- Page 1 8501 VKR OPTION WARNING: Read and follow all directions for each step to insure proper assembly of this product. USER’S GUIDE CLASS - S Version: 8501107 PART # 7095301 Revision: 09/11/01 REV. C...
- Page 2 TABLE OF CONTENTS Safety Statement.....2 Parts list......4 General Notes....3 Assembly Instructions..4-7 Tools Required....3 General Maintenance..8 IMPORTANT SAFETY INFORMATION THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES! 1. Before using, read all the warnings and instructions 6.
- Page 3 IMPORTANT NOTES Please note: * Thank you for purchasing the LifeFitness 8501 VKR OPTION. Please read these instructions thoroughly and keep them for future reference. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.
- Page 4 PARTS LIST PART # DESCRIPTION PART # DESCRIPTION 6625608 VKR FRAME 3102502 1/2” WASHER 6625708 VKR FRAME SUPPORT 3102802 3/8” LOCK NUT 6625802 VKR FOOT STEP 3102801 1/2” LOCK NUT 6177001 NON-SKID STRIP 3102904 3/8 X 3” BOLT 6405201 2” SQ. END CAP 3102917 1/2 X 4”...
- Page 5 11 3/8 X 3” FIGURE 2 STEP 2: • SECURELY assemble two ARM PADS (14) to the VKR FRAME (1) using four 3/8 X 3” BOLTS (11) and four 3/8” WASHERS (7) as shown in FIGURE 2. 3/8 X 3” 11 FIGURE 3 STEP 3: •...
- Page 6 11 3/8 X 3” FIGURE 4 STEP 4: • LOOSELY assemble the VKR FRAME SUPPORT (2) to the VKR FRAME (1) using two 3/8 X 3” BOLTS (11), four 3/8” WASHERS (7), and two 3/8” LOCK NUTS (9) as shown in FIGURE 4. FIGURE 5 STEP 5: •...
- Page 7 REAR UPRIGHT 1/2 X 4” 12 FIGURE 6 STEP 6: • SECURELY assemble the VKR FOOT STEP (3) to the 8500 REAR UPRIGHT using two 1/2 X 4” BOLTS (12), two 1/2 WASHERS (8), and two 1/2” LOCK NUTS (10). See FIGURE 6. Thank you for purchasing the LifeFitness 8501 VKR OPTION.
- Page 8 MAINTENANCE Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your LifeFitness customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately. Failure to do so may result in serious injury * PLEASE RECORD THE INFORMATION REQUESTED BELOW.
