Page 1 If the inquiry or concern cannot be resolved at the dealership level, please contact the Ford Customer Assistance Center. In the United States: Ford Motor Company Lincoln Customer Assistance Center 300 Renaissance Center P.O. Box 43360 Detroit, MI 48243 1-800-521-4140...
Page 2 All rights reserved. Reproduction by any means, electronic or mechanical, including photocopying, recording, or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Copyright @ 1995, Ford Motor Company...
Page 3: Table Of Contents
Table of Contents INTRODUCTORY INFORMATION SAFETY RESTRAINTS STARTING YOUR CONTINENTAL WARNING LIGHTS AND GAUGES INSTRUMENT PANEL CONTROLS STEERING COLUMN CONTROLS FEATURES ELECTRONIC SOUND SYSTEMS...
Page 4 DRIVING YOUR CONTINENTAL ROADSIDE EMERGENCIES CUSTOMER ASSISTANCE ACCESSORIES SERVICING YOUR CONTINENTAL QUICK INDEX INDEX GAS STATION INFORMATION...
Page 5: Introductory Information
Introductory Information Ford's Commitment to You At Ford Motor Company, excellence is the continuous commitment to achieve the best result possible. It is dedication to learning what you want, determination to develop the right concept, and execution of that concept with care, precision, and attention to detail.
Page 6 Things to Know About Using This Guide Congratulations on the purchase of your new vehicle. This guide has information about the equipment and the options for your new vehicle. You may not have bought all of the options available to you. If you do not know which information applies to your vehicle, talk to your dealer.
Page 7 Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. The Lincoln Commitment The Lincoln Commitment is more than the prestige of owning a superior luxury automobile, it is a comprehensive owner benefits package that is designed to provide you with services to support your every driving need.
Page 8 (160 km) from home. Destination Assistance (U.S. only) In the event of a collision or mechanical breakdown, Lincoln helps get you to your immediate destination with a reimbursement allowance for emergency transportation service such as taxicabs, rental cars, shuttles, etc.
Page 9 Lincoln Customer Assistance Center If you have questions regarding your Lincoln or the Lincoln Commitment, call our Customer Assistance Center: United States 1-800-521-4140 Canada 1-800-387-9333 You may call the Customer Assistance Center, Monday through Friday, 8 a.m. to 5 p.m. in all time zones.
Page 10 Buying a Ford Extended Service Plan If you bought your vehicle in the U.S., you can buy a Ford Extended Service Plan for your vehicle. This optional contract provides service protection for a longer period of time than the basic warranty that comes with your vehicle.
Page 11 Use only the type of engine oil that Ford recommends. See Engine oil recommendations in the Index. Do not use special "break-in" oils. Cleaning the Outside of Your Vehicle Washing and Polishing Your Vehicle Wash the outside of your vehicle, including the underside, with a mild detergent.
Page 12 Cleaning Chrome and Aluminum Parts Wash chrome and aluminum parts with a mild detergent. Do not use steel wool, abrasive cleaners, fuel, or strong detergents. Cleaning Plastic Parts Some of your vehicle's exterior trim parts are plastic. Clean with a tar and road oil remover if necessary. Use a vinyl cleaner for routine cleaning.
Page 13: Safety Restraints
Safety Restraints Important Safety Belt Information The use of safety belts helps to restrain you and your passengers in case of a collision. In most states and in Canada the law requires their use. Safety belts provide best restraint when: the seatback is upright the occupant is sitting upright (not slouched) the lap belt is snug and low on the hips...
Page 14 /!\ WARNING Never wear the shoulder belt under the arm. Never swing it around the neck over the inside shoulder. Never use a single belt for more than one person or across more than one seating position. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 15 Combination Lap and Shoulder Belts While your vehicle is in motion, the combination lap and shoulder belt adjusts to your movement. However, if you brake hard, corner hard or if your vehicle receives an impact of 5 mph (8 km/h) or more, the lap and shoulder belt locks and helps reduce your forward movement.
Page 16 Unfastening the lap/shoulder belts Shoulder Belt Height Adjustment Driver and right front passenger You can adjust the shoulder belt height to one of five (5) positions. To adjust the belt down, push the release button (see figures I and 2). To adjust the belt up, slide the adjuster up.
Page 17 Figure I - The shoulder belt height adjuster Figure 2 - The shoulder belt height adjuster...
Page 18 /!\ WARNING Position the shoulder belt height adjuster so that the belt rests across the middle of your shoulder. Be sure the shoulder belt is properly positioned on your shoulder each time you use the belt. If the shoulder belt is off your shoulder, on your upper arm or neck, there is a greater risk of severe injury in a collision.
Page 19 /!\ WARNING Rear facing infant seats should never be placed in the front seat. This mode must be used when installing a child seat on the front passenger seat and rear seats where dual locking refractors are provided. To switch the retractor from the emergency locking mode to the automatic locking mode, perform the following steps: 1.
Page 20 Unfastening the lap belts in the center front seating position NOTE: Be sure to read and understand Important Safety Belt Information at the beginning of this chapter. Pull the belt across your hips and insert the tongue into the correct buckle on your seat until you hear a snap and feel it lock.
Page 21 on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended. Do not use extension to change the fit of the shoulder belt across the torso. /!\ WARNING Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury.
Page 22 in moderate to severe frontal collisions. The supplemental air bag system does not provide restraint to the lower body. /!\WARNING The supplemental air bags are not designed to protect occupants in the front center seating position. The Importance of Wearing Safety Belts /!\WARNING Safety belts must be worn by all vehicle occupants to be properly restrained and...
Page 23 The Importance of Being Properly Seated In a collision, the air bag must inflate extremely fast to help provide additional protection for you. In order to do this, the air bag must inflate with considerable force. If you are not seated in a normal riding position with your back against the seatback, the air bag may not protect you properly and could possibly hurt you as it...
Page 24 /!\ WARNING REAR-FACING INFANT SEATS SHOULD NEVER BE USED IN THE FRONT SEAT. REAR-FACING INFANT SEATS MUST ALWAYS BE PLACED IN THE REAR SEAT. Failure to follow these instructions could result in serious injury. /!\ WARNING Do not place objects or mount equipment on or near the air bag cover on the steering wheel or in front seat areas that may come in contact with a deploying air...
Page 25 The driver air bag is in the center of the steering wheel and is indicated by the letters SRS. The right front passenger seat air bag is in the upper right- hand section of the instrument panel ledge above the glove compartment. The letters SRS appear there.
Page 26 If a collision occurs, the sensors sense the severity of the impact and activates the air bags if necessary. The air bag system is designed to deploy in frontal and front-angled collisions more severe than hitting a parked vehicle (of similar size and weight) head-on at about 28 mph (45 km/h).
Page 27 Inflated driver side air bag Inflated Passenger side air bag...
Page 28 /!\ WARNING If the air bag is inflated, THE AIR BAG WILL NOT FUNCTION AGAIN AND MUST BE REPLACED IMMEDIATELY. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision. To ensure that the air bag system will operate as intended in a crash, the system is equipped with a diagnostic module, which controls a readiness lamp and a warning tone.
Page 29 /!\ WARNING Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln- Mercury dealer. Disposal of air bags or air bag equipped vehicles...
Page 30 /!\ WARNING Passengers should not be allowed to ride in the cargo area. Persons not riding in a seat with a fastened seat belt are much more likely to suffer serious injury in a collision. Cargo should always be secured to prevent it from shifting and causing damage to the vehicle or harm to passengers.
Page 31 Safety Seats for Children Use a safety seat that is recommended for the size and weight of the child. Always follow the safety seat manufacturer's instructions when installing and using the safety seat. Ford recommends the use of a child safety seat having a top tether strap.
Page 32 /!\WARNING If you do not properly secure the safety seat, the child occupying the seat may be injured during a collision or sudden stop. An unsecured safety seat could also injure other passengers. /!\WARNING Carefully follow all of the manufacturer's instructions included with the safety seat you put in your vehicle.
Page 33 Safety belt buckle placement for child seats Installing Safety Seats in the Front and Rear Seating Positions Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for the front seat passenger and rear passengers.
Page 34 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer's instructions. See Figure 2. Be sure that the belt webbing is not twisted.
Page 35 Insert the belt tongue into the proper buckle for that seating position until you hear and feel the latch engage. See Figure 3. Make sure tongue is latched securely to buckle by pulling on tongue Routing the lap/shoulder belt...
Page 36 Buckling the belt 5. Grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. At this time, the retractor is in the automatic locking mode (child restraint mode). See Figure 4. NOTE: The dual locking mode retractor must be in the automatic locking mode to properly...
Page 37 Setting the retractor to automatic locking mode Allow the belt to retract. A clicking sound will be heard as the belt retracts. This indicates the retractor is in the automatic locking mode. Pull on the lap belt portion across the child seat towards the buckle and continue to pull up on the shoulder belt portion while pushing down on the child seat allowing the shoulder belt to...
Page 39 7. Before placing the child in the child seat, forcibly tilt the seat from side to side and in forward directions to make sure that the seat is securely held in place. See Figure 7. Checking that the seat is secure...
Page 40 8. Double check that the retractor is in the automatic locking mode. Try to pull more belt out of the retractor. If you cannot, the belt is in the automatic locking mode. See Figure 8. Checking the retractor...
Page 41 9. Check to make sure that the child seat is properly secured prior to each use. If the retractor is not locked, repeat steps 6 through NOTE: To remove the retractor from automatic lock mode, allow seat belt to retract fully to its stowed position and the retractor will automatically switch back to the vehicle sensitive locking mode for normal adult usage.
Page 42 Additional kits can be obtained at no charge from any Ford or Lincoln-Mercury dealer. Safety Belts for Children Children who are too large for child safety seats should always wear safety belts.
Page 43 If the shoulder belt portion of the lap/shoulder belt can be positioned so that it does not cross or rest in front of the child's face or neck, the child should wear the lap/shoulder belt. Moving the child closer to the seat belt buckle may help provide a good shoulder belt fit.
Page 44: Starting Your Continental
Starting Your Continental Ignition Understanding the Positions of the Ignition The positions of the key in the ignition ACCESSORY allows some of your vehicle's electrical accessories such as the radio and the windshield wipers to operate while the engine is not running.
Page 45 OFF allows you to shut off the engine and all accessories without locking the steering wheel, or the gearshift lever. ON allows You to test your vehicle's warning lights (except the brake system warning light) to make sure they work before you start the engine. The key returns to the ON position once the engine is started and remains in this position while the engine runs.
Page 46 /!\ WARNING Do not leave children, unreliable adults, or pets alone in your vehicle. They could accidentally injure themselves or others through inadvertent operation of the vehicle. Further, on hot, sunny days, temperatures in a closed vehicle could quickly become high enough to cause severe and possibly fatal injuries to people as well as animals.
Page 47 Make sure that the gearshift is in P (Park) and the parking brake is set before you turn the key. Before you start your vehicle, you should test the warning lights on the instrument panel to make sure that they work. Refer to the Warning Lights and Gauges chapter.
Page 48 For a warm engine: Do not hold the key in the START position for more than five (5) seconds at a time. If the engine does not start within five (5) seconds on the first try, turn the key to the OFF position. Wait a few seconds after the starter stops, then try again.
Page 49 A computer system controls the engine's idle speed. When you start your vehicle, the engine's idle normally runs higher than when it is warmed up. These faster engine speeds will make your vehicle move slightly faster than its normal idle speed. It should, however, slow down after a short time.
Page 50 /!\ WARNING To prevent electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. For best results, plug the heater in at least three hours before you start your vehicle. Using the heater for longer than three hours will not damage the engine, so you can plug it in at night to start your vehicle...
Page 51 The left side of the trunk /!\ WARNING If you see or smell fuel, do not reset the switch or try to start your vehicle. Have all the passengers get out of the vehicle and call the local fire department or a towing service.
Page 52 Pushing Vehicles with automatic transaxles cannot be started by pushing. Follow the directions under If Your Vehicle Needs a Jump-Start in the Roadside Emergencies Chapter. Guarding Against Exhaust Fumes Carbon monoxide, although colorless and odorless, is present in exhaust fumes. Take precautions to avoid its dangerous effects.
Page 53 Have the exhaust and body ventilation systems checked whenever: your vehicle is raised for service the sound of the exhaust system changes your vehicle has been damaged in a collision Improve your ventilation by keeping all air inlet vents clear of snow, leaves, and other debris. If the engine is idling while you are stopped in an open area for long periods of time, open the windows at least one inch (2 .
Page 54: Warning Lights And Gauges
Warning Lights and Gauges Instrument cluster...
Page 55 The following warning lights and gauges are on the instrument cluster. AD of the warning lights and gauges alert you to possible problems with your vehicle. Indicator Lights and Chimes Safety Belt Warning Light and Chime This warning light and chime remind you to fasten your safety belt.
Page 56 This light comes on when the parking brake is set, or if it is not set, it comes on briefly when you turn the ignition to the START position. It normally goes off shortly after the engine starts and you release the parking brake. If the light stays on after you have fully released the parking brake, have the hydraulic brake system serviced by your dealer or a qualified service...
Page 57 Engine Oil Pressure Warning Light This light indicates the engine's oil pressure, not the oil level. However, if your engine's oil level is low, it could affect the oil pressure. The light will come on briefly when you turn your key to the START and ON position.
Page 58 Traction Control Active Light equipped) This light comes on when the Traction Contron system begins applying and releasing the brakes and adjusting the engine characteristics to limit a wheelspin condition. It will be lit for a minimum of six seconds or for the duration of the Traction Control event.
Page 59 This light comes on every time you turn the ignition to the ON or START position (engine offl. The light should go off when the engine starts and the alternator begins to charge. If the light stays on or comes on when the engine is running, have the electrical system checked as soon as possible.
Page 60 Modification or additions to the vehicle may cause incorrect operation of the OBD 11 system. Additions such as burglar alarms, cellular phones, and CB radios must be carefully installed. Do not install these devices by tapping into or running wires close to powertrain control system wires or components.
Page 61 condition occurring. A warm up cycle consists of engine start from a cold condition (engine at ambient temperature) and running until the engine reaches normal operating temperature. On the fourth engine start up, the Service Engine Soon light will turn off as soon as the engine begins to crank.
Page 62 If the light fails to Ruminate, continues to flash, remains on, or you hear a beeping sound, have the system serviced at your Ford or Lincoln-Mercury dealer immediately. Anti-Theft Alarm Light (If equipped) This light flashes on and off when the ignition is turned to the OFF position and any door is opened.
Page 63 The Instrument Cluster In addition to warning lights, the instrument cluster has a message center/odometer, a speedometer, tachometer, fuel and coolant temperature gauges. The Electronic Message Center (M/C) The Electronic Message Center only works when the ignition is in the ON position. Each time the WC is powered the display goes through a self test by displaying the PLEASE FASTEN SEATBELT message.
Page 64 Operator Selectable Features Cluster Control Buttons and Message Center Control Buttons These features are controlled by the message center control buttons located to the right of the instrument cluster. System Check Pressing the SYSTEM CHECK button causes the M/C to cycle through a status of each of the systems being monitored.
Page 65 Doors Closed Trunk Closed Trunk Closed Exterior Lamps Distance to Empty Fuel Level Traction Control (if equipped) System Warnings System warnings alert you to possible problems or malfunctions in your vehicle's operating systems. There are up to 18 warning messages which can be displayed by the M/C to show the status of the monitored systems.
Page 66 Warning messages that have been reset are divided into two categories. They will reappear on the display ten minutes from the reset or they will not reappear until an ignition OFF-ON cycle has been completed. This reappearing of warning messages is a reminder that these warning conditions still exist within the vehicle.
Page 67 If the FUEL LEVEL ERROR message is displayed this means that there is a problem with the fuel indication system and you should contact your dealer for service as soon as possible. RESET A press of the RESET button will allow you to reset the current feature displayed.
Page 68 Pressing the MENU button once will allow you to enable or disable the EXPRESS WINDOW feature. This feature allows one tap down operation on the driver's window using the window switch on the driver's door armrest. Pressing MENU again will allow you to enable or disable the AUTO DOOR LOCK feature.
Page 69 Speedometer The speedometer tells you how many miles (kilometers) per hour your vehicle is moving. Tachometer The tachometer displays the approximate engine revolutions per minute (rpm), or how fast the engine is running. You can drive your vehicle at most rpm points on the tachometer but you must stay out of the red zone.
Page 70 4. Check the coolant level following the instructions on checking and adding coolant to your engine, see the Engine Coolant in the Index. If you do not follow these instructions, you or others could be injured. If the coolant continues to overheat, have the coolant system serviced as soon as possible.
Page 71 Lincoln RESCU System (If equipped) Lincoln RESCU runs a self-test when you start your vehicle. During this test, the Lincoln RESCU warning light, located in the overhead console, will briefly illuminate. If a problem is detected during the self-check, the light will remain lit and the message "RESCU FAILURE"...
Page 72: Instrument Panel Controls
Instrument Panel Controls The instrument panel (dashboard) on your vehicle is divided into several different sections. The illustrations on the following pages show the major parts of the instrument panel that are described in this chapter. Some items shown may not be on all vehicles.
Page 73 Cluster ood release handle Rear window def roster/heated Instrument panel Light...
Page 74 The Climate Control System Electronic Automatic Temperature Control System The control for your Electronic Automatic Temperature Control (EATC) is located at the center of the instrument panel and operates only when the key is in the ON position. The EATC feature maintains the temperature you select and automatically controls the airflow for your comfort.
Page 75 To turn your EATC on, push the AUTOMATIC button or any of the six override buttons along the bottom of the control. To turn your EATC off, press the OFF button. When the system is off, the display window will be blank (dark) except when OUTSIDE TEMP has been selected.
Page 76 The display window Automatic operation Push the AUTOMATIC button and select the desired temperature. The selected temperature and AUTO will be shown in the display window. The EATC will automatically heat or cool to achieve the set temperature. Under normal conditions, your EATC will need no additional attention.
Page 77 If unusual conditions exist (i.e., window fogging, etc.), the six manual override buttons allow YOU to select special air discharge locations. A thumbwheel allows you to adjust the fan speed to suit your needs. Temperature selection The RED and BLUE buttons at the upper left of the Control are for temperature selection.
Page 78 Fan speed and thumbwheel Your EATC automatically adjusts the fan speed to the existing conditions. You must push AUTOMATIC for automatic fan speed operation. To control the fan speed yourself, use the thumbwheel which will cancel the automatic fan speed control. The thumbwheel is located at the extreme right side of the EATC control panel.
Page 79 You can override the fan speed at any time. If you use the thumbwheel to override the fan speed, the EATC will continue to control the temperature but you control the fan speed. To return to auto fan control, press the AUTOMATIC button.
Page 80 MAX A/C button The MAX A/C feature allows for faster cooling because air is drawn from inside the vehicle. Using inside air causes the fan to sound louder which is normal for this selection. The Display window will change to indicate 60°F (16°C) and MAX A/C.
Page 81 FLR & DEF button Push this button to get air to the floor and windshield defrosters at the same time. The display will show the set temperature, FLR and the Defrost symbol. If the outside temperature is about 50°F (10°C) and above, the air will be dehumidified to remove moisture.
Page 82 If the EATC is turned OFF while the outside temperature is displayed, the temperature will continue to be displayed. Press the OUTSIDE TEMP button to clear the display window. When the ignition key is turned OFF the display will be blank (dark). NOTE: The outside temperature reading is most accurate when the vehicle is moving.
Page 83 Do not put objects under the front seats that interfere with the flow of air to the back seat area. Remove any snow, ice, or leaves from the air intake area of your EATC System which could block the air intake. The intake area is located at the bottom of the windshield, under the hood at the passenger side rear corner.
Page 84 The button that controls the rear window defroster and heated outside rearview mirrors Clear away any snow that is on the rear window and outside rearview mirrors before using the defroster. With the engine running, push the defroster button. After approximately 10 minutes, the defroster will turn off.
Page 85 The high beam indicator light on the instrument cluster will not be on. NOTE: If you have a vehicle with an automatic lighting system, the DRL system is active until the automatic system turns on the headlamps. NOTE: You may notice that the lights flicker when the vehicle is turned on or off.
Page 86 Cleaning the Exterior Lamps Do not use dry paper towel, chemical solvents or abrasive cleaners to clean the lamps, as these may cause scratches or crack the lamps. Setting the Autolamp On/Off Delay System By using the autolamp, you can set the headlamps to: turn on the lamps automatically at night turn off the lamps automatically during...
Page 87 If the autolamp is active, the headlamp system will come on immediately after starting your vehicle. If your vehicle is running before you activate the autolamp, there may be a 15 second delay before the headlights illuminate. 2. Turn the ignition key to ON or start your vehicle.
Page 88 Panel dim switch The switch that controls interior lamps and instrument panel brightness To turn on the interior lights, hold the Panel Dim switch up until the interior lights turn on. To turn off the interior lights, push the Panel Dim switch down.
Page 89 Map lamp Dome lamp ON/OFF Switches The map lamps on the inside roof of the car To turn on the map lamps, push the switches in front of each lamp. On vehicles equipped with the moon roof Option, the map lamps and switches are located on the inside rearview mirror.
Page 90 Rear passenger courtesy/reading lamp Cleaning the Interior Lamps Your interior dome lamps and map lamps are plastic and should be cleaned with a mild detergent diluted in water. Rinse them with clear water. Clock The digital clock 1. To set the hour, press and hold the hour button.
Page 91 For information about the cellular phone in your vehicle, refer to the Cellular Phone User's Manual provided with your phone. For further questions about your Lincoln cellular phone, contact the Ford Cellular System at 1-800-367- 3013(U.S.). In Canada, please contact your dealer.
Page 92: Steering Column Controls
Steering Column Controls The controls on the steering column and wheel are designed to give you easy access to the controls while you are driving. The Turn Signal Lever You can use the turn signal lever on the left side of the steering column to: operate the turn signals and cornering lamps turn the high beams on/off...
Page 93 If the turn signal stays on after you turn, move the lever back to the center (off) position. A warning chime will sound after approximately one-half mile (one kilometer) of driving if you do not return the lever to off. For lane changes, move the lever far enough to signal but not to latch.
Page 94 If the washer does not work, check the washer fluid level and fill it if it is low. See the Servicing Your Continental chapter. If there is enough fluid, consult your nearest Ford or Lincoln dealer. -Mercury...
Page 95 Do not try to clean the windshield when the washer fluid container is empty or activate the washers at any time for more than 15 seconds continuously. This could damage the washer pump system. /!\ WARNING In freezing weather, the washer solution may freeze on the windshield and obscure your vision.
Page 96 Steering wheel switch for hazard flashers The control Horn To sound the horn, push the center pad area of the steering wheel Press here to sound the horn The horn on the steering wheel...
Page 97 Tilt Steering /!\ WARNING Never adjust the steering wheel when the vehicle is moving. The lever to tilt the steering wheel...
Page 98 To change the position of the steering wheel, pull the release lever on the column toward you. Tip the steering wheel to the desired position. Release the lever to lock the steering wheel in place. Speed Control Your vehicle has speed control, so you can automatically maintain a constant speed above 30 mph (48 km/h).
Page 99 The speed control switches on the steering wheel To set the speed control: 1. Press and release the ON switch. 2. Accelerate to the desired speed above 30 mph (50 km/h) using the accelerator pedal. 3. Press the SET ACCEL switch and release it immediately to set your speed.
Page 100 NOTE: If your speed increases above your set speed while driving in (Overdrive) on a downhill grade, you may want to shift to D (Drive) to reduce vehicle speed. The speed control cannot reduce the vehicle speed if it goes above your set speed on a downhill grade.
Page 101 To reset the speed control to a higher speed, follow one of these procedures: ACCEL - Press and hold the SET ACCEL switch. Release the switch when the vehicle has accelerated to the desired speed. Depress the accelerator pedal. When the vehicle attains the desired speed, press the SET ACCEL switch and release it immediately.
Page 102: Features
Features Your vehicle has a variety of features designed for your comfort, convenience and safety. Read this chapter to find out about standard and optional features. Doors Childproof Locks for the Rear Doors In addition to power locks, your vehicle has childproof locks for the rear doors.
Page 103 To set the childproof lock on each rear door, open the rear door. Find the lever at the black label with the word LOCKED in white letters. Move the lever up. To release the childproof lock, open the rear door from the outside.
Page 104 Illuminated Entry System with Theater Lighting The interior lights will illuminate for approximately 25 seconds when either front door handle is lifted, any button on the keyless entry pad is pressed, or the remote entry system UNLOCK button is pushed. If the amount of light outside your vehicle is below a predetermined level, the exterior lights will also illuminate.
Page 105 taped to the trunk lid's right hinge support bar taped to the computer module in your driver's front door When you use keyless entry, the illuminated entry system turns on the interior lights for 25 seconds and the buttons on the keypad light up. Do not push the buttons with a key, ballpoint pen, pencil, or any other hard object.
Page 106 To lock all of the vehicle's doors at the same time, press 7/8 and 9/0 at the same time. It is not necessary to first enter the keypad code. This will also arm your anti-theft system (if equipped). Autolock The Autolock feature will automatically lock all the doors when: the vehicle's doors are fully closed the ignition key is turned to the ON position...
Page 107 4. Within five (5) seconds of pressing 1/2, enter your personal code, pressing each digit within five (5) seconds of the previous digit. 5. Enter a sixth digit to indicate which Personality should be recalled by this personal code. 1/2 Recall Personality 1 3/4 Recall Personality 2 9/0 No recall An of the vehicle doors will lock and then...
Page 108 Remote Entry System With the remote entry system, you can lock and unlock the vehicle doors and open the trunk without using a key. The buttons for the system are located on the two hand held transmitters that came with your vehicle. The remote also has a personal alarm feature.
Page 109 (included) that should last for several years of normal use. If you notice a significant decrease in operating range, the batteries should be replaced. Replacement batteries can be purchased at most pharmacies, watch stores or at your Ford or Lincoln-Mercury dealer.
Page 110 NOTE: The operating range of the remote entry system can also be affected by weather conditions (such as very cold temperatures) or structures around the vehicle (buildings, other vehicles, radio and TV towers, etc.). Typical operating range will allow you to be up to 33 feet (10 meters) away from your vehicle.
Page 111: Battery Saver
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Page 112 NOTE: The factory installed Remote Entry System has a PANIC feature that also chirps the vehicle horn and flashes the interior/exterior lamps when the PANIC button on the remote entry transmitter is pushed. The PANIC alarm and the Anti-Theft alarm are two separate features. Both the anti-theft alarm and the PANIC feature can be active at the same time.
Page 113 NOTE: Be sure to close all doors completely. If not, the alarm indicator light will remain on. Remember, your anti-theft system is armed only after the alarm indicator light remains on steadily for approximately 30 seconds after the last door is closed, and then goes out.
Page 114 Triggering the alarm system The armed system will be triggered if: any door is opened without disarming the system (see previous paragraphs), or the trunk lock cylinder is removed, or NOTE: You can open the trunk with your key without setting off the alarm. the hood is opened.
Page 115 /!\WARNING Do not let children play with the power windows. They may seriously hurt themselves. Make sure occupants are clear of the window(s) before closing. NOTE: Your vehicle is also equipped with a delayed accessory timer. This allows some of your accessories to remain on for up to 10 minutes after the key is turned to the OFF position.
Page 116 To operate, briefly press the driver's window switch to the down position. The window will then open automatically. To stop automatic operation, briefly press the switch again to either the up or down position. More than a quick press of the switch provides conventional power window operation.
Page 117 To close from vent position, press and hold the switch rearward. Occasionally wiping the outside guide rail covers of the moon roof with a clean cloth will help keep the moon roof working properly. The moon roof /!\WARNING Do not let children play with the moon roof. They may seriously hurt themselves.
Page 118 The four-way head restraint Adjusting the Seats /!\ WARNING Never adjust the driver's seat or seatback when the vehicle is moving. /!\WARNING To reduce the risk of serious injury in a collision, always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 119 The controls to operate the power reclining front seats are located on the inside of each front door. The arrows on the panel show the direction of the seat movement. To move the seat back, move the switch in the desired direction. The power reclining seat switch on the driver's side Power Lumbar Support...
Page 120 Heated Seats (If equipped) The driver's and front passenger's Heated Seats are controlled by the HEATED SEATS panel, which is located directly below the Automatic Temperature Control panel. The Heated Seat System will only operate with the ignition key in the ON position and will maintain a temperature automatically once it is selected.
Page 121 2. Rotate the thumbwheel from "0" to " 1 " (the lowest heat level). Allow five minutes for the heat level to stabilize. 3. If the heat level is not high enough for comfort, select increased heat levels "2' through "5" (the maximum level).
Page 122 Memory Profile System The Personality Memory Feature customizes your Continental for up to two (2) drivers. The following features are automatically recalled when unlocking the doors using the remote entry transmitter, keyless entry keypad, or by pressing the Memory 1 or Memory 2 switches on the driver's door: All driver's seat positions except power lumbar and head restraint.
Page 123 AUTO DOOR LOCKS - automatically locks all doors when the driver shifts out of PARK, all doors are closed, and the vehicle speed is at least three mph (five km/h). HORN CHIRP - sounds an audible "chirp" when you press the LOCK button on the remote entry transmitter to verify that the doors have been locked and the vehicle's anti-theft system has been armed (if equipped).
Page 124: Auto Save
keyless entry code or the Memory I or Memory 2 switches. Keyless Entry Up to three unique keyless entry codes can be programmed by the customer. Two of the codes can be assigned to recall Personality Memory I or Memory 2. Each time the 5-digit code is entered on the keypad, the driver's door will unlock and Personality Memory 1 or Memory 2 will be recalled.
Page 125 Pressing the SELECT switch will toggle between 1, 2 or no choice. If DRIVER I or DRIVER 2 is selected, the display, SAVED TO DRIVER I or SAVED TO DRIVER 2, will appear on the Message Center to confirm the change has been automatically saved with the Personality Memory.
Page 126 Road Calibrated Suspension Your Continental is equipped with a ride control system that is designed to read disturbances in the road surface every six inches at 60 mph (100 km/h) to provide you with optimal driving response. Ride control allows you to chose both a ride feel and steering effort that best flts your personal driving style.
Page 127 Best balance of vehicle Ideal ride chassis systems Traditional luxury steer 'Set it and forget it" mode and contemporary ride Ideal steering Easy steering Soft suspension Soft suspension Broken pavement city What a Lincoln used to traffic be (and can still be!!!)
Page 128 NOTE: The combination of FIRM RIDE CONTROL and LOW STEERING EFFORT is undesirable and cannot be selected. Mirrors Automatic Dimming Inside Rearview Mirror (If equipped) Some vehicles are equipped with an inside rearview mirror and an outside driver's side mirror which have an Auto-Dimming function.
Page 129 side mirrors are controlled by the setting on the inside mirror. There are two light sensors (photocells) in this mirror. The sensor that detects rear glare is located next to the switch. The second light sensor which determines outside light level is located on the backside of the mirror case.
Page 130 power mirror switch selector switch The electric remote control mirror switch To adjust the side mirrors: 1. Find the control switch in the driver's door panel. 2. Select the right or left mirror by moving the selector switch to R or L. 3.
Page 131 Sun Visors Using the Sun Visors Your vehicle has special sun visors. Besides the regular sun visor, you have a second visor. By using both the regular sun visor and the second visor, you shield the sun from both the front and the side of the vehicle at the same time.
Page 132 Garage Door Opener If you own a garage door opener, the overhead console of your Continental contains a bin to house your hand held garage door transmitter. This feature allows you to activate your garage door opener with a push of the GARAGE button once your transmitter has been installed inside the compartment.
Page 133 Universal Transmitter (If equipped) The Universal Transmitter provides a convenient way to consolidate the functions of up to three individual hand-held transmitters into one built-in device. The Universal Transmitter: will operate garage doors, gates, home/office lighting systems, security systems, by learning and transmitting the radio frequency of your current hand-held transmitters or nearly any device that is controlled by radio frequency.
Page 134 Programming the Universal Transmitter NOTE: It is recommended that your hand-held transmitter contain fresh batteries prior to programming. /!\ WARNING Make sure that people or objects are clear of the garage door, gate, etc. while you are programming the system. To program the Universal Transmitter: Make sure your vehicle's engine is off.
Page 135 4. When the Universal Transmitter light begins to flash rapidly (this could take up to 60 seconds), release both buttons. You can now use your Universal Transmitter instead of the hand-held controller. 5. To program the other two buttons on your Universal Transmitter, skip step two and repeat steps 3 and 4.
Page 136 Operating the Universal Transmitter /!\ WARNING Do not use the Universal Transmitter with any garage door opener that lacks safety "stop" and "reverse" features as required by federal standards. To operate, press the appropriate button on the Universal Transmitter. The light will illuminate while the signal is being transmitted.
Page 137 Utility compartment armrest utility compartment beverage holder The features on the full console Cupholder with full console The cupholder provides a space for your cup. Mini console cupholders Six passenger vehicles are equipped with a mini console that is located within the ashtray panel. To open the panel, press on the front of it and release.
Page 138 Trunk Opening the Trunk Manually Locate the trunk lock in the rear reflector to the right of the license plate to insert the key. Turn the key to the right to open the trunk. The trunk lock cylinder Using the Power Trunk Release You can use your power trunk release feature in three ways: With your electric trunk release, you can open...
Page 139 open trunk lid The remote control for the trunk The trunk lid cannot be opened if your vehicle is moving faster than three mph (five km/h). Cargo Storage System (If equipped) Your vehicle may be equipped with a cargo storage system.
Page 140 To operate: Grasp and squeeze the release handle to move the cargo storage system rearward. Place groceries, packages, etc. in the cargo storage system. Grasp and squeeze the release handle to move the cargo storage system forward untfl it locks into place.
Page 141 Positive Retention Driver's Side Floor Installing the floor mat Position the floor mat in foot well. Place mat eyelet over pointed end of retention post from the rear and rotate forward to install. Adjust floor mat position to allow proper operation of accelerator pedal and brake pedal.
Page 142 Removing the floor mat Lift floor mat just forward of retention post and rotate rearward to disengage from retention post. The Electronic Compass (If equipped) The electronic compass The compass is mounted to the inside rear view mirror. The display is in the upper right hand comer of the mirror glass.
Page 143 readings after a few days, perform a compass adjustment. Compass-Calibration I . For optimum calibration, switch off all non- essential electrical accessories (rear window defrost, heater/air conditioning, map lamps, wipers, etc.) and ensure all doors are shut. 2. Drive to an open, level area away from large metallic objects or structures.
Page 144 2. Insert an appropriate diameter rod (paper clip) into the right switch access hole underneath the compass module and gently press the right button for 1-2 seconds until "ZONE" and the current zone setting appear in the display. 3. Release the right button. 4.
Page 145 At zero pressure, the Securitires will provide you with a minimum driving capability of approximately 20 miles (30 kms). How you drive and the actual amount of air pressure left in your tires will determine exactly how many miles can be driven. To extend the mileage and help prevent damage to low or deflated tires, you should: not exceed 55 mph (90 km/h) and drive at a...
Page 146 If the warning remains on after you have adjusted the tires to recommended air pressure levels, take your vehicle to an authorized Lincoln/Mercury dealer for service. Flat Tire Warning If the sensors detect a tire pressure lower than I 0 psi (68 kps), the "Low Tire Pressure" warning will flash repeatedly in the overhead console and the message "Warning Low Tire Pressure"...
Page 147 Michelin tire dealer. Lincoln RESCU System (If equipped) /!\ WARNING It is important that you understand the limitations of your Lincoln RESCU System prior to initiating an activation. See Lincoln RESCU System Limitations later in this chapter for details.
Page 148: Quick Summary
Quick Summary To utilize your vehicle's assistance request feature, YOUR CELLULAR PHONE MUST BE ACTIVATED. Roadside or emergency assistance can be requested whenever your key is in the RUN/START position and for two minutes after the vehicle is turned off. An assistance request is initiated by pressing either the tow truck or ambulance button located in the overhead console.
Page 149: General Description
The Lincoln RESCU System utilizes Global Positioning System (GPS) technology and the nation's cellular phone network to track vehicle location and, at the touch of a button, put you in voice contact with the Lincoln Security Response Center.
Page 150 When you select a button, the vehicle's cellular phone will automatically place a call to the response center's central computer. Once contact is made, an electronic data message will be transmitted. This data message will include: Type of alarm (roadside or emergency) Vehicle Identification Number (VIN) Latitude and longitude coordinates Last recorded speed and direction of the vehicle...
Page 151 When this button is pressed, the Lincoln Security Response Center relays details of your situation and your location to the United States Auto Club (USAC) via a three-way phone call. The response center/USAC will: dispatch the appropriate service vehicle to your location.
Page 152 911 or other emergency services may provide a faster response. Activation and Deactivation When either of the two Lincoln RESCU buttons is pressed, a warning light, located in the overhead console, will begin to flash and status messages will be displayed on the vehicle's message center, confirming an assistance request has been made.
Page 153 Cellular Phone Interface During an activation, Lincoln RESCU takes control of the vehicle's cellular phone. If the phone is in use, THE CALL WILL BE TERMINATED and the Lincoln Security Response Center will automatically be dialed. The cellular handset becomes inoperative and all voice communication with the operator is accomplished via the cellular phone's "hands-free"...
Page 154: Automatic Redial
Message Center (low washer fluid, low oil, door ajar, etc.), they must be cleared in order to view the LINCOLN RESCU messages. To clear the vehicle messages, press the Message Center RESET button, which is located to the right of the display.
Page 155 Location Data Retransmit Capability During an activation, the Lincoln Security Response Center operator has the capability to initiate a retransmission of the electronic data message. This may be necessary to ensure a more precise determination of vehicle location or to track a vehicle that is moving.
Page 156 Service restricted to 48 contiguous states Your Lincoln RESCU System can be activated anywhere within the 48 contiguous states. If an activation occurs outside of this region, the Lincoln Security Response Center will not be able to assist you. Inoperative if cellular phone inactive or...
Page 157 Positioning capability temporarily degraded after battery reconnect When your vehicle is started, the Lincoln RESCU GPS receiver begins the process of determining vehicle location. The receiver will search the sky and attempt to acquire signals from all visible satellites. A real-time clock and an almanac...
Page 158 (PIN). In this situation, the user is required to enter the pin with any phone calls made over the network. The Lincoln RESCU System is not compatible with the pin feature. At the time your phone is activated, ask your carrier to assign you a phone number that does not require a personal identification number entry.
Page 159 911 or other emergency services. Registration Requirement You are required to register with the Lincoln Security Response Center shortly after receiving your vehicle. The registration process is simple and can be accomplished by calling the Lincoln Security Center at 1,800-334-1327.
Page 160 An acquaintance activation is initiated by pressing either the roadside or emergency assistance button. When voice communication is established with the Lincoln Security Response Center, indicate that you are a new user and the operator will follow special...
Page 161 Lincoln RESCU system. As described previously, the acquaintance call can also be used to complete the registration for new customers. Service Charges For four years, beginning with your vehicle's warranty period, you will be entitled to unlimited activations without facing service charges.
Page 162: Electronic Sound Systems
Electronic Sound Systems Volume on Treble Bass AM Display Tape FM1/FM2 Balance DSP Blank skip Fade Seek Autoset Scan Eject Fast forward BASS TREB Tune Compact discs Tape Dolby/ Compression Shuffle Rewind Memory preset buttons Luxury Audio System (Digital)
Page 163 Volume/ Treble Bass AM Display SCAN Dolby Tape Tune Autoset Fastforward Luxury Audio System (Analog)
Page 164 Luxury Audio System Using the Controls on Your New Radio How to turn the radio on and off Press the "VOL/PUSH ON" knob to turn the radio on. Press again to turn it off. How to adjust the volume Turn the "VOL/PUSH ON" knob clockwise to increase the volume and counter-clockwise to decrease the volume.
Page 165 Manual tuning adjusts your radio to any allowable broadcast frequency, whether or not a station is present on that frequency. (See All About Radio Frequencies in this section.) Using the "SEEK" function Press the right *) side of the 'SEEK" button to select the next listenable station up the frequency band.
Page 166 Using the Automatic Memor.y Store feature (“AUTOSET”) If the memory buttons have been set, either by using the Auto Memory Load feature or if you have set them manually, the system is prepared to let you use a convenient feature called Automatic Memory Store.
Page 167 Treble control allows YOU to adjust the higher, treble frequencies of your radio to your preference. The inner ring of the "BASS/TREB" knob adjusts the treble (turn clockwise to increase treble; counterclockwise to decrease treble). Adjusting speaker balance and speaker fader Push the "BAL/FADE"...
Page 168 3. 3. "JAZZ" - Jazz club with clearly reflected sounds. 4. “'STADIUM" - Outdoor stadium with a capacity of about 30,000. 5. “NEWS" - “Voice-only" type of sound with a limited audio band. To deactivate the DSP feature, press the "( DSP )"...
Page 169 If the player is in the tape mode but not in Play, pressing the 'TAPE" button will activate play. If the "TAPE" button is pressed with no tape inserted, the display will flash "NO TAPE". How to locate a desired track on the tape There are six ways to quickly locate a desired selection on the tape.
Page 170 Using the "SCAN" function with your cassette tape player Pushing the "SCAN" button will begin the forward scan mode on the tape currently playing, stopping on each tape selection for approximately eight seconds. To stop the scan mode on the presently sampled tape selection, press the "SCAN"...
Page 171 TD El - Radio tries to change sides of tape 3 times in a 10 second span. push ,EJECT" and try another tape. if problem persists, refer problem to qualified personnel for service. TD E2 - Tape eject failure. Radio tries to eject tape and it will not eject.
Page 172 Ford 6-CD Changer Introduction The Ford 6-CD Changer is mounted in your console and holds 6 CDs, all controlled by using buttons on your Luxury Audio System. Be sure to read all of the information provided on the following pages to get the most out of this system.
Page 173 Disc magazine eject button Figure 2 3. Load discs into the disc magazine slots (numbered I through 6) one at a time with labeled surfaces upward, starting with bottom slot number I (Figure 3). Figure 3 4. Insert loaded disc magazine into chamber unit with the arrow on top of the disc magazine pointing toward the changer (Figure 4).
Page 174 Figure 4 NOTE: To remove one or more compact disc(s) from the disc magazine, push the corresponding lever(s) to the back. Disc(s) will partially come out for easy removal. 5. Close unit by sliding changer panel door to the left. The Compact Disc Changer unit is now ready to play using the controls of your Luxury Audio System.
Page 175 How to change the disc being played When in the CD mode, you can change discs by pressing the right (pop.) side of the "TUNE DISCS" button (to select the next disc) or the left ( ) side of the "TUNE DISCS" button (to select the next disc) or the left ( ) side of the “TUNE DISCS”...
Page 176 Operating the Shuffle feature The shuffle feature on your CD player allows you to listen to your disc selections in a different order. When this feature is activated, your CD player will randomly select and play tracks on the disc. Press the "SHUFFLE"...
Page 177 How to take care of and clean the CD Changer and discs To ensure the continued performance of your CD Changer carefully read the following precautions: Always handle a disc by the edge. Never touch the playing surface. Before playing, inspect all discs for any contamination.
Page 178 - TOO HOT - Mechanism over 167' Farenheit, allow to cool before playing. - NO CD - Empty slot or magazine. - NO DJ - CD Changer not connected or not communicating. Common Operating Conditions of the CD Player The following information is designed to help you recognize typical situations that could be mistakenly interpreted as mechanical malfunctions of the disc player.
Page 179 If the sound skips: Badly scratched discs or extremely rough roads will cause the sound to skip. Skipping will not damage the disc player or scratch the discs. Common Radio Reception Conditions Several conditions prevent FM reception from being completely clear and noise-free, such as the following: Distance/Strength The strength of the FM signal is directly related...
Page 180 To minimize these conditions, a stereo/mono blend circuit has been incorporated into this system. This feature automatically switches a weak stereo signal to a clearer monaural signal, which improves the quality of reception. Several sources of static are normal conditions on AM frequencies.
Page 181 Some FM radio stations advertise a "rounded- off" frequency which is not the frequency they actually broadcast on. For example, a radio station that is assigned a frequency of 98.7 MHz may call itself "Radio 99" even though 99.0 MHz is not an allowable FM broadcast frequency.
Page 182 Driving Your Continental Your vehicle has an automatic overdrive transaxle. You may be familiar with the term "transmission." We use transaxle because it is a more accurate term for vehicles that have front- wheel drive. Driving with an Automatic Overdrive Transaxle Your automatic overdrive transaxle provides fully automatic operation in either (Overdrive) or D (Drive).
Page 183 To operate: 1. Start the engine. 2. Depress and hold the brake pedal. 3. Depress the thumb button (console-mounted gearshift only). 4. Move the gearshift lever out of P (Park). Your vehicle is equipped with a Brake Shift Interlock safety feature. This feature prevents the gearshift from being moved from the P (Park) position until the brake pedal is depressed.
Page 184 Using a column-mounted gearshift If your gearshift is on the column, you can use any of the following positions: Park neutral reverst overdrive drive first The positions of the column-mounted gearshift Once you place the gearshift securely into position, gradually release the brake pedal and use the accelerator as necessary.
Page 185 Using a console-mounted gearshift (If equipped) Thumb button Park Reverse Neutral Drive First The console-mounted gearshift The console-mounted gearshift thumb button and brake pedal must be depressed to move the gearshift lever out of P (Park). The thumb button pops out automatically when the gearshift latches into position.
Page 186 Driving When to use (Overdrive) (Overdrive) is the usual driving position for an automatic overdrive transaxle. It works the same way D (Drive) works, automatically upshifting or downshifting as the vehicle speeds or slows. However, (Overdrive) also shifts into a fourth gear - an overdrive gear - when your vehicle cruises at a consistent speed for any length of time.
Page 187 /!\ WARNING Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). Never leave your vehicle unattended while it is running. You can tell a column-mounted gearshift is securely latched in P (Park) if the lever is adjacent to the P (Park) and you cannot move it without pulling it toward you and rotating it downward.
Page 188 In general, this system improves your vehicle's stability and acceleration performance when road conditions warrant. Traction Control effective at all vehicle speeds. If the Traction Control system is cycled excessively, the brake portion of the system will shut down to prevent the front brakes from overheating. A limited Traction Control function using engine torque will still control wheels from spinning.
Page 189 Never hold the steering wheel to the extreme right or left for more than five seconds if the engine is running. This can damage the power steering pump. Air Suspension Adaptive Ride Control System Your vehicle has an air suspension system with automatic load leveling and automatic ride control.
Page 190 Brakes Applying the Brakes Your vehicle has anti-lock disc brakes on all four wheels. They adjust automatically as the brake pads wear down. When you press down hard on the brake pedal, the wheels will not lock and slide. The Anti-lock Brake System (ABS) automatically starts releasing and reapplying the front brakes independently and the rear brakes together whenever your wheels start to...
Page 191: Parking Brake
NOTE: If you are driving down a long or steep hill, shift to a lower gear and do not apply your brakes continuously. If you apply your brakes continuously, they may overheat and become less effective. Occasional brake squeal during light to moderate stops does not affect the function of the brake system and is normal.
Page 192 The Parking brake /!\ WARNING Always set the Parking brake fully and make sure that the gearshift is securely latched in P (Park). /!\ WARNING If the parking brake is fully released, but the Brake System light-remains on, have the brakes checked immediately. They may not be working properly.
Page 193 You have an automatic release for the parking brake. The parking brake should automatically unlock when you move the gearshift to any forward gear while the engine is running. However, the automatic release does not work when the gearshift is in reverse, neutral or park.
Page 194 Driving in Bad Weather Slippery roads On some slippery road surfaces, front-wheel drive may provide better acceleration than rear-wheel drive. However, this does not mean that your vehicle can stop any faster or any better than a vehicle with rear-wheel drive. Exercise the same caution while driving on slippery roads with your front-wheel drive vehicle as you would with a rear- wheel drive vehicle.
Page 195 /!\ WARNING Do not spin the wheels at over 35 mph (55 km/h). The tires may fail and injure a passenger or bystander. By moving the vehicle backward and forward, you may gain enough momentum to move out of the spot.
Page 196 The weight limits of your vehicles tires affect the GVWR or GAWR limitations. Usage of replacement tires with higher weight limit than originals does not increase GVWR or GAWR. Usage of lower capacity replacement tires may lower GVWR and GAWR limitations. /!\ WARNING If the GVWR or the GAWR specified on the Safety Compliance Certification Label is...
Page 197 3. Subtract the first reading from the second to figure the total weight of the load. After determining this load, you must also make sure that the total weight of your vehicle, plus the load it carries, is less than its GVWR. Also, make sure that the weight your vehicle carries over each axle is less than the GAWR for the respective axle.
Page 198 Service your vehicle more frequently if you tow a trailer. (See Servicing your vehicle if you tow in this chapter.) Ten to 15% of the loaded trailer's weight should be on the tongue. However, the tongue load should never exceed 10% of the maximum weight that your vehicle can safely tow.
Page 199 If you are not certain that you are using the right equipment in the proper manner, see your Ford or Lincoln-Mercury dealer. Do not use hitches that clamp onto your vehicle's bumper. The bumper is not designed to bear the load.
Page 200 To connect the trailer's safety chains: 1. Cross the chains under the trailer tongue and attach them to your vehicle's frame or hook retainers. Never attach the safety chains to your vehicle's bumper. The bumper is not designed to bear the weight of a trailer. 2.
Page 201 Driving While You Tow Be especially careful when driving while you tow a trailer. Never drive faster than 45 mph (70 km/h) when you tow in hilly country on hot days. Also, anticipate stops so that you can brake gradually. Towing a trailer increases the load on the engine and transaxle, particularly in hilly country and with heavier trailers.
Page 202: Roadside Emergencies
Roadside Emergencies Jump-Starting Your Vehicle Your vehicle's battery may die if you leave the lights on or any electrical equipment on after you turn the engine off. If this happens, you may be able to jump-start from a booster battery to start your vehicle.
Page 203 /!\ WARNING Batteries contain sulfuric acid which bums skin, eyes, and clothing. If the acid touches someone's skin, eyes, or clothing, immediately flush the area with water for at least 15 minutes. If someone swallows the acid, have him or her drink lots of milk or water first, then Milk of Magnesia, a beaten egg, or vegetable oil.
Page 204 5. Turn on the heater fan in both vehicles. Press the DEFROST button. Turn off all other switches and gauges. Connecting the jumper cables 1. Connect one end of the first jumper cable to the positive (+) terminal of the discharged battery. (You can connect either jumper cable to the positive (+) terminal, as long as you use the same cable for both positive terminals.) Most...
Page 205 Alternator mounting brace stud jumper cable Booster battery The engine with jumper cables...
Page 206 Jump-Starting 1. Make sure that the jumper cables are not in the way of moving engine parts, then start the booster vehicle. Run the engine at a moderate speed. 2. Let the discharged battery charge for a few minutes and then start the disabled vehicle. It may take a couple of tries before the vehicle starts.
Page 207 Changing a Tire if you get a flat tire while you are driving, do not apply the brake heavily. Instead, gradually decrease the speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Park on a level spot, turn off the ignition, set the parking brake, and turn on the hazard flashers.
Page 208 drive through an automatic car wash with this tire. Because the temporary spare tire is smaller than a conventional tire, it reduces the ground clearance. Your vehicle may get caught in the rails and it could be damaged. Spare Tire Location The spare tire is stored under the carpet on the floor of the trunk.
Page 209 To remove the spare tire: 1. Remove the spare tire cover. 2. Unscrew the wing-nut holding down the spare tire. 3. Lift out the spare tire and jack kit. Preparing to Change the Tire 1. Make sure that your vehicle will not move or roll.
Page 210 2. Get out the spare tire and jack. /!\ WARNING To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire. 3. Remove the center ornament from the aluminum wheel with the tapered end of the wheel nut wrench which came with your vehicle.
Page 211 The notches for the jack 2. Turn the jack handle clockwise until the wheel clears the ground. Remove the wheel lug nuts. 3. Replace the flat tire with the spare tire, making sure that the air valve stem is facing outward. 4.
Page 212 (not the dealer) to get a replacement key. NOTE: If entire lug wrench/lug nut key assembly is lost, see Your nearest Ford Or Lincoln-Mercury dealer who has access to a master set of keys. DO NOT USE A POWER IMPACT WRENCH...
Page 213 Lug nut key Anti-theft lug nut anti-theftft lug nut and key Removing the anti-theft lug nut Insert the key over the locking lug nut. Make sure that you hold the key square to the lug nut. If you hold the key on an angle, you may damage the key and the lug nut.
Page 214 Towing Your Vehicle If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. Typical towing options include wheel lift towing or flat bed towing. Front towing Rear towing When calling for a tow truck, tell the operator what kind of vehicle you have.
Page 215 (out of gas, need a tow, etc.) or emergency assistance (involved in an accident, report a crime or fire, require medical attention, etc.). See Lincoln RESCU System in the Features chapter for more information.
Page 216: Customer Assistance
Ford recommends taking your vehicle to your selling dealer who wants to ensure your continued satisfaction. You may, however, take your vehicle to any authorized Ford or Lincoln-Mercury dealer. In most cases, your dealer will be able to resolve your concern.
Page 217 Assistance Center. If you still have a service or product complaint, you may wish to contact the Dispute Settlement Board (U.S. only) or the Lincoln Centre (in Canada), The Dispute Setdement Board (U.S. Only) The Dispute Settlement Board is a voluntary,...
Page 218 What Kind of Cases Does the Board Review? The Board reviews all product performance and service complaints on Ford, Mercury and Lincoln Cars and Ford and Mercury Light Trucks under warranty that have not been resolved by a dealer or Ford Motor Company.
Page 219 How Does the Board Work? The Board has four members: three consumer representatives a Ford or Lincoln-Mercury dealer Consumer candidates for Board membership are recruited and trained by an independent consulting firm. Dealers are chosen because of their business leadership qualities.
Page 220 The decisions of the Board, however, may be introduced into evidence by any party in subsequent legal proceedings that may be initiated. How Do You Contact the Board? Write to the Board at the following address to request a brochure/apphcation. You will be sent a brochure and a one-page customer application form.
Page 221 the date of repair and the mileage at the time of repair the current mileage the name of the dealer who sold you the vehicle or who serviced your vehicle a brief description of your unresolved complaint a brief summary of actions that were taken with the dealer and Ford Motor Company the names (if known) of all people you contacted at the dealership...
Page 222 P.O. Box 1580, Station B Mississauga, Ontario L4Y 4G3 1-800-387-9333 Please have the following information available when contacting the Lincoln Centre: your telephone number (both business and home) the name of the dealer and the city where the dealership is located...
Page 223 Canadian Motor Vehicle Arbitration Plan (CAMVAP) If a specific item of concern arises, where a solution cannot be reached between a vehicle owner, Ford of Canada, and/or one of its dealers (that all parties can agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 224 Getting Help Outside the U.S. and Canada Before you export your vehicle to a foreign country, contact the appropriate foreign embassy or consulate to make sure local regulations do not prevent you from registering your vehicle. Officials at the embassy can also help you decide whether you should import your vehicle to that country.
Page 225 If you are in other foreign countries, contact the nearest Ford dealership. If the dealership cannot help you, they can direct you to the appropriate Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S. or Canada, register your Vehicle Identification Number and new address with Ford Motor Company Export Operations.
Page 226: Accessories
Accessories Ford Accessories for Your Vehicle A wide selection of accessories is available through your local authorized dealer. These fine accessories have been engineered specifically to fulfill your automotive needs. They are custom designed to complement the style and aerodynamic appearance of your Ford-built vehicle.
Page 227 Travel Heavy-duty battery Comfort and convenience Engine block heater Cargo net Protection and appearance Carpeted floor mats Cleaners, waxes and polishes Styled wheel protector locks Super Seal undercoating (in U.S. only) Touch-up paints Vinyl protectant Wheel splash guards (flat) Vehicle security system...
Page 228 NOTE: When adding accessories, equipment, passengers, and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR, GAWR as shown on the Safety Compliance Certification Label). Consult your dealer for specific weight information. NOTE: The Federal Communications Commission (FCC) or in Canada the Canadian Radio Telecommunications Commission (CRTC) regulates...
Page 229 OR ORDER TOLL FREE: 1-800-782-4356 Monday - Friday 8:00 A.M. - 6:00 PM. EST For Credit Card Holder Orders Only 1996 Continental Owner Manual Order Form DESCRIPTION 1996 Continental Service Manual 1996 Powertrain ControVEmission Diagnosis 1996 Car Service Spec. (FWD/RWD) 1996 Continental Electrical &Vacuum Troubleshooting Manual...
Page 232 For that special look of distinction. you have been provided a pull apart Registered Key Ring. This Key Ring carries the prestigious Lincoln Star Logo and is registered on the reverse side to facilitate its return should it ever become lost.
Page 233: Servicing Your Continental
Servicing Your Continental Service Made Easy Ford has two goals for servicing your vehicle. 1. When we can, we design parts that do not need to be serviced. 2. We want to make servicing your vehicle as easy as possible. To help you: We highlight do-it-yourself items in yellow in the engine compartment so that you can find them easily.
Page 234 Use only recommended fuels, lubricants, fluids, and service parts conforming to Ford specifications. Motorcraft parts are designed and built to provide the best performance in your vehicle. Using these parts for replacement is your assurance that Ford-buflt quality stays in your vehicle.
Page 235 Precautions When Servicing Your Vehicle Be especially careful when inspecting or servicing your vehicle. Here are some general precautions for your safety: Do not work on a hot engine. The engine cooling fan may come on unexpectedly. Always turn the engine off and let it cool. /!\ WARNING The cooling fan is automatic and may come on at any time.
Page 236: Index
3. Block the wheels. This will prevent your vehicle from moving unexpectedly. Working with the engine on: 1. Set the parking brake fully and make sure that the gearshift is securely latched in P (Park). 2. Block the wheels. This will prevent your vehicle from moving unexpectedly.
Page 237 Go to the front of the vehicle and release the auxiliary latch that is located under the hood at the center of the vehicle. Auxiliary hood release The auxiliary latch under the front edge of the hood The hood release under the instrument panel 3.
Page 238 Whenever you close the hood, latch it securely. NOTE: Apply lubricant to the hood latch at six- month intervals to maintain smooth and trouble- free operation. NOTE: Read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter before opening the hood.
Page 239 Engine coolant reservoir Power steering fluid reservoir Windshield washer fluid reservoir Engine oil filler cap Hood safety release High current fuse box Engine oil dipstick Air filter Engine compartment service points...
Page 240 Filling the Fuel Tank The fuel filler door cannot be opened from outside the vehicle. To unlatch the fuel door, push on the fuel door button located on the driver side door trim. The fuel door is on the exterior of passenger side, near the back of the vehicle.
Page 241 Fuel door release - manual override 1. After opening the fuel filler door, remove the cap carefully and slowly by turning it counterclockwise 1/2 to 3/4 turn. If a hissing sound is heard, wait until it stops, then continue turning until the cap is free. /!\ WARNING If the fuel cap is venting vapor or if you hear a hissing sound, wait until it stops before...
Page 242 /!\ WARNING If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision. NOTE: If you replace your fuel cap with an aftermarket fuel filler cap, the customer warranty may be void for any damage to the fuel tank and/or fuel system.
Page 243 If you are experiencing starting, rough idle or hesitation problems when the engine is cold, it may be caused by fuel with low volatility. Try a different brand of fuel. If the condition persists, see your dealer or a qualified service technician. Gasolines for clean air Fuels in certain areas of the country are required to contain oxygenates to improve air quality.
Page 244 Avoid breathing vapors while refueling. If fuel is splashed on the skin, wash with soap and water. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes, and seek medical attention. Gasoline and gasoline blends may contain small amounts of carcinogens, such as benzene.
Page 245 Fuel Economy Fuel economy is an estimate of the efficiency of your vehicle and can be calculated as Miles Per Gallon (MPG) or liters Per 100 Kilometers (L/ 100K). Do not calculate fuel economy during your vehicle's break-in period. This would not be an accurate estimate of how much fuel your vehicle will normally use.
Page 246 Using speed control in hilly terrain Extended use of the A/C, defroster, rear window defroster and other accessories Underinflated tires Heavy loads Aftermarket add-ons such as bike, ski or luggage racks, bug deflectors, etc. Self-Service Pointers If you choose to do your own fueling, you should also perform a few simple maintenance routines.
Page 247 The API Certification Mark Never use: "Non-Detergent" oils Oils labeled API SA, SB, SC, SD, SE, SF or Additional engine oil additives, oil treatments or engine treatments Engine oils with an SAE 5W-30 viscosity are PREFERRED for your vehicle. They provide the best engine performance, fuel economy and engine protection for all climates down to -15 F (-25 C).
Page 248 2. Set the parking brake, making sure the gearshift is securely latched in P (Park). 3. Open the hood. Protect yourself from engine heat. 4. Locate the engine oil dipstick (highlighted in yellow) and carefully pull it out of the engine. 5.
Page 249 Changing the Engine Oil and the Oil Filter Refer to the Maintenance Schedule and Record booklet for recommended intervals. /!\ WARNING Continuous contact with USED motor oil has caused cancer in laboratory mice. Protect your skin by washing with soap and water. Engine Coolant Checking the Engine Coolant NOTE: Be sure to read and understand...
Page 250 Your vehicle's coolant protects your engine from overheating in the summer and from freezing in the winter. Check the level of the coolant at least once a month. Simply look at the engine coolant reservoir located in the engine compartment. To locate the reservoir, see the diagram of your vehicle's engine under Engine Type, in this chapter.
Page 251 2. When the engine is cool, wrap a thick cloth around the cap and turn it slowly counter- clockwise to relieve pressure. 3. Step back while the pressure releases. 4. When you are sure that all the pressure has been released, use the cloth to turn and remove cap.
Page 252 your engine cooling system. Follow the recommended service interval for changing your engine coolant. NOTE: When you change or add engine coolant, it is important to maintain your engine coolant concentration between 40% (-11 F [-24 C]) and 60% (-62 F [-52 C]), depending on your local climate conditions.
Page 253 Engine coolant drain and flush Proper procedures for a complete coolant drain and flush of the cooling system can be found in the Car Service Manual. Following these recommended procedures will ensure that the specified coolant level and a 50/50 or appropriate mixture of coolant and water is maintained.
Page 254 Select maximum heater temperature and fan speed settings. Position control to discharge air at A/C vents in instrument panel. Start engine and allow to idle. While engine is idling, feel for hot air at A/C vents. NOTE: IF AIR DISCHARGE REMAINS COOL AND ENGINE TEMPERATURE GAUGE DOES NOT MOVE, SHUT ENGINE OFF IMMEDIATELY.
Page 255 The low-maintenance battery has removable vent caps for checking the electrolyte level and adding water. The electrolyte level should be checked at least every 24 months or 24,000 miles (40,000 km) in temperatures up to 90'F (32'C) and more often in temperatures above 90'F (32'C).
Page 256 If you do not let the engine relearn its idle, the idle quality of your vehicle may be adversely affected until the idle is relearned. Your vehicle will eventually relearn its idle while you drive it, but it takes much longer than if you use the previous procedure.
Page 257 (temperatures below 32 F [0 C]). State or local regulations on Volatile Organic Compounds (VOC's) may restrict use of the most common antifreeze, methanol. Washer fluids containing non- methanol antifreeze agents should be used only if they provide cold weather protection without damaging the vehicle's paint finish, wiper blades, and windshield washer system.
Page 258 Keep your tires inflated to the recommended pressures. Stay within the recommended load limits (see Load limits in the Index). Make sure the weight of your load is evenly distributed. If you do not take these precautions, your tires may fail or go flat.
Page 259 Do not include the spare tire as part of your rotation. For tire rotation intervals, see the Maintenance Schedule. If you notice that the tires wear unevenly, have them checked. Rotating the tires Replacing the Tires Replace any tires that show wear bands. When your tire shows a wear band, it has only I/ 1 6 inch (2 mm) of tread left.
Page 260 /!\ WARNING When replacing full size tires, never mix radial, bias-belted, or bias-type tires. Use only the tire sizes that are listed on the tire pressure decal. Make sure that all tires are the same size, speed rating, and load-carrying capacity.
Page 261 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 262 loading, either separately or in combination, can cause heat buildup and possible tire failure. Snow tires The tires on your vehicle have all-weather treads that provide traction in rain or snow. However, during the winter months in some climates, you may need to use snow tires.
Page 263 See Securitires in the Features chapter for more information. Automatic Transaxle Fluid Under normal circumstances, you do not need to check the fluid level of the transaxle, since your vehicle does not use up transaxle fluid. Refer to the Maintenance Schedule and Record booklet for replacement intervals.
Page 264 If the vehicle has not been driven and the fluid level is above the bottom dimple on the dipstick, do not add fluid. Recheck the fluid level after your vehicle has reached normal operating temperature. Normal operating temperature is reached after driving approximately 20 miles (30 km).
Page 265 Brake Fluid Under normal circumstances, your vehicle should not use up brake fluid rapidly. However, expect the level of the brake fluid to slowly fall as you put more mileage on your vehicle and the brake lining wears. You should check the brake fluid at every scheduled engine oil change, but be sure to check it at least once a year.
Page 266 /!\ WARNING Do not let the reservoir for the master cylinder run dry. This may cause the brakes to fail. The brake fluid reservoir Power Steering Fluid Check the level of the power steering fluid at least twice a year (i.e., every Spring and Fall). Checking and Adding Power Steering Fluid 1.
Page 267 3. Turn the engine off and check the level on the power steering reservoir. 4. The fluid level is viewed through the sight window on the power steering reservoir. If the power steering fluid is below the middle line, add fluid in small amounts, continuously checking the level.
Page 268 Use only MERCON ATF power steering fluid. If the power steering fluid is low, do not drive your vehicle for a long period of time before adding fluid. This can damage the power steering pump. Fuses Fuses (conventional and high current) protect your vehicle's electrical system from overloading.
Page 269 The instrument panel fuse panel location Emergency brake pedal Squeeze here to remove fuse panel cover...
Page 270 The instrument panel fuse panel...
Page 271 The Instrument Panel Fuses Fuse Fuse Amp Description Location Rating n And-theft indicator light n PWM dimming output for microphone illumination, ashtray illumination (R & L rear door),heated seat switches, heated backlight switch, EATC control panel, message center switches, cigar lighter, console shift illumination, navigation display module, and...
Page 272 Fuse Fuse Amp Description Location Rating Blower motor relay coil EATC control Airbag diagnostic Windshield wiper motor Windshield wiper control module (washer pump motor) PCM power relay coil Ignition coil SCP network Stand alone clock illumination Right and left rear side marker lamps License lamps Right and left tail lamps...
Page 273 Fuse Fuse Amp Description Location Rating Shift interlock VDM logic power Instrument cluster logic power Rear defrost control Luxury RCU station signal Navigation module signal Heated mirror right Heated mirror left Voltage dimming for FCU and stand alone clock Courtesy lamps in the doors Rear reading lamps Map lamps RH &...
Page 274 These, like fuses, open when the circuit load exceeds their amperage rating. High current fuses may be purchased from your Ford or Lincoln-Mercury dealer. The high current fuse panel is located in the engine compartment on the left-hand fender apron.
Page 275 The underside of the high current fuse panel cover...
Page 276 Fuse Maxi-Fuse Description Location Rating EATC blower motor Engine cooling fans Air suspension compressor relay ABS module EVAC and fill Fuse panel to LCM OBD 11 Fuse panel to LCM CD player Heated mirrors Heated backlight LH power windows Door locks RH power windows Ignition switch to fuse panel Ignition switch to fuse panel...
Page 277 Fuse Maxi-Fuse Description Location Amp Rating Not used Relay HI beam headlamps relay Fuel pump Thermactor pump Relay EATC blower motor relay Not used Relay Horns relay Relay Powertrain control module relay Checking and Replacing Fuses If you need to check a fuse, follow these steps: 1.
Page 278 The side view of a Blade type fuse The side view of a high current fjuse 4. Replace the fuse with one that has the right amperage rating. (See the following charts.) Instrument Panel Amperage Fuse Color Blue Yellow Green High Current Fuse Amperage Color...
Page 279 /!\ WARNING Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 5. Align the edge of the cover with the edge of the fuse panel and push the cover up until it latches.
Page 280 the headlamp beams are pointed substantially away from a position slightly down and to the right Headlamp Bulb The headlamps on your vehicle use replaceable bulbs. When the lamp bums out, simply replace the bulb, rather than the whole lamp. /!\ WARNING Handle a halogen headlamp bulb carefully and keep out of children's reach.
Page 281 1. Make sure that the headlamp switch is in the OFF position. 2. Lift the hood and remove the plastic sight shield covering the back of the headlamps by lifting up on the rear corners to release the velcro attachments. Lift the shield and pull towards the windshield.
Page 282 2. Slip the bulb retaining ring over the plastic base until it contacts the rear of the socket. Lock the ring into the socket by rotating it clockwise until you feel a "stop". 3. Push the electrical connector into the rear of the plastic base until it snaps, locking it into position 4.
Page 283 NOTE: The following procedure assumes that the vehicle's front structure is in factory alignment condition. If the vehicle has been in an accident requiring the front end of the vehicle to be repaired, the horizontal indicator should be recalibrated by the servicing facility. Before adjusting your headlamps, you must make sure that the air suspension has been adjusted to the proper ride height.
Page 284 Horizontal aim adjustment 1. Open the hood and lift the front end cover from its velcro attachments. Locate the horizontal level indicator and adjustment screw. 2. Use a 4mm socket and ratchet to turn the horizontal adjusting screw until the horizontal indicator is in line with the "0"...
Page 285 Overhead console-reading lamps (without moon roof) Passenger assist handle (rear seat) Under instrument panel *NA means Natural Amber. 1445 **Refer bulb replacement to a Ford -authorized radio service center. ***Refer bulb replacement to a Ford or Lincoln-Mercury dealer. Tradenumber 1893 214-2 211-2 211-2...
Page 286 Emission Control System Your vehicle is equipped with three (3) catalytic converters which are used to enable your vehicle to comply with applicable exhaust emissions requirements. /!\ WARNING Exhaust leaks may result in the entry of harmful and potentially lethal fumes into the passenger compartment.
Page 287 Ford strongly recommends the use of genuine Ford replacement parts. If other than Ford or Motorcraft parts or Ford authorized remanufactured parts are used for maintenance replacements or for the service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 288 Information about your vehicle's emission control system is on the Vehicle Emission Control Information decal located on or near the engine. This decal identifies engine displacement and gives some tune-up specifications. Readiness for Inspection/Maintenance Testing In some localities it may become a legal requirement to pass an Inspection/Maintenance (I/M) test of the On-Board Diagnostic (OBD) II system.
Page 289 3. Drive to accumulate at least four (4) minutes in the range of 30-45 mph (50-70 km/h). If stop and go conditions occur, the accumulative time must be within the 30-45 mph (50-70 km/h) range. No wide open throttle conditions should be encountered. 4.
Page 290 Motorcraft Parts If you replace Use the Motorcraft Service these parts ... Part with this part number AWSF-32EE** spark plug* FA-1615 air filter FG-800A fuel filter FL-820 oil filter standard BXT-65-850 battery *Refer to Vehicle Emission Control Information (VECI) decal for spark plug and gap specifications. **If a spark plug is removed for examination, it must be reinstalled in the same cylinder.
Page 291 Lubricant Specifications Item Ford Part No. Brake Master Cylinder C6AZ-19542-AA Hinges, Door Latch, Hood DOAZ-19584-AA Latch Auxiliary Latch, Trunk and Liftgate Latches Lock Cylinders E8AZ-19A501-B Transaxle, Automatic XT-2-QDX Constant Velocity Joints E43Z-19590-A Outboard and Inboard Engine Coolant E2FZ-19549-AA Power Steering (Pump XT-2-QDX Reservoir) Engine Oil...
Page 292: Maintenance Tips
NOTE: Rear axle lube quantities must be replaced every 100,000 miles (160,000 km) or if the axle has been submerged in water. Otherwise, the lube should not be checked or changed unless a leak is suspected or repair required. Vehicle Storage Maintenance Tips If you plan on storing your vehicle for an extended period of time (60 days or more), refer to the...
Page 293 Engine Start engine every 15 days. Run at fast idle until it reaches normal operating temperature. With your foot on the brake, shift through all the gears while the engine is running. Fuel system Fill fuel tank with high-quahty, premium unleaded fuel until the first automatic shutoff of the fuel pump nozzle.
Page 294 Battery Check and recharge as necessary. Keep connections clean and covered with a light coat of grease. If storing your vehicle for more than 30 days without recharging the battery, disconnect the battery cables to ensure battery charge is maintained for quick starting. NOTE: If battery cables are disconnected, it will be necessary to reset any memory features (eg.
Page 296 labels Air Bag warning Child Seat Label Child seat installation precautions Fuel Pump Shut-Off Safety Compliance Certification Label manufacturer, GVWR* GAWR** Vehicle Identification Servicing or warranty Information Number Child Proof Lock Gross Vehicle Weight Rating **Gross Axle Weight Rating...
Page 297 Engine compartment/ Servicing Windshield wipers Headlamp bulbs and Daytime Running Lights Hood latch Turn signal bulbs Parking lamp bulbs Cornering lamp bulbs Moon roof Keyless entry Side view mirrors Tires...
Page 298 Trunk Taillamp bulbs Backup lamp bulbs Brakelamp bulbs Turn signal bulbs High-mount brakelamp bulbs Fuel door Doors...
Page 299 Turn signals Windshield wiper Fuse panel Hood release Parking brake Gearshift- Automatic transmission Seats Speed control Head restraints...
Page 300 Remote fuel door release Seat controls Remote trunk release Side mirror controls Memory profile buttons power locks window controls...
Page 301 Lights Traction control Tilt steering Driver-side air bag Lights Traction Cluster Electronic sound system Tilt steering Rear window/ side mirror Driver-side defroster air bag Message center buttons Clock Climate control system Passenger-side air bag...
Page 302 Brake warning indicator Engine oil pressure light Traction control active light Charging system warning light Fuel gauge ANTI THEFT active light Service engine soon warning light Engine coolant temperature gauge Safety belt light Turn signal indicator lights High beam light Air bag readiness light Speedometer Tachometer Anti-theft active light Anti-lock brake warning indicator Message center Odometer...
Page 303 Fuel pump shutoff switch Air suspension shutoff switch Spare tire Cargo storage system Fuel door manual release...
Page 304 Engine coolant reservoir Power steering fluid reservoir Windshield washer fluid reservoir Automatic transaxlefluid dipstick Brake master cylinder Engine oil filler cap Hood safety release Engine oil dipstick High current fuse box Battery...
Page 305 Index ABS warning light... (see Anti-lock brake system) ... 53 Accessory position on the ignition ... 41 Accident damage... 232 Additives, engine oil... 245 Air bag supplemental restraint system... description... 17 disposal ... 25 indicator light ... 59 operation ... 20 proper seating...
Page 306 Anti-theft system... arming the system ... 109 description... 108 disarming an untriggered system ... 110 disarming a triggered system ... 111 triggering ... 111 warning light... 59 Assistance (see Customer assistance)... 213 Audio system ... (see Electronic sound system) ... 159 Automatic transaxle...
Page 307 applying the brakes... 187 brake warning light... 52 fluid, checking and adding ... 263 fluid, refill capacities... 287 fluid, specifications ... 289 new brake linings...6 noise... 188 parking... 188 trailer ... 197 when storing your vehicle ... 292 Brake-shift interlock... 180 Break-in period ...6 Bulbs, replacing...
Page 308 Cleaning your vehicle (continued)... instrument panel ... 69 mirrors ... 126,127 plastic parts ...8 polishing...7 rustproofing...8 safety belts... 17 tail lamps ... 83 upholstery and interior trim... 118 washing ...7 wheels ... 260 Climate control system ... air conditioning... 71 electronic automatic temperature ...
Page 309 Driving under special conditions bad weather heavy load high water slippery roads towing a trailer Electrical system fuses operating when the engine is off Electronic sound system accessory delay antenna radio reception tuning the radio...161 warranty and service information...178 Emergencies, roadside... battery acid spills...
Page 310 Engine coolant temperature gauge,. description ... Engine fan... Engine oil... "break-in" oils... changing oil and oil filter... checking and adding ... dipstick... disposal engine oil pressure warning light filter, specifications... refill capacities... specifications ... synthetic oil ... viscosity ... Exhaust fumes... Extended Service Plan, Ford...
Page 311 Fuel cap removing ... 238 replacing... 239 Fuel filter, specifications... 288 Fuel gauge ... 67 Fuel pump shut-off switch, starting after a ... collision ... Fuse panels engine compartment... 272 instrument panel ... 267 Fuses charts ... 269 Rating) checking and replacing... 275 Gas cap (see Fuel cap)...
Page 312 Headlamps (continued)... cleaning ... 83 daytime running lights... 81 flashing... 90 high beam ... 90 replacing bulbs... 277 turning on and off ... 82 warning chime ... 58 Head restraints ... 114 Heated mirrors ... 127 Heating ... electronic automatic temperature ... control system ...
Page 313 Keys... key in ignition chime... 42 positions of the ignition... 41 removing from the ignition... 42 stuck in lock position... 42 L ... Lamps ... autolamp delay system ... 83 checking ... 277 daytime running light system... 81 flashing the lamps ... 90 hazard flashers...
Page 314 Mirrors (continued)... heated... rearview ... Moon roof... Motorcraft parts..N National Highway Traffic . Safety Administration ..0 Odometer, description ... Oil filter ... Oil (see Engine oil)... Oil viscosity ... On-board diagnostic (OBD II) system ... 286 Overdrive...
Page 315 Radio (see Electronic sound systems) ... 159 Rearview mirror ... 125 Refill capacities for fluids ... 287 Remote entry system arming and disarming the anti-theft system... 106 locking/unlocking doors... 105 opening the trunk... 106 panic alarm ... 106 replacement/additional transmitters .. 107 replacing the batteries ...
Page 316 Seats ... adjusting the seats, power ... 115 child safety seats... 27 head restraints ... 114 Securitire ... 141 Service concerns ... 213 Servicing your vehicle, precautions when... servicing ... 233 Shift-lock system... 180 Shift positions (see Gearshift)... 181 Shoulder and lap belts ... (see Safety restraints)...
Page 317 Storage compartments center console... 133 map pockets ... 134 Storing your vehicle ... 290 Sun visor... 128 Supplemental air bag readiness light ... 59 Supplemental Restraint System (SRS) ... 17 Tachometer... 66 Tail lamps, cleaning... 83 Tether anchor installation (see Child restraints) ... 38 Tilt steering wheel...
Page 318 Tune-up specifications (VECI)... 285 Turn signal... indicator lights... 56 lever... 89 u... Used engine oil, disposal ...232,250,262 Universal transmitter..V Variable interval wipers 91 VECI (Vehicle Emission Control ... Information) decal ...286 Vehicle loading ... automatic transaxles ...193 calculating the load...193 Vehicle storage ...290 Ventilating your vehicle ...
Page 319 Windshield washer fluid and wipers checking and adding fluid...254 checking and replacing wiper blades . . 255 operation ...90 reservoir ...254...
Page 320 Service Station Information 4.6 Liter 4 Valve SFI (Sequential Fuel Injection) 8 Cylinder Engine Fuel PREMIUM FUEL ONLY- Octane 91 or higher 17.8 gallons (68.1 Liters) Fuel Tank Capacity Tire Size Refer to the Tire Pressure Decal Front- 30 PSI, Rear- 28 PSI (measured cold)- Tire pressure decal on the front Tire Pressure face of the passenger’s door jamb.
