Icom IC M802 Notes On Operation page 2

1. Press the [FREQ/CH] button until two frequencies are shown, one above the other.
At this point they may or may not be the same frequency. The upper is the receive
Frequency and the lower is the transmit frequency. Press the [TXF/TX] button.
2. Note: The TX in the middle left side of the [Function Display] will flash on and off.
3. Using the key pad, press [0]
4. The [Function Display] lower (smaller) number should now display 0
5. Press and Hold the [ENT] button until the TX in the middle left side is removed.
6. The channel is now programmed for no transmit frequency.
7. Note in the upper part of the [Function Display] the SIMP and DUP Indications have
been removed.
Page 39 at end of section:
