator lamp 74 Battery (SmartKey with...
Page 441 Interior 130 Locator lighting 127 Low beam 125 Manual headlamp mode 126 Night security illumination 127 Parking lamps 125 Rear fog lamp 128 Settings (control system) 157 Trunk 131, 132 Limiting opening height of trunk lid* 102 Limiting the gear range 168 Limp Home Mode 177 Line of fall 422 Loading 229...
Page 442 Index Manual shift program CL 55 AMG and CL 65 AMG Activating 175 Automatic transmission 175 Deactivating 177 Massage function 118 MAXCOOL maximum cooling 190 Maximum inflation pressure 310 Maximum load rating 310 Maximum loaded vehicle weight 310 Mechanical key 367 Memory function 122, 422 Recalling positions from memory 123...
Page 443 Engine oil level 348 Entry position 350 Hood 350 Lamps 353 Parking brake 341 Selector lever 341 SmartKey 350 SmartKey with KEYLESS-GO* 350 Tele Aid 356 TeleAid 356 Telephone* 356 Tires 358, ??–364 Trunk 357 Washer fluid 357 Multifunction steering wheel 26, 137, Buttons 137 Navigation system Operating 148...
Page 444 Index Tilt/sliding sunroof In an emergency 370 Trunk 101 Trunk lid from the inside 102 Trunk with SmartKey 93 Windows 197 Opening in an emergency Tilt/sliding sunroof 370 Operating COMAND see separate operating in- structions Garage door opener 255 Integrated remote control 255 Navigation system 148 Radio 142 Radio transmitters 267...
Page 445 Phone book* Loading 147 Quick search 147 Phone number* Dialing 147 Redialing 148 Plastic and rubber parts Cleaning 323 Poly-V-belt drive 422 Positions (Memory function) Recalling from memory 123 Positions (Memory function*) Storing into memory 123 Potential problems associated with under- inflated and overinflated tires 298 Power assistance 259 Power closing assist for doors and trunk...
Page 446 Index Reading lamps 131 Rear fog lamp 374 Bulb 374 Switching on 128 Rear lamp bulbs Replacing 377 Rear lamps see Tail lamps Rear passenger compartment Adjustable air vents 196 Rear seat head restraints Folding back with switch 115 Placing upright 115 Rear seats Head restraints 115 Rear view mirror 29...
Page 447 Reset button in the instrument cluster 153 Resetting All functions (control system) 153 All functions of a submenu 154 Fuel consumption 151 Maintenance service indicator 316 Stored speed in Distronic* 214 Trip odometer 134 Residual heat utilization 194, 423 Residual ventilation 194 REST (Residual engine heat utilization) 423 Restraint system see Infant and child re-...
Page 448 Index Self-test BabySmartTM air bag deactivation system 74 Tele Aid 243 Service Major service (Service B) 315 Minor service (Service A) 315 When due 315 Service (maintenance) 315 Service and warranty information 10 Service indicator 315 Service life (tires) 284 Service System see FSS 315 Setting Convenience functions 162...
Page 449 Shift lock 423 Shifting Gear selector lever positions 169 Into optimal gear range (automatic transmission) 167 Shoulder support Seat adjustment 117 Side impact air bags 67 Side marker lamps Replacing bulbs 374, 377 Side windows Automatic closing 199 Automatic opening 198 Cleaning 321 Closing 197, 198 Closing fully (Express-close) 199...
Page 450 Index Speedometer 25 Displays 210 Settings units 156 Speedometer display mode Selecting 156 Sporty driving suspension 220 SRS 70, 423 Indicator lamp 333 SRS indicator lamp 62 Standing lamps 125 Replacing bulbs 374, 377 Standing water Driving instructions 266 Starter switch 23 Switching on 48, 49 Starting difficulties 49 Starting the engine 48...
Page 451 Switching off Automatic central locking (control system) 161 Engine 59 ESP 83 Hazard warning flasher 130 Headlamps 59 Switching on Automatic central locking (control system) 161 ESP 84 Front fog lamps 128 Front lamps 125 Hazard warning flasher 130 Headlamps 52 High beams 129 Parking lamps 125 Rear fog lamp 128...
Page 452 Index Tightening torque 424 Tightening torque (Wheel bolts) 385 Tilt/sliding sunroof Closing in an emergency 370 Opening in an emergency 370 Stopping 204 Synchronizing 204 TIN 311 Tire Vehicle maximum load on 311 Tire and Loading Information 287 Tire and loading terminology 309 Tire care and maintenance 284 Tire Identification Number see TIN Tire inflation pressure...
Page 453 Message in display 357 Opening 101 Opening from inside vehicle 102 Opening with SmartKey 93 Parcel net 238 Tie-down hooks 230 Trunk lid 101, 103 Trunk lock 368 Unlocking with SmartKey 93 Unlocking with SmartKey with KEYLESS-GO 100 Trunk lid Limiting opening height* 102 Trunk lid emergency release 109 Trunk lid opening/closing system* 103,...
Page 454 Index Vacuum line routing diagram label 400 Vanity mirror in the sun visor 231 Vehicle Individual settings 153, 155 Locking in an emergency 368 Lowering 384 Service battery 386 Towing 391 Unlocking in an emergency 367 Vehicle battery 386 Vehicle capacity weight 311 Vehicle care 317 Cup holder 322 Distronic* system sensor cover 320...
Page 455 Warning indicators Parktronic* 226 Warning lamps see Lamps, indicator and warning Warning sounds Distance warning function* 216 Distronic* 210 Drivers seat belts 68 Parking brake 51 Warranty coverage 399 Washing the vehicle 317 Wear pattern (tires) 312 Weights 410 Wheel bolt wrench with socket wrench (ve- hicle tool kit) 365 Wheel change Tightening torque 385...
Page 457 If you have any questions about carrying out any type of service, turn to the advice of an authorized Mercedes-Benz Center.
