Page 2
Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, as well as your and your passengers’ safe-...
Product information... 9 Operator’s Manual ... 10 Service and Warranty Information.. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada ...
Page 4
Contents Safety and Security ... 53 Occupant safety... 54 Airbags ... 55 Seat belts ... 60 Children in the vehicle... 63 Blocking of rear window operation . 69 Panic alarm ... 70 Activating ... 70 Deactivating ... 70 Driving safety systems... 71 ABS ...
Page 5
Instrument cluster ... 114 Instrument cluster illumination ... 114 Coolant temperature gauge ... 115 Trip odometer ... 115 Tachometer... 115 Outside temperature indicator ... 116 Control system ... 117 Multifunction display... 117 Multifunction steering wheel... 118 Menus ... 120 Standard display menu ... 122 AUDIO menu ...
Page 6
Contents Power windows ... 169 Opening and closing the windows ... 169 Synchronizing power windows ... 172 Sliding/pop-up roof... 173 Opening and closing the sliding/pop-up roof ... 173 Synchronizing the sliding/pop-up roof ... 175 Driving systems ... 176 Cruise control... 176 Distronic*...
Page 7
Engine compartment ... 237 Hood ... 237 Engine oil ... 238 Transmission fluid level... 242 Active Body Control (ABC) fluid level... 242 Coolant ... 242 Battery ... 243 Windshield washer system and headlamp cleaning system... 244 Tires and wheels... 246 Important guidelines ...
Page 8
Contents Fuses ... 322 Fuse boxes in passenger compartment... 322 Fuse boxes in engine compartment... 324 Emergency engine shut-down ... 324 Technical data... 325 Spare parts service ... 326 Warranty coverage... 327 Loss of Service and Warranty Information Booklet... 327 Identification labels...
Please do not use them. Introduction Product information Mercedes-Benz original parts as well as conversion parts and accessories ap- proved by us are available at your autho- rized Mercedes-Benz Center where you will receive comprehensive information, in-...
Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your au- thorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...
Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price or lease price, if Mercedes-Benz USA, LLC and/or its au- thorized repair or service facilities fail to fix one or more substantial defects or mal-...
Calls to the toll-free Roadside Assistance number 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Cus- tomer Assistance Representatives 24 hours a day, 365 days a year. For additional information refer to the Mercedes-Benz Roadside Assistance Pro- gram brochure in your glove box.
Gasoline may have a considerably low- er octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult your authorized Mercedes-Benz Center or...
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.
Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Make sure that any repairs or modifications to electronic components are carried out by an authorized Mercedes-Benz Center. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 21
Item Page 1 Combination switch Turn signals Windshield wipers High beam 2 Cruise control lever Cruise control Distronic* 3 Instrument cluster 4 Multifunction steering wheel 5 Gear range indicator, clock Item Page 6 Lever for voice control sys- tem* (see separate operat- ing instructions) 7 Parking assist* (Parktronic) right front area warning in-...
Item Page 1 Coolant temperature gauge 2 Fuel gauge with: Fuel reserve warning lamp 3 L Left turn signal indicator lamp K Right turn signal indicator lamp 4 Speedometer with: v Electronic Stability Program (ESP) warning lamp l Distance warning lamp 5 Tachometer Vehicles without Distronic*: Warning lamp without...
At a glance Multifunction steering wheel Multifunction steering wheel Item Page 1 Multifunction display Operating control system 2 Selecting the submenu or setting the volume ç down/to decrease æ up/to increase 3 Telephone*: Press button í to take a call to dial a call ì...
Center console Upper part Item Page 1 Rear window sunshade 2 Parking assist* (Parktronic system) deactivation switch 3 Active Body Control (ABC) 4 Level control switch 5 Central locking switch Anti-theft alarm system in- dicator lamp 6 Hazard warning flasher on/off switch 7 Central unlocking switch At a glance...
At a glance Center console Lower part Item Page 1 KEYLESS-GO* start/stop 33, 43 button 2 Selector lever for automatic transmission 3 PASSENGER AIRBAG OFF indicator lamp 4 Thumbwheel for setting distance in Distronic* 5 Distance warning func- tion* on/off switch 6 Program mode selector for automatic transmission...
Overhead control panel Item Page 1 Left reading lamp on/off 2 Rear interior lighting on/off 3 Right reading lamp on/off 4 Interior lighting control 5 Sliding/pop-up roof 6 Hands-free microphone for Tele Aid (emergency call system), telephone* and voice control system* (see separate operating instruc- tions) 7 Rear view mirror...
At a glance Door control panel Door control panel Item Page 1 Door handle 2 Memory function (for stor- ing seat, mirror and steer- ing wheel settings) 3 Seat heating Seat ventilation* 4 Seat adjustment 34, 96 5 Exterior mirror adjustment Item Page 6 Switches for opening/...
Getting started Unlocking The“Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 31
Starter switch positions Starter switch 0 For removing key 1 Power supply for some electrical con- sumers, such as seat adjustment 2 Ignition (power supply for all electrical consumers) and driving position 3 Starting position Warning! When leaving the vehicle, always remove the key from the starter switch, take the KEYLESS-GO* card with you and lock the ve- hicle.
Getting started Unlocking Unlocking with KEYLESS-GO* Vehicles with KEYLESS-GO*: in addition to the two SmartKeys with remote controls and removable mechanical key, your vehi- cle comes equipped with two KEY- LESS-GO* cards. The function of the SmartKey overrules the KEYLESS-GO function. If you have the KEYLESS-GO function, your vehicle checks whether the KEYLESS-GO card is valid when you grasp the door han-...
Page 33
1 KEYLESS-GO start/stop button Before you press the KEYLESS-GO start/stop button, the vehicle’s on-board electronics have status 0 (as with key re- moved). Make sure the gear selector lever is set to P. Do not depress the brake pedal. Position 1 Press the KEYLESS-GO start/stop but- ton once.
Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the front passenger air- bag when it is properly installed.
Page 35
A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Seat adjustment The seat adjustment switches are located in each door.
Page 36
Getting started Adjusting Head restraint height Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint to support the back of the head approximately at ear level. Do not drive the vehicle without the seat head restraints. Head restraints are intend- ed to help reduce injuries during an acci- dent.
The front passenger seat head restraint automatically lowers after a few sec- onds when the front passenger seat is not occupied.This improves the driver's outward view as well as the forward view from the rear passenger compart- ment. When the front passenger seat is occu- pied again, the front passenger head restraint returns to the last set position within a few seconds.
Getting started Adjusting Steering column, lengthen or shorten Move stalk forward or backward in the direction of arrow 1 until a comfortable steering wheel position is reached with your arms slightly bent at the elbow. Steering column, height Move the stalk up or down in the direc- tion of arrow 2.
Page 39
Electrolyte drops coming into contact with the vehicle paint finish can only be completely removed while in their liq- uid state and by applying plenty of wa- ter. The buttons are located on the driver’s door. 1 Driver’s side mirror 2 Passenger side mirror 3 Adjustment button Make sure that the ignition is switched...
( page 54). Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 41
According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing positions. Infants and small children must ride in back seats and be seated in an appropriate infant or child restraint system, which is properly secured with the vehicle’s seat belt and top tether strap, or secured via lower anchors and top tether strap, fully in...
This could impair the effective- ness of the belts. Damaged seat belts or belts that were highly stressed in an accident must be replaced by an authorized Mercedes-Benz Center. Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health.
Page 43
Automatic transmission Gearshift pattern for automatic transmission P Park position with selector lever lock R Reverse gear N Neutral D Drive position Make sure that the gear selector lever is set to P. Starting with the SmartKey Turn the key in the starter switch to position 3 and hold until the engine starts ( page 31).
Page 44
If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center. Parking brake 1 Parking brake pedal 2 Parking brake release handle...
Page 45
Driving Firmly depress the brake pedal. Move selector lever in position D or R. Release the brake pedal. Carefully depress the accelerator pedal. Once the vehicle is in motion, the automat- ic central locking system engages and the locking knobs drop down. You can open a locked door from the inside.
Getting started Driving Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehi- cle control. Your vehicle’s ABS will not pre- vent this type of loss of control. Switching on headlamps Exterior lamp switch 1 Off...
Windshield wipers The combination switch is on the left of the steering column. Combination switch 1 Single wipe 2 Switching on windshield wipers Make sure that the ignition is switched Switching on windshield wipers Turn the combination switch to the de- sired position depending on the inten- sity of the rain.
Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is over 248°F (120°C) The coolant is too hot and is no longer cooling the engine.
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows: Warning! Wait until the vehicle is stationary before re- moving the key from the starter switch. The vehicle cannot be steered when the key is removed.
Getting started Parking and locking Parking brake 1 Parking brake 2 Release handle Step firmly on parking brake 1. When the engine is running, the indica- tor lamp ; (USA only) or 3 (Can- ada only) in the instrument cluster will be illuminated.
Turning off engine Place the gear selector lever in position P. Always set the parking brake in addi- tion to shifting to position P. On steep slopes, turn the front wheels towards the curb. Turning off engine with the SmartKey Turn the key in the starter switch ( page 31) to position 0 and remove The immobilizer is activated.
Page 52
Getting started Parking and locking Press the seat belt release button ( page 41). If you hear a warning signal you have ei- ther forgotten to turn off the lights, or not put the gear selector lever in P before opening the driver’s door. Turn off the lights or place the gear se- lector lever in P.
For safety reasons, we strongly recom- mend that you visit an authorized Mercedes-Benz Center immediately to have the system checked. More information can be found in the “Practical hints” section ( page 266).
SRS may not be op- erational. For your safety, we strongly rec- ommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 56
Operator’s Manu- Warning! Accident research shows that the safest place for children in an automobile is in the rear seat. Should you choose to place a child 12 years old or under in the front passenger...
Page 57
Mercedes-Benz Center at an additional cost. Please contact your local authorized Mercedes-Benz Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details.
Page 58
These instructions are available from your authorized Mercedes-Benz Center. Given the considerable deployment speed and the textile structure of the airbags, there is the possibility of abra- sions or other injuries resulting from air- bag deployment.
Page 59
When you sell your vehicle we strongly urge you to give notice to the subsequent owner that it is equipped with an SRS by alerting them to the applicable section in the Operator’s Manual. Front airbags Driver and passenger airbags are de- ployed: in the event of a frontal impact if impact exceeds a preset deployment...
Safety and Security Occupant safety The front passenger side impact airbag 2 will only deploy if the system senses that the front passenger seat is occupied. The window curtain airbags fill up the area between the A and C pillars (see arrows). 1 Window curtain airbag 2 Front side impact airbags 3 Rear side impact airbags...
Page 61
Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation or to failure.
Page 62
Safety and Security Occupant safety Warning! USE SEAT BELTS PROPERLY Seat belts can only work when used properly. Never wear seat belts in any other way than as described in this sec- tion, as that could result in serious inju- ries in case of an accident.
When scrapping the emergency tensioning device, our safety instructions must be fol- lowed. These are available at your autho- rized Mercedes-Benz Center. Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side im-...
Page 64
Safety and Security Occupant safety All lap-shoulder belts except the driver’s seat belt have special seat belt retractors for secure fastening of child restraints. To fasten a child restraint, follow child re- straint instructions for mounting. Then pull the shoulder belt out completely and let it retract.
Page 65
Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 66
Occupant safety Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart bag deactivation system. With the special child seat properly installed, the passenger front airbag will not deploy.
Page 67
Warning! Do not place powered-on laptops, cell phones and like electronic devices on the front passenger seat. Signals from such de- vices may interfere with the BabySmart system. Such signal interference may cause the PASSENGER AIRBAG OFF indicator lamp not to come on during self-test or be contin- uously lit, indicating that the system is not functioning.
Page 68
Safety and Security Occupant safety Child seat anchors – “LATCH” type This vehicle is equipped with two LATCH (Lower Anchors and Tethers for CHildren) type anchors (at each of the outer rear seats) for the installation of a “LATCH” child seat with the matching anchor fit- tings.
Warning! Children too big for child restraint systems must ride in back seats using regular seat belts. Position shoulder belt across chest and shoulder, not face or neck. A booster seat may be necessary to achieve proper belt positioning for children from 41 lbs. un- til they reach a height where a lap/shoulder belt fits properly without a booster.
Safety and Security Panic alarm Panic alarm An audible alarm and blinking exterior lamps will operate for approximately 2½ minutes. 1 Â button Activating Press and hold button 1 for at least one second. Deactivating Press button 1 again Insert key in the starter switch. For operation in the USA only: This de- vice complies with Part 15 of the FCC Rules.
Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ESP (Electronic Stability Program) In winter operation, the maximum ef- fectiveness of the ABS and the ESP is only achieved with winter tires (M+S tires), or snow chains as required.
Page 72
Safety and Security Driving safety systems Continuous steady brake pedal pressure yields the advantages provided by the ABS, namely braking power and the ability to steer the vehicle. On slippery road surfaces, the ABS will re- spond even with light brake pressure. The pulsating brake pedal can be an indication of hazardous road conditions and func- tions as a reminder to take extra care while...
The Brake Assist System (BAS) operates in emergency situations. If you apply the brakes very quickly, the BAS automatically provides full brake boost, thereby poten- tially reducing the braking distance. Apply continuous full braking pressure until the emergency braking situation is over. The ABS will prevent the wheels from locking.
Page 74
Safety and Security Driving safety systems Warning! Never switch off the ESP when you see the ESP warning lamp flashing in the in- strument cluster. In this case proceed as fol- lows: While driving off, apply as little throttle as possible While driving ease up on the accelerator Adapt your speed and driving style to the prevailing road conditions...
Page 75
Avoid spinning of a drive wheel for an extended period with the ESP switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Warning! When the ESP warning lamp illuminated continuously, the ESP is switched off.
In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada).
Anti-theft alarm system Once the alarm system has been armed, a visual and audible alarm is triggered when someone opens a door the trunk the hood The alarm system will also be triggered when someone attempts to raise the vehicle the vehicle is opened with the mechan- ical key If the alarm stays on for more than...
Safety and Security Anti-theft systems Tow-away alarm Once the tow-away alarm is armed, a visual and audible alarm will be triggered when someone attempts to raise the vehicle. The tow-away protection alarm is trig- gered, for example, if the vehicle is lift- ed on one side.
Controls in detail Locking and unlocking Seats Memory function Lighting Instrument cluster Control system Automatic transmission Good visibility Automatic climate control Power windows Sliding/pop-up roof Driving systems Loading Useful features...
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed on your vehi- cle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
Page 81
To prevent possible malfunction, avoid exposing the key to high levels of elec- tromagnetic radiation. Factory setting Global unlocking Press button Œ . All turn signal lamps blink once. The locking knobs in the doors move up. The anti-theft alarm system is switched off.
Page 82
Replace the batteries ( page 299). You can obtain the required batteries at any authorized Mercedes-Benz Cen- ter. Unlocking the trunk lid You can unlock the trunk separately. A minimum height clearance of 6.1 ft (1.90 m) is required to open the trunk lid.
KEYLESS-GO card* Specially equipped vehicles come with two KEYLESS-GO cards. On these vehicles, the validity of the KEYLESS-GO card is checked every time you grasp a door handle. If the card is valid, your vehicle unlocks the doors the trunk lid the fuel filler flap Warning! When leaving the vehicle, always remove the...
Page 84
Controls in detail Locking and unlocking If the KEYLESS-GO card is removed from the vehicle while the ignition is switched on (e.g. if passenger exits the vehicle with the card), the message will ap- CHIP CARD NOT RECOGNIZED! pear in the multifunction display. Find the card or change its present lo- cation immediately (e.g.
Page 85
If the symbols 2 or 3 do not light up during the check, then the batteries of the KEYLESS-GO card are discharged. Change the batteries ( page 299). You can obtain the batteries at any au- thorized Mercedes-Benz Center.
Page 86
Controls in detail Locking and unlocking Checking vehicle lock status If you cannot remember whether you have locked the vehicle, you can check the lock status using the KEYLESS-GO card. Briefly press programming button 1. The indicator lamp for “Driver’s door” 2 or “Global unlock”...
Loss of the KEYLESS-GO card If you lose your KEYLESS-GO card, you should do the following: Have the KEYLESS-GO card deactivat- ed by an authorized Mercedes-Benz Center. Report the loss immediately to your car insurance company. Have the mechanical lock replaced if necessary.
Controls in detail Locking and unlocking If the vehicle has previously been locked from the outside with the SmartKey, opening a door from the in- side will trigger the anti-theft alarm sys- tem. To cancel the alarm, do one of the fol- lowing: Press button Œ...
Opening the trunk lid from the outside The trunk lid lock is located in the rear li- cense plate recess. A minimum height clearance of 6.1 ft (1.90 m) is required to open the trunk lid. Press trunk lid lock 1. The trunk lid swings open.
Controls in detail Locking and unlocking Closing the trunk lid 1 Handle Lower trunk lid by pulling firmly on handle 1. Push the trunk lid closed from the out- side with hands placed flat on trunk lid. The power closing assist automatically ensures that the lid is pulled complete- ly closed ( page 94).
Pull the mechanical key out of the SmartKey ( page 297). Insert the mechanical key into the trunk lid lock. Turn the key completely to the right to position 1. The trunk remains locked even when the vehicle is centrally unlocked. You can only cancel the separate trunk locking mode by means of the mechan- ical key.
Page 92
Controls in detail Locking and unlocking Closing from the inside Press the remote control switch 2 until the indicator lamp in the switch goes out and the trunk lid is closed. To interrupt the closing procedure: Release remote trunk lid switch 2. Warning! Maintain sight of trunk area while operating the door mounted switch.
Page 93
Closing and locking the trunk lid with KEYLESS-GO* On vehicles with trunk lid opening/closing system and KEYLESS-GO, you can close the trunk lid and lock the vehicle simulta- neously. 1 Trunk lid closing switch 2 KEYLESS-GO switch Make sure that you have the SmartKey and the KEYLESS-GO card with you.
Controls in detail Locking and unlocking Power closing assist for doors and trunk lid Power closing assist for doors Press the doors gently past the initial engage position into the lock. The doors close automatically. Power closing assist for trunk lid Press the trunk lid gently into its lock.
Locking and unlocking from the inside You can lock or unlock the doors and the trunk from inside using the central locking switch. This can be useful, for example, if you want to lock the vehicle before starting to drive. The fuel filler flap cannot be locked or un- locked with the central locking switch.
Controls in detail Seats Seats Information on seat adjustment can be found in the “Getting started” section ( page 34). Lumbar support You can adjust the contour of the seat’s lumbar support to best support your back. The thumbwheels for the driver’s and front passenger’s seat are on the inner side of the seat.
Head restraints Information on head restraint adjustment can be found in the “Getting started” sec- tion ( page 36). Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint to support the back of the head approximately at ear level. Do not drive the vehicle without the seat head restraints.
Page 98
Controls in detail Seats Press switch 1. The rear head restraints will fold back- ward. Placing rear head restraints upright Pull the rear head restraint upright until it locks into position. Make sure that the head restraints en- gage when adjusting them manually. Otherwise, their protective function cannot be assured.
Multicontour seat* The multicontour seat has a movable seat cushion and inflatable air cushions built into the seat backrest to provide additional lumbar and side support. The seat cushion movement, seat backrest cushion height and curvature can be con- tinuously varied with regulators on the right side of the seat after turning the SmartKey in the starter switch to position 2 or pressing the KEYLESS-GO*...
Controls in detail Seats Massage function (PULSE) You can reduce muscle tension during long trips by periodically using the massage function. Press button 3. The indicator lamp on button 3 lights up. The air cushions in the lumbar re- gion inflate and deflate rhythmically. The massage function switches off au- tomatically after approximately eight minutes.
Page 101
Warning! The seat belts provide protection only with the backrest locked in place and, therefore, must be locked in place with the vehicle in motion. Do not drive the vehicle when the backrest is not locked in place. If the warn- ing message SEAT BACKREST, RIGHT - LOCK or SEAT BACKREST, LEFT - LOCK is displayed in the multifunction display, then...
Controls in detail Seats Seat ventilation* The switch is located on the door. Seat ventilation can be activated manually with the electronic key in starter switch posi- tion 1 or 2, or by the summer opening fea- ture ( page 171). The blue indicator lamps on the switch show the ventilation level selected: Level...
Seat heating Vehicles without seat ventilation* The switch is located on the door. 1 Normal heating 2 Rapid heating Make sure the ignition is switched on. All the lamps in the instrument cluster light up. Switching on seat heating Press switch 1. A red indicator lamp above the switch lights up.
Page 104
Controls in detail Seats Vehicles with seat ventilation* The switch is located on the door. The red indicator lamps on the switch show the heating level selected: Level Two indicator lamps on One indicator lamp on No indicator lamp on 1 Seat heating switch Make sure the ignition is switched on.
Memory function Prior to operating the vehicle, the driv- er should check and adjust the seat height, seat position fore and aft, and seat backrest angle if necessary, to en- sure adequate control, reach and com- fort. The head restraint should also be adjusted for proper height.
Controls in detail Memory function Storing positions into memory Adjust the seats, steering wheel and mirrors to the desired position ( page 34). Press memory button M. Release memory button M and push position button 1, 2 or 3 within three seconds.
Storing exterior rear view mirror park- ing position For easier parking you can adjust the pas- senger exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Setting parking position for exterior rear view mirror”...
Controls in detail Lighting Lighting For notes on how to switch on the head- lamps and use the turn signals, see the “Getting started” section ( page 46). Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel. Automatic headlamp mode Parking lamps (also side marker lamps, tail lamps, license plate...
Page 109
If you drive in countries where vehicles drive on the other side of the road than the country where the vehicle is regis- tered, you must have the headlamps modified for symmetrical low beams. Relevant information can be obtained at your authorized Mercedes-Benz Cen- ter.
Page 110
Controls in detail Lighting Daytime running lamp mode Turn exterior lamp switch to position M or U . When the engine is running, the low beam headlamps are automatically switched on. In low ambient light conditions the parking lamps will also switch on. Canada only When you shift from a driving gear to position N or P, the low beam switches off...
Combination switch The combination switch is located on the left side of the steering column. 1 High beam 2 High beam flasher Switching on high beams Turn exterior lamp switch to position B ( page 108). Push the combination switch in direction 1.
Controls in detail Lighting Interior lighting The controls are located in the overhead control panel. 1 Left front reading lamp 2 Rear interior lights 3 Right front reading lamp 4 Rocker switch for automatic control system Automatic control Activating Press the rocker switch to the center position 4.
Manual control Switching lamps on Press the ð symbol on rocker switch 4. The front interior lighting switches on. Switching lamps off Press the ñ symbol on rocker switch 4. The interior lighting switches off. The automatic control function is switched Switching rear interior lights on Press switch 2.
Controls in detail Instrument cluster Instrument cluster A full view illustration of the instrument cluster can be found in the “At a glance” section of this manual ( page 22). The instrument cluster is activated when open a door turn on the ignition press the reset button J ( page 22) switch on the exterior lamps You can change the instrument cluster set-...
248° F (120°C), i.e. in the red zone of the coolant temperature gauge. Doing so may cause serious engine damage which is not cov- ered by the Mercedes-Benz Limited War- ranty. Excessive coolant temperatures trigger a warning in the multifunction display ( page 278).
Controls in detail Instrument cluster Outside temperature indicator Warning! The outside temperature indicator is not de- signed to serve as an ice-warning device and is therefore unsuitable for that purpose. Indicated temperatures just above the freez- ing point do not guarantee that the road sur- face is free of ice.
Control system The control system is activated as soon as the key in the starter switch is turned to position 1. The control system enables you call up information about your vehicle change vehicle settings For example, you can use the control sys- tem to find out when your vehicle is next due for service, to set the language for messages in the instrument cluster dis-...
Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled by the buttons on the multifunc- tion steering wheel. 1 Multifunction display in the speed- ometer Operating the control system 2 Selecting the submenu or setting the volume ç...
Page 119
Pressing any of the buttons on the multi- function steering wheel will alter what is shown in the multifunction display. The information available in the multifunc- tion display is arranged in menus, each containing a number of functions or sub- menus.
Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
Page 121
Menus, submenus and functions Menu 1 Menu 2 Menu 3 Standard dis- AUDIO Telephone play Call up FSS Select radio Load phone station book Check tire pres- Operate CD Search for sure* player name in phone book Check engine oil level Digital speed- ometer...
Controls in detail Control system Standard display menu You can select the functions in the stan- dard display menu with button k or j . The following functions are available: Function Page Call up FSS Check tire pressure* Check engine oil level Call up digital speedometer see below Display digital speedometer...
You can only store new stations using the designated feature on the radio. Refer to separate COMAND operating instructions. You can also operate the radio in the usual manner. Operate the CD player Turn on the radio and select the CD player.
Page 124
Controls in detail Control system Clean CDs from time to time with a com- mercially available cleaning cloth. No sol- vents, anti-static sprays, etc. should be used for cleaning. Replace the CD in its case after use. Protect CDs from heat and direct sunlight.
CDs which have been inserted improp- erly or are unreadable will not be played. Push the magazine into the CD changer in the direction shown by the arrow and close the CD changer door. TEL menu* Warning! A driver’s attention to the road and traffic conditions must always be his/her primary focus when driving.
Page 126
Controls in detail Control system Answering a call When your telephone is ready to receive calls, you can answer a call at any time. In the display you will then see the message: Press button í . You have answered the call. In the dis- play you see the length of the call posi- tioned above the number.
Press button í . The system dials the selected phone number. If connection is successful, the name of the party you called and the duration of the call will appear in the display. If no connection is made, the con- trol system stores the dialed num- ber in the redial memory.
Controls in detail Control system Distronic* menu Use the Distronic menu to display the cur- rent settings for your Distronic system. What information is shown in the display depends on whether the Distronic system is active or inactive. Please refer to the “Driving systems” sec- tion of this manual ( page 179) for in- structions on how to activate Distronic.
Trip computer menu Use the trip computer menu to call up sta- tistical data on your vehicle. The following information is available: Function Page Fuel consumption statistics after start Fuel consumption statistics since last reset Call up range (distance to empty) 130 Fuel consumption statistics after start Press button ÿ...
Press button è or ÿ repeatedly until you see the malfunction message memory in the display. No malfunction messages If no malfunctions have occurred, the mes- sage in the display is: NO MALFUNCTION Malfunctions have occurred If malfunctions have occurred, you will see the number of malfunctions in the display: 1 Number of malfunctions Press button k or j .
Page 132
Controls in detail Control system Resetting all settings You can reset all the functions of all sub- menus to the factory settings. Press the reset button J ( page 22) in the instrument cluster for approxi- mately three seconds. In the display you will see the request to press the reset button J again to confirm.
Page 133
The table below shows what settings can be changed within the various menus. De- tailed instructions on making individual settings can be found on the following pag- INSTRUMENT CLUSTER LIGHTING Select temperature display Set daytime running lamp mode mode (USA only) Select speedometer display Set locator lighting mode...
Page 134
Controls in detail Control system Instrument cluster submenu Access the submenu via INST. CLUSTER menu. Use the SETTINGS INST. CLUS- submenu to change the instrument cluster display settings. The following functions are available: Function Page Select temperature display mode Select speedometer display mode Select language Selecting temperature display mode...
Page 135
Selecting language Move the selection marker with the æ or ç button to the INST. submenu. CLUSTER Press button j or k repeatedly until you see this message in the dis- play: TEXT The selection marker is on the current setting.
Page 136
Controls in detail Control system Setting daytime running lamp mode (USA only) Move the selection marker with the æ or ç button to the LIGHT- submenu. Press button j or k repeatedly until you see this message in the dis- play: LIGHT CIRCUIT HEADLIGHT MODE The selection marker is on the current...
Page 137
Press button j or k repeatedly until you see this message in the dis- play: LOCATOR LIGHTING The selection marker is on the current setting. Press æ or ç to select the de- sired setting. The locator lighting will be switched on or off.
Page 138
Controls in detail Control system You can temporarily deactivate the de- layed shut-off feature: Before leaving the vehicle, turn the key in the starter switch to position 0. Turn the key in the starter switch to position 2 and back to 0. The delayed shut-off feature is deacti- vated.
Page 139
Vehicle submenu Access the submenu via the VEHICLE SET- menu. Use the submenu to INGS VEHICLE make general vehicle settings. The follow- ing functions are available: Function Page Set station selection mode (radio) below Set automatic locking Setting station selection mode Use the function STATION SEARCH USING...
Page 140
Controls in detail Control system Convenience submenu Access the submenu via the CONVENIENCE menu. Use the sub- SETTINGS CONVENIENCE menu to change the settings for a number of convenience features. The following functions are available: Function Page Set key dependency Activate easy-entry/exit feature 140 Set parking position for exterior rear view mirrors...
Page 141
Warning! You must make sure that no one can be- come trapped or injured by the moving steering wheel and the driver’s seat when the easy-entry/exit feature is in operation and the driver’s door is being opened or the key is removed from the starter switch. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle.
Page 142
Controls in detail Control system Setting parking position for exterior rear view mirror Use the MIRROR SETTING WHEN PARKING function to select whether the passenger side exterior rear view mirror should be turned downward during parking maneu- vers when reverse gear is engaged. For ad- ditional information see “Setting parking position for exterior rear view mirror”...
Automatic transmission Information on driving with an automatic transmission is found in the “Getting start- ed” section ( page 43). Your transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down.
Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the selector lever is in position D. Downshifting Briefly press the selector lever to the left in the D– direction. The transmission will shift from the current gear to the next lower gear.
Gear ranges With the selector lever in position D, you can limit the transmission’s gear range by pressing the lever to the left (D-), and re- verse the gear range limit by pressing the lever to the right (D+). The selected gear range will appear in the tachometer display.
Coasting the vehicle, or driving for any other reason with selector lever in N can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. Warning! Getting out of your vehicle with the selector lever not fully engaged in position P is dan- gerous.
Warning! When leaving the vehicle, always remove the key from the starter switch, take the KEYLESS-GO* card with you and lock the ve- hicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Children could move the selector le- ver from position P, which could result in an accident and/or serious personal injury.
Move selector lever to P. Turn off the engine. Wait at least ten seconds before re- starting. Restart the engine. Move selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.
Steering wheel gearshift control (Speedshift) and manual shift program CL 55 AMG The CL 55 AMG can be driven in both the automatic and manual shift program modes. In the manual shift program mode you can change the gears manually on the steering wheel or by using the selector le- ver.
Page 150
Avoid spinning of a drive wheel for an extended period when driving off on slippery surface. This may cause seri- ous damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Downshifting Press the button located on the left side of the steering wheel.
Good visibility Information on the windshield wipers ( page 47) and for setting the rear view mirrors ( page 38) is found in the “Get- ting started” section. Rear view mirror Automatic antiglare rear view mirror The reflection brightness of the exterior rear view mirror on the driver’s side and the inside rear view mirror will respond au- tomatically to glare when...
Page 152
Controls in detail Good visibility Activating exterior rear view mirror parking position The buttons are located on the driver’s door. 1 Driver’s side exterior rear view mirror 2 Passenger-side exterior rear view mirror Follow these steps to activate the mirror parking position so that the passen- ger-side exterior rear view mirror will be turned downward to the stored position.
Page 153
Folding the exterior rear view mirrors in and out manually The exterior rear view mirrors can vibrate if they are not completely folded out. The buttons are located on the driver’s door. 1 Folds the exterior mirrors out 2 Folds the exterior mirrors in Make sure the ignition is switched on.
Controls in detail Good visibility Windshield wipers Information on the windshield wipers is found in the “Getting started” section ( page 47). Intermittent wiping is interrupted when the vehicle is at a standstill and a front door is opened. A rain sensor automatically controls the windshield wipers depending on how wet the windshield is.
Sun visors The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others. Swing sun visors down when you expe- rience glare.
Controls in detail Good visibility Rear window sunshade The switch is located in the center console. Turn the key to starter switch position 1 or 2. Vehicles with KEYLESS-GO*: press the start/stop button once or twice. Press the switch briefly at 1 to raise the sunshade.
Controls in detail Automatic climate control Item 1 Center air vent, left, adjustable 2 Fixed air vent, left 3 Air volume control for left center air vent 4 Air temperature control for center air vents 5 Air volume control for right center air vent 6 Fixed air vent, right 7 Center air vent, right, adjustable...
Page 159
Automatic climate control panel Item 1 Windshield defroster 2 Rear window defroster 3 Display 4 Residual engine heat utilization 5 Automatic climate control on/off 6 Air distribution, right 7 AC cooling on/off 8 Temperature control, right 9 Air volume (automatic, manual) 10 Temperature control, left 11 Air recirculation 12 Air distribution, left...
Controls in detail Automatic climate control The current climate control settings (ON/OFF, temperature, air volume, ac- tivated charcoal filter, etc.) are stored for each electronic key before it is re- moved from the starter switch or when the vehicle is locked using the KEYLESS-GO* card ( page 105).
Turning on cooler air Turn thumbwheel 4 in the direction of the blue marking. Cooler air will enter from the center air vent. Adjusting air distribution Use the air distribution controls 12 and 6 ( page 159) to separately adjust the air distribution on each side of the passenger compartment.
Controls in detail Automatic climate control Windshield fogged on the outside Switch the windshield wipers on. Press on both U buttons until they click in. The h , V , j and k sym- bols are no longer visible. Press button , to switch off the air recirculation ( page 159).
Air recirculation mode Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside. This setting cuts off the intake of outside air and recirculates the air in the passenger compartment. Warning! When the outside temperature is below 41°F (5°C), only switch to air recirculation mode for short periods to prevent window fogging.
Controls in detail Automatic climate control Deactivating Press button , ( page 159). The indicator lamp on the button goes out. If you keep button , pressed, the side windows and the sliding/pop-up roof will be returned to their previous position.
If you keep button e pressed, the side windows and the sliding/pop-up roof will be returned to their previous positions. The system switches automatically to the air recirculation mode if the carbon monoxide (CO) or nitrogen oxide (NO concentration of the outside air increases beyond a predetermined level, for example in a tunnel.
The compressor has turned itself off. The air condition- ing cannot be turned on again. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center.
Residual heat and ventilation With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes. This feature makes use of the residual heat produced by the engine. Activating Turn the key in the starter switch to position 1 or remove it from the starter switch.
Controls in detail Automatic climate control Switching ventilation on Push upper portion of switch. Switching ventilation off Push lower portion of switch. The compartment can get very warm due to its confined space. When storing heat sensitive objects in the compart- ment, close the air vent while heating the passenger compartment.
Power windows Opening and closing the windows The side windows can be opened and closed electrically. The switches for all the side windows are on the driver’s door. The switches for the respective windows are on the passenger door and on the rear cen- ter console.
Page 170
Controls in detail Power windows Turn key in the starter switch to position 1 or 2. Opening the windows Lightly press switch k to resistance point. The window will move downwards until you release the switch. Closing the windows Lightly press switch j to resistance point.
Page 171
Stopping windows Press respective switch again. You can also open or close the win- dows using the: SmartKey, see below button O in the control panel of the automatic climate control ( page 159). button e in the control panel of the automatic climate control ( page 159).
Controls in detail Power windows Closing the side windows and sliding / pop-up roof with KEYLESS-GO* Press and hold lock button at door ( page 52) until the side windows and the sliding/pop-up roof are closed. Warning! When closing the windows and the sliding/ pop-up roof, make sure that there is no dan- ger of anyone being harmed by the closing procedure.
Sliding/pop-up roof Opening and closing the sliding/ pop-up roof 1 Push up to raise roof at rear 2 Pull down to lower roof at rear 3 Push forward to slide roof closed 4 Push back to slide roof open With the roof closed or tilted open, a screen can be slid into the roof opening to guard against sun rays.
Page 174
Controls in detail Sliding/pop-up roof Opening the sliding/pop-up roof auto- matically To select a sunroof opening position, press the switch to the resistance point and release it when the sunroof has reached the required position. The sliding/pop-up roof now opens to the position set if the switch is pressed past the resistance point in the “open”...
Opening (Summer opening feature) Press and hold button Œ after un- locking the vehicle. The windows and sliding/pop-up roof begin to open after approximately one second. Release the ‹ button to stop proce- dure. Closing (Convenience feature) Press and hold button ‹ after lock- ing the vehicle.
Controls in detail Driving systems Driving systems The driving systems of your vehicle are de- scribed on the following pages: Cruise control and Distronic*, with which the vehicle can maintain a preset speed ABC with vehicle level control systems, with which you can change vehicle sus- pension characteristics.
Page 177
1 Set current or higher speed 2 Set current or lower speed 3 Cancel cruise control 4 Resume at previously set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift 1 or depress 2 the cruise control lever.
Page 178
Controls in detail Driving systems Setting to last stored speed (“Resume” function) Warning! The speed stored in memory should only be set again if prevailing road conditions per- mit. Possible acceleration or deceleration differences arising from returning to preset speed could cause an accident and/or seri- ous injury to you and others.
Distronic* When activated, the Distronic adaptive cruise control system increases driving convenience afforded by the cruise control during travel on expressways and other major roads. If the Distronic distance sensor detects a slower moving vehicle directly ahead, your vehicle speed will be reduced so that you follow that vehicle at a preset distance.
Page 180
Controls in detail Driving systems Warning! Distronic cannot take street and traffic con- ditions into account. Only use Distronic if the road, weather and traffic conditions make it advisable to travel at a steady speed. Warning! Use of Distronic can be dangerous on slip- pery roads.
Page 181
Distronic displays in the speedometer dial Set speed If Distronic is activated, one or two seg- ments light up around the set speed. The vehicle speed displayed on the speedometer can briefly vary from the speed setting on the Distronic system. Segments If Distronic detects a vehicle directly ahead, the segments from the speed of the...
Page 182
Controls in detail Driving systems Warning! An intermittent warning sounds and the distance warning lamp in the instru- ment cluster is illuminated if the Distronic system calculates that the distance to the vehicle ahead and your vehicle’s current speed indicate that Distronic will not be ca- pable of slowing the vehicle sufficiently to maintain the preset following distance, which creates a danger of a collision.
Page 183
Distronic deactivated If Distronic is deactivated, you can see the standard display of Distronic in the multi- function display. 1 Vehicle ahead, if detected 2 Actual distance to vehicle ahead 3 Desired distance to vehicle ahead 4 Symbol for activated distance warning function 5 Your vehicle Distronic activated...
Page 184
Controls in detail Driving systems Activating Distronic You can activate Distronic if you are driving between 25 mph (40 km/h) and 110 mph (180 km/h) the ESP is activated ( page 73) If Distronic has not been activated after pressing the cruise control lever you will see the message in the multifunction display.
Page 185
Setting a lower speed Briefly tip the cruise control lever in the direction of arrow 2 ( page 183) to decrease vehicle speed in increments of 5 mph (Canada: 10 km/h). The new speed is set. The stored speed is displayed in the multifunction display for approximately five seconds ( page 183), and one or two segments around the stored speed...
Page 186
Controls in detail Driving systems Deactivating Distronic There are several ways to deactivate the Distronic system: Briefly tip the cruise control lever in the direction of arrow 3 ( page 183). Step on the brake pedal. Distronic will be deactivated. The last speed set will be stored into memory.
Page 187
1 Distance warning function on/off switch 2 Thumbwheel for setting distance Increasing distance Increasing the distance setting tells Dis- tronic to maintain a greater following dis- tance to the vehicle ahead. Turn thumbwheel 2 towards ¯ . Decreasing distance Decreasing the distance setting tells Dis- tronic to maintain a shorter following dis- tance to the vehicle ahead.
Page 188
Controls in detail Driving systems Complex driving situations are not al- ways fully recognized by Distronic. This could result in wrong or missing dis- tance warnings. Activating Press switch 1. Indicator lamp on the switch lights up. A loudspeaker symbol appears in the multifunction display ( page 183).
Page 189
The most likely cause for a malfunctioning system is a dirty sensor (located behind the hood grill), especially at times of snow and ice or heavy rain. In such a case, Dis- tronic will switch off, and the message DISTRONIC - CLEAN SENSOR! SEE OPERA- appears in the multifunction TOR'S MAN.
Controls in detail Driving systems Lane changing Distronic has not yet detected the vehicle changing lanes. There will be insufficient distance to the lane changing vehicle. Narrow vehicles Because of their narrow profiles, the vehi- cles traveling near the outer edges of the lane have not yet been detected by Dis- tronic.
Page 191
1 ABC switch 2 Indicator lamp Start the engine. Suspension for sporty driving The setting for sporty driving is selected when indicator lamp 2 is illuminated. Press ABC switch 1 to change from regular suspension to sporty driving suspension. Indicator lamp 2 comes on. Suspension for regular driving The setting for regular driving is selected when indicator lamp 2 is off.
Page 192
Controls in detail Driving systems The following vehicle level settings can be selected when the vehicle is stationary: Vehicle level when Use for stationary Normal level Normal operation Raised level 1 Driving with snow chains ( page 253) Raised level 2 Very rough road surface conditions Dependent on load...
Pressing the switch twice in quick suc- cession will cause the vehicle to imme- diately raise or lower according to the starting level. The selected vehicle level setting re- mains stored in memory even if the en- gine is turned off and restarted. Normal level (see table) Speed dependent lowering of vehicle chas- sis (approximate values):...
Page 194
Controls in detail Driving systems Warning! Make sure that no persons or animals are in the area in which you are maneuvering. You could otherwise injure them. The Parktronic system is an electronic aid designed to assist the driver during park- ing maneuvers.
Page 195
Front sensors Center approx. 40 in (100 cm) Corners approx. 24 in (60 cm) Rear sensors Center approx. 48 in (120 cm) Corners approx. 32 in (80 cm) During parking maneuvers, pay special attention to objects located above or below the height of the sensors (e.g. planters or trailer hitches).
Page 196
Controls in detail Driving systems The position of the gear selector lever de- termines which warning indicators will be activated. Selector lever Warning indicator position Front area activated R or N Rear and front area activated Neither activated As your vehicle approaches an object, one or more segments will light up, depending on the distance between your vehicle and the object.
Loading Roof rack* Warning! Use only roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Preparing roof rack installation Open trim at the trim strips in the roof. Secure the roof rack according to man- ufacturer’s instructions for installation.
Controls in detail Loading Warning! Always fasten items being carried as secure- ly as possible. In an accident, during hard braking or sud- den maneuvers, loose items will be thrown around inside the vehicle and can cause in- jury to vehicle occupants unless the items are securely fastened in the vehicle.
Useful features Interior storage spaces Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the trunk if possible. Do not pile luggage or cargo higher than the seat backs.
Page 200
Controls in detail Useful features Storage compartment in the glove box A storage compartment is located in the cover of the glove box. It can be used to store check cards, pens, a flashlight, etc. 1 Storage compartment in glove box Lightly press the marking on the lid of storage compartment 1.
Page 201
Opening storage compartment The compartment contains a coin holder. Press button 1 and lift the armrest. The storage compartment can be heat- ed or cooled. The compartment can get very warm due to its confined space. When storing heat-sensitive objects in the compart- ment, close the air vent while heating the passenger compartment.
Page 202
Controls in detail Useful features Cup holder in front of seat armrest Warning! When not in use, keep the cup holder closed while traveling. Place only containers that fit into the cup holder to prevent spills. Use lids on open containers and do not fill containers to a height where the contents, especially hot liquids, could spill during vehicle maneu- vers.
Page 203
Folding cup holder in Press the second cup holder in the di- rection of arrow 3 until it engages. Press release button 4 and fold the cup holder into the storage compartment until it engages. Close the storage compartment. Controls in detail Useful features Cup holder in rear seat armrest Warning!
Page 204
Controls in detail Useful features Opening cup holder Push front of sliding compartment 1. The cup holder slides out. Closing cup holder Push sliding compartment 1 back until it engages. Auxiliary cup holder You can fasten the auxiliary cup holder onto the left front side of the passenger seat.
Page 205
Warning! When not in use, remove the auxiliary cup holder. Place only containers that fit into the auxiliary cup holder to prevent spills. Use lids on open containers and do not fill con- tainers to a height where the contents, es- pecially hot liquids, could spill during vehicle maneuvers.
Controls in detail Useful features Parcel net in trunk You can hang a parcel net in the trunk. The hooks and the parcel net in the trunk can hold a load of up to 29.8 lbs (13.5 kg). Hang the parcel net on hooks 1 on the left and right sides of the trunk.
Rear seat ashtray Opening ashtray Pull at top of cover to open ashtray. Removing ashtray insert Press latch 1 to disengage ashtray in- sert and remove it. Reinstalling the ashtray insert Install ashtray insert. Close the ashtray. Cigarette lighter 1 Cigarette lighter Make sure the ignition is switched on.
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.
Warning! Please do not forget that your primary re- sponsibility is to drive the vehicle. A driver’s attention to the road must always be his/her primary focus when driving. For your safety and the safety of others, we rec- ommend that you pull over to a safe location and stop before placing or taking a tele- phone call.
Page 210
Controls in detail Useful features The Tele Aid system (Telematic Alarm Identification on De- mand) The Tele Aid system consists of three types of response: Automatic and manual emergency Roadside Assistance and Information The Tele Aid system is operational provid- ing that the vehicle’s battery is charged, properly connected, not damaged and cel- lular and GPS coverage is available.
Page 211
If a malfunction is indicated as outlined above, the system may not operate as ex- pected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible. Emergency calls An emergency call is initiated automatical- following an accident in which the...
Page 212
Controls in detail Useful features The Tele Aid system is available if: It has been activated and is operation- al. Activation requires a subscription for monitoring services, connection and cellular air time The relevant cellular phone network and GPS signals are available and pass the information on to the response cen- Location of the vehicle on a map is only possible if the vehicle is able to receive...
Page 213
Roadside Assistance button • . Press and hold the button (for longer than 2 seconds). A call to a Mercedes-Benz Roadside As- sistance dispatcher will be initiated. The button will flash while the call is in progress. The message...
Infor- mation regarding the operation of your ve- hicle, the nearest Mercedes-Benz Center or Mercedes-Benz USA products and ser- vices is available to you. For more details concerning the Tele Aid system, please visit www.mbusa.com and use your ID and password (sent to you sep- arately) to learn more (USA only).
Page 215
Tele Aid system has detected a fault or the service is not currently ac- tive, and may not initiate a call. Visit your Mercedes-Benz Center and have the system checked or contact the Re- sponse Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Cana- da) as soon as possible.
Page 216
In the event that you have locked your ve- hicle unintentionally (e.g. key inside vehi- cle), and the reserve key is not handy: Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
In the event your vehicle was stolen: Report the incident to the police. The police will issue a numbered inci- dent report. Give this number to the Mercedes-Benz Response Center along with the pass- word which was issued to you when you subscribed to the service.
Page 218
If you should experience diffi- culties with programming the transmit- ter, contact your authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 219
The indicator lamp on the integrated remote control will flash, first slowly and then rapidly. The rapid flashing lamp indicates successful program- ming of the new frequency signal. When the indicator lamp flashes rapid- ly, release both buttons. To program the remaining two buttons, repeat the above steps.
Page 220
Controls in detail Useful features Canadian programming During programming, your hand-held transmitter may automatically stop trans- mitting. Continue to press and hold the inte- grated remote control transmitter but- ton (refer to steps two through four in the “Programming” portion) while you repeatedly press (“cycle”) your hand-held transmitter every two sec- onds until the frequency signal has...
Infrared reflecting windshield 1 Mounting location for electronic toll collection devices (infrared transpar- ent) 2 Infrared transparent area (pass-through for electronic signals) 3 31.5 in (80 cm) 4 19.0 in (48 cm) 5 1.75 in (4.5 cm) Your vehicle is equipped with infrared re- flecting glass which reduces the amount of radiated heat entering the interior through the windows.
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Operation The first 1000 miles (1500 km) In the “Operation” section you will find de- tailed information on operating, maintain- ing and caring for your vehicle. The first 1000 miles (1500 km) The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but...
Avoid frequent acceleration and decel- eration. Have all maintenance work performed at regular intervals by an authorized Mercedes-Benz Center. Fuel consumption is also increased by driv- ing in cold weather, in stop-and-go traffic, on short trips and in hilly country.
Have the brake system inspected at an au- thorized Mercedes-Benz Center immedi- ately. All checks and service work on the brake system should be carried out by an autho- rized Mercedes-Benz Center.
ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the acceler- ator pedal and applying the brake re- duces engine performance and causes premature brake and drivetrain wear.
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for re- pairs. Tread wear indicators (TWI) are required by law. These indicators are located in six...
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires for the winter season for all four wheels to insure normal balanced handling characteristics. On packed snow, they can reduce your stopping distance in comparison to summer tires.
Operation Driving instructions CL500 (without Sport Package*) Your vehicle is factory equipped with “H”-rated tires, which have a speed rating of 130 mph (210 km/h). CL 600 (without Sport Package*) Your vehicle is factory equipped with “Y”-rated tires, which have a speed rating of 188 mph (300 km/h).
The trunk is the preferred place to carry ob- jects. Driving abroad Abroad, there is a widely-spread Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from your authorized Mercedes-Benz Center.
Refer to the radio transmitter operation in- structions regarding use of an external an- tenna. Catalytic converter Your Mercedes-Benz is equipped with monolithic type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial con- trol of the pollutants in the exhaust emis- sions.
Mercedes-Benz Center authorized techni- cians. Engine adjustments should not be altered in any way. Moreover, the specified service jobs must be carried out regularly accord- ing to Mercedes-Benz servicing require- ments. For details refer to the Service Booklet. Operation Driving instructions...
The engine should not be operated with the coolant temperature over 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! Driving when your engine is badly over- heated can cause some fluids, which may have leaked into the engine com- partment, to catch fire.
At the gas station Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious inju- ry. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! The fuel filler flap is located on the right-hand side of the vehicle towards the rear.
Operation At the gas station Leaving the engine running and the fuel cap open can cause the ? lamp to illuminate. More information can be found in the “Practical hints” section ( page 268). Check regularly and before a long trip 1 Windshield washer and headlamp cleaning system More information on refilling the reser-...
Engine compartment Hood Warning! Do not pull the release lever while the vehi- cle is in motion. Otherwise the hood could be forced open by passing air flow. Opening The hood lock release lever is located in the driver’s footwell to the left of the park- ing brake pedal.
Operation Engine compartment Warning! If you see flames or smoke coming from the engine compartment, or if the coolant tem- perature gauge indicates that the engine is overheated, do not open the hood. Move away from vehicle and do not open the hood until the engine has cooled.
Page 239
Checking the engine oil level with the control system You can check the engine oil level on the multifunction display. Turn the key in the starter switch to position 2. The standard display ( page 122) should appear in the multifunction display. Press button k or j on the steering wheel until the following mes- sage is seen in the multifunction dis-...
Page 240
Operation Engine compartment If there is excessive engine oil with the en- gine at normal operating temperature, the following message will appear: ENGINE OIL LEVEL REDUCE OIL LEVEL Have excess oil siphoned. If you want to stop the checking proce- dure, press the k or j button on the multifunction steering wheel.
Page 241
Excessive oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. Screw the filler neck cap 1 back on the filler neck.
The transmission fluid level does not need to be checked. If you notice transmission fluid loss or gear shifting malfunctions, have an authorized Mercedes-Benz Center check the automatic transmission. Active Body Control (ABC) fluid level Regular fluid level check is not required. If...
When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.
Operation Engine compartment Observe all safety instructions and precautions when handling automotive batteries. Risk of explosion Keep flames or sparks away from battery. Do not smoke. Battery acid is caustic. Do not allow it to come into contact with skin, eyes or clothing. In case it does, immediately flush affected area with clear water and seek medical help if...
Page 245
The windshield washer system on this ve- hicle is heated, so a fluid mixture produced for temperatures of approximately 14°F (–10°C) should be sufficient. 1 Washer fluid reservoir More information can be found in the “Technical data” section ( page 344). Warning! Washer solvent/antifreeze is highly flam- mable.
When replacing rims, use only genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can re- sult in the bolts loosening and possibly an accident.
Life of tires The service life of a tire is dependent upon varying factors including but not limited to: Driving style Tire pressure Distance driven Warning! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Keep unmounted tires in a cool, dry place with as little exposure to light as possible.
Page 248
Operation Tires and wheels The pressures listed for light loads are minimum values offering high driving comfort. Increased inflation pressures listed for heavier loads may also be used for light loads. These higher pressures produce favorable handling characteristics. The ride of the vehicle, however, will be somewhat harder.
Page 249
Switch on the ignition. Press button è or ÿ on the mul- tifunction steering wheel repeatedly until the standard display menu ap- pears in the multifunction display ( page 118). Press the k or j button repeat- edly until you see the current inflation pressures for each tire appear in the display.
Page 250
Operation Tires and wheels Activating the tire inflation pressure monitor You must activate the tire inflation pres- sure monitor in the following cases: If you have changed the tire pressure If you have replaced the wheels or tires If you have installed new wheels or tires Make sure that the tire pressure is cor- rectly set.
Mercedes-Benz Center. Warning! Have the tightening torque checked after changing a wheel. Wheels could become loose if not tightened with a torque of 110 ft.lb. (150 Nm). Use only genuine Mercedes-Benz wheel bolts specified for your vehicle's rims.
Operation Winter driving Winter driving Before the onset of winter have your vehi- cle winterized at an authorized Mercedes-Benz Center. This service in- cludes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system.
Chains should only be used on the rear wheels. Follow the manufacturer's mounting instructions. Use only snow chains that are ap- proved by Mercedes-Benz. Your autho- rized Mercedes-Benz Center will be glad to advise you on this subject. Do not use snow chains with tire sizes 245/45 R18 on 8½J x 18 rim and...
SERVICE A EXCEEDED BY XXXX MILES (KM) SERVICE A EXCEEDED BY XXX DAYS SERVICE A EXCEEDED BY X DAY An acoustic signal will also sound. The Mercedes-Benz Center will reset the service indicator following a completed service.
Resetting the service indicator In the event that the service on your vehi- cle is not carried out by an authorized Mercedes-Benz Center, you can reset the service indicator yourself. Switch on the ignition. The standard display of the control sys- tem appears ( page 117).
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others ap- plied later.
Page 257
Mercedes-Benz Center. The following topics deal with the cleaning and care of your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care prod- ucts. Additional information can be found in the booklet “Vehicle Care Guide“.
Page 258
Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Use only a mild car wash detergent, such as Mercedes-Benz ap- proved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 259
Cleaning the Distronic* system sensor cover 1 Distronic* system sensor cover Use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo, with plenty of water to clean sensor cover 1. To prevent scratches, never apply strong force and use only a soft, non-scratchy cloth when cleaning the sensor cover.
Page 260
Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes-Benz approved Wheel Care, us- ing a soft bristle brush and a strong spray of water. Follow instructions on container.
Page 261
By lining the seats with a proper intermediate cover, contact-discoloration will be prevented. Wipe leather upholstery with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Exercise particular care when cleaning per- forated leather as its underside should not become wet. Operation...
Practical hints What to do if …? Where will I find...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Suggested solution Turn the ESP back on ( page 75). If the ESP cannot be turned back on, have the system checked at an authorized Mercedes-Benz Center as soon as possi- ble. When driving off apply as little throttle as possible.
Page 265
Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability. Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions in- creases the risk of an accident.
Page 266
SRS may not be operational. For your safety, we strongly recommend that you visit an autho- rized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in...
Page 267
Suggested solution Release the parking brake. Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. If you find that the brake fluid in the brake fluid reservoir has fallen to the...
Page 268
The fuel cap not closed tight. Suggested solution Have the vehicle checked as soon as possible by an authorized Mercedes-Benz Center. An on-board diagnostic connector is used by the service station to link the vehicle to the shop diagnostics sys- tem.
If the light remains out, have the sys- tem checked as soon as possible by an authorized Mercedes-Benz Center. Do not use the BabySmart restraint to transport children on the front pas- senger seat until the system has been repaired.
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property dam- age or personal injury. Warning!
Page 271
Do not turn steering wheel too far to avoid damaging the front fenders. Listen for scraping noises. Do not exceed a speed of 50 mph (80 km/h). Visit a service center as soon as pos- sible. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 272
Continue driving with added caution. Wheels may lock during hard brak- ing, reducing steering capability. Have the system checked at an au- thorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions in- creases the risk of an accident.
Page 273
Have the air filter checked by an au- thorized Mercedes-Benz Center. Continue driving with added caution. Have the system checked at an au- thorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions in- creases the risk of an accident.
Page 274
Notify an authorized Mercedes-Benz Center. If it is intact: Drive immediately to the nearest au- thorized Mercedes-Benz Center. Ad- just driving to be consistent with reduced braking responsiveness.
Page 275
Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. If you find that the brake fluid in the...
Page 276
Change the position of the card in the vehicle. Operate the vehicle with the key in the starter switch if necessary. Take the card out of the vehicle. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 277
Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without a sufficient amount of coolant in the cooling sys- tem.
Page 278
Only start the engine again after the message disappears. You could oth- erwise damage the engine. The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty.
Page 279
Do not continue to drive. Otherwise the engine will overheat due to an in- operative water pump which may re- sult in damage to the engine. Notify an authorized Mercedes-Benz Center. If it is intact: Do not continue to drive the vehicle with this message displayed.
Page 280
Ignition system Exhaust system Fuel system Possible solution Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Try activating Distronic* again later. Clean the Distronic* cover in the ra- diator grille ( page 259). Restart the vehicle.
Page 281
Display ENGINE OIL LEVEL STOP, ENGINE OFF! ENGINE OIL LEVEL REDUCE OIL LEVEL ENGINE OIL VISIT WORKSHOP! Possible cause There is no oil in the engine. There is a dan- ger of engine damage. You have added too much engine oil. There is a risk of damaging the engine or the cat- alytic converter.
Page 282
( page 238) and add oil as required. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in se- rious engine damage that is not cov- ered by the Mercedes-Benz Limited Warranty.
Page 283
Practical hints What to do if …? Possible solution Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions in- creases the risk of an accident. Continue driving with added caution.
Page 284
Refuel at the next gas station ( page 235). Close the hood ( page 238). Remove the key from the starter switch. Visit an authorized Mercedes-Benz Center as soon as possible. Remove the key from the starter switch. Fold back and push the seat backrest...
Page 285
In the control system, set lamp oper- ation to manual ( page 136). Switch on headlamps using the exte- rior lamp switch. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 286
Practical hints What to do if …? Display TURN SIG., RF CHECK LIGHT! BACK-UP LIGHT ON! HIGH BEAM, L CHECK LIGHT! HIGH BEAM, R CHECK LIGHT! MARKER LIGHT, FL CHECK LIGHT! MARKER LIGHT, FR CHECK LIGHT! FR. L. PARK. LAMP CHECK LIGHT! BACK-UP LIGHT ON! FR.
Page 287
The left backup lamp is malfunctioning. Practical hints What to do if …? Possible solution Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 288
Practical hints What to do if …? Display REVERSE LIGHT, R CHECK LIGHT! REAR FOGLIGHT CHECK LIGHT! LICENSE PLATE LIGHT, L CHECK LIGHT! LICENSE PLATE LIGHT, R CHECK LIGHT! TAIL LIGHT, L CHECK LIGHT! BACK-UP LIGHT ON! TAIL LIGHT, R CHECK LIGHT! BACK-UP LIGHT ON! TURN SIG., LR...
Page 289
Practical hints What to do if …? Possible solution Visit an authorized Mercedes-Benz Center as soon as possible. Activate the tire inflation pressure monitor* ( page 248).
Page 290
Possible solution Check the tire pressure at the next service station. Have the tire inflation pressure mon- itor* checked by an authorized Mercedes-Benz Center. Change the wheel ( page 308). Check and correct tire pressure as required ( page 248).
Page 291
Display TIRE PRES. CAUTION, TIRE DEFECT! TIRE PRES. CHECK TIRES! TIRE PRES., RF CAUTION, TIRE DEFECT! TIRE PRES., RF CHECK TIRES! Warning! Do not drive with a flat tire. A flat tire affects the ability to steer or brake the vehicle. Possible cause One or more tires is rapidly deflating.
Page 292
Practical hints What to do if …? Display TIRE PRES., LF CAUTION, TIRE DEFECT! TIRE PRES., LF CHECK TIRES! TIRE PRES., RR CAUTION, TIRE DEFECT! TIRE PRES., RR CHECK TIRES! Warning! Do not drive with a flat tire. A flat tire affects the ability to steer or brake the vehicle.
Page 293
Carefully bring the vehicle to a halt. Check the tire pressure. Change the wheel ( page 308). Possible solution Have the Tele Aid system checked by an authorized Mercedes-Benz Cen- ter. Have the Tele Aid system checked by an authorized Mercedes-Benz Cen- ter.
Page 294
Close the trunk lid. Add washer fluid ( page 244). Have cruise control or Distronic* checked by an authorized Mercedes-Benz Center. Wait until the seat, mirrors and steer- ing wheel have moved to their driving positions. The message will disappear.
Where will I find...? First aid kit The first aid kit is stored in the rear center armrest. Fold rear arm rest down 1. Press handle 1 upwards. Fold lid 2 up. Remove first aid kit. Check expiration dates and contents for completeness at least once a year and replace missing/expired items.
Practical hints Where will I find...? Vehicle jack To prepare the vehicle jack for use Remove the vehicle jack from the spare wheel well under the trunk floor. Push the crank handle up. Turn the crank handle clockwise until it engages (operational position).
Unlocking/locking in an emergency Unlocking the vehicle Unlocking the driver’s door If you are unable to unlock the driver’s door using the SmartKey, open the door using the mechanical key. 1 Mechanical key locking tab 2 Mechanical key Move locking tab 1 in direction of ar- row and slide the mechanical key out of the housing.
Practical hints Unlocking/locking in an emergency Unlocking the trunk If you are unable to unlock the trunk with the SmartKey, open the trunk with the me- chanical key as follows: Trunk lock Insert the mechanical key into the trunk lid lock. Turn the key counterclockwise to position 1.
If the batteries in the SmartKey or the KEY- LESS-GO* card are discharged, the vehicle can no longer be locked or unlocked. It is recommended to have the batteries re- placed at an authorized Mercedes-Benz Center. Warning! Keep the batteries out of reach of children.
Practical hints Unlocking/locking in an emergency KEYLESS-GO* card 1 Battery cover Replacement batteries: Lithium, type CR 2025 or equivalent. Pry open cover 1 (e.g. by using a nar- row blade screw driver). Remove the batteries. Install new batteries as indicated by the “+”...
Opening/closing in an emergency Sliding/pop-up roof The sliding/pop-up roof drive is located behind the lens of the interior overhead light. You can open or close the sliding/pop-up roof manually should an electrical malfunc- tion occur. 1 Lens Pry off lens 1 using a srewdriver. Turn the key in the starter switch to position 1 or 2.
Correct headlamp adjustment is extremely important. Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See your autho- rized Mercedes-Benz Center for headlamp adjustment. Back-up bulbs will be brought into use when the following lamps malfunction:...
Page 303
Your hands should be dry and free of oil and grease. If the newly installed bulb does not light up, visit an authorized Mercedes-Benz Center. Have the LEDs and bulbs for the follow- ing lamps replaced by an authorized...
Practical hints Replacing bulbs Replacing bulbs for front lamps Warning! Do not remove the cover for the Bi-Xenon headlamp. Because of high voltage in xenon lamps, it is dangerous to replace the bulb or repair the lamp and its components. We rec- ommend that you have such work done by a qualified technician at an authorized Mer- cedes-Benz Center.
Parking and standing lamp bulb Switch off the lights. Open the hood ( page 237). Press ends of housing cover 1 tab to- gether and remove cover. Pull out the bulb socket with the bulb. Pull the bulb out of the bulb socket. Insert a new bulb in the socket.
Page 306
Practical hints Replacing bulbs Switch off the lights. Open trunk. Turn lock counterclockwise and move the trim to the side. Turn bulb socket counterclockwise and pull out. Gently twist bulb counterclockwise and pull out of bulb holder. Insert new bulb into the holder and turn it clockwise.
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
(20000 km) (aggregate of all uses) may cause wheel rim failure leading to an acci- dent and possible injuries. Drive to the nearest Mercedes-Benz-Center as soon as possible to have the spare wheel replaced with a regular road wheel. Never operate the vehicle with more than one spare wheel mounted.
Page 309
More information can be found in the “Technical data” section ( page 333). Preparing the vehicle Take vehicle tool kit tray and vehicle jack out of trunk. Take the spare wheel out of wheel well ( page 296). Lifting the vehicle Prevent the vehicle from rolling away by blocking wheels with wheel chocks (not included) or other sizable, heavy...
Page 310
Practical hints Flat tire 1 Jack support tube cover Move cover 1 toward rear by pressing at point indicated by arrow. Remove cover 1 carefully to avoid damage to the locking tabs. 1 Jack arm 2 Jack support tube hole 3 Crank Insert jack arm 1 fully into tube hole 2 up to the stop.
Page 311
Unscrew the alignment bolt, install last wheel bolt and tighten slightly. Warning! Use only genuine equipment Mercedes-Benz wheel bolts. They are identi- fied by the Mercedes star. Other wheel bolts may come loose. Do not tighten the wheel bolts when the ve- hicle is raised.
Page 312
Practical hints Flat tire Lowering the vehicle Lower vehicle by turning crank coun- terclockwise until vehicle is resting ful- ly on its own weight. Remove the jack. 1 - 5 Wheel bolts Tighten the five wheel bolts evenly, fol- lowing the diagonal sequence illustrat- ed (1 to 5), until all bolts are tight.
Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Service Booklet for mainte- nance intervals or contact your autho- rized Mercedes-Benz Center for further information. Warning! Do not place metal objects on the battery as this could result in a short circuit.
Practical hints Battery The battery is located in the trunk under the right hand wheel well cover panel. 1 Battery cover 2 Locking knob 3 Negative terminal 4 Cover over positive terminal Disconnecting the battery Turn off all electrical consumers. Depress the parking brake firmly or move the gear selector lever to posi- tion P.
Reconnecting the battery Turn off all electrical consumers. Connect the positive lead and fasten its cover 4. Connect negative lead 3. Never invert the terminal connections. The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.
(12V). Jump start- ing with a more powerful battery could damage the vehicle’s electrical system, which will not be covered by the Mercedes-Benz Limited Warranty. Use only jumper cables with sufficient cross-section and insulated terminal clamps. Always make sure that the jumper ca-...
Page 317
Remove the jumper cables first from negative terminals 2 and 4 and then from positive terminals 1 and 3. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center. Do not tow-start the vehicle.
Practical hints Towing the vehicle Towing the vehicle Mercedes-Benz recommends that the vehi- cle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. Use flatbed or wheel lift/dolly equip- ment with key in starter switch turned to position 0.
Page 319
To be certain to avoid a possibility of damage to the transmission, however, we recommend the drive shaft be dis- connected at the rear axle drive flange for any towing beyond a short tow to a nearby garage. Warning! Prior to towing the vehicle with all wheels on the ground, make certain that the key is in starter switch position 2.
Page 320
Practical hints Towing the vehicle To signal turns while being towed with the hazard warning flasher in use, turn key in starter switch to position 2 and activate the combination switch for the left or right turn signal in the usual manner –...
Installing towing eye bolt Front of vehicle 1 Cover on right side of front bumper Removing cover Press mark on cover in direction of ar- row. Lift cover off to reveal threaded hole for towing eye bolt. The towing eye bolt is supplied with the tool kit (located in the storage compart- ment under the trunk floor).
Spare fuses Special fuse extractor Only install fuses that have been tested and approved by Mercedes-Benz and that have the specified amperage rat- ing. Never attempt to repair or bridge a blown fuse. Have the cause determined and remedied by an authorized Mercedes-Benz Center.
Page 323
Do not use sharp objects such as a screw driver to open the fuse box in the dashboard, as this could damage it. Opening Open the passenger door. Using the flat of your hand, press on the middle of the cover. The edge of cover 1 lifts up slightly from the dashboard.
Practical hints Fuses Fuse boxes in engine compartment There are two fuse boxes located in the en- gine compartment on both the driver’s and front passenger side in front of the firewall (dividing wall between engine compart- ment and passenger compartment). 1 Fuse box cover, driver’s side 2 Slide 1 Fuse box cover, front passenger side...
Technical data Spare parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and Tires Electrical system Main Dimensions Weights Fuels, coolants, lubricants etc. Consumer information...
More than 300000 different spare parts for Mercedes-Benz models are available. Mercedes-Benz original spare parts are subjected to stringent quality inspections. Each part has been specifically developed, manufactured or selected for and adapted to Mercedes-Benz vehicles.
Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center. Technical data Warranty coverage...
Technical data Identification labels Identification labels 1 Certification label (on driver’s B pillar) 2 Vehicle Identification Number (VIN) (below right rear passenger seat) 3 Engine number (engraved on engine) 4 VIN, visible (lower edge of windshield) 5 Information label, California version Vacuum line routing for emission con- trol system 6 Emission control label...
Layout of poly-V-belt drive CL 500 1 Automatic belt tensioner 2 Power steering pump 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley CL 55 AMG The CL 55 AMG has two poly-V-belts (belt one shown in purple/belt two shown in black).
Poly-V-belt 7 ft 10 in (2390 mm) The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. CL 55 AMG (215.374) 4-stroke engine, gasoline injec- tion 3.82 in (97.00 mm)
Moreover, tires and rims not approved by Mercedes-Benz may, under load, ex- hibit dimensional variations and differ- ent tire deformation characteristics that could cause them to come into contact with the vehicle body or axle parts.
All season tires (radial-ply tires) 225/55 R17 97H M+S AS Winter tires (radial-ply tires) 225/55 R17 97H M+S For use with snow chains contact an authorized Mercedes-Benz Center Must not be used with snow chains CL 600 CL 55 AMG...
Technical data Electrical system Electrical system Model CL 500 Generator (alternator) 14 V/150 A Starter motor 12 V/1.7 kW Battery 12 V/95 Ah Spark plugs Bosch F 8 DPP332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque 15 –...
Technical data Fuels, coolants, lubricants etc. Please refer to the Factory Approved Ser- vice Products pamphlet, or inquire at your Mercedes-Benz Center. Fuels, coolants, lubricants etc. Recommended engine oils MB Automatic Transmission Oil Hypoid gear oil SAE 85 W 90...
Page 338
Technical data Fuels, coolants, lubricants etc. Low temperature cooling system Fuel tank including a reserve of Fuel tank including a reserve of Air conditioning system Windshield washer and headlamp cleaning system: Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and commercially available pre- mixed windshield washer solvent/antifreeze for temperatures below freezing.
Please follow FSS recommendations for scheduled oil changes. Failure to do so could result in engine damage not covered by the Mercedes-Benz Limited Warranty. Engine oil additives Do not blend oil additives with engine oil. They may be harmful to the engine opera- tion.
Therefore, the brake fluid must be re- placed every two years, preferably in the spring. Only brake fluid approved by Mercedes-Benz is recommended. Your au- thorized Mercedes-Benz Center will pro- vide you with additional information. Premium unleaded gasoline To maintain the engine’s durability and performance, premium unleaded gaso- line must be used.
Gasoline additives A major concern among engine manufac- turers is carbon build-up caused by gaso- line. Mercedes-Benz recommends only the use of quality gasoline containing additives that prevent the build up of carbon depos- its.
Coolant system design and coolant used stipulate the replacement interval. The above replacement interval is only applica- ble if MB 325.0 anticorrosion/antifreeze solution or other Mercedes-Benz approved products of equal specification (see Facto- ry Approved Service Products pamphlet) are used to renew the coolant concentra- tion or bring it back up to the proper level.
Page 343
Before the start of the winter season (or once a year in hot southern regions), you should have the anticorrosion/antifreeze concentration checked. The coolant is also regularly checked each time you bring your vehicle to your authorized Mercedes-Benz Center for service.
Technical data Fuels, coolants, lubricants etc. Windshield and headlamp washer system Both the windshield and headlamp washer systems are supplied from the windshield washer fluid reservoir. The washer fluid reservoir has a capacity of approx. 7.1 US qt. (6.7 l). Refill the reservoir with MB Windshield Washer Concentrate and water (or con- centrate and commercially available...
Consumer information The following text is published as required of all manufacturers of passenger cars un- der Title 49, Code of U.S. Federal Regula- tions, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966.” Uniform tire quality grading Quality grades can be found, where appli- cable, on the tire sidewall between tread shoulder and maximum section width.
Page 346
Technical data Consumer information Temperature The temperature grades are A (the high- est), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
(PASSENGER AIRBAG OFF indicator lamp in the cen- ter console lights up). See your autho- rized Mercedes-Benz Center for availability. BabySmart compatible child seats Special restraint system for children.
Page 348
Technical terms COMAND (Cockpit Management and Data Sys- tem) Information and operating center for vehicle sound and communications systems, including the radio and navi- gation, as well as for other optional equipment (CD changer, telephone, etc.). Control system The control system is used to call up vehicle information and to change component settings.
Page 349
(Emergency Tensioning Device) Device which deploys in certain frontal and rear collisions exceeding the sys- tem's threshold to tighten the seat belts. ->SRS (Flexible Service System) Service indicator in the multifunction display that informs the driver when the next vehicle maintenance service is due.
Page 350
Engine speeds within the red marking of the tachometer dial. Avoid this en- gine speed range, as it may result in se- rious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Parktronic* System which uses visual and acoustic signals to assist the driver during park- ing maneuvers.
Page 351
(Research Octane Number) The Research Octane Number for gaso- line as determined by a standardized method. It is an indication of a gaso- line's ability to resist undesired detona- tion (knocking). The average of both the ->MON (Motor Octane Number) and RON (Research Octane Number) is posted at the pump, also known as AN- TI-KNOCK INDEX.
ABC 190, 347 Messages in display 271 Setting vehicle level 191 ABS 23, 71, 347 ABS control 72 Malfunction indicator lamp 265 Messages in display 272 Warning lamp 265 Accelerator position, automatic transmission 148 Accident In case of 48 Activating Air conditioner (cooling) 166 Air recirculation mode 163 Anti-theft alarm system 77...
Page 354
Index Air conditioner (cooling) Turning off 166 Air pressure see Tire inflation pressure 247 Air recirculation mode 163 Activating 163 Deactivating 164 Air vents, rear passenger compartment Adjustable 168 Air volume Adjusting 162 AIRBAG OFF indicator lamp 269 Airbags 55 BabySmart deactivation system 65, 347...
Page 355
Automatic transmission 143 Accelerator position 148 Activating steering wheel gearshift control 149 Deactivating steering wheel gearshift control 150 Emergency operation (Limp Home Mode) 148 Fluid level 242 Gear ranges 145 Gear selector lever position 146 Gear shifting malfunctions 148 Kickdown 148 One-touch gearshifting 144 Program mode selector switch 147 Selector lever position 143...
Page 356
Index Bulbs, replacing 302 Additional turn signals 302 Backup lamps 303 Brake lamps 303 Fog lamps 302 Front lamps 302 High beam 302 High mounted brake lamp 303 License plate lamps 303, 306 Low beam 302 Parking lamps 302, 303, 305 Rear fog lamp 303, 305 Side marker lamps 302, 305 Standing lamps 302, 303, 305...
Page 357
Cleaning Cup holder 260 Distronic* system sensor cover 259 Gear selector lever 260 Hard plastic trim items 260 Headlamps 154 Headliner 261 Instrument cluster 260 Leather upholstery 261 Light alloy wheels 260 Parktronic* system sensor 259 Plastic and rubber parts 261 Seat belts 261 Steering wheel 260 Windows 260...
Page 358
Index Coolant 242 Adding 243 Checking level 242 Messages in display 277, 278 Temperature 234 Temperature gauge 115 Warning lamp 278 Coolant level 236 Checking 242 Courtesy lighting 113 Cruise control 176, 348 Canceling 177 Driving downhill 177 Driving uphill 177 Fine adjustment 178 Lever 183 Saving current speed 177...
Page 359
Displays Digital speedometer 122 Distronic* 181 Messages 239, 270 Service indicator 254 Showing malfunctions 131 Distance Decreasing in Distronic* 187 Increasing in Distronic* 187 Setting in Distronic* 186 Warning function 187 Distance to empty (range) Calling up 129 Distance warning function* 187 Activating 188 Deactivating 188 Distronic* warning lamp 187...
Page 360
Index Driving systems 176 ABC 190 Cruise control 176 Distronic* 179 Driving safety systems 71 Parktronic* 193 Vehicle level control 191 Easy-entry/exit feature 96 Activating 140 Electrical fuses 322 Electrical system 334 Electronic Stability Program see ESP 23, 73, 348 Emergency calls Initiating an emergency call 212 With Tele Aid 211...
Page 361
Fahrenheit Setting temperature units 134 Fastening the seat belts 40 Fine adjustment Cruise control 178 Distronic* 185 First aid kit 295 Flat tire 308 Lowering the vehicle 312 Mounting the Spare wheel 308 Preparing the vehicle 308, 309 Flexible Service System (FSS) 254, 349 Fog lamp, rear 110, 303 Replacing bulb 305 Fog lamps...
Page 362
Index Gear selector lever Cleaning 260 Position 146 Gearshift pattern for automatic transmission 43 Global Locking 81 Unlocking 81 Global Positioning System (GPS) 349 Glove box 21, 199 Closing 199 Opening 199 Good visibility 151 GPS 210, 349 Hand-held transmitter Programming integrated remote control 218 Hands-free microphone 27...
Page 363
Inside rear view mirror Adjusting 38 Antiglare 151 Installing Infant and child restraint systems 67 Wiper blades 307 Instrument cluster 21, 22, 114, 349 Cleaning 260 Coolant temperature gauge 115 Illumination 114 Multifunction display 117 Outside temperature indicator 116 Selecting language 135 Instruments and controls see Cockpit 20 Integrated remote control Canadian programming 220...
Page 364
Index KEYLESS-GO* card 83 Central locking 84 Changing the batteries 299 Checking the batteries 82, 85 Checking vehicle lock status 86 Factory setting 84 Locking the vehicle 86 Loss of 87 Messages in display 276 Reprogramming 84 Restoring to factory setting 81 Turning off the engine 51 Unlocking 83 Unlocking with 32...
Page 365
Limp Home Mode 148 Line of fall 349 Loading 197 Cargo tie-down hooks 198 Instructions 197 Roof rack 197 Locator lighting 110 Setting 136 Lock button 349 Door handle (KEYLESS-GO*) 52 SmartKey 30, 80 Trunk 86 Locking 49, 80 Central (KEYLESS-GO* card) 84 Fuel filler flap 235 Global, SmartKey 81 The vehicle with KEYLESS-GO* 86...
Page 366
Index Mirrors Activating exterior rear view mirror parking position 152 Adjusting 38 Automatic antiglare for rear view mirror 151 Exterior rear view mirror 38 Exterior rear view mirror parking position 142 Exterior rear view mirror parking positions 142 Inside rear view mirror 38 Storing exterior rear view mirror park- ing position 107 MON (Motor Octane Number) 235, 350...
Page 368
Index Passenger compartment 231 Fuse box in 322 Inside rear view mirror 38 Interior lighting 112 Parcel net in front passenger footwell 205 Passenger safety see Occupant safety 54 Pedals 225 Phone book* Loading 126 Quick search 126 Phone number* Dialing 126 Redialing 127 Plastic and rubber parts...
Page 369
Rear passenger compartment Adjustable air vents 168 Rear seat head restraints Folding back with switch 92, 97 Placing upright 98 Rear seats Head restraints 97 Rear view mirror automatic antiglare 151 Rear view mirrors see Mirrors Rear window Blocking operation 69 Rear window defroster 165 Activating 165 Deactivating 165...
Page 370
Index Safety Occupant 54 Safety belts see Seat belts 40 Safety defects Reporting 18 Safety systems Driving 71 Saving current speed 177 Screwdriver (vehicle tool kit) 295 Seat belt force limiter 63 Seat belts 60 Cleaning 261 Fastening 40 Proper use of 42, 62 Safety guidelines 58 Warning lamp 266 Seat cushion depth...
Page 371
Parking position for exterior rear view mirrors 142 Slower speed in cruise control 178 Speed in cruise control 178 Speed in Distronic* 184 Speedometer display mode 134 Station selection mode 139 Suspension tuning 190 Temperature (interior) 160 Temperature indicator 134 Units Speedometer 134 Temperature 134...
Page 372
Index Spare parts service 326 Spare wheel Mounting 308 Speed Resetting stored speed in Distronic* 185 Saving current 177 Speed settings Cruise control 178 Distronic* 184, 185 Speedometer 23 Displaying gear range 145 Displays 181 Settings units 134 Speedometer display mode Selecting 134 Sporty driving suspension 191 SRS 62, 351...
Page 373
Switching off Automatic central locking (control system) 139 Engine 51 ESP 75 Hazard warning flasher 111 Headlamps 50 Switching on Automatic central locking (control system) 139 ESP 75 Front fog lamps 110 Front lamps 108 Hazard warning flasher 111 Headlamps 46 High beams 111 Parking lamps 108 Rear fog lamp 110...
Page 374
Index Tools 295 Tow-away alarm 25, 78 Arming 78 Disarming 78 Disarming for transport 78 Towing eye bolt (vehicle tool kit) 295 Installing 321 Towing the vehicle 318 Tracking services For stolen vehicle 217 Traction 147, 351 Transmission see Automatic transmission 242 Tread depth (tires) 252 Trip computer 129...
Page 375
Useful features 199 Ashtrays 206 Cigarette lighter 207 Garage door opener 217 Interior storage spaces 199 Tele Aid 209 Telephone* 208 Vehicle Individual settings 131, 133 Locking 25 Locking in an emergency 298 Lowering 312 Proper use of 16 Service battery 313 Towing 318 Unlocking 25 Unlocking in an emergency 297...
Page 376
Index Wear pattern (tires) 251 Weights 336 Wheel change Tightening torque 312 Wheels Rotating 251 Tires and wheels 246 Window curtain airbags 59 Windows see Side windows Windshield Refilling washer fluid 244 Replacing wiper blades 307 Washer fluid 244, 344 Windshield washer 236 Windshield washer fluid Message in display 294...
Page 383
If you have any questions about service, maintenance and the carrying out thereof, seek the advice of an authorized Mercedes-Benz Center.
