Icom IC M802 Notes On Operation page 9

b. The Channel Indication display shows the label with the
channel number below. If no label has been entered, the
Receive Frequency with the channel number below will be
displayed.
2. Press the [FREQ/CH] button to display the label display if not shown.
3. Press [F] button.
4. Note: F in the upper right side of the [Function Display]
5. Press [FREQ/CH] button to display the label input. The
underscore/digit at the left most letter or blank will blinking. e.g.
WWVH 25
6. The keypad may be used to enter the label.
7. Each number also creates letters. For example the 2 key if pressed
once will insert a 2 on the display. Pressing again will display a
capital A, again B, Again C, Again a, again b, again c, again 2.
8. IF the next letter you wish to enter is on a different key, you may start pressing that key
after the first letter has been displayed.
9. IF the next letter is on the same key, e.g. A then B, you must move the flashing
underscore over to the next letter with the [CH] knob before proceeding.
Examples:
Enter a label for the time standard WWVH that is an AM station
transmitting on 25,000kHz.
For practice, enter WWVH 25M as that combination results in
using all the techniques to enter the label.
Label to enter: WWVH 25M
1. Press the [FREQ/CH] button to display the label display.
2. Press the [F]
3. Note: the flashing underscore/digit on the left side of the display.
4. Press keys [9], then [9] to display W on the [Function Display]
5. Rotate Clockwise the [CH] knob one click to move the cursor to the right one letter on
the [Function Display]
6. Press keys [9], then [9] then to display the second W on the [Function Display]
7. Press keys [8], then [8], then [8], then [8] to display V on the [Function Display]
8. Press keys [4], then [4], then [4] to display H on the [Function Display]
9. Rotate clockwise the [CH] knob one click to move the cursor to the right one letter on
the [Function Display]
10. IF there is already a letter in that position Press [1] key 6 time to show a blank [_].
and then [FREQ/CH] button to edit the label.
