overvieW

The Loup Elite Monitor is a full featured display designed to provide accurate population, blockage, bin level, shaft RPM and other
readings for gravity drills, air seeders and planters. This manual will familiarize you with operation, calibration and technical
information. All aspects and features are detailed but may not be applicable to your system configuration.
THE LOuP ELEcTRONIcs ELITE MONITOR Is cAPABLE Of MONITORINg AND DIsPLAyINg:
• Ground speed (Implement Mounted Speed Sensor, optional Radar, GPS Speed or Simulated Speed)
• Population in Seeds/Acre (up to 48 sensors can be connected)
• Population readouts for Average Population, Auto Scan, and Section Average are available
• Target Population display along with readout for Percent of Target
• Spacing between seeds or Seeds per Foot (S/FT or IN/S)
• Six shaft speed RPM's (Left, Center & Right)
• Seed Flow (up to 192 sensors can be connected)
• Flow Summary page of all learned population and blockage sensors
• Field Area and Total Area
• Rate Calibration
• Six Hoppers (displayed as bargraph display)
• Three Fan Speed Sensors
• Sixteen Liquid Flow Sensors
• External Scale Fuctionality
cusTOMIzE uP TO 4 TOP DIsPLAy WINDOWs WITH THE INfORMATION yOu WANT TO sEE .
TARgET
POPuLATION
TOOgLE
fLOW scREEN
POPuLATION
READOuT
sETuP DRILL
sEcTIONs
cONfIguRE
uP TO 3
IMPLEMENTs
